Coronary Atherosclerosis with Multislice CT: What is beyond coronary atherosclerosis

1
Coronary Atherosclerosis with Multislice CTWhat
is beyond coronary atherosclerosis
Christoph R Becker
Radiology
Konstantin Nikolaou
Tobias Jakobs
Bernd Wintersperger
2
Calcified Noncalcified Plaques
3
CTA Inclusion Criteria

• Asymptomatic patients
• CV risk factors
• Positive calcium scan
• Symptomatic patients
• No CAD history
• Atypical chest pain
• Inconsistent stress test
• 100 mg CaHA

4
Patient Preparation

• ??-blocker
• R/o Contra indications
• Informed consent
• Metoprolol
• 50 - 100 mg orally
• 30 - 90 min prior
• HR 50 - 60 bpm

5
Coronary CTA Parameters

• Testbolus 20 ml _at_ 4 ml/s
• 120 ml (300 mg iodine) _at_ 3 ml/s NaCl 60 ml
  _at_ 3 ml/s
• 500 ms gantry rotation
• 120 kV, 300 mA
• 4 x 1 mm collimation
• 3 mm/s table feed
• 40 s breath hold

6
ECG Tube Current Modulation
7
CTA Radiation Exposure
mSv
8
Left Coronary Artery (RAO)
Coronary Angiography
MDCT VRT
9
Right Coronary Artery (LAO)
LAO 60
Coronary Angiography
MDCT VRT
10
Detection of Coronary Stenoses
MDCT
Coronary Angiography
11
Coronary StenosesCTA Angiography
12
CTA Limitations

• Artifacts
• Cardiac motion
• Breathing
• Blooming
• Poor opacification
• Small vessel

13
Solutions

• Rot. time ??blocker
• Cardiac motion artifacts
• Scan times
• Breathing artifacts
• CM utilization
• Slice thickness
• Small vessels
• Blooming artifact

14
16 Detector Row CT Angiography

• 200 ms
• 9 Lp/cm
• 0.8 mm
• 20 s breath hold
• 60 ml CM

15
Coronary Plaque Imaging
MDCT
Coronary Angiography
16
Non Calcified Plaque Density
17
Coronary Atherosclerosis
Intimal Thickening
18
Atheroma

• 38 YOM
• Non specific complain
• Risk Factors
• Cholesterin
• Smoker
• No calcium

19
Calcified Nodule

• 62 YOM
• Suspicion of CAD
• 12 mg CaHA

20
Fibrocalcified Plaque
100 HU
21
Thrombus

• 42 YOM
• Epigastric chest pain
• Risk Factors
• Hypertension
• Smoker
• No calcium

22
Thrombus
23
Acute Posterior Wall Infarction
24
Myocardial Infarction Scar
anterior LAD
posterior RCA
lateral LCx
25
CT Plaque Density
p 0.018
50 12 HU
89 31 HU
Lipid
Fibrose
Lipid
Fibrosis
26
CTA vs IVUSSchröder Heart 200185576
27
Carotid AtherosclerosisEstes 1998 J Cardiovasc
Surg 39527
28
Plaque DistributionLeber 2001 Circulation
Myocardial Infarction n 12 122 Plaque
Stable Angina n 12 135 Plaque
29
Summary

• Detection of stenoses
• Calcium
• Small vessels
• Characterization of plaques
• Identify atheromas
• Follow up under therapy
• Acute coronary event
• Intracoronary thrombus
• Myocardial infarction

30
