Circuit Retiming with Interconnect Delay

1
Circuit Retiming with Interconnect Delay

• CUHK CSE CAD Group Meeting One
• Evangeline Young
• Aug 19, 2003

2
Circuit Retiming

• Given a circuit, we want to relocate the
  registers to achieve a better clock period.

Clock period 3 units
Clock period 2 units
Retiming
Registers
3
Circuit Retiming

• In order to maintain the functionality of the
  circuit, registers can only be moved in certain
  ways

Retiming
4
Circuit Retiming

• Given a circuit, how should we place the
  registers to minimize the clock period?

5
Traditional Approach

• This retiming problem is firstly introduced in
  the following classical paper
• Retiming Synchronous Circuitry, Charles E.
  Leiserson and James B. Saxe, Algorithmica,
  65-35, 1991
• Only gate delay was considered.
• Three methods are proposed. One of them solves
  the problem by mixed integer linear programming
  (MILP).

6
Traditional Approach

• Notations
• d(v) is the delay of node v.
• w(e) is the original no. of registers on edge e.
• c is the clock period that we want to check if it
  is feasible.
• r(v) is the retiming value of node v, i.e., the
  no. of registers moved from the output to the
  input of node v. (r(v) is what we want to find.)
• s(v) is the longest delay from a register
  connected directly to node v to the output of v.

7
Traditional Approach

• More about s(v)

A
s(v) is the delay from point A to B, including
the delay of v.
B
v
8
Traditional Approach

• Integer Linear Program
• d(v) ? s(v) for all node v (1)
• s(v) ? c for all node v (2)
• r(u)? r(v) ? w(e) for all edge e(u,v) (3)
• s(u) s(v) ? -d(v) wherever e(u,v) s.t.
• r(u) - r(v) w(e) (4)

9
Traditional Approach

• Write R(v) as r(v) s(v)/c
• The ILP can be written as an MILP
• r(v) R(v) ? -d(v)/c for all node v (1)
• R(v) r(v) ? 1 for all node v (2)
• r(u)? r(v) ? w(e) for all edge e(u,v) (3)
• R(u) R(v) ? w(e)-d(v)/c for all edge e(u,v)
  (4)
• The above set of difference constraints can be
  solved in polynomial time, though it consists of
  both integer and real variables.

10
Traditional Approach

• Use binary search to find the optimal clock
• T0 0
• T1 e10 // a large no.
• Repeat
• c (T0 T1)/2
• Check if c is a feasible clock period by solving
  the MILP.
• If success, T1 c otherwise, T0 c.
• Until success and (T1 - T0)/T1 lt e

11
Retiming with Interconnect Delay

• We consider clock period minimization.
• Retiming has been studied and applied extensively
  at logic synthesis.
• However, most previous retiming algorithms ignore
  interconnect delay.
• Interconnect delay should be considered for high
  performance circuits in DSM design.
• This solution is going to be presented in the
  upcoming ICCAD 2003.

12
Retiming with Interconnect Delay

• We assume that wire delay is directly
  proportional to its length.
• This assumption is reasonable
• For short wires, the quadratic component of a
  wire delay is significantly smaller than its
  linear component.
• For long wires, buffer insertion can be done.

13
Retiming with Interconnect Delay
14
Retiming with Interconnect Delay

• Now, a retiming solution needs to specify
• the retiming label r(v) for each node v.
• the positions of the registers on each edge.

r( ) 0
r( ) -1
Retiming
r( ) 0
r( ) 0
The positions of the registers on the edges are
important as there are interconnect delay.
15
Our Contributions

• Optimal algorithm
• O(VE log V V2 log2V) time per
  iteration.
• Near-optimal algorithm
• Only 0.13 larger than the optimal on average.
• O(VbE VbEh) time per iteration, e.g., a
  circuit with 16.1K gates and 28.6K wires can be
  retimed in 44.32s by a 1.8GHz PIII PC.
• Based on an optimal algorithm handling
  interconnect delay only, i.e., no gate delay.

16
Optimal Approach

• Rewrite the ILP on p.8 as follows
• d(v) ? s(v) for all node v (1)
• s(v) ? c for all node v (2)
• r(u)? r(v) ? w(e) for all edge e(u,v) (3)
• s(v) s(u) d(e) d(v) - c(r(v) - r(u) w(e))
• for all edge e(u,v) (4)

17
Optimal Approach

• Similarly, write R(v) as r(v) s(v)/c
• r(v) R(v) ? -d(v)/c for all node v (1)
• R(v) r(v) ? 1 for all node v (2)
• r(u)? r(v) ? w(e) for all edge e(u,v) (3)
• R(u) R(v) ? w(e) - d(v)/c - d(e)/c
• for all edge e(u,v) (4)
• Again, the above set of constraints can be solved
  in polynomial time, though the runtime is quite
  long.

18
Optimal Approach
V
E
copt
Circuit
Runtime (s)
s1488
655
1405
18.85
5.62
s1494
649
1411
20.78
4.37
s3271
1574
2707
10.24
33.70
s3330
1791
2890
27.05
43.14
s3384
1687
2782
24.16
25.19
s4863
2344
4093
23.58
87.75
s5378
2781
4261
27.25
138.68
s6669
3082
5399
22.96
177.59
s9234
5599
8005
42.73
512.86
s13207
7953
11302
72.34
1161.07
s15850
9774
13794
67.82
1545.59
s35932
16067
28590
29.54
8644.27
s38417
22181
32135
36.52
7680.79
s38584
19255
33010
gt15000
19
Near Optimal Approach

• Transform the original graph G by splitting each
  node v (represents a gate) into a pair of nodes
  v1 and v2 connected by an edge with delay d(v).

v1
delay d(v)
delay 0
v
v2
delay d(v)
20
Near Optimal Approach

• After representing each gate by a wire, we can
  find an optimal retiming solution S for the
  transformed circuit G1. (We will show how to find
  the optimal solution with no gate delay.)
• The clock period of S will be a lower bound L for
  the optimal solution Topt of G.
• From S, we can obtain a feasible retiming
  solution for the original circuit G.

21
Near Optimal Approach

• Registers retimed into a wire representing a gate
  v will be moved backward to the input edges or
  forward to the output edges depending on their
  distances from v1 and v2.
• Linear programming is used to determine the
  positions of the registers on each edge after
  this relocation step to minimize the clock period
  considering both gate and wire delay.

v1
v2
22
Near Optimal Approach

• It is now the problem of solving the retiming
  problem optimally assuming that gate delay is
  zero.
• When there is no gate delay, the set of
  constraints on p.17 becomes
• r(v) R(v) ? 0 for all node v (1)
• R(v) r(v) ? 1 for all node v (2)
• r(u)? r(v) ? w(e) for all edge e(u,v) (3)
• R(u) R(v) ? w(e)-d(e)/c for all edge e(u,v)
  (4)

23
Near Optimal Approach

• Lemma 1 Given R(v) for all node v that satisfy
  constraint (4), we can obtain a solution to
  constraint (1)-(4) by setting
• r(v) trunc(R(v))
• Given Lemma 1, we only need to solve constraint
  (4) R(u) R(v) ? w(e)-d(e)/c for all edge
  e(u,v).
• Consider the input graph G(V,E) such that the
  weight of each edge e(u,v) is -w(e)d(e)/c.

24
Near Optimal Approach

• There is a solution to constraint (4) iff G has
  no positive cycles.
• Positive cycle detection in G can be achieved by
  positive cycle detection in a smaller graph
  H(Vb,Eh) constructed from G. This technique can
  be applied in other positive cycle detection
  problems, not necessarily in circuit retiming.
• After solving R(v), we can find r(v) and s(v) for
  all node v.

25
Near Optimal Approach

• After the binary search, we can find the optimal
  clock and the corresponding r(v) and s(v) for all
  node v. Then, we can place the registers
  accordingly

Assume that r(v)-r(u)w(e) 4
u
v
c
c - s(u)
Other registers are placed right in front of v.
26
Near Optimal Approach

• First, assuming that gate delay is zero.
• Binary search to find the minimum feasible clock
  period c
• To test the feasibility of a fixed c
• Transforming to a positive cycle detection
  problem on a reduced graph
• Can be solved by a single-source longest-path
  algorithm

27
Results
copt
Circuit
Topt (s)
cnear opt
Tnear opt (s)
18.85
s1488
18.82
5.62
0.28
20.78
s1494
20.78
4.37
0.25
10.24
s3271
10.24
33.70
1.09
27.05
s3330
27.05
43.14
0.50
24.21
s3384
24.16
25.19
0.74
23.58
s4863
23.58
87.75
3.12
27.27
s5378
27.25
138.68
1.16
23.07
s6669
22.96
177.59
1.91
42.73
s9234
42.73
512.86
4.08
72.34
s13207
72.34
1161.07
8.11
67.82
s15850
67.82
1545.59
24.02
29.59
s35932
29.54
8644.27
61.25
36.53
s38417
36.52
7680.79
83.56
s38584
gt15000
94.26
445.63
28
Future Directions

• Consider a more accurate modeling for the
  interconnect delay, e.g., use Elmore delay.
• How to map the retiming solution to the
  floorplanning or placement solution? Registers
  are large and take up silicon resources.
• How to consider fan-out capacitance with
  interconnect delay?
