Activation Records

1
Activation Records

• CS 671
• February 7, 2008

2
The Compiler So Far

• Lexical analysis
• Detects inputs with illegal tokens
• Syntactic analysis
• Detects inputs with ill-formed parse trees
• Semantic analysis
• Tries to catch all remaining errors

3
Goals of a Semantic Analyzer

• Find remaining errors that would make program
  invalid
• undefined variables, types
• type errors that can be caught statically
• Figure out useful information for later phases
• types of all expressions
• data layout
• Terminology
• Static checks done by the compiler
• Dynamic checks done at run time

4
Scoping

• The scope rules of a language
• Determine which declaration of a named object
  corresponds to each use of the object
• C and Java use static scoping
• Mapping from uses to declarations at compile time
• Lisp, APL, and Snobol use dynamic scoping
• Mapping from uses to declarations at run time

5
Symbol Tables

• Purpose
• keep track of names declared in the program
• Symbol table entry
• associates a name with a set of attributes
• kind of name (variable, class, field, method, )
• type (int, float, )
• nesting level
• mem location (where will it be found at runtime)

6
An Implementation

• Symbol table can consist of
• a hash table for all names, and
• a stack to keep track of scope

y
\
x
\
y
x
7
Type Systems

• A languages type system specifies which
  operations are valid for which types
• A set of values
• A set of operations allowed on those values
• The goal of type checking is to ensure that
  operations are used with the correct types
• Enforces intended interpretation of values
• Type inference is the process of filling in
  missing type information

8
Intermediate Code Generation

• Source code

lexical errors
Lexical Analysis
tokens
syntax errors
Syntactic Analysis
AST
semantic errors
Semantic Analysis
AST
Intermediate Code Gen
IR
9
Run time vs. Compile time

• The compiler must generate code to handle issues
  that arise at run time
• Representation of various data types
• Procedure linkage
• Storage organization
• Big issue 1 Allow separate compilation
• Without it we can't build large systems
• Saves compile time
• Saves development time
• We must establish conventions on memory layout,
  calling sequences, procedure entries and exits,
  interfaces, etc.

10
Activation Records

• A procedure is a control abstraction
• it associates a name with a chunk of code
• that piece of code is regarded in terms of its
  purpose and not of its implementation
• A procedure creates its own name space
• It can declare local variables
• Local declarations may hide non-local ones
• Local names cannot be seen from outside

11
Control Abstraction

• Procedures must have a well defined call
  mechanism
• In many languages
• a call creates an instance (activation) of the
  procedure
• on exit, control returns to the call site, to the
  point right after the call.
• Use a call graph to see set of potential calls

12
Handling Control Abstractions

• Generated code must be able to
• preserve current state
• save variables that cannot be saved in registers
• save specific register values
• establish procedure environment on entry
• map actual to formal parameters
• create storage for locals
• restore previous state on exit

13
Local Variables

• Functions have local variables
• created upon entry
• Several invocations may exist
• Each invocation has an instantiation
• Local variables are (often) destroyed upon
  function exit
• Happens in a LIFO manner
• What else operates in a LIFO manner?

14
Stack

• Last In, First Out (LIFO) data structure

stack
main () a(0)
Stack grows down
void a (int m) b(1)
void b (int n) c(2)
void c (int o) d(3)
void d (int p)
15
Stack Frames

• Basic operations push, pop
• Happens too frequently!
• Local variables can be pushed/popped in large
  batches (on function entry/exit)
• Instead, use a big array with a stack pointer
• Garbage beyond the end of the sp
• A frame pointer indicates the start (for this
  procedure)

16
Stack Frames

• Activation record or stack frame stores
• local vars
• parameters
• return address
• temporaries
• (etc)
• (Frame size not known until
• late in the compilation process)

Arg n Arg 2 Arg 1 Static link
previous frame
fp
Local vars Ret address Temporaries Saved regs Arg
m Arg 1 Static link
current frame
sp
next frame
17
The Frame Pointer

• Keeps track of the bottom of the current
  activation record
• g()
• f(a1,,an)
• g is the caller
• f is the callee
• What if f calls two functions?

Arg n Arg 2 Arg 1 Static link
gs frame
fp
Local vars Ret address Temporaries Saved regs Arg
m Arg 1 Static link
fs frame
sp
next frame
18
Stacks

• Work languages with nested functions
• Functions declared inside other functions
• Inner functions can use outer functions local
  vars
• Doesnt happen in C
• Does happen in Pascal
• Work with languages that support function
  pointers
• ML, Scheme have higher-order functions
• nested functions AND
• functions as returnable values
• (ML, Scheme cannot use stacks for local vars!)

19
Handling Nested Procedures

• Some languages allow nested procedures
• Example

proc A() proc B () call C()
proc C() proc D()
proc E() call B()
call E() call
D() call B()
call sequence
A
B
Can B call C? Can B call D? Can B call E? Can E
access C's locals? Can C access B's locals?
C
D
E
B
20
Handling Nested Procedures

• In order to implement the "closest nested scope"
  rule we need access to the frame of the lexically
  enclosing procedure
• Solution static links
• Reference to the frame of the lexically enclosing
  procedure
• Static chains of such links are created.
• How do we use them to access non-locals?
• The compiler knows the scope s of a variable
• The compiler knows the current scope t
• Follow s-t links

21
Handling Nested Procedures

• Setting the links
• if callee is nested directly within caller
• set its static link to point to the caller's
  frame pointer
• proc A()
• proc B()
• if callee has the same nesting level as the
  caller
• set its static link to point to wherever the
  caller's static link points
• proc A()
• proc B()

22
Activation Records

• Handling nested procedures
• We must keep a static link (vs. dynamic link)
• Registers vs. memory
• Registers are faster. Why?

Cycles?
ld ebx, 0fp ld ecx, 4fp add eax,ebx,ecx
add eax,ebx,ecx
23
Registers

• Depending on the architecture, may have more or
  fewer registers (typically 32)
• Always faster to use registers
• (remember the memory hierarchy)
• Want to keep local variables in registers
• (when possible why cant we decide now?)

24
Caller-save vs. Callee-save Registers

• What if f wants to use a reg? Who must
  save/restore that register?
• g()
• f(a1,,an)
• If g saves before call, restores after call
  ?caller-save
• If f saves before using a reg, restores after
  ?callee-save
• What are the tradeoffs?

Arg n Arg 2 Arg 1 Static link
gs frame
fp
Local vars Ret address Temporaries Saved regs Arg
m Arg 1 Static link
fs frame
sp
next frame
25
Caller-save vs. Callee-save Registers

• Usually some registers are marked caller save
  and some are marked callee save
• e.g. MIPS r16-23 callee save
• all others caller save
• Optimization if g knows it will not need a
  value after a call, it may put it in a
  caller-save register, but not save it
• Deciding on the register will be the task of the
  register allocator (still a hot research area).

26
Parameter Passing

• By value
• actual parameter is copied
• By reference
• address of actual parameter is stored
• By value-result
• call by value, AND
• the values of the formal parameters are copied
  back into the actual parameters
• Typical Convention
• Usually 4 parameters placed in registers
• Rest on stack
• Why?

27
Parameter Passing

• We often put 4/6 parameters in registers
• What happens when we call another function?
• Leaf procedures dont call other procedures
• Non-leaf procedures may have dead variables
• Interprocedural register allocation
• Register windows

r32
r33
r34
r35
r32
1
1
1
r33
r34
r35
r32
r33
r34
r35
r32
A()
B()
C()
Outgoing args of A become incoming args to B
28
Return Address

• Return address - after f calls g, we must know
  where to return
• Old machines return address always pushed on
  the stack
• Newer machines return address is placed in a
  special register (often called the link register
  lr) automatically during the call instruction
• Non-leaf procedures must save lr on the stack
• Sidenote Itanium has 8 branch registers

29
Stack Maintenance

• Calling sequence
• code executed by the caller before and after a
  call
• code executed by the callee at the beginning
• code executed by the callee at the end

30
Stack Maintenance

• A typical calling sequence
• Caller assembles arguments and transfers control
• evaluate arguments
• place arguments in stack frame and/or registers
• save caller-saved registers
• save return address
• jump to callee's first instruction

31
Stack Maintenance

• A typical calling sequence
• Callee saves info on entry
• allocate memory for stack frame, update stack
  pointer
• save callee-saved registers
• save old frame pointer
• update frame pointer
• Callee executes

32
Stack Maintenance

• A typical calling sequence
• Callee restores info on exit and returns control
• place return value in appropriate location
• restore callee-saved registers
• restore frame pointer
• pop the stack frame
• jump to return address
• Caller restores info
• restore caller-saved registers

33
Handling Variable Storage

• Static allocation
• object is allocated an address at compile time
• location is retained during execution
• Stack allocation
• objects are allocated in LIFO order
• Heap allocation
• objects may be allocated and deallocated at any
  time.

34
Review Normal C Memory Management

• A programs address space contains 4 regions
• stack local variables, grows downward
• heap space requested for pointers via malloc()
  resizes dynamically, grows upward
• static data variables declared outside main,
  does not grow or shrink
• code loaded when program starts, does not change

FFFF FFFFhex
stack
heap
static data
code
0hex
35
Intel x86 C Memory Management

• A C programs x86 address space
• heap space requested for pointers via malloc()
  resizes dynamically, grows upward
• static data variables declared outside main,
  does not grow or shrink
• code loaded when program starts, does not change
• stack local variables, grows downward

heap
static data
code
stack
36
Static Allocation

• Objects that are allocated statically include
• globals
• explicitly declared static variables
• instructions
• string literals
• compiler-generated tables used during run time

37
Stack Allocation

• Follows stack model for procedure activation
• What can we determine at compile time?
• We cannot determine the address of the stack
  frame
• But we can determine the size of the stack frame
  and the offsets of various objects within a frame

38
Heap Allocation

• Used for dynamically allocated/resized objects
• Managed by special algorithms
• General model
• maintain list of free blocks
• allocate block of appropriate size
• handle fragmentation
• handle garbage collection

39
Summary

• Stack frames
• Keep track of run-time data
• Define the interface between procedures
• Both language and architectural features will
  affect the stack frame layout and contents
• Started to see hints of the back-end optimizer,
  register allocator, etc.
• Next week Intermediate Representations
