CCSDS IWS CNES 2230 October 2001 Archive Ingest Methodology Study

1
CCSDS IWS CNES22-30 October 2001Archive
Ingest Methodology Study
Nestor Peccia
2
ESOC Ingest Methodology Study

• GC Proposal submitted under LET - SME
• (Leading Edge Technologies for Small and Medium
  Enterprise)
• on Archive Ingestion Methodology
• Two Phases (100 Keuro each)
• Phase 1 includes the feasibility analysis, design
  and initial demonstration via prototype of the
  archival ingestion process
• Phase 2 shall permit, from Phase 1 results, to
  implement, test and validate the procedures and
  software tools that support the ingest process.
  Interoperability between archives shall be
  demonstrated.
• Proposal is under evaluation

3
ESOC Ingest Methodology Study

• First Proposal
• It has an initial study phase, which will
  include
• Describing a methodology for an OAIS archive
  ingest process
• Identifying and selecting resources (procedures,
  standards, tools) required to support the archive
  ingest process
• Producing an initial Archive Design for the
  elements of an OAIS archive required to support
  the ingest process
• On the basis of selected standards and design,
  specify in details the steps to be carried out
  between the producer and the archive by refining
  the ingest process protocol, including the
  definition of a standardised formalism to specify
  the SIPs and to perform the actual delivery
• Prototyping of the ingest process
• A second phase would consist of building upon the
  results of the initial phase, and cover
• Refining the Archive Design
• Implementation, test and validation of the
  procedures and software tools that support the
  ingest process.
• Demonstration of interoperability between ESA
  different types of archives (space science, earth
  observation, micro-gravity, etc).

4
First Proposal on Ingest Methodology

• Ingest Process Methodology
• Resource identification
• Reviewing available standards required to support
  the representations of both the AIPs and the SIPs
• The standard Data Description Languages (EAST,
  DEDSL, XML, etc.) and their applicability to the
  representation of the Information Packets.
• The standards for Metadata representations, such
  as METS, IMS, MPEG21, DIDL, etc.
• Reviewing of tools available to help to control,
  conduct and monitor the various steps of the
  ingest process
• Selection of a set of representation standards,
  and identification of tools that can support the
  various steps of the ingest process in the
  specific case of an ESA archive.

5
First Proposal on Ingest Methodology

• Archive Design
• Reviewing existing archive standards
• Designing data objects, representation
  information and preservation description
  information
• Packaging data objects into data sets and
  collections
• Determining storage media, designing volumes and
  volume sets
• Designing the data production process
• Planning for data validation
• Developing high level descriptive information for
  the archive catalogue.
• An initial Archive Design will be required as
  part of the study work, in order to specify the
  components of the OAIS archive that are required
  to support the ingest process.

6
First Proposal on Ingest Methodology

• Ingest Process Refinement
• At this stage the detailed procedures required to
  support the ingest process will be defined on the
  basis of the archive design and of the selected
  standards and tools. A standardised formalism to
  specify the SIPs and to perform the actual
  delivery will be defined.
• Prototyping
• A prototype will be developed, which will
  demonstrate the concept by applying the ingest
  methodology to the ingestion of ESA mission data.

7
First Proposal on Ingest Methodology

• Structure of the Study
• Consolidation Phase a preliminary analysis
  phase, aiming at specifying the various
  components required to implement the ingestion
  methodology, and assessing the feasibility of the
  definition of an ingestion methodology within
  ESA.
• Prototype Development Phase building upon the
  results of the Consolidation Phase, a prototype
  will be developed that demonstrates the
  applicability of the concepts in the framework of
  archiving of mission data.
• Installation Presentation Phase the final
  phase will cover the installation and
  demonstration of the prototype, together with the
  production of the study report and the final
  presentation of the study results to ESA.

8
Second Proposal on Ingest Methodology

• Scope
• It proposes to study the positive impact that XML
  and emerging related technologies such as SOAP
  and UDDI can bring to the definition of the
  central archive concept, and to provide a simple
  prototype to demonstrate our results. The
  principle interest area of the study is the
  ingestion process i.e. the method by which data
  and metadata can be contributed to the central
  archive function.

9
Second Proposal on Ingest Methodology

• Proposal
• Examine the success of XML and related
  technologies in parallel data warehousing and
  data mining projects outside the Space industry,
  such as in the world of finance and the
  pharmaceutical industry.
• Examine the current state of the art of XML and
  related technologies, through assessment of
  progress made by such important players in the
  market as Microsoft and IBM.
• Establish pertinent standards or subset of
  standards that match best the needs of the
  ingestion process.
• Define an overview process for resolving the
  interface between generic projects and the
  central archive.
• Design, and implement a simple prototype to
  demonstrate the ingestion process concept.

10
Second Proposal on Ingest Methodology

• The Innovation
• The scope of the study we foresee is to
  investigate the suitability of XML, SOAP and UDDI
  to enable the provision of a suitable front end
  to an archive, which would allow the ingestion of
  metadata from a variety of sources. In addition
  to the ingestion of metadata, the question of
  physically including data in the central archive
  would also be addressed, taking into account the
  need to update the delivered metadata to reflect
  the actual physical location of the data. A small
  proof-of-concept prototype would be developed
  utilising the technologies discussed above to
  demonstrate the feasibility of concept.

11
Second Proposal on Ingest Methodology

• Technical Approach (four phases )
• An study of the current state of XML and related
  technologies, including SOAP and UDDI, including
  examination of existing standards available for
  use in real developments. The study will look at
  how the current technology can be applied to the
  specific problem of defining a front-end
  interface to the central archive concept.
• The specification of requirements and data to be
  used in the generation of a software prototype
  which can demonstrate the applicability of the
  studied technologies in the resolution of the
  front-end interface to the central archive
  concept.
• The detailed design and implementation of the
  prototype according to the requirements specified
  in the preceding phase. The testing of the
  prototype in readiness for demonstration.
• Concluding the project by summarising the
  findings and test results into appropriate
  documentation, and the presentation of the
  results to ESA.

12
Second Proposal on Ingest Methodology

• Comparison with the state of the art
• Vodafone UK
• The millions of calls carried each day on the
  network generate a massive volume of data
  relating to the transaction details of each call
  made. The data is of immediate value as the basis
  for billing and managing the network
  infrastructure. The retention of this information
  is not only necessary for legal reasons, but
  essential to good customer service. Vodafone had
  identified that this call data storage and data
  enquiry system was a strategic initiative for the
  group.
• 20 billion records
• 5Tb database size
• 52 million files a day
• 9Tb raw disk storage
• 9Tb tape storage
• High availability

13
Second Proposal on Ingest Methodology

• Comparison with the state of the art
• XMM SOC at Vilspa
• The system is installed at the VILSPA ground
  station near Madrid. It is responsible for
  archiving images from the X-Ray Multi-Mirror
  telescope for later retrieval and processing. The
  data repository employed a Sun Enterprise 3500
  server with 3Gb Ram as an AMS server with a
  storage system comprising a Sun StorEdge A3500
  running an AMS Disk Array containing 22 x 18Gb
  Drives. Alongside this were two L3500 AMS tape
  Libraries. The system had to have high
  operational resilience to collate the data as it
  came from the satellite payload. The RDBMS in the
  system is Oracle.
• However, in both of the above examples the data
  ingestion process is somewhat static and
  predefined i.e. data in very specific formats is
  expected. The aim of this new ingestion process
  is to vastly improve the flexibility with such
  archives i.e. allowing data in many different
  forms to be ingested.

14
3rd Proposal XOAIS Prototype Architecture
15
3rd Proposal XOAIS Prototype Architecture

• Ingestion. Ingest functions include receiving
  SIPs, performing Validation on SIPs, generating
  an Archival Information Package (AIP) which
  complies with the archives data formatting and
  documentation standards. A data conversor module
  is introduced in order to extract such
  information. The Data Conversor shall produce
  such information in the Long Term Preservation
  Space Markup Language, that has been defined in
  the previous phase. Descriptive Information from
  the AIPs (Metadata) are produce for inclusion in
  the archive database.In the same way, the
  ingestion process is based on the definition of a
  Meta-data system. This shall be based on a tree
  structure, a hierarchical model with root,
  branches and leaves elements. This step is
  the definition of the elements of the language in
  order to define the metadata using the XML
  Schema.
• Archive. This entity provides the services and
  functions for the storage, maintenance and
  retrieval of the Object Data and the Metadata.
• Access. This entity supports Consumers in
  determining the existence, description, location
  and availability of information stored in the
  OAIS and allowing consumers to request and
  receive information products.
• HMI. Based on Tcl/Tk, a shareware scripting
  language that may easy the integration of the
  other different modules in a straightforward way.
