Title: Complete WPF Overview Tutorial with Example - iFour Technolab


1
iFour Consultancy
https//www.ifourtechnolab.com/wpf-software-develo
pment
2
What is WPF?
  • WPF, which stands for Windows Presentation
    Foundation, is Microsoft's latest approach to a
    GUI framework, used with the .NET framework.
  • WPF , previously known as "Avalon", was initially
    released as part of .NET Framework 3.0 in 2006 ,
    and then so many other features were added in the
    subsequent .NET framework versions.
  • It is a powerful framework for building Windows
    applications.
  • WPF offers Separation of Appearance and
    Behaviour.
  • WPF contains features that will help you develop
    rich windows applications.
  • WPF employs XAML, an XML-based language, to
    define and link various interface elements.
  • WPF has a built-in set of data services to enable
    application developers to bind and manipulate
    data within applications

https//www.ifourtechnolab.com/wpf-software-develo
pment
3
Architecture of WPF
  • The major components of WPF architecture are as
    shown in the figure. The most important code part
    of WPF are -
  • Presentation Framework
  • Presentation Core
  • Milcore
  • The architecture of WPF can be classified into
    three layers,
  • Managed Layer
  • Unmanaged Layer
  • Core API Layer
  • Managed Layer
  • The Presentation Framework This DLL consists of
    all classes that are required to create the WPF
    UI. This wraps up the controls, data bindings,
    styling, shapes, media, documents, annotations,
    animation and more.
  • Presentation core This is a low-level API
    exposed by WPF providing features for 2D, 3D,
    geometry and so on.

https//www.ifourtechnolab.com/wpf-software-develo
pment
4
  • Unmanaged layer
  • Milcore is a part of unmanaged code which allows
    tight integration with DirectX (responsible for
    display and rendering).
  • WindowsCodecs WindowsCodecs provides Imaging
    support in WPF. Image display, processing,
    scaling and transform are all handled by
    WindowsCodecs
  • CLR makes the development process more productive
    by offering many features such as memory
    management, error handling, etc.
  • Core API Layer
  • This layer has OS core components like Kernel,
    User32, GDI, Device Drivers, Graphic cards etc.
    These components are used by the application to
    access low-level APIs. User32 manages memory and
    process separation.
  • DirectX DirectX is the low-level API through
    which WPF renders all graphics. DirectX talks
    with drivers and renders the content.
  • GDI GDI stands for Graphic Device Interface.
    GDI provides an expanded set of graphics
    primitives and a number of improvements in
    rendering quality.

https//www.ifourtechnolab.com/wpf-software-develo
pment
5
WPF Advantages
  • In the earlier GUI frameworks, there was no real
    separation between how an application looks like
    and how it behaved.
  • In WPF, UI elements are designed in XAML while
    behaviors can be implemented in procedural
    languages such C and VB.Net. So it very easy to
    separate behavior from the designer code.
  • With XAML, the programmers can work in parallel
    with the designers.
  • The separation between a GUI and its behavior can
    allow us to easily change the look of a control
    by using styles and templates.
  • Easier animation and special effects.
  • Support rich data visualization.
  • UIs are completely re-sizable without loss of
    quality.

https//www.ifourtechnolab.com/wpf-software-develo
pment
6
WPF Features
Feature Description
Control inside a Control Allows to define a control inside another control as a content.
Data binding Mechanism to display and interact with data between UI elements and data object on user interface.
Media services Provides an integrated system for building user interfaces with common media elements like images, audio, and video.
Templates In WPF you can define the look of an element directly with a Template
Animations Building interactivity and movement on user Interface
Alternative input Supports multi-touch input on Windows 7 and above.
Direct3D Allows to display more complex graphics and custom themes
https//www.ifourtechnolab.com/wpf-software-develo
pment
7
iFour Consultancy
https//www.ifourtechnolab.com/wpf-software-develo
pment
8
Index
  • What is XAML?
  • Advantages of XAML
  • Basic Syntax of XAML
  • Namespaces
  • Why XAML in WPF

https//www.ifourtechnolab.com/wpf-software-develo
pment
9
What is XAML?
  • XAML stands for Extensible Application Markup
    Language
  • Its a simple language based on XML to create and
    initialize .NET objects with hierarchical
    relations.
  • Today XAML is used to create user interfaces in
    WPF, Silverlight, declare workflows in WF
    (Workflow Foundation) and for electronic paper in
    the XPS standard.
  • All classes in WPF have parameterless
    constructors and make excessive usage of
    properties. That is done to make it perfectly fit
    for XML languages like XAML.

https//www.ifourtechnolab.com/wpf-software-develo
pment
10
Advantage of XAML
  • It very easy to create, initialize, and set
    properties of objects with hierarchical
    relations.
  • XAML code is short and clear to read
  • Separation of designer code and logic
  • Graphical design tools like Expression Blend
    require XAML as source.
  • The goal of XAML is to enable visual designers to
    create user interface elements directly.
  • All you can do in XAML can also be done in code.
    XAML is just another way to create and initialize
    objects. You can use WPF without using XAML. It's
    up to you if you want to declare it in XAML or
    write it in code.

https//www.ifourtechnolab.com/wpf-software-develo
pment
11
Basic Synatx of XAML
  • When you create your new WPF project, you will
    encounter some of the XAML code by default in
    MainWindow.xaml as shown below.

https//www.ifourtechnolab.com/wpf-software-develo
pment
12
Information Description
ltWindow It is the opening object element or container of the root.
xClass "Resources.MainWindow" It is a partial class declaration which connects the markup to the partial class code defined behind.
xmlns Maps the default XAML namespace for WPF client/framework
xmlnsx XAML namespace for XAML language which maps it to x prefix
gt End of object element of the root
ltGridgtlt/Gridgt It is starting and closing tags of an empty grid object.
lt/Windowgt Closing the object element
https//www.ifourtechnolab.com/wpf-software-develo
pment
13
Syntax
  • The syntax of an Object element starts with a
    left angle bracket (lt) followed by the name of an
    object, e.g. Button.
  • Define some Properties and attributes of that
    object element.
  • The Object element must be closed by a forward
    slash (/) followed immediately by a right angle
    bracket (gt).

https//www.ifourtechnolab.com/wpf-software-develo
pment
14
Syntax
  • Example of simple object with no child element
  • ltButton/gt
  • Example of object element with some attributes
  • ltButton Content "Click Me" Height "30" Width
    "60" /gt
  • lt/StackPanelgt

https//www.ifourtechnolab.com/wpf-software-develo
pment
15
Syntax
  • Example of an alternate syntax do define
    properties (Property element syntax)
  • ltButtongt
  • ltButton.ContentgtClick Melt/Button.Contentgt
  • ltButton.Heightgt30lt/Button.Heightgt
  • ltButton.Widthgt60lt/Button.Widthgt
  • lt/Buttongt
  • Example of Object with Child Element StackPanel
    contains Textblock as child element
  • ltStackPanel Orientation "Horizontal"gt
  • ltTextBlock Text "Hello"/gt
  • lt/StackPanelgt

https//www.ifourtechnolab.com/wpf-software-develo
pment
16
Namespaces
  • At the beginning of every XAML file you need to
    include two namespaces.
  • The first is http//schemas.microsoft.com/winfx/20
    06/xaml/presentation. It is mapped to all wpf
    controls in System.Windows.Controls.
  • The second is http//schemas.microsoft.com/winfx/2
    006/xaml it is mapped to System.Windows.Markup
    that defines the XAML keywords.

https//www.ifourtechnolab.com/wpf-software-develo
pment
17
Why XAML in WPF?
  • Both XAML WPF are independent pieces of
    technology.
  • For better Understanding, let us create a window
    with a button in it using XAML as below

https//www.ifourtechnolab.com/wpf-software-develo
pment
18
  • Output

https//www.ifourtechnolab.com/wpf-software-develo
pment
19
  • In case you choose not to use XAML in WPF, then
    you can achieve the same GUI result with
    procedural language as well. Lets have a look at
    the same example, but this time, we will create a
    button in C

https//www.ifourtechnolab.com/wpf-software-develo
pment
20
  • From the above example, it is clear that what you
    can do in XAML to create, initialize, and set
    properties of objects, the same tasks can also be
    done using code.
  • So below are the two less known facts about XAML
  • WPF doesn't need XAML
  • XAML doesn't need WPF

https//www.ifourtechnolab.com/wpf-software-develo
pment
21
iFour Consultancy
https//www.ifourtechnolab.com/wpf-software-develo
pment
22
Element Tree
  • Windows Presentation Foundation (WPF) has a
    comprehensive tree structure in the form of
    objects. In WPF, there are two ways that a
    complete object tree is conceptualized -
  • Logical Tree Structure
  • Visual Tree Structure
  • There are many technologies where the elements
    and components are ordered in a tree structure so
    that the programmers can easily handle the object
    and change the behavior of an application.
  • Mostly, WPF developers and designers either use
    procedural language to create an application or
    design the UI part of the application in XAML
    keeping in mind the object tree structure.

https//www.ifourtechnolab.com/wpf-software-develo
pment
23
Logical Tree Structure
  • In WPF applications, the structure of the UI
    elements in XAML represents the logical tree
    structure. In XAML, the basic elements of UI are
    declared by the developer. The logical tree in
    WPF defines the following -
  • Dependency properties
  • Static and dynamic resources
  • Binding the elements on its name etc.

https//www.ifourtechnolab.com/wpf-software-develo
pment
24
  • Lets have a look at the following example in
    which a button and a list box are created.

https//www.ifourtechnolab.com/wpf-software-develo
pment
25
Visual Tree Structure
  • In WPF, the concept of the visual tree describes
    the structure of visual objects, as represented
    by the Visual Base Class. It signifies all the UI
    elements which are rendered to the output screen.
  • When a programmer wants to create a template for
    a particular control, he is actually rendering
    the visual tree of that control. The visual tree
    is also very useful for those who want to draw
    lower level controls for performance and
    optimization reasons.
  • In WPF applications, visual tree is used for -
  • Rendering the visual objects.
  • Rendering the layouts.
  • The routed events mostly travel along the visual
    tree, not the logical tree.

https//www.ifourtechnolab.com/wpf-software-develo
pment
26
Visual Tree Structure
  • In WPF, the concept of the visual tree describes
    the structure of visual objects, as represented
    by the Visual Base Class. It signifies all the UI
    elements which are rendered to the output screen.
  • When a programmer wants to create a template for
    a particular control, he is actually rendering
    the visual tree of that control. The visual tree
    is also very useful for those who want to draw
    lower level controls for performance and
    optimization reasons.
  • In WPF applications, visual tree is used for -
  • Rendering the visual objects.
  • Rendering the layouts.
  • The routed events mostly travel along the visual
    tree, not the logical tree.

https//www.ifourtechnolab.com/wpf-software-develo
pment
27
https//www.ifourtechnolab.com/wpf-software-develo
pment
28
https//www.ifourtechnolab.com/wpf-software-develo
pment
29
  • The logical tree leaves out a lot of detail
    enabling you to focus on the core structure of
    the user interface and to ignore the details of
    exactly how it has been presented.
  • The logical tree is what you use to create the
    basic structure of the user interface.
  • The visual tree will be of interest if you're
    focusing on the presentation. For example, if you
    wish to customize the appearance of any UI
    element, you will need to use the visual tree.

https//www.ifourtechnolab.com/wpf-software-develo
pment
30
iFour Consultancy
https//www.ifourtechnolab.com/wpf-software-develo
pment
31
Layout
  • The layout of controls is very important and
    critical for application usability. It is used to
    arrange a group of GUI elements in your
    application. There are certain important things
    to consider while selecting layout panels -
  • Positions of the child elements
  • Sizes of the child elements
  • Layering of overlapping child elements on top of
    each other
  • Fixed pixel arrangement of controls doesnt work
    when the application is to be sed on different
    screen resolutions. XAML provides a rich set of
    built-in layout panels to arrange GUI elements in
    an appropriate way. Some of the most commonly
    used and popular layout panels are as follows -

https//www.ifourtechnolab.com/wpf-software-develo
pment
32
Sr. No. Panels Description
1 Stack panel is a simple and useful layout panel in XAML. In stack panel, child elements can be arranged in a single line, either horizontally or vertically, based on the orientation property.
2 In WrapPanel, child elements are positioned in sequential order, from left to right or from top to bottom based on the orientation property.
3 DockPanel defines an area to arrange child elements relative to each other, either horizontally or vertically. With DockPanel you can easily dock child elements to top, bottom, right, left and center using the Dock property.
https//www.ifourtechnolab.com/wpf-software-develo
pment
33
Sr. No. Panels Description
4 Canvas panel is the basic layout panel in which the child elements can be positioned explicitly using coordinates that are relative to the Canvas any side such as left, right, top and bottom.
5 A Grid Panel provides a flexible area which consists of rows and columns. In a Grid, child elements can be arranged in tabular form.
https//www.ifourtechnolab.com/wpf-software-develo
pment
34
iFour Consultancy
https//www.ifourtechnolab.com/wpf-software-develo
pment
35
Nesting layout
  • Nesting of layout means the use layout panel
    inside another layout, e.g. define stack panels
    inside a grid. This concept is widely used to
    take the advantages of multiple layouts in an
    application.

https//www.ifourtechnolab.com/wpf-software-develo
pment
36
  • Considering example of real world wherein we used
    grid layout for outlining and used stackpanel to
    display controls inside it.

https//www.ifourtechnolab.com/wpf-software-develo
pment
37
  • Output

https//www.ifourtechnolab.com/wpf-software-develo
pment
38
iFour Consultancy
https//www.ifourtechnolab.com/wpf-software-develo
pment
39
Controls
  • Windows Presentation Foundation (WPF) allows
    developers to easily build and create visually
    enriched UI based applications.
  • The classical UI elements or controls in other UI
    frameworks are also enhanced in WPF applications.
  • All of the standard WPF controls can be found in
    the Toolbox which is a part of the
    System.Windows.Controls.
  • These controls can also be created in XAML markup
    language.

https//www.ifourtechnolab.com/wpf-software-develo
pment
40
Control Library
  • Grid Layout
  • Label
  • Buttons
  • Editors
  • Lists
  • Menus and toolbars
  • Scroll Viewer
  • Building Blocks
  • ToolTip
  • Thumb
  • Border
  • Popup
  • Document Viewers
  • Frame
  • Ranges
  • Containers

https//www.ifourtechnolab.com/wpf-software-develo
pment
41
Grid Layout
  • Grid
  • Column Definition
  • Row Definition
  • Grid Lines

https//www.ifourtechnolab.com/wpf-software-develo
pment
42
Labels
  • The Label control, in its most simple form, will
    look very much like the TextBlock which we used
    in another article. You will quickly notice
    though that instead of a Text property, the Label
    has a Content property. The reason for that is
    that the Label can host any kind of control
    directly inside of it, instead of just text.

ltLabel Content"This is a Label control." /gt
https//www.ifourtechnolab.com/wpf-software-develo
pment
43
Buttons
https//www.ifourtechnolab.com/wpf-software-develo
pment
44
Editors
  • PasswordBox
  • TextBox
  • RichTextBox
  • InkCanvas

https//www.ifourtechnolab.com/wpf-software-develo
pment
45
List
  • Four standard list controls- ListBox, ComboBox,
    ListView, TreeView.
  • List controls can be filled from one of the two
    sources.
  • 1. Items Property
  • 2. ItemsSource Property.

https//www.ifourtechnolab.com/wpf-software-develo
pment
46
List View
  • List view derives from listBox
  • It has ability to separate view properties from
    control properties.
  • View property must be changed to grid view ad set
    properties on that object.

https//www.ifourtechnolab.com/wpf-software-develo
pment
47
Tree view
ltTreeViewgt ltTreeViewItem Header'Coders'gt ltTreeVie
wItem Header'Don' /gt ltTreeViewItem
Header'Dharma' /gt lt/TreeViewItemgt ltTreeViewItem
Header'Noncoders'gt ltTreeViewItem Header'Chris'
/gt lt/TreeViewItemgt lt/TreeViewgt
https//www.ifourtechnolab.com/wpf-software-develo
pment
48
New Lists using Templates
https//www.ifourtechnolab.com/wpf-software-develo
pment
49
Menus ToolBars
https//www.ifourtechnolab.com/wpf-software-develo
pment
50
Expander
  • Expander is a layout in which we can add control
    and expand it when we need. When have less space
    in our application then we can use expander
    layout.
  • We can assign the expand direction either down,
    up, left or right.
  • At the time of expander creation we can assign
    IsExpanded property true or false. It has the
    same drawback as GroupBox that it can contain
    only one control.
  • ltWindow xClass"GroupBoxDemo.MainWindow"
  •         xmlns"http//schemas.microsoft.com/winfx/
    2006/xaml/presentation"
  •         xmlnsx"http//schemas.microsoft.com/winf
    x/2006/xaml"
  •         Title"GroupBox Demo"
  •         Width"250"
  •         Height"180"gt
  •     ltGridgt
  • ltExpander HeaderDescription"
  • HorizontalAlignment"Left"
  • Margin"10,10,0,0"
  • VerticalAlignment"Top"
  • IsExpanded"False"
  • Height"299"
  • Width"497"gt
  • ltTextBlock TextWrapping"Wrap"
  • Text"This is some text
    content."
  • Margin"5"/gt
  • lt/Expandergt
  •     lt/Gridgt

https//www.ifourtechnolab.com/wpf-software-develo
pment
51
Group Box
  • ltWindow xClass"GroupBoxDemo.MainWindow"
  •         xmlns"http//schemas.microsoft.com/winfx/
    2006/xaml/presentation"
  •         xmlnsx"http//schemas.microsoft.com/winf
    x/2006/xaml"
  •         Title"GroupBox Demo"
  •         Width"250"
  •         Height"180"gt
  •     ltGridgt
  •         ltGrid.RowDefinitionsgt
  •             ltRowDefinition Height"Auto"/gt
  •             ltRowDefinition Height"Auto"/gt
  •         lt/Grid.RowDefinitionsgt
  •
  •         ltGroupBox Header"Mouse Handedness"gt
  •             ltStackPanelgt
  •                 ltRadioButton Content"Left-Handed"
    Margin"5"/gt
  •                 ltRadioButton Content"Right-Handed
    " Margin"5" IsChecked"True"/gt
  •             lt/StackPanelgt
  •         lt/GroupBoxgt
  •
  • The GroupBox control allows you to visually group
    content and provide a title for grouped elements.
  • When you use the default styling for a GroupBox,
    the child controls are surrounded by a border
    that includes a caption. There is no need to
    explicitly define a Border.
  • Configuring a GroupBox is similar to setting up
    an Expander. Both controls inherit from the same
    base class and include the same properties for
    controlling the header area and content. The key
    difference is that a GroupBox does not add the
    user interaction that permits the content to be
    expanded and collapsed.

https//www.ifourtechnolab.com/wpf-software-develo
pment
52
Separator
  • The Separator Control is used to separate items
    in items controls.
  • The intention is to divide the items on the menu
    or toolbar into logical groups.
  • It uses borders and rectangles.

ltListBoxgt     ltListBoxItemgtSports Carlt/ListBoxItemgt     ltListBoxItemgtCompact Carlt/ListBoxItemgt     ltListBoxItemgtFamily Carlt/ListBoxItemgt     ltListBoxItemgtOff-Road Carlt/ListBoxItemgt     ltSeparator/gt     ltListBoxItemgtSupersports Bikelt/ListBoxItemgt     ltListBoxItemgtSports Tourerlt/ListBoxItemgt     ltListBoxItemgtCruiserlt/ListBoxItemgt lt/ListBoxgt
https//www.ifourtechnolab.com/wpf-software-develo
pment
53
TabControl
  • The WPF TabControl allows you to split your
    interface up into different areas, each
    accessible by clicking on the tab header, usually
    positioned at the top of the control.

ltWindow xClass"WpfTutorialSamples.Misc_controls.
TabControlSample xmlnshttp//schemas.microsoft.
com/winfx/2006/xaml/presentation
xmlnsx"http//schemas.microsoft.com/winfx/2006/x
aml" Title"TabControlSample" Height"200"
Width"250"gt ltGridgt ltTabControlgt ltTabItem
Header"General"gt ltLabel Content"Content
goes here..." /gt lt/TabItemgt ltTabItem
Header"Security" /gt ltTabItem Header"Details"
/gt lt/TabControlgt lt/Gridgt lt/Windowgt
https//www.ifourtechnolab.com/wpf-software-develo
pment
54
Dialog
  • Standalone applications typically have a main
    window that both displays the main data over
    which the application operates and exposes the
    functionality to process that data through user
    interface (UI) mechanisms like menu bars, tool
    bars, and status bars. A non-trivial application
    may also display additional windows to do the
    following
  • Display specific information to users.
  • Gather information from users.
  • Both display and gather information.
  • These types of windows are known as dialog boxes,
    and there are two types modal and modeless.

https//www.ifourtechnolab.com/wpf-software-develo
pment
55
  • A modeless dialog box, on the other hand, does
    not prevent a user from activating other windows
    while it is open.
  • For example, if a user wants to find occurrences
    of a particular word in a document, a main window
    will often open a dialog box to ask a user what
    word they are looking for.
  • Since finding a word doesn't prevent a user from
    editing the document, however, the dialog box
    doesn't need to be modal.
  • A modeless dialog box at least provides a Close
    button to close the dialog box.
  • A modal dialog box is displayed by a function
    when the function needs additional data from a
    user to continue. Because the function depends on
    the modal dialog box to gather data
  • the modal dialog box also prevents a user from
    activating other windows in the application while
    it remains open.
  • In most cases, a modal dialog box allows a user
    to signal when they have finished with the modal
    dialog box by pressing either an OK or Cancel butt
    on.
  • Pressing the OK button indicates that a user has
    entered data and wants the function to continue
    processing with that data.
  • Pressing the Cancel button indicates that a user
    wants to stop the function from executing
    altogether

https//www.ifourtechnolab.com/wpf-software-develo
pment
56
Dialog-Message box
  • A message box is a dialog box that can be used to
    display textual information and to allow users to
    make decisions with buttons.
  • To create a message box, you use
    the MessageBox class. MessageBox lets you
    configure the message box text, title, icon, and
    buttons, using code like the following.
  • The following figure shows a message box that
    displays textual information, asks a question,
    and provides the user with three buttons to
    answer the question.

string messageBoxText "Do you want to save
changes?" string caption "Word
Processor" MessageBoxButton button
MessageBoxButton.YesNoCancel MessageBoxImage
icon MessageBoxImage.Warning
// Display message box MessageBox.Show(messageBox
Text, caption, button, icon)
https//www.ifourtechnolab.com/wpf-software-develo
pment
57
Message box(cont..)
  • // Display message box
  • MessageBoxResult result MessageBox.Show(messageB
    oxText, caption, button, icon)
  • // Process message box results
  • switch (result)
  • case MessageBoxResult.Yes
  • // User pressed Yes button
  • break
  • case MessageBoxResult.No
  • // User pressed No button
  • // ...
  • break
  • case MessageBoxResult.Cancel
  • // User pressed Cancel button
  • // ...
  • break

https//www.ifourtechnolab.com/wpf-software-develo
pment
58
  • Other Common Dialog Boxes are
  • Open File Dialog
  • Save File Dialog Box
  • Print Dialog Box
  • A modeless dialog box, such as the Find Dialog
    Box shown in the following figure, has the same
    fundamental appearance as the modal dialog box.
  • Screenshot that shows a Find dialog box.
  • However, the behavior is slightly different, as
    described in the following sections.
  • A modeless dialog box is opened by calling
    the Show method.
  • Unlike ShowDialog, Show returns immediately.
    Consequently, the calling window cannot tell when
    the modeless dialog box is closed and, therefore,
    does not know when to check for a dialog box
    result or get data from the dialog box for
    further processing.
  • Instead, the dialog box needs to create an
    alternative way to return data to the calling
    window for processing.

https//www.ifourtechnolab.com/wpf-software-develo
pment
59
Window
  • Window is the root window of XAML applications
    which provides minimize/maximize option, title
    bar, border, and close button.
  • It also provides the ability to create,
    configure, show, and manage the lifetime of
    windows and dialog boxes.
  • When you create a new WPF project, then by
    default, the Window control is present.
  • ltWindow xClass"GroupBoxDemo.MainWindow"
  •         xmlns"http//schemas.microsoft.com/winfx/
    2006/xaml/presentation"
  •         xmlnsx"http//schemas.microsoft.com/winf
    x/2006/xaml"
  •         Title"GroupBox Demo"
  •         Width"250"
  •         Height"180"gt
  •     ltGridgt
  •         ltGrid.RowDefinitionsgt
  •             ltRowDefinition Height"Auto"/gt
  •             ltRowDefinition Height"Auto"/gt
  •         lt/Grid.RowDefinitionsgt
  •
  •         ltGroupBox Header"Mouse Handedness"gt
  •             ltStackPanelgt
  •                 ltRadioButton Content"Left-Handed"
    Margin"5"/gt
  •                 ltRadioButton Content"Right-Handed
    " Margin"5" IsChecked"True"/gt
  •             lt/StackPanelgt
  •         lt/GroupBoxgt
  •

https//www.ifourtechnolab.com/wpf-software-develo
pment
60
Context Menu
  • A context menu, often referred to as a popup or
    pop-up menu, is a menu which is shown upon
    certain user actions, usually a right-click with
    the mouse on a specific control or window.
  • Contextual menus are often used to offer
    functionality that's relevant within a single
    control.

https//www.ifourtechnolab.com/wpf-software-develo
pment
61
  • ltRichTextBoxgt
  • ltRichTextBox.ContextMenugt
  • ltContextMenugt
  • ltMenuItem Command"Cut"gt
  • ltMenuItem.Icongt
  • ltImage Source"Images/cut.png"
    /gt
  • lt/MenuItem.Icongt
  • lt/MenuItemgt
  • ltMenuItem Command"Copy"gt
  • ltMenuItem.Icongt
  • ltImage Source"Images/copy.png
    " /gt
  • lt/MenuItem.Icongt
  • lt/MenuItemgt
  • ltMenuItem Command"Paste"gt
  • ltMenuItem.Icongt
  • ltImage Source"Images/paste.pn
    g" /gt
  • lt/MenuItem.Icongt
  • lt/MenuItemgt
  • lt/ContextMenugt

https//www.ifourtechnolab.com/wpf-software-develo
pment
62
Third-party controls
  • Third-party controls are those which are not
    created by Microsoft but are created by some
    individual or company by using WPF User Control
    or Custom Control. Telerik and DevExpress are the
    most popular companies for creating third-party
    controls.

https//www.ifourtechnolab.com/wpf-software-develo
pment
63
  • ltWindow xClass "WPF3rdPartyControls.MainWindow
    "
  • xmlns "http//schemas.microsoft.com/winfx/200
    6/xaml/presentation"
  • xmlnsx "http//schemas.microsoft.com/winfx/2
    006/xaml"
  • xmlnsd "http//schemas.microsoft.com/express
    ion/blend/2008"
  • xmlnsmc "http//schemas.openxmlformats.org/m
    arkup-compatibility/2006"
  • xmlnslocal "clr-namespaceWPF3rdPartyControl
    s"
  • xmlnstelerik "http//schemas.telerik.com/200
    8/xaml/presentation"
  • mcIgnorable "d" Title "MainWindow" Height
    "350" Width "604"gt
  • ltGridgt
  • lttelerikRadCalculator HorizontalAlignment
    "Left" Margin "174,25,0,0"
  • VerticalAlignment "Top" /gt
  • lt/Gridgt
  • lt/Windowgt

https//www.ifourtechnolab.com/wpf-software-develo
pment
64
Calendar
  • Calendar is a control that enables a user to
    select a date by using a visual calendar display.
  • It provides some basic navigation using either
    the mouse or keyboard

https//www.ifourtechnolab.com/wpf-software-develo
pment
65
Cont..
https//www.ifourtechnolab.com/wpf-software-develo
pment
66
Date picker
  • A Date Picker is a control that allows a user to
    pick a date value.
  • The user picks the date by using Combo Box
    selection for month, day, and year values

https//www.ifourtechnolab.com/wpf-software-develo
pment
67
Cont..
Properties Properties
Date Gets or sets the date currently set in the date picker.
DayFormat Gets or sets the display format for the day value.
DayFormatProperty Gets the identifier for the DayFormat dependency property.
Orientation Gets or sets a value that indicates whether the day, month, and year selectors are stacked horizontally or vertically.
YearFormat Gets or sets the display format for the year value.
MonthFormat Gets or sets the display format for the month value.

https//www.ifourtechnolab.com/wpf-software-develo
pment
68
  • A control that displays an image, you can use
    either the Image object or the Image Brush
    object.
  • An Image object display an image, while an Image
    Brush object paints another object with an image.

https//www.ifourtechnolab.com/wpf-software-develo
pment
69
Cont..
Properties Properties
wSource Gets or sets the source for the image.
Width Gets or sets the width of a FrameworkElement. (Inherited from FrameworkElement)
StretchProperty Identifies the Stretch dependency property.
Opacity Gets or sets the degree of the object's opacity. (Inherited from UIElement)
Name Gets or sets the identifying name of the object.
CanDrag Gets or sets a value that indicates whether the element can be dragged as data in a drag-and-drop operation. (Inherited from UIElement)
https//www.ifourtechnolab.com/wpf-software-develo
pment
70
Popup
  • Popup is a control that displays content on top
    of existing content, within the bounds of the
    application window.
  • It is a temporary display on other content.

https//www.ifourtechnolab.com/wpf-software-develo
pment
71
Cont..
Properties Properties
Child Gets or sets the content to be hosted in the popup.
ChildProperty Gets the identifier for the Child dependency property.
IsOpen Gets or sets whether the popup is currently displayed on the screen.
Opacity Gets or sets the degree of the object's opacity. (Inherited from UIElement)
Name Gets or sets the identifying name of the object.
https//www.ifourtechnolab.com/wpf-software-develo
pment
72
Progress Bar
  • Progress Bar is a control that indicates the
    progress of an operation, where the typical
    visual appearance is a bar that animates a filled
    area as the progress continues.
  • It can show the progress in one of the two
    following styles -
  • A bar that displays a repeating pattern, or
  • A bar that fills based on a value.

https//www.ifourtechnolab.com/wpf-software-develo
pment
73
Cont..
Properties Properties
IsIndeterminate Gets or sets a value that indicates whether the progress bar reports generic progress with a repeating pattern or reports progress based on the Value property.
ShowError Gets or sets a value that indicates whether the progress bar should use visual states that communicate an Error state to the user.
ShowPaused Gets or sets a value that indicates whether the progress bar should use visual states that communicate a Paused state to the user.
Name Gets or sets the identifying name of the object.
https//www.ifourtechnolab.com/wpf-software-develo
pment
74
Scroll Viewer
  • A ScrollViewer is a control that provides a
    scrollable area that can contain other visible
    elements.

https//www.ifourtechnolab.com/wpf-software-develo
pment
75
Cont..
Properties Properties
ComputedHorizontalScrollBarVisibility Gets a value that indicates whether the horizontal ScrollBar is visible.
ComputedHorizontalScrollBarVisibilityProperty Identifies the ComputedHorizontalScrollBarVisibility dependency property.
ScrollableHeight Gets a value that represents the vertical size of the area that can be scrolled the difference between the width of the extent and the width of the viewport.
Name Gets or sets the identifying name of the object.
ScrollableWidth Gets a value that represents the horizontal size of the area that can be scrolled the difference between the width of the extent and the width of the viewport.
https//www.ifourtechnolab.com/wpf-software-develo
pment
76
Toggle Button
  • A Toggle Button is a control that can switch
    states, such as CheckBox and RadioButton. .

https//www.ifourtechnolab.com/wpf-software-develo
pment
77
Cont..
Properties Properties
IsChecked Gets or sets whether the ToggleButton is checked.
IsCheckedProperty Identifies the IsChecked dependency property.
IsThreeState Gets or sets a value that indicates whether the control supports three states
Name Gets or sets the identifying name of the object.
IsThreeStateProperty Identifies the IsThreeState dependency property.
https//www.ifourtechnolab.com/wpf-software-develo
pment
78
tooltip
  • A tooltip is a control that creates a pop-up
    window that displays information for an element
    in the GUI.

https//www.ifourtechnolab.com/wpf-software-develo
pment
79
Cont..
Properties Properties
IsOpen Gets or sets a value that indicates whether the ToolTip is visible.
Placement Gets or sets how a ToolTip is positioned in relation to the placement target element.
PlacementTarget Gets or sets the visual element or control that the tool tip should be positioned in relation to when opened by the ToolTipService.
Name Gets or sets the identifying name of the object.
https//www.ifourtechnolab.com/wpf-software-develo
pment
80
iFour Consultancy
https//www.ifourtechnolab.com/wpf-software-develo
pment
81
Dependency Property
  • In WPF applications, Dependency property is a
    specific type of property which extends the CLR
    property. It takes the advantage of specific
    functionalities available in the WPF property
    system.
  • A class which defines a dependency property must
    be inherited from the DependencyObject class.
  • Many of the UI controls class which are used in
    XAML are derived from the DependencyObject class
    and they support dependency properties, e.g.
    Button class supports the IsMouseOver dependency
    property.

https//www.ifourtechnolab.com/wpf-software-develo
pment
82
Dependency Property (Cont...)
  • The following XAML code creates a button with
    some properties.
  • ltWindow xClass "WPFDependencyProperty.MainWindo
    w"
  • xmlns "http//schemas.microsoft.com/winfx/2006/x
    aml/presentation"
  • xmlnsx "http//schemas.microsoft.com/winfx/2006
    /xaml"
  • xmlnslocal "clr-namespaceWPFDependencyProperty
    "
  • Title "MainWindow" Height "350" Width
    "604"gt
  • ltGridgt
  • ltButton Height "40" Width "175" Margin
    "10" Content "Dependency Property"gt
  • ltButton.Stylegt
  • ltStyle TargetType "xType Button"gt
  • ltStyle.Triggersgt
  • ltTrigger Property "IsMouseOver" Value "True"gt
  • ltSetter Property "Foreground" Value
    "Red" /gt
  • lt/Triggergt
  • lt/Style.Triggersgt
  • lt/Stylegt
  • lt/Button.Stylegt
  • lt/Buttongt

https//www.ifourtechnolab.com/wpf-software-develo
pment
83
https//www.ifourtechnolab.com/wpf-software-develo
pment
84
Why We Need Dependency Properties
  • Dependency property gives you all kinds of
    benefits when you use it in your application.
    Dependency Property can used over a CLR property
    in the following scenarios -
  • If you want to set the style
  • If you want data binding
  • If you want to set with a resource (a static or a
    dynamic resource)
  • If you want to support animation

https//www.ifourtechnolab.com/wpf-software-develo
pment
85
Why We Need Dependency Properties
  • Basically, Dependency Properties offer a lot of
    functionalities that you wont get by using a CLR
    property.
  • The main difference between dependency properties
    and other CLR properties are listed below -
  • CLR properties can directly read/write from the
    private member of a class by using getter and
    setter. In contrast, dependency properties are
    not stored in local object.
  • Dependency properties are stored in a dictionary
    of key/value pairs which is provided by the
    DependencyObject class. It also saves a lot of
    memory because it stores the property when
    changed. It can be bound in XAML as well.

https//www.ifourtechnolab.com/wpf-software-develo
pment
86
iFour Consultancy
https//www.ifourtechnolab.com/wpf-software-develo
pment
87
Routed Event
  • A Routed Event is a type of event that can invoke
    handlers on multiple listeners in an element tree
    rather than just the object that raised the
    event. It is basically a CLR event that is
    supported by an instance of the Routed Event
    class. It is registered with the WPF event
    system. RoutedEvents have three main routing
    strategies which are as follows -
  • Direct Event
  • Bubbling Event
  • Tunnel Event

https//www.ifourtechnolab.com/wpf-software-develo
pment
88
Bubbling Event
  • A Bubbling Event begins with the element where
    the event is originated.
  • Then it travels up the visual tree to the topmost
    element in the visual tree.
  • So, in WPF, the topmost element is most likely a
    window.

https//www.ifourtechnolab.com/wpf-software-develo
pment
89
Tunnel Event
  • Event handlers on the element tree root are
    invoked and then the event travels down the
    visual tree to all the children nodes until it
    reaches the element in which the event
    originated.
  • The difference between a bubbling and a tunneling
    event is that a tunneling event will always start
    with a preview.
  • In a WPF application, events are often
    implemented as a tunneling/bubbling pair. So,
    you'll have a preview MouseDown and then a
    MouseDown event.

https//www.ifourtechnolab.com/wpf-software-develo
pment
90
Direct Event
  • A Direct Event is similar to events in Windows
    forms which are raised by the element in which
    the event is originated.
  • Unlike a standard CLR event, direct routed events
    support class handling and they can be used in
    Event Setters and Event Triggers within your
    style of your Custom Control.
  • A good example of a direct event would be the
    MouseEnter Event.

https//www.ifourtechnolab.com/wpf-software-develo
pment
91
iFour Consultancy
https//www.ifourtechnolab.com/wpf-software-develo
pment
92
Input And Data Binding
  • Windows Presentation Foundation (WPF) provides a
    powerful API with the help of which applications
    can get input from various devices such as mouse,
    keyboard, and touch panels.
  • Data binding is the process that establishes a
    connection between the application UI and
    business logic. If the binding has the correct
    settings and the data provides the proper
    notifications, then, when the data changes its
    value, the elements that are bound to the data
    reflect changes automatically

https//www.ifourtechnolab.com/wpf-software-develo
pment
93
What We Will Cover
  • Binding data to UI Elements
  • Using Converters to convert data during Binding
  • Using Data Templates to visualize data

https//www.ifourtechnolab.com/wpf-software-develo
pment
94
Data Binding Concepts
  • Binding Components
  • Target Object
  • Target Property
  • Binding Source
  • Path
  • Target Property Must be a dependency property

https//www.ifourtechnolab.com/wpf-software-develo
pment
95
Binding Modes
  • OneWay-Updates the target property only when the
    source property change.
  • TwoWay-Updates the target property or the
    property whenever either the target property or
    the source property changes.
  • OneWayToSource-updates the source property when
    the target property changes
  • OneTime- Updates the target property only when
    the application starts or when the DataContext
    undergoes a change.

https//www.ifourtechnolab.com/wpf-software-develo
pment
96
What Triggers Updates
  • Triggering supported by TwoWay or OneWayToSource
    mode of binding
  • Dependency property or INotifyPropertyChanged
  • UpdateSourceTrigger property
  • Explicit -Updates the binding source only when
    you call.
  • UpdateSource- method.
  • LostFocus-Updates the binding source whenever the
    binding target element loses

https//www.ifourtechnolab.com/wpf-software-develo
pment
97
Data Binding Methods
  • Binding using XAML
  • Binding using Code

ltLabel Name"lblNote" Content"DynamicResource
ResourceKeyNote" /gt ltTextBox Name"txtNote"
VerticalContentAlignment"Top"
HorizontalAlignment"Stretch" Text"Binding
AppointmentNote,ModeTwoWay" VerticalAlignment"S
tretch" Width"Auto" Height"Auto" /gt
MyData myDataObject new MyData(DateTime.Now)
Binding myBinding new
Binding("MyDataProperty") myBinding.Source
myDataObject myText.SetBinding(TextBlock.TextPr
operty, myBinding)
https//www.ifourtechnolab.com/wpf-software-develo
pment
98
Converting DataOverview
  • Used when data doesnt match between bindings
    create a conversion class
  • When to use
  • Culture changes needed
  • Different View of data then native storage
  • Incompatible data types between target and source

https//www.ifourtechnolab.com/wpf-software-develo
pment
99
Converting Data Out-of-Box Converters
  • Contained in the System.Windows.Controls
    namespace
  • BooleanToVisibilityConverter
  • Converts True/False to Visible, Hidden or
    Collapsed
  • BorderGapMaskConverter
  • Represents a converter that converts the
    dimensions of a GroupBox control into a
    VisualBrush

https//www.ifourtechnolab.com/wpf-software-develo
pment
100
Data Templates Overview
  • Makes it easy to put content with data
  • Easy to define visual styles for data
  • Reusable and modifiable

https//www.ifourtechnolab.com/wpf-software-develo
pment
101
iFour Consultancy
https//www.ifourtechnolab.com/wpf-software-develo
pment
102
Styles
  • The .NET framework provides several strategies to
    personalize and customize the appearance of an
    application.
  • Style gives uniformity to our application and
    improves user UI experience.
  • Styles provide us the flexibility to set some
    properties of an object and reuse these specific
    settings across multiple objects for a consistent
    look.
  • In styles, you can set only the existing
    properties of an object such as Height, Width,
    Font size, etc.
  • Only default behavior of a control can be
    specified.
  • Multiple properties can be added into a single
    style.

https//www.ifourtechnolab.com/wpf-software-develo
pment
103
Scenario
  • As you can see in first image, Width and Height
    properties of each button is set.
  • It is tedious to set property of each button like
    this to maintain uniformity.
  • And this is not the case only for buttons as
    there will be many more elements. It is not
    feasible to give style like this.
  • Rather what we can do is, declare a style for
    particular element by setting properties of that
    control. Just like it is done in second image.
  • Sounds more efficient. Right? Lets see an
    example.

https//www.ifourtechnolab.com/wpf-software-develo
pment
104
Example
ltWindow xClass "XAMLStyle.MainWindow"
xmlns "http//schemas.microsoft.com/winfx/2006/x
aml/presentation" xmlnsx
"http//schemas.microsoft.com/winfx/2006/xaml"
xmlnsd "http//schemas.microsoft.com/expressio
n/blend/2008" xmlnsmc "http//schemas.openx
mlformats.org/markup-compatibility/2006"
xmlnslocal "clr-namespaceXAMLStyle"
mcIgnorable "d" Title "MainWindow" Height
"350" Width "604"gt ltWindow.Resourcesgt
ltStyle xKey "myButtonStyle" TargetType
"Button"gt ltSetter Property "Height"
Value "30" /gt ltSetter Property
"Width" Value "80" /gt ltSetter
Property "Foreground" Value "Blue" /gt
ltSetter Property "FontSize" Value "12" /gt
ltSetter Property "Margin" Value "10"
/gt lt/Stylegt lt/Window.Resourcesgt
ltStackPanelgt ltButton Content "Button1"
Style "StaticResource myButtonStyle" /gt
ltButton Content "Button2" Style
"StaticResource myButtonStyle" /gt
ltButton Content "Button3" Style"StaticResource
myButtonStyle" /gt lt/StackPanelgt
lt/Windowgt
https//www.ifourtechnolab.com/wpf-software-develo
pment
105
Explanation
  • Styles are defined in the resource dictionary and
    each style has a unique key identifier and a
    target type.
  • Inside ltstylegt you can see that multiple setter
    tags are defined for each property which will be
    included in the style.
  • All of the common properties of each button are
    now defined in style and then the style are
    assigned to each button with a unique key by
    setting the style property through the
    StaticResource markup extension.
  • The advantage of doing it like this is
    immediately obvious, we can reuse that style
    anywhere in its scope and if we need to change
    it, we simply change it once in the style
    definition instead of on each element.

https//www.ifourtechnolab.com/wpf-software-develo
pment
106
Style Levels
Sr.No Levels Description
1 Control Level Defining a style on control level can only be applied to that particular control. Given below is an example of a control level where the button and TextBlock have their own style.
2 Layout Level Defining a style on any layout level will make it accessible by that layout and its child elements only.
3 Window Level Defining a style on a window level can make it accessible by all the elements on that window.
4 Application Level Defining a style on app level can make it accessible throughout the entire application. Lets take the same example, but here, we will put the styles in app.xaml file to make it accessible throughout application.
https//www.ifourtechnolab.com/wpf-software-develo
pment
107
Triggers
  • A trigger basically enables you to change
    property values or take actions based on the
    value of a property.
  • So, it allows you to dynamically change the
    appearance and/or behavior of your control
    without having to create a new one.
  • Triggers are used to change the value of any
    given property, when certain conditions are
    satisfied.
  • Triggers are usually defined in a style or in the
    root of a document which are applied to that
    specific control.

https//www.ifourtechnolab.com/wpf-software-develo
pment
108
Types Of Triggers
  • There are three types of triggers-
  • Property Triggers
  • Data Triggers
  • Event Triggers

https//www.ifourtechnolab.com/wpf-software-develo
pment
109
Property Triggers
  • In property triggers, when a change occurs in one
    property, it will bring either an immediate or an
    animated change in another property.
  • For example, you can use a property trigger to
    change the appearance of a button when the mouse
    hovers over the button.
  • ltWindow xClass "WPFPropertyTriggers.MainWindow"
  • xmlns "http//schemas.microsoft.com/winfx/200
    6/xaml/presentation"
  • xmlnsx "http//schemas.microsoft.com/winfx/2
    006/xaml"
  • Title "MainWindow" Height "350" Width
    "604"gt
  • ltWindow.Resourcesgt
  • ltStyle xKey "TriggerStyle" TargetType
    "Button"gt
  • ltSetter Property "Foreground" Value
    "Blue" /gt
  • ltStyle.Triggersgt

https//www.ifourtechnolab.com/wpf-software-develo
pment
110
Data Triggers
  • A data trigger performs some actions when the
    bound data satisfies some conditions.
  • For example, There is checkbox and label. When
    the checkbox is checked, it will change labels
    foreground color to red.
  • ltWindow xClass "WPFDataTrigger.MainWindow"
  • xmlns "http//schemas.microsoft.com/winfx/200
    6/xaml/presentation"
  • xmlnsx "http//schemas.microsoft.com/winfx/2
    006/xaml"
  • Title "Data Trigger" Height "350" Width
    "604"gt
  • ltStackPanel HorizontalAlignment "Center"gt

https//www.ifourtechnolab.com/wpf-software-develo
pment
111
Event Triggers
  • A data trigger performs some actions when the
    bound data satisfies some conditions.

lt/DoubleAnimationUsingKeyFramesgt ltDoubleAnimation
UsingKeyFrames Storyboard.TargetProperty
"Height" Duration
"004"gt
ltLinearDoubleKeyFrame Value "30" KeyTime
"000"/gt
ltLinearDoubleKeyFrame Value "40" KeyTime
"001"/gt
ltLinearDoubleKeyFrame Value "80" KeyTime
"002"/gt
ltLinearDoubleKeyFrame Value "150" KeyTime
"003"/gt
lt/DoubleAnimationUsingKeyFramesgt
lt/Storyboardgt
lt/BeginStoryboardgt
lt/EventTrigger.Actionsgt
lt/EventTriggergt lt/Button.Triggersgt
lt/Buttongt lt/Gridgt lt/Windowgt
https//www.ifourtechnolab.com/wpf-software-develo
pment
112
  • Thank You

https//www.ifourtechnolab.com/wpf-software-develo
pment
Write a Comment
User Comments (0)
About PowerShow.com
