EEEGEF 492'lab2intro TDD: Symbol Table using Junit

1
EEE/GEF 492.lab2intro TDD Symbol Table using
Junit Java
Royal Military College of Canada Electrical and
Computer Engineering
Dr. Terry Shepard shepard_at_rmc.ca 613-541-6000
ext. 6031
2
Outline

• Purpose of Lab 2
• TDD Test Driven Development
• an explicit and important part of XP
• Unit Testing Frameworks
• JUnit
• Getting started with Junit

3
Purpose of Lab 2

• Explore the use of TDD, Junit and Java for the
  eventual development of a symbol table component
  for use in a Java debugger
• Use the symtbl work products from Lab 1 as the
  starting point
• Add a type for each symbol
• Add a memory model, contents of memory
• Add ability to print symbol values formatted
  according to their types

4
TDD Test Driven Development

• One of the key practices of eXtreme Programming
  (XP)
• Other key practices include pair programming and
  refactoring
• There is ongoing debate about whether it is
  necessary to use all the practices at once

5
TDD is a Hot Topiceg. article in Sept. 2005
issue of Computer magazine from the IEEE

• Test-Driven Development Concepts, Taxonomy, and
  Future Direction, by David Janzen, Simex LLC and
  Hossein Saiedian, University of Kansas

6
from JUnit in Action
Manning Publications, 2003, by Vincent Massol
and Ted Husted

• Test-driven development (TDD) is a programming
  practice that instructs developers to write new
  code only if an automated test has failed, and to
  eliminate duplication. The goal of TDD is clean
  code that works.

7
From the Agile Alliance

• Test-driven development (TDD) is the craft of
  producing automated tests for production code,
  and using that process to drive design and
  programming. For every tiny bit of functionality
  in the production code, you first develop a test
  that specifies and validates what the code will
  do. You then produce exactly as much code as will
  enable that test to pass. Then you refactor
  (simplify and clarify) both the production code
  and the test code.

8
from Janzen and Saiedian

• As Beck states, XP takes the known best
  practices and turns the knobs all the way up to
  ten. Many developers might have been thinking
  and coding in a test-first manner, but TDD does
  this in an extreme way always writing tests
  before code, making tests as small as possible,
  and never letting code degrade. TDD fits within a
  process model, and the development of
  incremental, iterative, and evolutionary process
  models has been vital to its emergence.

Kent Beck, Aim, Fire, IEEE Software,
Sept./Oct. 2001, pp. 87-89.
9
from Janzen and Saiedian

• Tools have played an important role in the
  emergence of TDD, which assumes the existence of
  an automated unit testing framework. Such a
  framework simplifies both the creation and
  execution of software unit tests. Test harnesses,
  basically automated testing frameworks, provide a
  combination of test drivers, stubs, and
  interfaces to other subsystems. Often such
  harnesses are custom-built, although commercial
  tools do exist to assist with test harness
  preparation.

10
from Janzen and Saiedian

• The proliferation of software tools that support
  TDD shows that it has widespread support and will
  likely become an established approach. JUnits
  simplicity and elegance have been a significant
  factor in TDDs use, particularly in the Java
  community. Programmers can develop unit tests
  easily and execute large test suites with a
  single button click, yielding quick results about
  the systems state.

11
from Janzen and Saiedian

• TDD has yet to achieve widespread acceptance in
  academia, at least partly because faculty who do
  not specialize in software engineering are not
  likely to be familiar with it. TDD instructional
  materials that target undergraduate courses
  remain basically nonexistent.

12
from Janzen and Saiedian
13
from Janzen and Saiedian

The Edwards study used novice programmers
14
from Janzen and Saiedian

• Both industry and academic settings can benefit
  from more research. In particular, academic
  studies need to examine whether TDD improves or
  at least does not hinder learning. Can TDD be
  incorporated into the undergraduate curriculum in
  a way that improves students ability to design
  and test? If so, then TDD must be written into
  appropriate student texts and lab materials.

15
Unit Testing in TDD

• Motto Clean code that works. (Ron Jeffries)
• Unit testing has broader goals that just
  insuring quality
• Improve developers lives (coping, confidence)
• Support design flexibility and change
• Allow iterative development with working code
  early

based on slides from CS494, University of Virginia
16
Unit Testing Benefits

• Developers can work in a predictable way of
  developing code
• Programmers write their own unit tests
• Get rapid response for testing small changes
• Build many highly-cohesive loosely-coupled
  modules to make unit testing easier

based on slides from CS494, University of Virginia
17
Red/Green/Refactor

• The TDD mantra of how to code
• Red write a little test that doesnt work,
  perhaps even doesnt compile
• Green Write code to make the test work quickly
  (perhaps not the best code)
• Refactor Eliminate duplication and other
  problems that you did to just make the test work

based on slides from CS494, University of Virginia
18
What is a framework?

• In software development, a framework is a defined
  support structure in which another software
  project can be organized and developed. A
  framework may include support programs, code
  libraries, a scripting language, or other
  software to help develop and glue together the
  different components of a software project. The
  word "framework" has become a buzzword due to
  recent continuous and unfettered use of the term
  for any generic type of libraries. Sometimes, the
  word framework is used in place of the synonomous
  term, library, for the purpose of impressing
  venture capitalists.

definition from http//en.wikipedia.org/wiki/Frame
work -- note that the examples given do not
include unit testing frameworks
19
Do we call it unit testing?

• many in the Extreme Programming community favor
  the terms "developer testing" or "programmer
  testing" over the term "unit testing," since many
  other test activities (like function or
  acceptance test) can now be done at
  "developer-time."
• from http//en.wikipedia.org/wiki/Unit_test

20
Unit Testing Frameworks (UTFs)

• http//en.wikipedia.org/wiki/List_of_unit_testing_
  frameworks
• http//en.wikipedia.org/wiki/XUnit
• http//opensourcetesting.org/
• Junit http//www.junit.org/index.htm

21
Junit Architecture
voir http//www.progx.org/index.php?sectionarticl
esarticleJava/article14 -- en français for
more details, see http//junit.sourceforge.net/doc
/cookstour/cookstour.htm
22
Getting started in Junit

• Junit.org
• cook book, FAQ, cooks tour
• Lab 3 from eee/gef 321B last winter
• Tutorial www.cs.umanitoba.ca/eclipse/10-JUnit.pd
  f

23
writing Junit tests

• How do I write a simple test?
• Create a subclass of TestCase
• Write a test method
• Write a suite() method
• Write a main() method

based on http//junit.sourceforge.net/doc/faq/faq.
htm
24
1. Create a subclass of TestCase

• package junitfaq
• import java.util.
• import junit.framework.
• public class SimpleTest extends TestCase
  //paren closed on a future slide

based on http//junit.sourceforge.net/doc/faq/faq.
htm
25
2. Write a test method

• Write a test method to assert expected results on
  the object under test
• public void testEmptyCollection()
• Collection collection new ArrayList()
• assertTrue(collection.isEmpty())

based on http//junit.sourceforge.net/doc/faq/faq.
htm
26
3. Write a suite() method

• Write a suite() method that uses reflection to
  dynamically create a test suite containing all
  the testXXX() methods
• public static Test suite()
• return new TestSuite(SimpleTest.class)

based on http//junit.sourceforge.net/doc/faq/faq.
htm
27
4. Write a main() method

• Write a main() method to conveniently run the
  test with the textual test runner
• public static void main(String args)
• junit.textui.TestRunner.run(suite())
• //closing paren from item 1. above

based on http//junit.sourceforge.net/doc/faq/faq.
htm
28
Lab 3 from eee/gef 321B

• http//phillips.rmc.ca/courses/321-2005/labos/lab
  3.html
• http//tarpit.rmc.ca/paul/EEE321B/Lab3/EEE321B_La
  b03.html
• repeat the steps from 321 to make sure you have
  Junit up and working properly
• use the test cases there as a model for getting
  started constructing your test cases for symtbl

29
Today in Lab 2

• Follow one or more of the three Getting Started
  in Junit steps proposed above.
• Create at least one junit test for a java version
  of symtbl, and write enough code to get a green
  bar.
