Firewalls and Network Security

1
Firewalls andNetwork Security

• William Crespo
• Vincent Lauria
• Michael Theriault

2
Synopsis of Presentation

• Security Issues Today
• Firewalls
• How do they work?
• What can they do?
• The future of Security

3
Security Issues Today

• What are the issues and problems?
• Who are the intruders and why?
• What are their techniques?

4
What are the Issues Problems?

• Security was not a fundamental design
  consideration
• The Internet is growing exponentially
• User dependence is increasing
• With increasing complexity
• There are billions of entry points

5
Attack Sophistication vs.Required Intruder
Knowledge
Required Intruder Knowledge
Back-Orifice
Attack Sophistication
Auto. Toolkits
Widespread DDoS
Packet spoofing
Auto. probe scanning
1990
2000
Results from a Carnegie Mellon University Study
6
Who are the intruders?

• Criminals

• Curious Intruders

• Insiders

• Corporate Spies

7
Motives

• Money
• Access to additional resources
• Competitive advantages
• Curiosity and Mischief

8
Possible Attacks

• Compromises and Vulnerabilities
• DDoS (Distributed Denial of Service)
• Sniffing
• Port Scanning
• Malicious code

9
Compromises and Vulnerabilivties

• Unauthorized access to a machine
• Usually due to
• No current patches
• Misconfiguration

10
Example of Smurf DoS attack
ICMP request with spoofed IP of target
Intruder
Target
11
Example of Smurf DoS attack
Intruder
Flood Target with replies
Target
12
Sniffing

• Examines traffic on same physical network
• Intruder must have physical access to network
• Used to gather usernames and passwords

13
Port Scanning

• Wide array of tools to scan open many open ports
  quickly
• Can find out a lot about a network (including OS)
  by looking at open ports
• Also allows intruders to find unprotected Windows
  shares

14
Malicious Code

• Includes Viruses and Trojan Horses
• Ex. Melissa, I Love you Virus
• Difficult to control, because inexperienced user
  can take actions without understanding
  consequences

15
Consequences

• Financial loss
• Web sites unable to fulfill providing a service
• Loss of data
• Loss of public confidence

16
Consequences
US Senate 99
New York Times 98
Dept. of Interior 99
17
FIREWALLS

• What do they do?
• How do they work?

18
What is a firewall?

• A firewall is a machine that monitors all traffic
  to and from a site
• This allows for monitoring, filtering, logging,
  and proper access to the network

19
Firewall Zones

Zones
Servers
DMZ (web servers)
Workstations
20
Our Hardware Implementation

• We created a basic deny-all firewall using
  Windows 2000 Server
• Opened DNS, Web, and ACS2 telnet
• Dynamically assigned IP with NAT
• The next screen shows a snapshot of the Win2K
  Routing Service
• We will demonstrate the firewall using this
  laptop as a workstation

21
Example
DNS Telnet Web
22
How do Firewalls work?

• Most firewalls function through packet filtering
• Filter based upon port or address

Courtesy http//www.vicomsoft.com/knowledge
/reference/firewalls1.html
23
Filtering based on Port

• Filtering based on port occurs by examining the
  Transport layer
• Deny-all
• Reject all packets except to required services

Courtesy http//www.vicomsoft.com/knowledge
/reference/firewalls1.html
24
Filtering Based on Address

• The incoming and outgoing address can be examined
  to see if the computer is allowed access to the
  network
• However, this can be circumvented by an attacker
  who fakes the incoming address, making it look as
  if they are allowed

25
How firewalls prevent

• Lets look over some of the common attacks we
  spoke about

26
Preventing Compromises and Vulnerabilities

• By hiding internal network information, a
  firewall can protect internal servers
• Web serves still need to be patched, but we can
  hide information about them
• i.e. Services and OS running

27
Other Prevention

• Preventing DDoS
• Turn off ping except to trusted IPs
• Preventing Port Scanning
• Turn off all ports except ports needed
• Use NAT to hide IPs
• Preventing Malicious Code
• Difficult to block with firewall
• Internal zones can prevent spreading and
  contamination

28
Direction of Internet Vulnerabilities

• Sophistication of attacks is increasing
• Knowledge is being passed to less knowledgeable
• Vendor testing cycle is decreasing
• Relying on patches

29
Direction of Internet Security

• Better encryption methods
• Adding more security to the transport and IP
  layer of protocols
• IPSEC
• Packet level security based on socket or
  destination address

30
We would like to thank

• Professor D. Starobinski
• The class for your time and patience.

Thank you
