Changes in Occupational Performance Resulting
from Visual Field Deficit
2
Behavioral Changes

• Four behavioral changes occur following onset of
  VFD
• They explain the limitations observed in
  occupational performance

3
Behavioral Change 1

• Adoption of a narrow, restricted search pattern
  confined to midline and sound side
• Person narrows their scope of scanning
• Seems paradoxical in that one would expect the
  patient to widen their scanning in an effort to
  see around the blind spot
• Occurs because of perceptual completion

4
Perceptual Completion

• Normal perceptual mechanism used to increase
  speed in visual processing
• CNS samples visual array internally completing
  scene based on expectation of what will be found
  in array

5
Even with a visual field deficit as large as a
hemianopsia, the CNS will perceptually complete
the missing field
6
Because of Perceptual Completion

• Initially person is unaware of VFD
• Gradually discovers loss through interaction with
  environment
• Experiences collisions etc
• But often misinterprets mistakes as being due to
  altered depth perception
• Learns to distrust deficit side and focuses
  attention on sound field
• Reduces visual search to deficit side
• Person restricts scanning to midline and sound
  side

7
Restriction in Scanning

• Will prevent person from noticing obstacles in
  environment contributing to
• Collisions
• Disorientation
• Will prevent person from noticing objects in
  environment contributing to
• Difficulty locating items needed for ADLs
• Appearance of neglect
• (but person does not have neglect)

8
Behavioral Change 2

• Even when aware of deficit, person scans very
  slowly towards deficit side
• Cause because of perceptual completion, person
  doesnt have the benefit of a distinct boundary
  between the seeing and the blind field
• Doesnt know when hes in the blind field or how
  far to go to locate a target

9

• You can imagine the dilemma of the hemianopic
  person by picturing yourself at the front of a
  long tunnel. The tunnel is pitch black inside.
  You are instructed to run down to the end of the
  tunnel as fast as you can. Not to worry-youll
  know when youve reached the end of the tunnel
  because there is a wall down there and youll run
  into it.
• WILL YOU RUN FAST OR SLOW DOWN THE TUNNEL WHEN
  YOU CANT SEE WHERE YOU ARE GOING??

10
Slowed Search

• Prevents person from completing activities in a
  timely manner
• Very frustrating
• In dynamic tasks, like driving, may prevent
  person from safely completing the task

11
Behavioral Change 3

• Missing and/or mis-identifying visual detail on
  the blind side
• Occurs if foveal area in macula is involved
  creating macular scotoma
• Person will miss visual information falling into
  the scotoma

12
Missing/Mis-identification

• Can significantly impair reading performance
• Omits or transforms words
• Can cause incomplete performance of tasks
• Only eats part of the food on plate
• Can cause inaccurate task completion
• Dials the wrong telephone number because he
  misread the numbers on the pad

13
Behavioral Change 4

• Reduced visual monitoring of the hand during
  completion of activities
• Only occurs if VFD is on the same side as the
  dominant hand
• And the VFD affects the foveal/macular area

14
Reduced Visual Monitoring

• Can reduce
• Legibility of handwriting
• Accuracy in pouring
• Completion of tasks requiring fine dexterity
• Sewing/threading a needle

15
Behavioral changes create deficits in orientation
and mobility and reading and writing. These
deficits, in turn, cause limitations in a variety
of daily living activities.
16
Orientation and MobilityAmbulation

• Shortened and uncertain stride
• Due to inability to monitor support surface
• Uncertainty approaching, negotiating changes in
  support surfaces
• Curb etc.
• Frequent collisions with unexpected objects
• Adoption of shoe/floor gazing
• Using of trailing and other tactual strategies

17
Orientation and MobilityPostural Adaptation

• Often complain of decreased balance
• Rondot, Odier, Valade (1992)
• Persons with hemianopsia display greater
  displacement of body weight towards VFD side
• 4x times greater displacement than norms
• Still present 7 years post
• Balance instability may be due to reduction in
  peripheral visual input on blind side
• Shift of gravity center towards VFD may
  contribute to collisions with objects on VFD side

18
Orientation and MobilityOrientation to Space

• Often see significant deficits due to
• Erroneous perception of field provided by
  perceptual completion
• Inability to scan fast enough over a dynamic
  scene to comprehend the scene as a whole
• CNS doesnt get enough visual input to build
  working topographical memory

19
Orientation and MobilityOrientation to Space

• Disorientation
• Literally get lost in space as CNS doesnt get
  pertinent visual cues
• Double whammy if occipital lesion occurs as
  person may also lose ability to make saccades
  towards acoustic targets
• Affects safety in dynamic environments
• Adapt by following others and avoidng dynamic
  environments

20
Limitations in Reading

• Occur if fovea and macula are involved
• Affected by both left and right hemianopsia
• Miss or misread words
• Lose place on line, skip lines
• Experience reduced speed and accuracy
• Caused by alteration of perceptual (visual) span

21
Perceptual (visual) Span

• Field of useful vision during eye fixation
• Can be thought of as a window
• Relies on foveal and parafoveal field
• Foveal acute detailed vision to see letters
• Parafoveal less acute, provides gross feature
  detection
• and perception of length and shape of words
• Has spatial and temporal dimensions
• Spatial
• Approximately 8 degrees or 10-15 characters wide
• Asymmetrical, extending farther to right than
  left
• Temporal
• fixation time of 200-250 ms within the perceptual
  span is required for skilled reader to recognize
  a word

22
Perceptual Span continued

• Person fixates in the middle of a word
• Shifts gaze fixation from middle of one word to
  the middle of the next word
• Skips over small words, spaces
• Gaze shift is driven by parafoveal vision which
  detects presence of letters to right side
• Foveal and parafoveal input is used by reader to
  maintain continuous acquisition of text
  information reducing recognition time

23
Perceptual Span in Reading


President Ge
Bush went to
George Bus
24
Reading Comprehension

• For comprehension to occur
• Word recognition must be completed within a
  specific time period
• Words must be read with fluency (accuracy and
  rhythm)
• The fewer the fixations and the shorter their
  duration, the faster the reading speed

25
Hemianopsia

• Shortens the perceptual span
• Causes misidentification or omission of words
• Snow is read as now
• Hanger is read as hang
• Person is forced to commit a regression (re-read
  the word)
• Or in the case of RVFD, forced to spell the word
  for it to make sense
• Both types of errors reduce reading speed and
  accuracy

26

• Significance of reading deficit is determined by
  the degree of field sparring
• The closer the scotoma border is to the fovea,
  the more impaired the reading
• Most reading errors are made by persons with 1-2
  degrees of field sparring
• Rt VFD 67
• Lt VFD 84
• Reading speed is slowed as person is unable to
  use parafoveal vision to assist in guiding
  reading saccades

27
Patient with left homonymous hemianopsia imaged
with a scanning laser ophthalmoscope
Reading performance is influenced by how closely
the border of the scotoma (ds) comes to foveal
fixation Example 1 scotoma border is less that
2 deg from fixation and and influences
reading more than Example 2 where border is
farther away
Fixation
Example 1
Fixation
Example 2
28
Reading DeficitsRight vs.Left VFDZihl J, Eye
Movement Patterns in Hemianopic Dyslexia, Brain,
1995

• LVFD oculomotor changes
• Smaller amplitude of long saccade to left
• Normal subjects 14 degree
• LVFD subjects 9.4 degree
• Increase in number of saccades to left
• Increase in number of repetitions of saccades to
  left

29
How would this oculomotor deficit affect reading
performance?
30
How would this oculomotor deficit affect reading
performance?

• Cause person to skip lines or
• Begin reading in middle of line
• Reduce reading speed
• Poor page navigation
• Decreased comprehension

31

• RVFD oculomotor changes
• Significantly longer fixation durations
• Increased of regressive saccades
• Increased of repetitions in saccades to the
  right
• smaller amplitude of saccades to the right

32
How would this oculomotor change affect reading
performance?
33
How would this oculomotor change affect reading
performance?

• Cause omission of endings of words
• Leading to misidentification or spelling of words
• Poor page navigation
• Significantly reduced reading speed
• And reading comprehension

34
Reading DeficitsRight vs. Left

• Persons with RVFD read 3x more slowly than norms
• Reading saccades are more disorganized
• Persons with LVFD read 2x more slowly than norms
• Greatest difficulty locating beginning of text
  line
• Both groups have particular difficulty with
  numbers
• No context to check accuracy

35
Additional Factors in Reading Performance

• Difficulty using/adapting to bifocal
• Experience blurry vision due to increased eye
  movement
• Often need single lens reading glasses
• Presence of hemi-inattention
• Increases errors especially omissions to left
• Presence of aphasia-language deficit
• Short term memory loss
• Other disruptions in concentration

36
Reduced Eye Hand CoordinationWriting

• Legibility is reduced
• Drift up or down
• on line
• Write on top of
• other words
• Position incorrectly

37
ADL Challenges Caused by VFD

• The daily activities affected are those that
• Depend on vision to complete the task
• Require monitoring of a wide visual field
• Require interaction with a dynamic visual field

38
ADL Challenges(in descending order)

• Driving
• Shopping and community events
• Yard work
• Meal preparation
• Financial management
• Functional communication
• Calendars, telephones, clocks, TV viewing
• Housekeeping
• Selfcare
• Limited problems with grooming, clothing selection

39
Emotional Impact

• Anxiety in crowded or dynamic environments
• Patient described as Crowd-it is
• Unable to process sufficient visual input for
  safety
• CNS sounds alarm through autonomic system
• Person experiences SOB, rapid heart rate,
  sweating, nausea
• Loss of self confidence
• Experiences many many embarrassing mistakes
• Increase in passivity
• Feels more comfortable with others leading
• Social isolation
• Doesnt tolerate change

40
Occupational Therapy Assessment
41
Quantification of the Deficit

• Spontaneous recovery will not occur for most
  patients
• Therefore compensation is the primary approach in
  therapy
• To teach compensatory strategies, must know
  location and extent of the VFD

42
Clinical Observations

• Suggest the presence and location of the deficit
• biVABA clinical observation sheet
• Observations can be made during ADLs
• Compare observations with team members to look
  for consistencies in behavior that suggest
  presence and location

43
Clinical ObservationsFrom Brain Injury Visual
Assessment Battery for Adults

• Observe the client move through crowded areas
  with moving obstacles
• Collides or comes very close to obstacles
  consistently on one side
• Stares straight ahead at the floor immediately in
  front of him/her
• And/or consistently stares to one side
• Stays very close to one side of the wall when
  ambulating down a hallway
• Uses fingers to trail wall to tactually guide
  self
• Refuses to take the lead when ambulating,
  preferring to walk behind others
• Appears anxious or uncertain in crowded areas
• Stops walking when approaching or passing by
  another moving person or objects
• Complains of feeling off balance particularly to
  one side

44
Clinical Observations cont

• Observe pt reading out loud a paragraph of 10
  point print on 8.5-11 paper
• Transforms words by omitting or misreading
  letters on one side of words
• Abbreviates scan to one side of page, omitting
  words on that side
• Uses finger to direct scan across the line of
  print and maintain place on the page
• Consistently loses place on one side of the page
• Hesitates reading a word, or misreads a word
  initially then corrects self reads very slowly

45
Clinical Observations cont

• General observations
• Avoids crowds and crowded environments such as
  shopping centers
• Complains of disorientation when riding in a car
  or wheelchair
• Reads only half of a wide sign or misses signage
  on one side
• Transforms numbers. Example reads an 8 as a
  6or 3
• Displaces handwriting to one side when completing
  a form such as a check
• Handwriting drifts up and down when writing on
  line or addressing an envelope

46

• General Observations continued
• Complains of being unable to follow what is
  happening on TV particularly when viewing
  sporting events or shows with a lot of action
• Makes mistakes dialing a telephone, such as
  pressing a similar but incorrect number
• Scans shelves or counters very slowly to find
  items and often is unable to locate an item
• Has become very particular that items be returned
  to a specific location following use and becomes
  upset with others who leave items out or return
  them to a different location

47
Standardized Assessments

• Ideal Automated perimetry or evaluation by an
  ophthalmologist or optometrist
• Challenges
• Limited access
• Patient may not have physical or attentional
  capability for assessment
• Reality Must rely on combination of standardized
  clinical assessments and observation

48
AAO Red Dot Confrontation Test

• Test Materials
• Basic Visual Function Assessment form
• Targets (2 red dots placed on 2 tongue
  depressors-one dot on each side of one end of the
  stick)
• Occluder (eye patch)
• Test Environment
• Well lighted room, light source behind pt
• Free from visual, auditory and physical
  distractions

49

• Procedure
• Pt is seated with eyeglasses OFF
• EX sits directly across and 1 meter from pt
• To test right eye
• Occlude pts left eye
• Instruct pt to focus on EX left eye
• EX closes right eye to ensure he/she has same
  visual field experience as pt
• EX present both targets simultaneously to pt, in
  location A, then B, then C, then D
• Targets must be held 20 inches from client to
  enable both targets to be seen in the unimpaired
  field
• If targets are held too close to the pt, the pts
  nose may occlude one of the targets causing an
  invalid test
• If you cannot see both targets, the pt will not
  be able to see both targets
• Note whether pt sees both targets
• If pt sees both targets, ask whether the 2 dots
  are equally bright

50
AAO Red Dot Confrontation Test
51
Position A level with top of forehead
directly above outside edge of
shoulder Position B Level with Adams apple at
the outside edge of the shoulders Position
C Level with forehead, adjacent to temples of
face Position D Level with Adams
apple, adjacent to the jaw line of
face Position E (hold targets horizontally) one
target level with brow line other target level
with chin
Target Locations
Occluded eye
Occluded eye
52
Scoring
Scoring Key target seen - target not
seen D target seen but color is diminished


-
-
D
D


-
-
Scoring indicates presence of left hemianopsia in
the left eye
53
Kinetic Two Person Confrontation Test

• Test materials
• Basic Visual Function Assessment form
• Patch occluder
• Penlight
• Interesting target, large enough to be seen at 1
  meter distance without eyeglasses
• Environment
• Dim illumination to enhance visibility of
  penlight illumination must be sufficient for EX
  to view patients eye for movement during
  fixation. Room should be free from distractions

54
Test Procedure

• The patient is seated comfortably with eyeglasses
  off
• One EX sits directly across and approximately 1
  meter
• from the patient. Other EX holds the penlight
  and stands
• behind the patient.

55
Test Procedure cont

• Occlude one eye
• Instruct patient to fixate on the target held by
  the front EX. (EX holds target at patients eye
  level)
• As patient fixates on target, rear EX brings
  lighted penlight from behind the patient to the
  front moving slowly in an arc
• The patient is instructed to indicate as soon as
  the penlight is seen
• Front EX observes patients eye during the exam
  to ensure patient does not look for the penlight
• Rear EX notes location that patient sees the
  penlight and records it on the form

56
Scoring
X
Horizontal Plane (3 and 9 oclock positions) EX
indicates location on arc X where patient first
notices penlight
Occluded eye
Occluded eye
X
Vertical Plane (12 and 6 oclock positions) EX
indicates location on arc X where patient first
notices penlight
X
X
X
X
Patient with left homonymous hemianopsia
