Bluetooth The Universal Radio Interface for Ad
hoc, Short-Range Connectivity

• CIS 642
• Maria Adamou

2
Overview

• Introduction
• Bluetooth Air Interface
• Architecture
• Connection Establishment
• Piconets and Scatternets
• Power Management
• Security
• Competing technologies
• Issues facing Bluetooth

3
Introduction

• In February 1998 five major telecom and PC
  companies Ericsson, Nokia, IBM, Toshiba, and
  Intel- formed a Special Interest Group (SIG) to
  create a standard radio interface for short-range
  connectivity between electronic devices
• The radio interface was named Bluetooth after a
  Danish Viking king Harald Bluetooth who united
  Denmark and Norway during 10th century
• This group was further expanded in December 1999
  with 3Com, Lucent, Microsoft and Motorola
• Today more than 2000 companies have joined as
  adopters of the Bluetooth technology

4
What is Bluetooth

• Bluetooth is a universal standard radio interface
  for short-distance, point-to-multipoint voice and
  data transfer between portable devices
• Its nominal link range is from 10 cm to 10 meters
  but can be extended to 100 meters by increasing
  the transmission power
• Printers, desktops, fax machines, cellular phones
  and virtually any other digital device can be
  part of the Bluetooth system and form ad hoc
  groupings that replace cables

5
Goals

• The system must operate globally
• The system must support peer connectivity,
  connections are made on an ad hoc basis
• The connection must support voice and data
• Ability to withstand interference from other
  sources
• The radio transceiver must be small and operate
  at low power, to fit into small, portable
  devices, such as mobile phones, headsets, PDAs
  etc
• Low cost, short-range

6
User Scenarios

• 3-in-1 phone At home, portable phone (fixed line
  charge), when on the move, mobile phone (cellular
  charge), and when your phone comes within range
  of another mobile phone a walkie-talkie (no
  telephony charge)
• Ultimate Headset Connect your wireless headset
  to your mobile phone, mobile computer or any
  wired connection
• Interactive Conference in meetings and
  conferences
• Automatic Synchronizer Automatic synchronization
  of your desktop, PDA, notebook and your mobile
  phone.
• Internet Bridge use of a mobile telephone or
  cordless modem device that provides modem
  services to a PC, to enable cordless access for
  dial-up networking services.
• LAN access use of a device that acts as a LAN
  access point (LAP) providing Bluetooth access
  services to one or more data terminals.
• many others...

7
Definitions

• Piconet a collection of (up to eight) devices
  connected via Bluetooth technology in an ad hoc
  fashion. Each piconet is identified by a
  different frequency hopping sequence and all
  hosts on the same piconet are synchronized
• Scatternet two or more independent and
  non-synchronized piconets that communicate with
  each other
• Master unit the device in a piconet whose clock
  and hopping sequence are used to synchronize all
  other devices in the piconet
• Slave units all devices in a piconet that are
  not the master (up to 7 active units for each
  master)

8
Bluetooth Air Interface

• License-free, globally available frequency band
  Industrial-Scientific-Medical (ISM) band, at 2.45
  GHz in most countries in the world
• Frequency-hopping (FH) spread spectrum to better
  support low-cost, low-power radio implementations
  with maximum immunity to interference
• Channels use a Frequency-Hopping/ Time Division
  Duplex (TDD) scheme the channel is divided into
  slots of 625ms giving 1600hops/sec and subsequent
  slots are alternately used for transmitting and
  receiving (TDD)
• One packet can be transmitted per slot
• The channel makes use of 79 equally spaced 1-MHz
  channels (from 2,402 MHz to 2,480 MHz), frequency
  shift keying (FSK) modulation
• 1 Mb/s transmission/reception rate
• 2 power levels 0dBm for 10 meters or 20dBm (100
  meters)

9
Packet Definition
0 - 2745 bits
54 bits
72 bits
Access code
Packet Header
Payload
3
4
1
1
1
8
ARQN
TYPE
FLOW
SEQN
HEC
M_ADDR

• 72-bit access code unique for the channel, used
  for packet identification and synchronization,
  derived from the master
• Header 3-bit slave address, packet type, flow
  control bits, ARQ bit, sequence number,
  Header-Error-Check fields
• Payload 0-2745 bits
• Multislot packets have been defined a packet may
  cover one, three or five slots, sent on a single
  hop channel

10
Links supported

• Two types of links to support multimedia
  applications
• Synchronous Connection-Oriented (SCO) link
• Asynchronous Connectionless Link (ACL)
• SCO links support symmetrical, circuit-switched
  point-to-point connections typically used for
  voice
• Reservation is carried out by the master and the
  slave
• ACL links support packet-switched
  point-to-multipoint connection typically used for
  bursty data transmission
• Master units use a polling scheme to control ACL
  connections a master-to-slave packet or a POLL
  packet poll the slave. Collisions are avoided.
• All SCO and ACL traffic is scheduled by the master

11
Architecture
12
RF and Baseband

• Controls the units synchronization and
  transmission frequency hopping sequence,
  compresses and puts data into packets, assigning
  identifiers etc
• The two link types SCO and ACL are also managed
  by this layer
• Takes care of retransmissions and transmission
  error detection and recovery

13
HCI

• Provides a uniform interface method for accessing
  the Bluetooth hardware capabilities
• It contains a command interface to the Baseband
  controller and link manager and access to the
  hardware status

14
Link Manager Protocol (LMP)

• Responsible for
• Connection set-up
• Generation, exchange and control of link and
  encryption keys for Authentication and Encryption
• Link mode negotiation and set-up, e.g. data or
  data/voice
• Sending and receiving of data
• Management of power modes, power consumption and
  state of a unit

15
Logical Link Control and Adaptation Protocol
(L2CAP)

• L2CAP is an interface between upper layer
  protocols and baseband and operates in parallel
  to LMP
• Multiplexing L2CAP must support protocol
  multiplexing, since a number of protocols (e.g.
  SDP, RFCOMM and TCS Binary) can operate over
  L2CAP.
• Segmentation and Reassembly Data packets
  exceeding the Maximum Transmission Unit, MTU,
  must be segmented before being transmitted. This
  and the reverse functionality, reassemble, is
  performed by L2CAP.
• Quality of Service The establishment of an L2CAP
  connection allows the exchange of information
  regarding current Quality of Service for the
  connection between the two Bluetooth units

16
Service Discovery Protocol (SDP)

• Defines how a Bluetooth client's application
  shall act to discover available Bluetooth
  servers' services (like printing, file transfer,
  synchronization) and their Bluetooth
  characteristics.
• Defines how a client can search for a service
  based on specific attributes without the client
  knowing anything of the available services.
• Provides means for the discovery of new services
  becoming available when the client enters an area
  where a Bluetooth server is operating.
• Provides functionality for detecting when a
  service is no longer available

17
Other protocols

• RFCOMM - Cable replacement protocol emulates
  serial port to cover applications that use serial
  ports of the kind used in PCs and provides
  transport capabilities for upper level services
• Telephony Control Protocols
• TCS BIN defines the call control signaling for
  the establishment and release of calls between
  units
• TCS AT Commands transmitting control signals for
  telephony control
• Adopted protocols
• PPP
• TCP/UDP/IPThe TCP/UDP/IP standards are defined to
  operate in Bluetooth units allowing them to
  communicate with other units connected, for
  instance, to the Internet.

• WAP

18
Connection Establishment

• When units are not connected they are in STANDBY
  mode, where they listen to 32 unique (for each
  unit) wake-up channels, for page or inquiry
  messages, for about 10ms each
• Wake-up interval ranges between 0 to 3.84s
  (usually 1.28s)
• A unit enters the PAGE or INQUIRY state in which
  it broadcasts page or inquiry messages
• If the paging unit knows the identity of the unit
  to which it wants to connect, it knows the
  wake-up sequence and transmits the units access
  code every 1.25ms to 16 different hop frequencies
  defined for the slave unit (total 10ms period)
• If the pager does not know the identity of the
  unit, it broadcasts an inquiry message according
  to a common inquiry sequence, every 0 to 2.56s

19
Connection Establishment
20
Piconets and Scatternets

• Two or more Bluetooth units that share a FH
  channel form a piconet. At most 1 master and 7
  slaves can be in one piconet
• Any unit can become a master, but by definition
  the paging unit that establishes the piconet is
  the master
• The master identity and clock specify the channel
  parameters
• All devices in a piconet are synchronized to the
  same FH sequence
• Up to 10 piconets can co-exist with overlapping
  coverage areas and form a scatternet
• A unit can be a master in one piconet and a slave
  in another, or slave in several piconets

21
Power Management

• Frequency-hopping mechanism provides
  synchronization between master-slaves therefore
  no dummy packets have to be exchaged
• A receiver can quickly decide whether a packet is
  present or not, by the access code and the header
  and sleep for the rest of the slot
• Power-save modes
• HOLD mode, where no communication is possible for
  a specified hold time
• SNIFF mode, where the slave listens only to some
  slots (depends on the application)
• PARK mode, where the slave listens to the
  masters beacon at large intervals to
  re-synchronize, does not have a MAC address and
  does not participate in the traffic

22
Modes of operation
23
Security

• As radio signals can be easily intercepted,
  Bluetooth devices have built-in security to
  prevent eavesdropping or falsifying the origin of
  messages (spoofing)
• The main security features are
• a challenge-response routine for authentication
• stream cipher for encryption
• session key generation session keys can be
  exchanged during a connection

24
Competing Technologies

• Infrared Data Association (IrDA) vs Bluetooth
• IEEE 802.11b vs Bluetooth

25
IrDA vs Bluetooth

• Wireless Standard
• IrDA already proven standard (50 million units)
• Bluetooth still in development
• Data Transfers
• IrDA up to 4Mbps 16Mbps( under development)
• Bluetooth 1Mbps(max) 721Kbps(average)
• Range
• IrDA 3 feet
• Bluetooth - 30 feet (or more)
• Line of Sight
• Required for IrDA, can be advantage in crowded
  situations
• Not required for Bluetooth (penetrates walls)
• Cost of Implementation
• IrDA - Currently 2
• Bluetooth- Initially 20

26
IEEE 802.11b vs Bluetooth
27
IEEE 802.1b vs Bluetooth

• The 802.15.2 task group deals with Co-existence
  and interoperability between Bluetooth and
  802.11b
• Bluetooth offers ubiquity and low price
• Both technologies can co-exist reasonably well
  Bluetooth will function as an aid to a
  larger-scale network

28
Issues facing Bluetooth

• Implementation Issues
• Cost
• Interoperability
• Performance

29
Future of Bluetooth

• Conservative estimates foresee several hundred
  million Bluetooth-enabled devices in the next
  five years
• By 2004, 75 of all mobile devices will support
  Bluetooth
• Communications companies will no longer have to
  build external cables and PC cards to enable
  their wireless phones and network cards to
  interface with computers
• Bluetooth will provide the "glue" for the merger
  of wireless and computers.

30
References
