A very difficult case of diabetes

1
A very difficult case of diabetes

• Dr Vincent Connolly

2
8 Years Old

• 2y bumping into objects
• 3y retinal pigmentation optic atrophy combined
  retinal receptor dystrophy
• gt 97th centile for weight
• 3rd centile for height
• Normal intellect
• 4y progressive hearing difficulty sensori-motor
  hearing loss
• 6y bilateral hearing aids
• Investigation of short stature/obesity/small
  genitalia
• ITT max GH 3mu/l

• Height 120cm, weight 37.8 kg
• BMI 26.25 kg/m2
• Pituitary tests normal
• GTT normal
• Triglycerides raised
• GH low
• Linear growth, advanced bone age
• Raised AST
• Visual acuity L 1/60 R 1/60

3
Insulin Resistance

• 9y totally blind
• 13y investigations
• Fasting insulin 85mu/l
• Stimulated insulin gt 700mu/l
• Profoundly insulin resistant

• 14y delayed secondary sexual characteristics
• Hypogonadal / micro penis / Hypoplastic scrotum
• Small testes / pubic hair normal
• Elevated gonadotrophins, testosterone 8 nmol/l

4
Polydipsia, polyuria

• Diabetes mellitus RBG 18mmol/l
• Weight 71.8 kg BMI 32.8
• Diet alone
• Oral agents
• Modest weight reduction
• Hba1c normal range, HBGM 5-11

5
What type of diabetes is this?

• Type 1
• Type 2
• Secondary
• MODY
• Diabetes associated with another diagnosis

6
Relevant Genetic Syndromes Associated With
Diabetes

• Diabetes-deafness syndrome mtDNA
• Maternally transmitted NIDDM deafness
• MELAS mtDNA
• (N)IDDM, myopathy, encephalopathy, lactic
  acidosis, stroke-like episodes
• Alstroms -
• NIDDM, retinopathy, deafness, obesity. GH def
• LMB 11, 16, 4
• IGT, retinopathy, mental retardation, obesity,
  polydactyly

7
Relevant Genetic Syndromes Associated With
Diabetes

• Leprechaunism 19
• NIDDM, IUGR, dysmorphic features
• Rabson-Mendenhall 19
• (N)IDDM, acanthosis nigricans, pineal hyperplasia
• Kearns-Sayre mtDNA
• NIDDM, ophthalmoplegia, retinal deg,
  cardiomyopathy
• Larsens -
• Cone dystrophy, endocrine dysfunction, abnormal
  LFTs, obesity, NIDDM, hypogonadism

8
Teenage Years

• Genetics Mitochondrial DNA - NAD
• LFTs AST 131, GGT 417
• Lipids cholesterol 7.2 mmol/l Triglycerides
  6.1mmol/l
• Diabetes hba1c 10.9
• Hyperinsulinaemic isoglycaemic clamp
• Ave insulin conc 115mu/l
• M value 48mg/m2/min (obese diabetics 80)

9

• Hypogonadism
• LH 40.4iu/l, FSH 53.0 IU/l
• Testosterone 7.4nmol/l
• Bones
• Hip, BMD reduced gt2sdmean
• Intellect
• University, European studies
• Family history
• Mothers name fathers name
• Maternal great aunt blind aged 14

10
24y Current Situation

• Blind- combined receptor defect
• Deaf- bilateral sensori-neural
• Diabetes- insulin resistance
• Obesity- BMI 32.8kg/m2
• Primary Hypogonadism
• Abnormal liver function
• Growth hormone deficiency

11
What is the optimal diabetes treatment plan ?

• Metformin alone
• Acarbose
• Metformin Sulphonylurea
• Insulin /- Metformin
• Thiazoledinedione

12
Diabetes Management

• Stepwise increase in standard therapy
• Hba1c 11
• Insulin metformin combination
• Hba1c 8.9
• Introduction of Rosiglitazone, phasing out of
  insulin
• Hba1c 7

13
Change in HbA1c
Metformin
Insulin Metformin
Rosiglitazone Metformin
Metformin
Insulin Metformin
Rosiglitazone Metformin
14
Change in BMI
Rosiglitazone Metformin
Insulin Metformin
Metformin
Rosiglitazone Metformin
Insulin Metformin
Metformin
15
Mode of action of Thiazolidinediones
Insulin resistance
16
Mode of action of Thiazolidinediones

• Thiazolidinediones act as insulin sensitisers by
  promoting the uptake of triglycerides into
  adipocytes.
• The net effect is to decrease the systemic
  availability of fatty acids.
• Insulin résistance improves as fatty acid uptake
  in muscle is also reduced.
• Thiazolidinediones lower triglycerides and
  increase HDL-cholesterol levels.
• Rosiglitazone is associated with an increase in
  LDL-cholesterol.

17
Common Features of Alstroms

• nystagmus and photodysphoria in early infancy
• Progressive pigmentary retinopathy (cone-rod
  dystrophy) leading to blindness
• Childhood obesity, often moderating to
  high-normal weight in adulthood
• Mild to moderate bilateral sensorineural hearing
  loss
• Congestive heart failure secondary to dilated
  cardiomyopathy in infancy or early adulthood
• Normal extremities / absence of polydactyly or
  syndactyly

• hyperinsulinemia / insulin resistance
• Non-insulin dependent diabetes mellitus (type 2
  diabetes or NIDDM) developing in early adulthood
• Progressive chronic nephropathy that presents as
  tubular dysfunction
• Normal intelligence with some reports of delayed
  early developmental milestones

18
Alstrom Syndrome International
19
Balanced Translocation
20
The Genetics

• The gene was mapped to the 2p13 breakpoint on
  the maternal allele to a genomic fragment of 1.7
  kb
• A novel gene, ALMS1
• The paternal copy of the gene, had a frameshift
  mutation
• 12.9-kb transcript of ALMS1 encodes a protein of
  4,169 amino acids

21
ALMS 1 Gene Expression
22
Problems

• Marked weight gain
• Fluid retention
• Reports of cardiomyopathy associated with
  Alstroms

23
Should the glitazone be continued?

• Continue glitazone
• Stop glitazone

24
Next step

• Novomix 30, 40 units bd
• BG gt 10mmol/l
• HbA1c gt10

25
What future treatment plan would you recommend?

• Continue insulin
• Add metformin
• Add GLP1 analogue (exenatide)
• Add DPP-IV inhibitor (sitagliptin)
• Manage obesity
• Not sure

26
Incretins

• Peptides secreted by the intestinal mucosa in
  response to food intake
• (GLP-1)
• Glucose-dependent insulinotrophic polypeptide
  (GIP)

27
What does GLP mean ?

• Glucose lowering protein
• Glucagon like peptide
• Good looking presenter

28
Incretins and glycaemic control7,8
Bloodglucose control
DPP-4enzyme rapidly degrades incretins
Adapted from 7. Drucker DJ. Cell Metab.
20063153165. 8. Miller S, St Onge EL. Ann
Pharmacother 2006401336-1343.
29
Mode of action of sitagliptin8
Bloodglucose control
Sitagliptin is a DPP-4 inhibitor and inhibits the
breakdown of incretins and thereby increases
active incretin levels
DPP-4enzyme rapidly degrades incretins
DPP-4 dipeptidyl peptidase 4 inhibitor
Adapted from 8. Miller S, St Onge EL. Ann
Pharmacother 2006401336-1343.
30
Physiological effects of incretins

• ? prandial insulin secretion
• ? glucagon secretion
• ? Acid secretion and GI motility (? gastric
  emptying
• ? satiety and ? food intake
• ? ß cell protection
• ? Cardiovascular effects

31
What is this?

• Monitor lizard
• Gila lizard
• Damien Hirst creation

32
Exenatide

• Synthetic equivalent of exendin-4
• Found in the saliva of the Gila monster
• 53 homology with human GLP-1
• Now available in US for treatment of T2D (Byetta,
  Lilly/Amylin)
• Given as bd sc injection
• Licensed as adjunct to MFN, SU or both
• Due for release in UK anytime now

33
Summary of Exenatide data

• 2yr extension of RCTs (open label)
• Sustained effect on glycaemic control
• Further wt loss 2.7kg vs 4.7kg
• Add on to TZDs successful
• Exenatide LAR
• Benefit in islet cell transplants

34
Comparison
35
(No Transcript)
36
Common Surgical Procedures for Weight Loss
DeMaria E. N Engl J Med 20073562176-2183
37
Weight Maintenance after Bariatric Surgery
Sjöström L, Lindroos AK, Peltonen M et al. N
Engl J Med. 200435126
38
Results

• Diabetes remission 73 (surgical) versus 13
  (medical), plt0.001
• Greater percentage of wt loss at two yrs and
  lower baseline A1c values were independently
  associated with remission
• Percentage of weight loss explained most of the
  variance
• 20 (surgical) versus 1.4 (medical), plt0.001

39
Future treatment plan

• Continue insulin
• Add metformin
• Add GLP1 analogue (exenatide)
• Add DPP-IV inhibitor (sitagliptin)
• Manage obesity
• Not sure

40
Trial of exenatide

• Awaiting results!!!

41
Thank you
