DNA Replication I: Basic Mechanism and Enzymology

1
DNA Replication I Basic Mechanism and Enzymology
Liuqing Yang
2
Contents

• General Features of DNA Replication
• Enzymology of DNA Replication
• DNA Damage and Repair

3
Semicomservative Replication
There are three hypothesis about DNA replication
4
Mix DNA containing nomal isotope of nitrogen(14N)
and DNA labeled with a heavy isotope of nitrogen
(15N), then, subject it to cesium chloride
density gradient centrifugation
Two DNAs localization
The amounts of DNA
5
Three hypothesis of DNA replication
6
The result of cesium chloride density gradient
centrifugation Left light DNA Right
heavy DNA
7
Behaviors of heat-denatured DNAs in
ultracentrifugation
8
Semidiscontinuous Replication
Three hypothesis of DNA replication
9

• DNA polymerase of all natural replicating
  machines can make DNA in only one direction 5
  3.
• So Reiji Okazaki concluded that both strands
  could not replicate continuously

10

• He proposed a Semidiscontinuous Replication
  model
• One stand (the leading stand) continuously in
  direction, the other srand (the lagging strand)
  would have to be made discontinuously as show in
  previous figure

11

• Okazaki made two predictions derived from his
  model
• Lable newly synthesized DNA and check it in very
  short periods, we should get DNA in short pieces
• Eliminate DNA ligase, this short pieces of DNA
  ought to be detectable even with ralatively long
  period
• Then his research team tested these predictions
  experimentally

12
(No Transcript)
13
Priming of DNA Synthesis

• The replication of M13 phage DNA by an E.coli
  extract is inhibited by a inhibitor of E.coli RNA
  polymerase
• Tuneko Okazaki, wife and scientific colleague of
  Reiji Okazaki, found that DNase can not
  completely destroy Okazaki fragments, it leaved
  little pieces of RNA 10-12 bases long

14
The explanation of previously two phenomena is
that the DNA replication needs a RNA
primer, which is 10-12 bases long. M13 phage DNA
uses the E.coli RNA polymerase to make
RNA primers for its replication.
15
Tuneko Okazaki used the capping enzyme, guanylyl
transferase, and alpha-32PGTP to lable the
5-ends of only intact primer, after DNase
Incubation, then subject it to
gel electrophoresis a-d before DNase
incubation e-h after DNase incubation a and e
cells were defective in RNase H b and f cells
were defective in the nuclease activity of
DNA pol I c and g cells were defective in
both d and h wild type
16
Bidirectional Replication
The theta mode of DNA replication in E.coli
17
Experimental demonstration of bidirectional DNA
replication first, use low radioactivity DNA
precursor, after the bubble had grown somewhat,
a more radioactivity DNA precursor added Right
diograph interpretation
18
Bidirectional DNA replication in eukaryotes Low
radioactivity DNA precursor added after high
radioactivity
19
Autoradiograph of replicating embryonic Triturus
vulgaris DNA Note the constant size and shape of
the pairs of streaks, suggesting that all the
coresponding replicons bigan replicating at the
same time
20
Rolling Circle Replication

• The E.coli phages with single-stranded circular
  DNA genomes, such as phineX174, use a relatively
  simple form of rolling circle replication in
  which a double-stranded replicative form (RFI)
  give rise to many copies of a single-stranded
  progeny DNA

21
Schematic representation of rolling circle
replication
22
Strand Separation

• Helicase can harnesses the chemical energy of ATP
  to separate the two parental DNA strands at the
  replicating fork
• Use a E.coli strain carrying a temperature-sensiti
  ve mutations in the dna B gene, when the
  temperature rise to the nonpermissive level, the
  DNA synthesis halt immediately
• We would expect if the dna B encodes helicase

23
DNA helicase assay
24
Dna B alone had halicase activity This was
stimulated by Dna G and SSB
substrates
products
25
Single-Strand DNA-Binding Proteins

• SSBs do not catalyze strands separation, they
  bind selectively to single-stranded DNA as soon
  as it forms and prevent its annealling
• The T4 phage SSB is gp32, the M13 phage SSB is
  gp5, all of these proteins act cooperatively (the
  binding of one protein facilitates the binding of
  the next)

26
SSBs also have other functions, Such
as Stimulation of DNA synthesis
Right figure stimulation of DNA synthesis By the
T4 phage SSB, gp32
27
Temperature-sensitivity of DNA Synthesis in
cells infected by T4 Phage with a
temperature- Sensitive mutation in the SSB
Gene Blue gene 23 mutant Red gene
23 and 32 mutant Yellow gene 32 and 49 mutant
28
Prevent DNA degradation Degradation of T4 DNA in
cells infected by T4 phage with
a temperature-sensitive mutation in gene 32
29
Topoisomerases

• Topoisomerases can release the positive
  supercoils, which were caused by the proceeding
  of the replication fork. It can also introduce
  negative supercoils into DNA

30
Assay for a DNA Topoisomerases
Incubate relexed circular ColE1 DNA with
varying amounts of E.coli gyrase
(topoisomerases) Lane 1 positive
control Lane 2 no gyrase Lane 3-10 gyrase
increasing Lane 11 no ATP Lane 12 no
spermidine (???) Lane 13 no
MgCl2 Lane 14 supercoiled DNA incubated with
gyrase without ATP as a ctr
31
DNA polymerase I

• Pol I (a single 102-KD polypeptide chain)
• DNA polymerase activity
• 3 5 exonuclease activity (proofreading)
• 5 3 exonuclease activity

32

• Pol I cleaved by mild proteolytic treatment into
  two polypeptide
• Klenow fragment has DNA polymerase activity and
  proofreading activity, be often used to sequence
  a DNA
• A small fragment has 5 3 exonuclease activity
• The whole Pol I is used to lable a probe in vitro

33

• A pol I laked mutant still has DNA replicating
  activity strongly suggests that Pol I is not the
  DNA replicating enzyme
• Following experiments indicated that Pol III is
  the enzyme replicates E.coli DNA

34
The Pol III Holoenzyme
35
Identify which subunit responsible for the DNA
polymerase activity
Separation of pol III and the alpha unit from a
cell that over-expresses the alpha unit
36
Purification and identify the function of the E
subunit
purification
Proofreading function
37
Damage Caused by Alkylation of Bases
Alkyl groups uaually are electrophiles(????),
they can seek centers of negative charge
in other molecules This figure shows
electron-rich centers in DNA
38
Mispair caused by Alkylation
39
Damage caused by UV
40
DNA repair machanisms

• Directly undoing DNA damage
• Excision repair
• Double-srand break repair
• Mismatch repair

41
Two models of Directly undoing DNA damage
42
Two types of excision repair
Base excision repair
Nucleotide excision repair
43
Double-strand break repair

• Homologous recombination
• Nonhomologous end-jioning

44
Mismatch repair in E.coli
45
Coping with DNA without repair it

• Recombination repair (post replication repair)
• Error-prone bypass
• Error-free bypass (human cells)

46
An overview of error-prone Bypass process
In human error-free Bypass these two
bases Displaced by AA
47
Thank you !
