Title: Geometric Design (II)

1
Geometric Design (II)
2
Learning Objectives
• To calculate minimum radius of horizontal curve
• To understand design concepts for transition
curves and compute min length
• To understand the role of SSD in horizontal and
vertical design
• To define and apply grade considerations
• To develop vertical curves
• (Chapter 6.1 6.4)

3
Horizontal Curve
• Curve requiring the most centripetal force for
the given speed
• Given emax, umax, Vdesign

R
4
Horizontal Curve Properties
• Based on circular curve
• D degree of curve
• ? central angle
• T length of tangent
• L length of curve
• LC long chord
• M middle ordinate dist
• E external dist

5
Horizontal Design Iterations
• Design baseline
• Curve radius above the minimum
• Superelevation and side-friction factor not
exceeding the maximum values
• Design is revised to consider
• cost, environmental impacts, sight distances,
aesthetic consequences, etc.

6
Horizontal Curve Sight Distance
• Sight line is a chord of the circular curve
• Sight Distance is curve length measured along
centerline of inside lane

7
Horizontal Curve Sight Distance
• Figure 6-10

8
Transition Curves
• Gradually changing the curvature from tangents to
circular curves

Without Transition Curves
With Transition Curves
9
Transition Curves
• Gradually changing the curvature from tangents to
circular curves
• Use a spiral curve
• L min length of spiral (ft)
• V speed (mph)
• C rate of increase of centrifugal accel
(ft/sec3), 13

10
Transitional Curves
• Gradually changing the cross-section of the
roadway from normal to superelevated (Figure 6-9)

Keep water drainage in mind while considering all
of the available cross-section options
11
Vertical Alignment
Reduced Speed
Increased Speed
12
Vertical Alignment
• measure of inclination or slope, rise over the
run
• Cars negotiate 4-5 grades without significant
speed reduction
• Trucks significant speed changes
• 5 increase on short descending grades
• 7 decrease on short ascending grades

13
functional class, and design speed

Rural Arterials
Terrain 60mph 70mph
Level 3 3
Rolling 4 4
Mountainous 6 5
14
• Maximum length which a loaded truck can travel
without unreasonable speed reduction
• Based on accident involvement rates with 10mph
speed reduction as threshold

15
General Design Speed Reduction
16
Vertical Curves
• To provide transition between two grades
• Consider
• Drainage (rainfall)
• Driver safety (SSD)
• Driver comfort
• Use parabolic curves
• Crest vs Sag curves

17
Vertical Curves
18
Vertical Curves
• Given
• G1, G2 initial final grades in percent
• L curve length (horizontal distance)
• ? Develop the actual shape of the vertical curve

point of vertical intersection
PVI
point of verticaltangency
point of vertical curvature
G1
G2
19
Vertical Curves
• Define curve so that PVI is at a horizontal
distance of L/2 from PVC and PVT
• Provides constant rate of change of grade

A
G1
G2
20
Example
• G1 2
• G2 -4
• Design speed 70 mph
• Is this a crest or sag curve?
• What is A?

21
Vertical Curves
• Major control for safe operation is sight
distance
• MSSD should be provided in all cases (use larger
sight distance where economically and physically
feasible)
• For sag curves, also concerned with driver
comfort (large accelerations due to both
gravitational and centrifugal forces)

22
Crest Vertical Curves
• Critical length of curve, L, is where sight line
is tangent to the crest
• Assume driver eye height (H1) 3.5 ft and object
height (H2) 2.0 ft and SMSSD

23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
Sag VC - Design Criteria
