Mehwish Nagda, Christo Frank Devaraj, Indranil Gupta, Gul Agha

1

• Mehwish Nagda, Christo Frank Devaraj, Indranil
  Gupta, Gul Agha
• University of Illinois (Urbana-Champaign)

2
Motivation

• Many scientific disciplines express ideas,
  results and phenomena through differential
  equations
• From competition in ecosystems to Schroedingers
  Wave Equation
• Can we translate the scalability and reliability
  inherent in non-Computer distributed systems into
  protocols for distributed systems?
• Can we generate code for such distributed
  protocols?
• Can we do this rigorously, rather than
  hand-wavily?

3
Approach

• DiffGen Toolkit to systematically translate a
  subset of differential equation systems into
  equivalent distributed protocol code in C so that
  the protocols are guaranteed to
• show equivalent stochastic behavior as original
  equation system
• be probabilistically scalable
• be probabilistically reliable
• have low and scalable bandwidth at each process
• have low convergence times
• DiffGen internals are backed by rigorous
  translation methodologies, that guarantee
  provable properties of generated code.

4
Internals Input Semantics
Dx 0.3x2z2 - 0.3x2y2 Dy
0.3y2z2 - 0.3x2y2 Dz -0.3x2z2
-0.3y2z2 0.3x2y2 0.3x2y2

• The above is a sample input into the toolkit for
  a system of 3 equations.
• Each equation has to be in the form Dxi f(x1,
  x2, ..., xi, ..., xn) where xi is the variable
  that is differentiated.
• 0.3x2z2 is a term in the first equation for
  variable x.
• Each term in the equation starts with a positive
  or negative constant value.
• Variables in the term are separated by .
• Exponents for each variable follow the '
  character. A variable with no exponent defined
  has an exponent of 1.

sample input (diffsys) file
5
Intermediate Representation, diffIR

• Input system is converted to diffIR, the
  intermediate representation of the differential
  equation system
• The differential system contains a list of
  differential equations in the system.
• The differential equation contains a list of
  positive and negative terms as well as the
  differential equation variable.
• The equation term contains the constant in the
  term, the set of variables involved in the term
  and their exponents, and a reference to the
  matching negative or positive term in the
  differential equation system.

equation variable
negative terms
positive terms
positive terms
negative terms
differential equation
constant
match term
differential equation
variable
exp
variable
exp
equation term
differential system
6
Science of Protocol Design

• The toolkit then maps the equation system to a
  state machine which contains
• One state per basic variable in the original
  equation system
• Actions mapped onto these states by mapping terms
  to one of three actions

Term T
flipping
Periodically toss coin with probability p.c If
heads, switch state to state y with c.x term
7
Term T

one time sampling
with
Periodically toss coin with probability p.c If
heads, sample
other processes uniformly at random from
across the group If first target
choices are in state x and for all j,
the jth process sampled
is in the same state as the jth variable in
(when ordered
lexicographically), then switch state to
state y with the T term
Term T
tokenizing
with
A variable w in X is chosen such that Flipping
or one time sampling actions are created for
processes in state w with actions modified so
that instead of switching state a token is sent
to a random process known to be in state x that
transitions into the state of the variable with
the corresponding T term on receiving the token
8
Template files

• The diffIR is mapped to the above actions and the
  code is generated into template files. Template
  files implement
• Alarm System Timer events are used to wake nodes
  up to carry out protocol actions every protocol
  period. A node in a particular state will set a
  timer for each negative term in the corresponding
  differential equation.
• Core Probabilistic Functions Code for flipping,
  one time sampling and tokenizing are written in
  the form of four parameterized C functions
  (flipping, ots, tok_flipping and tok_ots).
• Communication The messaging subsystem is built
  out of an interface that has two methods send_msg
  and receive_msg. We provide both a simulator
  implementation and a UDP sockets implementation.
• Server The server is used to register each
  client and to stop the protocol.

9
Generated Code

• Code generated is for the Lotka Volterra model.
  The output protocol is for majority selection in
  a distributed system
• Code generated consists of the header snippet (in
  fixedclient.h and common.h) and the
  initialize_states and schedule_timer_event
  functions (in fixedclient.c)
• The header snippet defines the number of states
  (equations) in the input system and constants for
  each state
• The initialize_states function initializes the
  number of negative terms in each equation

Dx 0.3xz - 0.3xy Dy 0.3yz -
0.3xy Dz -0.3xz -0.3yz 0.3xy
0.3xy

sample input
define STATES 3 int state_termsSTATES defi
ne ST_x 0 define ST_y 1 define ST_z 2
header snippet fixedclient.h common.h
void initialize_states() state_termsST_x
1 state_termsST_y 1
state_termsST_z 2
Initialize_states snippet fixedclient.c
10
Generated Code
void schedule_timer_event (int nodeid, struct
pp_payload payload) int curr_term,
to_state, prev_state int curr_state
float p curr_state get_state()
prev_state curr_state if (curr_state !
payload-gtstate) return curr_term
payload-gtterm if (curr_state ST_x
curr_term 0) int
num_states int states, exponents
num_states 2 states
(int)malloc(num_statessizeof(int))
exponents (int)malloc(num_states sizeof(int)
) states0 ST_ystates1 ST_x
exponents0 1exponents1 0
ots (ST_z, 0.5, num_states, states,
exponents) if (curr_state ST_y
curr_term 0)

• The schedule_timer_event function chooses which
  of the four core probabilistic functions should
  be called depending on the process current state
  and the term associated with the current alarm.
  The function is written using the three mapping
  techniques for flipping, one time sampling and
  tokenizing.

schedule_timer_event snippet fixedclient.c
11
Additional DiffGen Capabilities

• Simple lightweight Internal Simulator for testing
  and performance evaluation that is
• synchronous
• based on a discrete event simulation model
• assumes a FIFO message queue

12
This is Continuing Work

• Internal
• New rewriting techniques Develop graphical
  simulator
• Automated Debugging helped by emergent
  knowledge of common bug classes among
  differential equation-based protocols
• Incorporating other Diff. Eqn based methodologies
  as they emerge
• Graphical Simulator
• External
• Combine with auxiliary methodologies for
  augmenting protocol properties, e.g., topology
  awareness
• Combine with IDEs?

13
Alpha version Demo

• We have a (working!) version of the DiffGen
  toolkit
• Please ask for a demo!
