Analyzing Stack and Heap Bounds for Primitive
Recursive Programs in PR-Hume

• Kevin Hammond, Pedro Vasconcelos, Sun
  Meng,Álvaro Rebón Portillo, Leonid
  TimochoukUniversity of St Andrews,
  ScotlandGreg Michaelson, Robert Pointon, Graeme
  McHale, Chunxiu LiuHeriot-Watt University,
  ScotlandJocelyn SérotLASMEA, Clermont-Ferrand,
  France
• http//www.hume-lang.org

2
HumeHigher-order Uniform Meta-Environment
David HumeScottish Enlightenment Philosopher
and Sceptic 1711-1776
3
Hume Research Objectives

• Real-Time, Hard Space Functional Programming
• Including Device Drivers, Derek!
• Virtual Testbed for Space/Time Cost Modelling
• Generative, Domain-Specific Language Design

4
Overview

• Hume Language Design and Examples
• Stack and Heap Usage for Primitive Recursive
  Programs
• Cost Model
• Inference Algorithm (Type-and-Effect System)
• Results of the Analysis
• Conclusions and Further Work

5
Hume Design Domain (1)
6
Hume Design Domain (2)
7
State of the Art...

• Embedded Systems Engineering
• big trend to high level software design (UML
  etc.)
• 80 of all embedded software is now written in
  C/C
• 75 of embedded software is delivered late
• bugs can cost 14,000 each to fix!
• A Major Problem with C/C is Poor Memory
  Management
• explicit allocation, deallocation
• pointer following
• etc. etc.
• No Accurate Method for Determining Memory Usage
• profiling, guesswork(!!), approximation

8
A New Direction?
9
Hume Design Objectives
Reliability,Expressibility,Controllability,Pred
ictability,Costability

• Targets embedded/critical applications
• Hard real-time target
• Formally bounded time and space
• I/O managed through low-level ports/streams
• Memory-mapped, timed, interrupts or devices
• Asynchronous concurrency model (multicore?)
• Simple, easily costed, exception handling
  mechanisms
• Transparent design and implementation
  correctness by construction
• uses Haskell FFI to allow external calls in
  C/assembler etc.
• High level of expressiveness/productivity
• Rule-based system concise clear using
  functional notation
• Runtime errors reduced by strong polymorphic
  types
• Structured reuse through higher order functions
• Thread management simplified by implicit
  concurrency/parallelism
• Elimination of memory errors through automatic
  memory management

10
FSA-derived Notation

• Based on generalised Mealy machines (see
  Michaelson et al. 2003)
• Boxes encapsulate a set of rules each mapping
  inputs to outputs
• Multiple inputs/outputs are grouped into tuples
• Sets of boxes are wired into static process
  networks (automata)
• Boxes repeat indefinitely once a result is
  produced (tail recursion)
• Boxes are asynchronous (ignored inputs/outputs)
• Wires are single-buffered

box b ...match (patt11, ..., patt1k) -gt
(expr11, ..., expr1m) ... (pattn1, ...,
pattnk) -gt (expr11, ..., exprnm)
11
Hume Language Structure

• Declaration Metaprogramming Layer

Coordination Layer
Expression Layer
12
Expression Layer

• Purely functional, strict, higher-order,
  polymorphic, stateless
• Matches are total
• Timeouts/space overflows are managed through
  exceptions

varid expr1  exprn -- function/constructor
application(expr1, , exprn) -- tuples lt expr1,
, exprn gt -- vectors (sized) expr1, , exprn
-- lists (bounded) let decls in expr -- local
value declarations expr within cexpr --
timeout/space restriction if expr then expr else
expr -- conditional expression case expr of
matches -- case expression expr type -- type
cast expr as type -- type coercion (cost
implication)
13
Example Parity Checker

• type Bit word 1
• type Parity boolean
• parity true (true,true)
• parity false (false,false)
• box even_parity2
• in (bBit, pParity)
• out (showstring, p'Parity)
• match
• (0,true) -gt parity true
• (1,true) -gt parity false
• (0,false) -gt parity false
• (1,false) -gt parity true
• wire even_parity2 (comm1, even_parity2.p'
  initially true) (comm2,
  even_parity2.p)

comm1
b
p (true,)
even_parity2
p
comm2
14
Hume Language Levels

• Full Hume
• recursive functions
• recursive data structures
• PR-Hume
• primitive-recursive functions
• primitive-recursive data structures
• HO-Hume
• higher-order non-recursive functions
• non-recursive data structures
• FSM-Hume
• 1st-order non-recursive functions
• non-recursive data structures
• HW-Hume
• no functions
• non-recursive data structures

Full Hume
PR-Hume
HO-Hume
FSM-Hume
HW-Hume
15
Predicting the Cost

• ?

16
A Type-and-EffectSpace Cost Model

• Relates language structure to ltheap, max stackgt
  usage
• operational semantics expressed using sequent
  style
• Tuned to prototype Hume abstract machine
  interpreter
• allows accuracy to be measured
• can be exploited by compiler

Both heap and stack can be cleared after a single
box step
Stack Heap
Derived from theoretical work on cost analysis
for parallel programs
17
Sized Types
10 Nat10 6,1,2 Nat6 3

• Types are annotated with sizes
• magnitude of natural
• length of a list
• Sizes can be weakened to any greater size
• defined as a subtyping relation
• so 10 Nat11 but not 10 Nat9
• ? means unknown size, greater than any other
  size, so 10 Nat?
• ? means undefined size, less than any other size
• Will be used to determine recursion bounds

18
Latent Costs

• Define costs for functions
• Allow costs to be captured for higher-order
  functions

19
Types and Effects for Stack/Heap Usage

• Size/Cost Expressions
• Types and Effects

20
Cost Rules Basic Expressions
21
Cost Rules Conditionals/Cases
22
Cost RulesFunction Applications
23
Cost Rules Function Decls
24
Cost Inference

• Restrict cost annotations in types to be
  variables
• Separately collect constraints on variables
• So, standard unification can be used on types
• Constraints must be solved to determine closed
  costs

25
Cost Inference

• Restrict cost annotations in types to be
  variables
• Separately collect constraints on variables
• So, standard unification can be used on types
• Constraints must be solved to determine closed
  costs

26
Solving Recurrences

• For recursive programs, the effect system
  generates recurrence relations on constraints
• These are solved to give closed forms
• use e.g. Mathematica, called during cost analysis

• use an oracle of known recurrences
• write a new recurrence solver
• Constraints are monotonically increasing

27
Example Length

• For the recursive length function
• length 0
• length (xxs) 1 length xs
• The type inferred is
• length t7x21-x19,x20-gtnatx27,
  x19 gt76x21, x20 gt24x21,x27gtx21

stack,heap
28
Example Take

• For the recursive take function
• take n
• take n (x xs) if n gt 0 then (x take (n-1)
  xs) else
• The type inferred is
• take natx53-x51,x52-gtt118x56
  -x54,x55-gtt118x62, x51gt0,x52gt0,x54gt10
  9min(x53,x56), x55gt713min(x53,x56),x62gtmin
  (x53,x56)

29
Example Twice/Map

• For the Higher-Order twice and map2 functions
• twice f x f (f x)
• map2 f
• map2 f (x) f x
• map2 f (x(y)) f x,f y
• add1 x 1x
• h x map2 (twice add1) x
• The types inferred are
• twice (t21-x14,x15-gtt21)-x2,x3-gtt21-x4,x5
  -gtt21,
• x2gt0,x3gt0,x4gt6max(1x14,1),x5gtx15x15
• map1 (t54-x62,x63-gtt73)-x45,x46-gtt54x6
  4
• -x47,x48-gtt73x6
  5,
• x45gt0,x46gt0,x47gt6max(1max(1x62,1),2),
• x48gtmax(8x63,3),x65gt1
• add1 int-x23,x24-gtint, x23gt7,x24gt4
• h intx112-x75,x76-gtintx113, x75gt3
  0,x76gt25,x113gt1

30
Results

• !

31
Results
function heap (est) stack(est) heap(GHC
-O2) length 10 181(181) 72(72)
1632length 100 1711(1711)
612(612) 2357 length 1000 17011(17011)
6012(6012) 15630length 10000 170011(170011)
60012(60012) 141626 reverse 10
381(381) 88(98) 2080reverse 100
26862(26862) 810(813) 35395 reverse
1000 2518512(2518512) 8008(8013) 3051874 twice
/map2 1 25(25) 30(30)
1564 twice/map2 2 38(38) 30(30)
1592 lift 129(144) 89(89) --
32
Results (Pump)
2.6KBv. 2.4KB

• Cost model applied to mine drainage example
• implemented in prototype Hume abstract machine
  compiler
• compared with measured dynamic runtime costs

9
box heap est heap actual stack est stack
actual pump 47 38 17 17environ 49 47 29
29water 54 54 24 24logger 119 105 39
31others 115 106 70 70wires 96 84
- - totals 480 434 179 171
33
The Reality

• !!

34
RTLinux Memory Usage (Pump)
Module Size Used by hume_module
61904 0 (unused) rtl_sched
43200 0 hume_module rtl_fifo
10016 0 hume_module rtl_posixio
7232 0 rtl_fifo rtl_time
10064 0 hume_module rtl_sched
rtl_posixio rtl 27216 0
hume_module rtl_sched rtl_fifo
rtl_posixio rtl_time
text data bss dec
hex filename 30146 52 30048 60246
eb56 hume_module.o
35
Comparison with Java/Ada (Pump)

• Source
• 867 (234) for Java
• 251 (51) for Hume
• ? (206) for Ada
• Size of object code (byte code)
• 7991 (2003) for Hume
• 18316 (7360) for JVM
• ? (12045) for Ada
• Memory Requirement
• 9MB for Java (JVM, MacOSX)
• 60KB (RTLinux, bare RTS), 400KB (MacOSX, normal
  RTS) for Hume
• Execution Time
• Hume is 9-12x faster than the JVM
• The KVM is 30-80 slower than the JVM

Only one benchmark shown here
But results have been repeated for smaller cases
Direct Real-time comparison requires rewrite to
RTSJ
36
Vehicle Sim. Statistics
Thu Aug 21 190606 BST 2003 Box
Statistics control MAXRT 53120ns, TOT
1960041024ns, MAXHP 57, MAXSP 36 env
MAXRT 9101600ns, TOT 1580087776ns, MAXHP
49099, MAXSP 129 vehicle MAXRT 2973120ns,
TOT 2269933760ns, MAXHP 49164, MAXSP
133 Box heap usage 98440 (99414 est) Box stack
usage 298 (319 est) Stream/MIDI
Statistics output1 MAXRT 22688ns, TOT
3188562720ns, MAXHP 71, MAXSP 1 ...
37
Vehicle Sim. Statistics (2)
Wire Statistics control.0 MAX DELAY 24544ns,
MAXHP 47 env.0 MAX DELAY 67072ns, MAXHP
11 vehicle.0 MAX DELAY 33056ns, MAXHP
47 vehicle.1 MAX DELAY 32448ns, MAXHP
2 vehicle.2 MAX DELAY 9118688ns, MAXHP
11 vehicle.3 MAX DELAY 9135968ns, MAXHP
2 Total heap usage 197022 (199078 est) Total
stack usage 597 (640 est) Sat Aug 23 064619
BST 2003
38
Related Work (Analysis)

• Regions (Tofte)
• explicit labelled memory areas, automatic
  deallocation
• Cyclone (Morrissett)
• C syntax, region inference
• Sized Types (Hughes Pareto)
• properties of reactive systems, progress, not
  inference, not cost
• Camelot/GRAIL (Sannella, Gilmore, Hofmann et al.)
• stack/heap inference from JVM bytecode,
  parametric costs, tail recursion
• Worst-Case Execution Time Analysis (Wellings et
  al)
• Java/Ada, probabilistic cache/execution costs

39
Conclusions

• Cost Analysis forPrimitive Recursive,
  Higher-Order, Polymorphic Functions
• strict, purely functional notation
• generates cost equations plus recurrences
• recurrences solved by reference to an oracle or
  external solver
• soundness results under construction
• Good Practical Results Obtained in a number of
  cases
• no loss of accuracy for non-recursive definitions
• exact worst-case solutions obtained for many
  definitions
• size-aliasing can cause problems for composing
  polymorphic definitions

40
Further Work/Work in Progress

• Modelling
• soundness proofs
• under construction
• extends Hughes/Pareto MML to inference, different
  cost domain
• many technical problems solved, some remaining
• resolve size aliasing problem
• extend to general data structures
• application to other language paradigms
  non-strict, object-oriented, C/C
• Real-Time Models
• Predictive real-time models need better hardware
  (especially cache) models
• alternative real-time scheduling algorithms
  should be tried
• 1MEuro Framework VI Proposal (FET-OPEN)
• with Jocelyn Sérot (LASMEA, France), Martin
  Hofmann (Ludwigs-Maximilian Univerität, Germany)
  and AbsInt GmbH (Saarbrücken, Germany)

41
Recent Papers

• Inferring Costs for Recursive, Polymorphic and
  Higher-Order Functional Programs
• Pedro Vasconcelos and Kevin Hammond
• To appear in Proc. 2003 Intl. Workshop on
  Implementation of Functional Languages (IFL 03),
  Edinburgh,
• Springer-Verlag LNCS, 2004. Winner of the Peter
  Landin Prize for best paper
• Hume A Domain-Specific Language for Real-Time
  Embedded Systems
• Kevin Hammond and Greg Michaelson
• Proc. 2003 Conf. on Generative Programming and
  Component Engineering (GPCE 2003), Erfurt,
  Germany,
• Springer-Verlag LNCS, Sept. 2003. Proposed for
  ACM TOSEM Fast Track Submission
• FSM-Hume Programming Resource-Limited Systems
  using Bounded Automata
• Greg Michaelson, Kevin Hammond and Jocelyn Sérot
• Proc. 2004 ACM Symp. on Applied Computing (SAC
  04), Nicosia, Cyprus, March 2004
• The Design of Hume
• Kevin Hammond
• Invited chapter in Domain-Specific Program
  Generation,
• Springer-Verlag LNCS State-of-the-art Survey, C.
  Lengauer (ed.), 2004

42
http//www.hume-lang.org
43
HumeHigher-order Uniform Meta-Environment
David HumeScottish Enlightenment Philosopher
and Sceptic 1711-1776
44
Results (Far Lifts)
12.8KBv. 7.2KB

• Cost model applied to recursive lifts

box heap est heap actual stack est stack
actual lift1 939 610 218 206lift2 939
392 218 152floors 35 31 21
21logger 715 261 20 20schedule 78
70 35 35totals 2706 1364
512 434
