Schmitt Trigger

• Invented by American scientist Otto H. Schmitt in
  1934.
• A comparator circuit with hysteresis.
• Positive feedback to the noninverting input of a
  comparator or differential amplifier.
• Noninverting and Inverting Configurations.
• Output retains its value until the input changes
  sufficiently to trigger a change.

4
Schmitt Trigger

• Also called Regenerative Comparator.
• Converts an analog input signal to a digital
  output signal.
• Sine wave to square wave conversion.
• An active circuit made to behave as a Schmitt
  trigger by applying a positive feedback.
• Loop gain is more than unity.
• Positive feedback introduced by adding a part of
  the output voltage to the noninverting input
  terminal of the OPAMP.

5
(No Transcript)
6
Block Diagram of a Schmitt Trigger
Symbol
7
Schmitt Trigger

• Uses two different threshold voltage levels to
  avoid input noise.
• Upper and lower trigger points .
• Action due to dual-threshold known as hysteresis.

Any noise amplitude between UTP and LTP eliminated
UTP
LTP
8
Typical Hysteresis Curve
Dual Threshold Action
Circuit Transfer Function
9
Comparator vs Schmitt Trigger
UTP
0
LTP
Comparator (Zero Crossing)
One Threshold
Schmitt Trigger
UTP and LTP
10
Threshold Points

• Values at which the output makes transition from
  one level to the other called Threshold points
  or trip points.
• Upper Threshold Point (UTP) and Lower Threshold
  Point (LTP).
• As input amplitude crosses threshold points,
  output voltage changes state.

11
Inverting Schmitt Trigger

• As input voltage increases and reaches the upper
  threshold point (UTP) the output voltage goes to
  negative saturation.
• As the input voltage decreases and reaches lower
  threshold point (LTP) the output voltage goes to
  positive saturation.
• When the voltage difference between UTP and LTP
  is larger than the noise, the output remains
  stable.

12
The circuit has two stable state outputs.
13
Inverting Schmitt Trigger
14
Biased Inverting Schmitt Trigger
Reference Voltage
15
(No Transcript)
16
Biased Inverting Schmitt Trigger

Reference Voltage
17
Schmitt Trigger with a Reference Voltage
18
Noninverting Schmitt Trigger

• As input voltage increases and reaches the upper
  threshold point (UTP) the output voltage goes to
  positive saturation.
• As the input voltage decreases and reaches lower
  threshold point (LTP) the output voltage goes to
  negative saturation.
• When the voltage difference between UTP and is
  larger than noise, the output remains stable.

19
(No Transcript)
20
Noninverting Schmitt Trigger with a Reference
Voltage
21
Schmitt Trigger Oscillator Astable Multivibrator
C charges when V0 Vsat C discharges when V0
-Vsat
Positive feedback ensures saturation.
Capacitor voltage determines the output state. RF
and C are the timing components.
22
Applications of Schmitt Trigger

• One bit analog to digital conversion.
• To ensure proper level detection.
• To improve the noise immunity of a system.
• To ensure that a logic output level changes only
  when data changes and not as a result of spurious
  noise that may have been picked up.

23
Ideal Integrator and Differentiator
24
Ideal Integrator and Differentiator
25
Ideal OPAMP Differentiator
26
Ideal OPAMP Differentiator
i
Current cannot flow into the OPAMP input
terminals due to very high input impedance.
27
Practical OPAMP Differentiator
28
Ideal OPAMP Integrator
i
Current cannot flow into the OPAMP input
terminals due to very high input impedance.
29
(No Transcript)
30
