Hybrid Systems: From Models to Code

1
Hybrid Systems
From Models to Code

• Tom Henzinger
• UC Berkeley

2
French Guyana, June 4, 1996
800 million embedded software failure
3
Mars, December 3, 1999
Crashed due to uninitialized variable
4
4 billion development effort
40-50 system integration validation cost
5
Sources of Complexity
-concurrency -real time -heterogeneity
A hybrid system consists of multiple continuous
(physical) and discrete (computational)
components that interact with each other in real
time.
6
Embedded Software Design Current State
Design Simulate
Model (e.g., Simulink)
Code generation
Optimize Test
Code
7
Embedded Software Design Our Vision
Design Verify
Model
Compilation (analysis, optimization, and code
generation)
Code
8
The FRESCO Project (Formal Real-Time Software
Components)
MASACCIO correctness by formal
verification against requirements
Hybrid System Model
GIOTTO correctness by schedulability
analysis against resources
Time-Safe Code
9
Continuous (Euclidean) Systems
n
State space R
Dynamics initial condition
differential equations
Room temperature x(0) x0 x(t)
-Kx(t)
x
x0
t
Analytic complexity.
10
Discrete (Boolean) Systems
m
State space B
Dynamics initial condition
transition relation
Heater
off
on
heat
off
on
t
Combinatorial complexity.
11
The Curse of Concurrency
300,000 latches
12
11
10 stars
11
10 stars
100,000
10 states
13
Hybrid Systems
m
n
State space B ? R
Dynamics initial condition
transition relation
differential equations
Thermostat
off
x -Kx
x0
on
off
x K(H-x)
on
t
14
Hybrid Automata
y
x
15
Hybrid Automata
far
near
x 1000
x?-50,-40
x?-50,-30
app!
app
x ? 1000
x ? 0
exit!
x 100 ? x ? 2000,?)
x 0
exit
past
x?30,50
x ? 100
train
16
Hybrid Automata
up
open
y 90
y 9
y 0
y ? 90
raise
raise?
lower?
raise?
lower
down
closed
y 0
y -9
y 0
y ? 0
gate
lower?
17
Hybrid Automata
app
exit
t 0
t 0
t 1
app?
t 1
exit?
idle
t ? ?
t ? ?
lower!
raise!
controller
raise
lower
18
Requirements
Safety ?? ( x ? 10 ? locgate closed
) Liveness ?? ?? ( locgate open ) Real
time ?? z 0. ( z 1 ?
?? ( locgate open ? z ? 60 ))
Verification and failure analysis by model
checking (e.g., HyTech).
19
Two Problems with Hybrid Automata
1. Scalability Possible solutions
-hierarchy (MASACCIO)
-assume-guarantee
decomposition (interfaces) 2. Robustness Possible
solutions
-e-variability
-discounted future
20
MASACCIO
MASACCIO
Hierarchical Hybrid Automata
21
MASACCIO
MASACCIO
Hierarchical Hybrid Automata
22
MASACCIO
MASACCIO
Hierarchical Hybrid Automata
23
MASACCIO
MASACCIO
Hierarchical Hybrid Automata
24
MASACCIO
MASACCIO
25
Two Problems with Hybrid Automata
1. Scalability Possible solutions
-hierarchy (MASACCIO)
-assume-guarantee
decomposition (interfaces) 2. Robustness Possible
solutions
-e-variability
-discounted future
26
The Robustness Problem
Hybrid Automaton
Property
27
The Robustness Problem
Hybrid Automaton
Safe
x 3
28
The Robustness Problem
Hybrid Automaton
Unsafe
x 3?
29
A Possible Solution of the Robustness Problem
Metrics on Traces
Model
Property
instead of
Yes or No
consider
?-Variation
30
A More Radical Solution of the Robustness
Problem
Discounting the Future
value(Model,Property) States ? Yes, No
value(Model,Property) States ? R
31
A More Radical Solution of the Robustness
Problem
Discounting the Future
value(Model,Property) States ? Yes,
No value(m,?T) ?X. (T ? pre(X))
discountedValue(Model,Property) States ?
R discountedValue(m,?T) ?X. max(T, ??pre(X))
discount factor 0lt?lt1
32
A More Radical Solution of the Robustness
Problem
Discounting the Future
Robustness Theorem If discountedBisimilarity(m1,m
2) gt 1 - ?,
then discountedValue(m1,p) - discountedValue(m2,p
) lt f(?).
Further Advantages of Discounting -approximabili
ty because of geometric convergence (avoids
non-termination of verification
algorithms) -applies also to probabilistic
systems and to games (enables reasoning under
uncertainty and control)
33
The FRESCO Project (Formal Real-Time Software
Components)
MASACCIO correctness by formal
verification against requirements
Hybrid System Model
GIOTTO correctness by schedulability
analysis against resources
Time-Safe Code
34
The History of Computer Science Lifting the
Level of Abstraction
High-level languages Programming to the
application
Requirements focused code
Compilation
The assembly age Programming to the
platform
Resource focused code
-Traditional high-level languages abstract
time. -This abstraction is unsuitable for
real-time applications, which are still
programmed in terms of platform time (priority
tweaking). -GIOTTO Real-time programming in
terms of application time.
35
GIOTTO
MASACCIO
Time-Triggered Programming
36
GIOTTO
MASACCIO
Time-Triggered Programming
37
GIOTTO
MASACCIO
Time-Triggered Programming
200 Hz
400 Hz
1 kHz
200 Hz
38
GIOTTO
MASACCIO
Time-Triggered Programming
1. Concurrent Periodic Tasks -sensing


-control law computation

-actuating 2. Multiple
Modes of Operation -navigational modes
(autopilot, manual, etc.)
-maneuver modes (taxi,
takeoff, cruise, etc.)
-degraded modes (sensor,
actuator, CPU failures)
39
GIOTTO
MASACCIO
Time-Triggered Programming
Mode 1
Mode 2
Condition 1.2
Task S 400 Hz
Task S 400 Hz
Task C 200 Hz
Task C 200 Hz
Task A 1 kHz
Task A 1 kHz
Condition 2.1
Task A 1 kHz
Mode 4
Mode 3
Task S 400 Hz
Task C 100 Hz
Task C 200 Hz
Task A 1 kHz
Task A 2 kHz
40
GIOTTO
MASACCIO
Separation of Concerns
Functionality.
Timing and interaction.
Host code e.g. C
Glue code Giotto
-Real time.
-Reactive.
-Concurrent.
-No time. -Atomic. -Sequential.
This kind of software is reasonably well
understood.
The software complexity lies in the glue code.
41
Two Opposing Forces
Requirements
Verification
Model
Environment
Implementation
Resources
42
Two Opposing Forces
Requirements
Verification
Model
Environment
Implementation
property preserving
Resources
43
Two Opposing Forces
Requirements
Verification
Component
Component
Implementation
Resources
44
Two Opposing Forces
Requirements
(time, fault tolerance, etc.)
Verification
no change
Component
Component
Deep Compositionality
Implementation
no change
Resources
45
Achieving Verifiability and Compositionality in
GIOTTO The FLET (Fixed
Logical Execution Time) Assumption
Software Task
write actuator output at time td, for fixed d
dgt0 is the task's "logical execution time"
read sensor input at time t
46
Embedded Programming in GIOTTO
The programmer specifies sample rate d and jitter
j to solve the control problem at hand. The
compiler ensures that d and j are met on a given
platform (hardware resources and performance)
otherwise it rejects the program.
47
Implementing the FLET Assumption
time t
time td
possible physical execution on CPU
buffer output
48
Contrast the FLET with Standard Practice
output as soon as ready
49
Advantages of the FLET and GIOTTO
-predictable timing and value behavior (no
internal race conditions, minimal
jitter) -portable, composable code (as long as
the platform offers sufficient performance)
50
Research Agenda
From Hybrid Models -robust hybrid models (tube
topologies, discounting) -model checking for
hierarchical and stochastic hybrid models
-multi-aspect assume-guarantee decomposition of
hybrid models (interface theories for time,
resources, fault tolerance) To Embedded
Code -distributed schedulability analysis and
code generation -on-line code modification and
fault tolerance
51
Credits
Scalable and Robust Hybrid Systems Luca de
Alfaro, Arkadeb Ghosal, Marius Minea, Vinayak
Prabhu, Marcin Jurdzinski, Rupak Majumdar GIOTTO
Ben Horowitz, Christoph Kirsch, Rupak Majumdar,
Slobodan Matic, Marco Sanvido
52
Collaborators of the FRESCO Project
-Alex Aiken on time-safety analysis of embedded
code -Karl Hedrick on Giotto implementation of
electronic throttle control -Edward Lee on Giotto
modeling and code generation in Ptolemy -Edward
Lee on rich interface theories as type theories
for component interaction -George Necula on model
checking device drivers -George Necula on
scheduler-carrying embedded code -Alberto
Sangiovanni-Vincentelli on synthesis of protocol
converters from interfaces -Alberto
Sangiovanni-Vincentelli and Shankar Sastry on
platform-based design of a helicopter flight
control system using Giotto -Shankar Sastry on
hybrid automata
