ENVI 21 Life in the Ocean

1
(No Transcript)
2
(No Transcript)
3

• Phytoplankton
• Over 4000 described species
• Bacillariophyceae (Diatoms)
• Dominant in temperate and high-latitude waters
• Prefer well-mixed, nutrient-rich conditions
• Pelagic and benthic forms
• Pelagic forms generally non-motile
• Unicellular, though some may form chains, which
  then may form mats
• Test composed of two silica valves
• Tests are important components of marine
  sediments in some areas - diatomaceous oozes
• An ooze is any sediment that contains more than
  30 tests, the rest typically terrigenous

4
Fig. 2.1
5

• Phytoplankton
• Bacillariophyceae (Diatoms)
• Two basic body shapes
• Pennate Elongate, typically motile, mostly
  benthic (Exception Nitzschia)
• Centric Mostly planktonic (Ex Coscinodiscus,
  Chaetoceros)

6

• Phytoplankton
• Bacillariophyceae (Diatoms)
• Planktonic forms typically non-motile with
  anti-sinking mechanisms
• Reduced body size
• Structural elaborations increase drag
• Formation of chains
• Reduction of internal ion concentration
• Sequestration of low-density ions, e.g. NH4
• Production and storage of oils
• Many of these mechanisms are generally applicable
  to planktonic organisms
• Living cells typically sink 0-30 m d-1, while
  dead cells may sink twice as rapidly
• Senescent or near-senescent cells may
• Lose ability to regulate ion content or sequester
  low-density ions
• Lose ability to produce and store oils
• Release a chemical (e.g. a polysaccharide) that
  lowers viscosity of water immediately surrounding
  cell

7
(No Transcript)
8

• Phytoplankton
• Dinophyceae (Dinoflagellates)
• Motile forms possess two flagella
• Not all dinoflagellates are motile and not all
  are autotrophic
• Some lack flagella
• Some heterotrophic (50)
• Some mixotrophic (auto- and heterotrophic)
• Some symbiotic (e.g. zooxanthellae)
• Two basic forms
• Thecate Covered with theca made of cellulose
  plates
• Theca may have spines
• Athecate Less common

9
Fig. 2.3
10

• Phytoplankton
• Dinophyceae (Dinoflagellates)
• Important open-water primary producers,
  especially in tropical regions
• More tolerant of low nutrients and low light than
  diatoms
• Advantage for thriving under post-diatom-bloom
  conditions
• Often abundant in summer/autumn following spring
  and summer blooms of diatoms
• Motility allows individuals to maintain position
  in water column under low-turbulence conditions
• Motility also allows individuals to spend
  daylight hours in surface waters (light for
  photosynthesis) and night hours in deeper waters
  (nutrients more plentiful)
• Most abundant phytoplankton in stratified,
  nutrient-poor tropical and subtropical waters

11
Thecate species of heterotrophic dinoflagellates
use pallium feeding
Feed on other plankton with a pallium (sac)
extruded from a microtubular basket. Siana and
Montrasor (Eur. J. Phycol. 2005) reported
ingestion rates up to 36 diatoms/ Protoperidinium
vorax /hr Other reports are lower
http//chbr.noaa.gov/pmn/images/PhytoplanktonPics/
Protoperidinium/ProtoperidiniumSEM02.jpg
12

• Protoperidinum feeding on Ceratium furca
• Arrow shows pallium
• Arrowheads show multiple Protoperidinium feeding
  on the same prey
• Olseng, et al. 2002 Mar Ecol Prog Series
• Other species of dinoflagellates use a tube
  inserted into prey to consume the cytoplasm
• Only naked dinoflagellate species engulf prey

Olseng, et al. (2002) Mar Ecol Prog Series
13
Swimming with bioluminescent dinoflagellates
Campbell and Reece Figure 28.12x2
14
Dinoflagellates often cause Harmful Algal Blooms
http//www.whoi.edu/redtide/
15

• Phytoplankton
• Haptophyceae (Coccolithophorids)
• Very small (typically less than 20 µm)
• Covered by calcium carbonate coccoliths
• Coccoliths may be important components of
  sediments
• Typically motile at some life stage (have
  flagella)
• Most species occur in warm water at relatively
  low light intensities
• Most abundant at depths of ca. 100 m in clear,
  tropical, oceanic water
• Blooms may cover extensive areas
• Ex Bloom covering 1000 x 500 km of sea surface
  in North Atlantic (area roughly equivalent in
  size to Great Britain)

16

• Phytoplankton
• Chrysophyceae (Silicoflagellates)
• Silica test, usually with spines
• Single flagellum
• Relatively rare but more common in colder water
  than tropics
• Cyanobacteria (Blue-Green Bacteria)
• Most relatively minor primary producers
• Certain species may be important in particular
  areas for limited periods of time
• Some can fix nitrogen (e.g. mats of Oscillatoria)
• Attribute may explain relatively high abundances
  of Oscillatoria in tropical waters which often
  have low concentrations of nitrogen sources
  generally used by algae (e.g. ammonia, nitrite,
  nitrate)

17
Cyanophyceae (Cyanobacteria)

• Phycoerythrin and phycobilin
• accesory pigments.
• Nitrogen Fixation
• Some symbiotic
• Some filamentous or colonial

• Katagnymene spiralis
• Two colonies of Trichodesmium
• Aphanizomenon sp. colony note heterocyst (H)
• Benthic Rivularia atra
• Lichen Lichina confinis
• Diatom with cyanobacterial symbiont Richelia
  intracellularis (R)
• Dinoflagellate with a "collar" specialised for
  Synechococcus (S) cyanobionts.

http//www.bom.hik.se/njasv/mcb.htmlpics20cyano
18

• Phytoplankton
• Prochlorophytes
• Very small (0.6-0.8 µm diameter)
• Components of nanoplankton and picoplankton
• Resemble bacteria in some respects and algae in
  others
• Structurally, resemble large chloroplasts with
  internal membranes that facilitate photosynthesis
• Appear to be closely related to cyanobacteria and
  may be ancestors of modern algae
• In some areas, e.g. oceanic equatorial Pacific,
  production by prochlorophytes may constitute a
  substantial fraction of total phytoplankton
  chlorophyll (up to 60) and primary production
• Cell densities may be comparable to those for
  bacteria (ca. 106 ml-1)
• Phytoplankton community in some areas may change
  from diatom- or dinoflagellate-dominated
  assemblages to prochlorophyte-dominated
  assemblages
• Shift has profound consequences for entire food
  web

19
(No Transcript)
20

• Phytoplankton
• Prochlorophytes
• Very small (0.6-0.8 µm diameter)
• Components of nanoplankton and picoplankton
• Resemble bacteria in some respects and algae in
  others
• Structurally, resemble large chloroplasts with
  internal membranes that facilitate photosynthesis
• Appear to be closely related to cyanobacteria and
  may be ancestors of modern algae
• In some areas, e.g. oceanic equatorial Pacific,
  production by prochlorophytes may constitute a
  substantial fraction of total phytoplankton
  chlorophyll (up to 60) and primary production
• Cell densities may be comparable to those for
  bacteria (ca. 106 ml-1)
• Phytoplankton community in some areas may change
  from diatom- or dinoflagellate-dominated
  assemblages to prochlorophyte-dominated
  assemblages
• Shift has profound consequences for entire food
  web

21

• Phytoplankton
• Blooms
• Occur when conditions become favorable for one
  species or group of phytoplankton
• Population of that species or group increases
  rapidly and suddenly
• If bloom species is a dinoflagellate, densities
  sometimes increase so rapidly and reach such high
  levels that reddish-brown pigment they produce
  may color the water and cause a red tide

22
http//www.whoi.edu/redtide/
23

• Phytoplankton
• Blooms
• Red tides typically become visibly apparent when
  cell concentrations reach 2-8 x 106 cells l-1
• Cell concentrations may exceed 108 cells l-1
• As nutrients are depleted and bloom begins to
  break down, bacteria begin to decompose the
  remaining organic material
• If material is sufficiently abundant, bacterial
  decomposition may deplete oxygen in surface
  waters, negatively impacting local fauna
• Phenomenon applies to any large phytoplankton
  bloom, not just red tides
• Red tides may involve species that produce
  pigments but are not toxic or may involve species
  that produce compounds that are toxic to marine
  life

24

• Phytoplankton
• Blooms
• Toxin (Saxitoxin) may be
• Released into water, where it may be consumed
  directly by organisms that graze on phytoplankton
  (e.g. zooplankton) and indirectly at higher
  trophic levels
• Transmitted from dinoflagellates directly to
  higher organisms, e.g. clams, mussels, scallops,
  oysters, which then may be food for larger
  animals
• Result of consuming tainted fish or bivalves is
  Paralytic Shellfish Poisoning (PSP) - may be
  fatal
• Some forms can be extremely toxic
• Ex Pfiesteria
• Blooms triggered by coastal pollution
• Causes extensive fish kills
• Toxin can cause memory loss in humans

25
(No Transcript)
