Unit Testing with JUnit and Clover

1

• Unit Testing with JUnit and Clover

Based on material from Daniel Amyot JUnit Web
site
2
JUnit (http//www.junit.org)

• A unit test framework for Java
• Authors Erich Gamma, Kent Beck
• Part of XUnit family (HTTPUnit, Cactus), CppUnit
• Essential part of the eXtreme Programming
  methodology, but can be used independently
• Used for regression testing as well, but not for
  system testing
• Integrated to Eclipse, but can be used standalone

3
eXtreme Programming (XP) and unit testing

• In XP, a test shall
• Be written first
• before any code
• Executed
• will likely fail!
• Then
• Implementation code should be written that would
  be the minimum code required to get the test to
  pass and no extra functionality.
• Once the code is written, re-execute the test and
  it should pass.
• When needed, refactor the code mercilessly.
• Improve performance, maintainability, readability

4
Common XP day
5
Some benefits of JUnit (and Test-Driven
Development)

• Testing is a Good Thing
• Immediate gratification with build iterations
• Start with The Simplest Thing That Could
  Possibly Work.
• Green bar addiction!
• Break the cycle of more pressure means fewer
  tests
• Whenever you are tempted to type something into a
  print statement or a debugger expression, write
  it as a test instead.
• Martin Fowler
• Reduce code captivity
• If others can test it, others can work on it.

6
What is a JUnit test?

• A test script is just a collection of small
  Java methods.
• General idea is to create a few Java objects, do
  something interesting with them, and then
  determine if the objects have the correct
  properties.
• What is added? Assertions!
• A package of methods that checks various
  properties
• equality of variables
• identity of objects
• The assertions are used to determine the test
  case verdict.

7
A JUnit test case

• / Test of copy method, class
  ProblemBase.Value /
• public void testCopy()
• System.out.println("testCopy")
• Value v1 new Value( )
• v1.setName( "X" )
• Value v2 v1.copy( )
• v1.setName( "Y" )
• String expected "X"
• String actual v2.getName( )
• Assert.assertEquals( expected, actual )

8
A JUnit test case

• / Test of copy method, class
  ProblemBase.Value /
• public void testCopy()
• System.out.println("testCopy")
• Value v1 new Value( )
• v1.setName( "X" )
• Value v2 v1.copy( )
• v1.setName( "Y" )
• String expected "X"
• String actual v2.getName( )
• Assert.assertEquals( expected, actual )

Method signature no parameters
9
A JUnit test case

• / Test of copy method, class
  ProblemBase.Value /
• public void testCopy()
• System.out.println("testCopy")
• Value v1 new Value( )
• v1.setName( "X" )
• Value v2 v1.copy( )
• v1.setName( "Y" )
• String expected "X"
• String actual v2.getName( )
• Assert.assertEquals( expected, actual )

Objective create a duplicate object, instead of
copying reference
10
A JUnit test case

• / Test of copy method, class
  ProblemBase.Value /
• public void testCopy()
• System.out.println("testCopy")
• Value v1 new Value( )
• v1.setName( "X" )
• Value v2 v1.copy( )
• v1.setName( "Y" )
• String expected "X"
• String actual v2.getName( )
• Assert.assertEquals( expected, actual )

Check for a condition that should not be violated
11
A JUnit test class

• import junit.framework.
• // Each test class must extend the Junit
• // TestCase class
• public class CopyTest extends TestCase
• // Must provide a constructor with String
• // argument
• public CopyTest(String name)
• super(name)
• // Insert your test cases here. setup(),
• // tearDown() and main() methods can also be
• // added.

12
Assertions and verdicts

• Assertions are defined in the special JUnit class
  Assert
• If the assertions are true, the method continues
  executing.
• If any assertion is false, the method stops
  executing, and the result for the test case will
  be fail.
• If any other exception is thrown during the
  method, the result for the test case will be
  error.
• If no assertions were violated for the entire
  method, the test case will pass.
• The Assert class name is often not required
• assertEquals( expected, actual )

13
Assertion methods

• Assertion methods can verify
• Objects are identical, or not identical
• Objects are null or non-null
• Equality of objects
• via or equals() depending on type
• Boolean conditions are true or false
• There is also an unconditional failure method.

14
JUnit execution (with failures)
15
JUnit execution (success!)
16
JUnit plugin for Eclipse
17
JUnit framework
TestResult
fTests
Your tests here.
18
Some benefits of this framework

• No major difference between a test case and a
  test suite
• Both can be invoked using the run() method
• Test cases are often associated with methods, and
  test suites with classes
• Uses reflection to lean about classes and methods
• Test suite structure discovered at run time
• Test suites can invoke the test cases
  automatically
• Common setup and teardown (clean up) for all test
  cases in a test suite
• Default ones can be overriden
• Integrated to Uis, and wizard for test creations
• Simple, efficient, and automated!

19
Java code coverage tool Clover

• Discovers sections of code that are not being
  adequately exercised by your (unit) tests.
• Supports method, statement, and branch coverage
• Reports its findings in multiple formats
• From project level down to individual lines of
  source code
• Historical charting of code coverage and other
  metrics
• Integrated to Eclipse and other IDEs
• http//www.thecortex.net/clover/index.html

20
Clover plugin for Eclipse
21
Clover coverage filters

• One can choose not to instrument certain types of
  blocks in the code (e.g. assertions and exception
  catching), in order to focus on the coverage of
  interest.

22
Clover plugin caveats

• This plugin may (very likely!) not work correctly
  if you have configured your Eclipse project so
  that the Java source and output directories are
  the same.
• Use different directories for the original source
  code and instrumented source code
• When compiling your Java project with the Clover
  plugin, you must add and use a Java Development
  Kit (JDK) to your list of Installed JRE locations
  (see instructions).
• Not free software

23
Fixing the Clover plugin caveats
24
For more information

• JUnit Web site
• http//junit.org
• Documentation on installation and use of JUnit
• E. Gamma, K. Beck, JUnit Cookbook
• http//junit.sourceforge.net/doc/cookbook/cookbook
  .htm
• Internals of JUnit
• JUnit A Cooks Tour
• http//junit.sourceforge.net/doc/cookstour/cooksto
  ur.htm
• Clover Eclipse Plugin (with installation
  instructions)
• http//www.thecortex.net/clover/userguide/eclipse/
