North American and California IPv6 Task Force MetroNet6 Project

1
North American and California IPv6 Task Force
MetroNet6 Project

• Presented by Peter Kirstein for Jim Bound
  (Jim.Bound_at_ipv6forum.com)
• CTO, IPv6 Forum www.ipv6forum.com
• Chair North American IPv6 Task Force
  www.nav6tf.org
• HP Senior Fellow

2
Overview

• MetroNet6 A Wireless MESH Network to support
  First Responders (the bottom line).
• Project Deployment Analysis and View
• Summary
• Acknowledgments

3
MetroNet6 Evolution

• Essential first idea and vision developed by
  principals from NAv6TF www.nav6tf.org Jim Bound
  and Larry Levine (also Director CEDREC FT
  Monmouth U.S. Army) in 2001 after 911 as means to
  use IPv6 to enhance First Responder
  communications for RFI New York City Mass Transit
  Network, supported by the IPv6 Forum
  www.ipv6forum.com
• Idea was presented to U.S. Congress by NAv6TF in
  2003, but was unable to achieve wide support.
• California IPv6 Task Force (CAv6TF)
  www.cav6tf.org took ownership of the project and
  enhanced technical work in 2005 led by Geof
  Lambert and George Usi and a team of volunteer
  Subject Matter Experts (SMEs) within the NAv6TF
  and CAv6TF.
• NAv6TF Moonv6 www.moonv6.org project U.S. wide
  network was added to the design center to emulate
  First Responder command control network 2006.
• NAv6TF and CAv6TF began working with U.S. and
  California Government, and local Sacramento First
  Responder contacts and officially started the
  current MetroNet6 in 2005.
• Please see current CAv6TF MetroNet6 Web Page
• http//www.cav6tf.org/html/metronet6.html

4
What is MetroNet6?

• MetroNet6 is a proposal to develop a prototype
  end-to-end secure Wireless MESH network for first
  responders and across their metropolitan area of
  operations emergency support infrastructure,
  using IEEE 802.11.x, IEEE 802.16x, Satellite
  Communications and the Internet Protocol, Suite
  support IPv6 and Mobile IPv6 to provide security,
  discovery, connectivity, legacy support, and
  end-to-end interoperability, supporting an
  Emergency Management Network (EMN)
• Communications within specific first responder
  networks.
• Communications between multiple first responder
  independent networks.
• Communications within area of operations
  Metropolitan EMN Internet Network command
  control.
• Communications between Metropolitan EMN Internet
  Network city-to-city-command control.
• Communications between Metropolitan EMN Internet
  Network state-to-state-command control.

5
Who are the stakeholders?

• Federal Government Home Land Security supporting
  EMN Internet Network.
• State Government supporting EMN Internet Network.
• Regional Government supporting EMN Internet
  Network.
• First Responders
• Police
• Fire Department
• EMS Rescue
• Hospitals and Doctors
• State National Guard
• Other crisis management support infrastructure
  (ie Dept of Forestry)
• Other law enforcement agencies

6
What is a Wireless 802.11x Infrastructure Network?
Access Point Network
Discussion IEEE 802.11 Network advantages,
current state of the art, security, and future
directions.
7
What is a Wireless Cellular or IEEE 802.16 WIMAX
network?
Discussion 3G-4G Cellular and IEEE 802.16
Network advantages, similarities, current state
of the art, security, and future directions.
8
What is a Wireless Satcom net?
Supports multiple forms of communications to end
nodes via wireless or broadband.
9
What is a Wireless Ad Hoc network?

• Self organizing, healing, adaptive.
• Base Station is within the node for waveform
  communications
• Neighbors can only hear next hop neighbors.
• Topology maps must be maintained by each node.
• Node must be a router and a host.
• Various routing protocols defined known as
  MANET.
• New proposals to use Node Discovery from IPv6
  for topology sharing between nodes.
• To access an external network one node must be
  a gateway.

Wireless Link Media
10
What is a MESH Wireless Ad Hoc network?

• Self organizing, healing, and adaptive sub Ad
  Hoc Networks connected to a Base Station.
• Base Station supports multiple network link
  medias (e.g. WIMAX, Cellular, Satcom Ground
  Station, access to Broadband).
• Base Station can be extended via line of sight
  or Satcom.
• Neighbors access all neighbors through the Base
  Station and other Ad Hoc Networks through routing
  topology.
• Base Stations can be replicated for High
  Availability.
• Access to an external network can be learned
  from routing advertisements.
• Benefits of IEEE Infrastructure and Ad Hoc Mode.
• All networks may be seamless mobile where IP
  location is changing relative to the entire MESH
  network.

11
Wireless MESH Ad Hoc Network Technical Summary

• A Wireless MESH ad hoc Network is a set of
  connected ad hoc and fixed network locations that
  are connected in a MESH topology where the
  backbone for communications is done predominantly
  over a Wireless link media waveform, and can be
  managed to be dynamic so it can contract and
  expand as required. The key difference is that
  all of the ad hoc and fixed networks are viewed
  and connected as one MESH IP network autonomous
  system, thus can support a set of network
  infrastructure services across the MESH topology.

12
Wireless MESH Network Architecture Layers As
Hastily Formed Network (HFN)

• HFN IP Network Communications Backbone (core),
  and interface to any existing network
  infrastructure.
• HFN IP Subnets
• HFN IP and Waveform Gateways to the HFN IP
  Subnets and Backbone
• HFN Users and Radio Nets

Fireman
HFN IP Subnets
Police
Coast Guard
HFN IP Network Comm Backbone Network Satcom,
WIMAX, Cellular (HFN Command Control Center)
National Guard
911 Stations
EMS Vehicles
HFN Network Utility Information Services
Civilian Agencies
Doctors and Hospitals
Federal Agencies
Shelters
13
Wireless MESH Ad Hoc Network Base Industry
Technology Enablers

• Next Generation Networks
• All IP Convergence
• Fixed to Seamless Mobile Networking Convergence
• IPv6 Transition, Mobile IPv6, IPsec End-to-End
• Wireless WAN Backbone Proliferation
• Sensor Networks
• Net Centricity
• Network Services view not a platform view
• Principles Connectivity, Interoperability,
  Security, Discovery, and End-to-End
  communications.

14
Wireless MESH IT Network Services Infrastructure
Subscriber, Policy, AAA, IPsec, DNS, and Security
Services
Local Mobility Manager Server, Router, IPsec,
and AAA, supporting IPv6
Satcom and WIMAX
Regional Mobility Access Manager Server, Router
Voice, Video, and Gaming Services, Mobile
Correspondent Nodes
IPv6 Access Router
Internet Core/Edge
Cell Base Stations
Other Provider Services
Server Content and Gateway Services
802.11 APs
Mobile Nodes, Sensors, and Ad Hoc Networks
Internet Protocol Control Plane
Layer 2 Control Plane Signals
15
General MetroNet6 Network Architecture
16
Communications between multiple first responder
independent networks
17
Communications within area of operations
Metropolitan EMN Internet Network command control
18
Communications between metropolitan EMN Internet
Network city-to-city-command control
Sacramento, CA NAv6TF Moonv6 www.moonv6.org
Peering Site
Metropolitan City 1 Internet Area of Operations
Metropolitan city-to-city EMN Gateway Network
Palo Alto, CA NAv6TF Moonv6 www.moonv6.org
Peering Site
Metropolitan City 2 Internet Area of Operations
19
Communications between Metropolitan EMN Internet
Network state-to-state-command control
20
MetroNet6 Proposal Initial Outline Criteria

• Previous slides define high-level use cases and
  network topology design center.
• Internet Protocol Layer would use IPv6 as
  dominant for End-2-End node communications and
  routing protocol (all nodes capable of IPv4 and
  IPv6)
• Security will be critical and IPsec should be
  used as first order of defense, but other ambient
  security methods will be required within
  MetroNet6.
• Link Layer would use IEEE 802.1x protocols
• Seamless Network Mobility would use Mobile IPv6
  and enhancements as defined in IETF Network
  Mobility group (NEMO).
• But, first responders must be able to operate
  without NEMO infrastructure too.
• NAv6TF Moonv6 backbone would be used for
  inter-city and inter-state network
  communications.
• First responder specific networks would have to
  define and select a Mobile Ad Hoc Networking
  routing protocol, with support from CAv6TF and
  NAv6TF networking Subject Matter Experts (SMEs).
• Various Internet Networks would need to be
  defined and designed, with support from CAv6TF
  and NAv6TF networking SMEs.
• IPv6 Transition mechanisms will be required to
  interoperate with legacy operations and
  applications that have not moved to IPv6, with
  support from CAv6TF and NAv6TF networking SMEs.
• Wireless and broadband networking infrastructure
  would have to be defined and determined to
  support MetroNet6 various network topologies,
  with support from NAv6TF Moonv6 SMEs.
• Secure transmissions and authentication of users.

21
MetroNet6 Wireless MESH Network Properties
Overview

• Network is usually wireless.
• Network is not permanent.
• Network must be self-forming and self-healing.
• Access to services from External Internet Network
  may be direct or through an Access or Gateway
  network.
• Access Network and Internet Network may also be
  mobile.
• Greatest connectivity and interoperability
  achieved with the Internet Protocol suite for
  networking layers, and to support seamless
  routing.
• Network must be able to hear broad wireless
  router advertisements beacons (e.g. Geocast,
  Anycast)

• Each node on the network may be a router.
• Each node on the network will usually be powered
  by batteries.
• The link environment the nodes operate can be
  affected by local interference and terrain.
• Each node on the network will often communicate
  over a radio network infrastructure.
• The radio network infrastructure must
  interoperate with the Internet Protocol Suite for
  maximum open systEMN connectivity and
  interoperability.
• Using IEEE 802.1x provides open link media
  standard and off-the-shelf commercial devices,
  and evolution towards Next Generation Networks.

22
Project Management (PMI)

• Objective Statement
• Plan, fund, develop, build, and test a
  convergent and Internet-Protocol-interoperable
  Metropolitan wire line and wire less pilot
  Network, (MetroNet6 SACRAMENTO testbed) for First
  Responders with standards for voice, video,
  graphics, workflow intelligence, cellular, and
  other forms of data communications under a
  24x7x365 availability criteria and 24-hour Return
  to Operation control limit with a budget of
  800,000 and 10,000 staff hours by September 30,
  2007.
• Deliverables
• Open standards outlining IP (TCP/IP)
  interoperability for first responders
• IPv6/IPv4 IP-based connectivity cloud with a
  24-hour Real-Time-Ops plan
• Wireless MESH network, supporting Mobile Ad Hoc
  Networks with a real-time-recovery plan.
• First responder IP-based interoperability IP
  platform for county-to-county, state-to-state,
  and state-to-federal standards designed by
  Internet pioneers.
• Cellular and convergent IP communications in a
  mobile/portable form factor for first responders
  and disaster victims.
• Rugged and mobile computing device standards with
  multimedia functions and possible IPv6 expansion
  capabilities

23
Collaborative Projects California OES

• California Office of Emergency Services Research
• OES currently working on ERMN (Emergency Response
  Management Network)
• OASIS project Statewide Satellite System
• RIMS Response Information Management System
• ERMN Emergency Response Management Network
• MetroNet6 layer being considered here

24
Resource Requirements

• Integration of technologies by enabling
  technology vendors.
• Schedule is set for project with RFI for all
  three layers of design soon to be released.
• Human Resources will be regional, national, and
  global. Sacramento based resources , CISSPs,
  CISMs, and Stakeholders.
• MoonV6 will provide backbone include Calfornia
  IPv6 Task Force SMEs, backbone engineerstransit
  of IPv6 traffic
• Project Ramp Estimation 800K (readiness
  assessments and expenses) for 2007 Capital
  Operational Expenditures
• To complete pilot Sacramento to Palo Alto,
  (assumes no outside assistance or adoption)
  estimated 3 million
• Enabling Technology Providers will provide core
  networking equipment some donation offers
  already flowing in from SMEs and manufacturers.

25
MetroNet6 Initial Deployment Model
26
Summary

• End-2-End interoperability in three layers
• Core Network
• Mobile Network
• Applications E2E
• MetroNet6 completion date targeted for December
  2008
• Project Pilot in Sacramento California managed by
  CAv6TF.

27
Acknowledgements

• George Usi NAv6TF and CAv6TF SME and MetroNet6
  Project Leader.
• Geof Lambert NAv6TF Vice Chair, Chair NAv6TF,
  and Director MetroNet6
• Yanick Pouffary IPv6 Forum Fellow, and NAv6TF
  Technology Director
• Larry Levine Original Co-Designer and NAv6TF
  Steering Committee Advisor
• The many NAv6TF and CAv6TF volunteer SMEs that
  participated in many meetings and architecture
  discussions.
• U.S. Federal, State, and Local Government persons
  that have taken the time to listen to the
  MetroNet6 vision.
