ITM How to Edit a Data Set

1
ITM How to Edit a Data Set

• Module 4
• Chapter 4 Topic 1, 2, and 3,
• Pages 103 174

2
Objectives

• Basic Edit Operation
• Specify a file or member
• Basic edit commands
• Save edited data
• Edit Profile
• What is it?
• Changing a profile
• Save a profile
• Advanced Edit Commands

3
Topic 1 Basic Edit Operation

• Using the ISPF Text Editor
• Used for PDS members most often
• Also sequential data sets
• Records must be lt 255 bytes
• ISPF reads entire member in VS
• Terminate edit saves changes to disk

4
Starting Edit

• Option 2 on Primary Option Menu
• User provides
• Project
• Group
• Type
• Member
• Can provide a member with a pattern or blank
• Displays a member list
• Place S to select a member name
• See Figure 4-2, Page 107

5
Edit Data Display

• Three distinct areas
• Heading Area
• Line Command Area
• Screen Window

6
Heading Area

• Top two screen lines
• Informative Messages
• Enter commands
• At Kirkwood, it is at the bottom of the screen

7
Line Command Area

• First six columns of lines 3-24
• One line for each source member
• Can enter line commands
• i.e. Deleting and Inserting Lines

8
Screen Window

• Remaining columns after column 6
• Only 72 characters display
• PF10/PF22 to move window left
• PF11/PF23 to move window right
• PF7/PF19 to move window up
• PF8/PF20 to move window down
• Holds source member data
• Change data by
• Overwriting
• Terminal editing keys
• Insert, Delete, Erase E-O-F keys

9
Line Numbers

• AKA, Sequence Numbers
• Two Numbering Formats
• COBOL
• Six digits long
• Numbers stored in first six positions of each
  record
• Standard (STD)
• Eight digits long
• Only last six displayed
• Fixed length records
• Numbers stored in last eight positions
• Variable length records
• Numbers stored in first eight positions

10
Types of Commands in Edit

• Primary Commands
• Entered in Command Input Area
• Generally apply to entire source member
• Line Commands
• Entered in Line Command Area
• Apply to individual lines
• Type over the line numbers

11
Line Command Examples

• Insert Lines
• Delete Lines
• Repeat Lines
• Copy and Move Lines
• Use RENUM to renumber

12
Insert Lines

• I
• Insert a single line following this line
• In
• Insert n lines following this line
• See Figure 4-5, Page 111-112

13
Delete Lines

• D
• Delete this line
• Dn
• Delete n lines starting with this line
• DD
• Delete the block of lines beginning with the
  first DD command and ending with the second DD
  command
• See Figures 4-6 and 4-7, Page 114-115

14
Repeat Lines

• R
• Repeat this line
• Rn
• Repeat this line n times
• RR
• Repeat a block of lines
• RRn
• Repeat a block of line n times
• See Figures 4-8 and 4-9, Page 116-117

15
Copy Lines

• C
• Copy this line
• Cn
• Copy n lines starting with this line
• CC
• Copy a block of lines
• See Figure 4-10, Page 119

16
Move Lines

• M
• Move this line
• Mn
• Move n lines starting with this line
• MM
• Move a block of lines
• See Figure 4-11, Page 120

17
Copy and Move Line Destination

• A
• Copy or move lines after this line
• An
• Repeat the copy or move n times after this line
• B
• Copy or move lines before this line
• Bn
• Repeat the copy or move n times before this line

18
RESET Command

• Used to remove informational messages or error
  messages
• Doesnt affect actual text

19
Create a New Member

• Specify member on Edit Entry Panel
• Creates empty space in VS
• See Figure 4-1, Page 105
• Initially no line numbers or source data
• Figure 4-12, Page 122

20
Terminate Edit

• With saving member
• PF3/15
• Returns to edit entry panel
• PF3/15 again to return to main menu
• SAVE on command input area
• Doesnt end edit
• Without saving member
• CANCEL or CAN on command input area

21
Topic 2 How to Control the Edit Profile

• Edit Profiles control editing options
• Tabs, column boundaries, line numbers
• ISPF maintains separate edit profiles
• Correspond to data set types
• i.e. COBOL profile

22
Display Edit Profile

• Enter PROFILE in command input area
• Lines indicate
• Profile name
• Record format and length
• Various edit mode setting
• Settings saved when edit terminated
• Unless profile locked

23
Controlling Profiles

• Switch or create a profile
• In command input area
• Switch by specifying different profile
• Create by specifying a new profile
• Uses current profile settings
• Lock a Profile
• Any changes only affect current session
• Type PROFILE LOCK in command input area
• Exceptions
• CAPS, NUMBER, PACK, and STATS

24
Four Important Profile Settings

• Tabs
• Boundary Control
• Masking
• Line numbering

25
Tabs - Types

• To cursor to a particular location (tab stop)
• Two Types
• Hardware
• Use 3270s Tab key
• Uses a special control character (attribute byte)
• Takes up one position on the screen
• Displays as blank
• Logical
• Enter a special tab character to set tab stops
• Advances with the ENTER key
• Used at Kirkwood
• See Figure 4-15, Page 129

26
Controlling Tabbing

• Two Commands
• TABS line command
• Defines location of each tab stop
• TABS primary command
• Activates or deactivates tabs

27
Defining and Activating Tab Stops (at Kirkwood)

• With PROFILE open
• Enter COLS in the line command area
• Displays column numbers
• Enter TABS in the line command area
• Set tab stops with a
• Use spacebar for blank areas
• Enter TABS ON primary command
• Activates tabs

28
Boundary Control

• Determines the range of columns in edit
• For COBOL
• Right margin is column 7
• Left margin is column 72
• At Kirkwood
• Dont use Boundary command
• Profile changed to NUM ON STD COB

29
Edit Masking

• Pre-defined line for initial contents inserted
  lines
• Generally blank
• Use MASK line command to change
• Remove a MASK line with the D line command or
  RESET primary command
• Deactivate with MASK line command containing only
  blanks

30
Line Numbering

• AKA, sequence numbers
• Five commands
• NUMBER
• NONUMBER
• AUTONUM
• RENUM
• UNNUM

31
NUMBER and NONUMBER

• Defines how line numbers are stored
• NUMBER ON / OFF STD / COBOL / STD COBOL
• Edit checks if member has valid COBOL and
  STANDARD line numbers
• NUMBER DISPLAY
• Displays generated sequence numbers in data
  window
• NONUMBER
• Turns number mode off

32
AUTONUM

• Controls if a member is/isnt renumbered
  automatically when saved
• Normally off
• AUTONUM ON / OFF

33
RENUM and UNNUM

• RENUM to resequence line numbers
• Starts with 100, then by 100s
• RENUM ON / OFF STD / COBOL / STD COBOL
• Resequences line numbers unless OFF is specified
• RENUM DISPLAY
• UNNUM to remove line numbers
• Blanks replace line numbers
• Turns off NUMBER mode

34
Other Edit Modes

• STATS (Page 138 140)
• Controls automatic maintenance of library
  statistics
• NULLS (Page 140)
• Controls how trailing blanks are handled on the
  3270 screen
• If ON, must use space bar

35
Other Edit Modes (cont.)

• AUTOLIST (Page 141)
• Controls automatic source list printing
• RECOVERY (Page 141)
• Controls automatic journal kept for recovery
  purposes
• UNDO available
• HEX (Page 141 142)
• Controls hexadecimal display

36
Other Edit Modes (cont.)

• CAPS (Page 142)
• Controls automatic conversion of lowercase data
  to uppercase
• Normally OFF for text data
• LC or UC for specific lines
• LCn or UCn for lines starting with the current
  line
• LCLC or UCUC for block of lines beginning with
  the first and ending with the second command

37
Other Edit Modes (cont.)

• PACK (Page 143)
• Controls how data is stored
• Compressed or not
• AUTOSAVE (Page 143 144)
• Controls automatic saving of modifications
• NOTES (Page 144)
• Controls displaying of notes

38
Topic 3 Advanced Edit Options

• IMACRO (Page 144)
• Control the edit macro run at start of an edit
  session
• FIND (See Module 5)
• Find a character string
• CHANGE (See Page 147)
• Find a character string and replace with another
  string

39
CHANGE Command Syntax

• FIND / CHANGE
• string-1
• string-2
• range
• NEXT / PREV / FIRST / LAST / ALL
• CHARS / PREFIX / SUFFIX / WORD
• X / NX
• col-1 col-2

40
CHANGE Parameters

• FIND
• Look for string-1
• CHANGE
• Look for string-1
• If found, replace with string-2
• string-1
• Text string to be found
• Use apostrophes or quotes if contains spaces or
  commas
• Hex string as Xhex-digits
• Text string as Ttext-string
• Picture string as Ppicture-string

41
CHANGE Parameters (cont.)

• string-2
• Replacement for string-1
• In apostrophes or quotes if contains spaces or
  commas
• Hex value as Xhex-digits is only for CHANGE
• Range
• Range of lines identified by two labels
• Default is first and last lines of the file

42
CHANGE Parameters (cont.)

• NEXT
• Starts at current line and locates next
  occurrence of string-1
• The default
• PREV
• Starts at current line and locate the previous
  occurrence of string-1
• Search backwards
• FIRST
• Starts at top and locates first occurrence of
  string-1

43
CHANGE Parameters (cont.)

• LAST
• Starts bottom and locates first occurrence of
  string-1
• Search backwards
• ALL
• Same as FIRST, but indicates count of the
  occurrences of string-1
• CHARS
• Any occurrence of string-1 satisfies the search
• Default

44
CHANGE Parameters (cont.)

• PREFIX
• String-1 must be at the beginning of a word to
  satisfy the search
• SUFFIX
• String-1 must be at the end of a word to satisfy
  the search
• WORD
• String-1 must be surrounded by spaces or special
  characters to satisfy the search

45
CHANGE Parameters (cont.)

• X and NX
• Control the search of excluded lines
• X says to search only excluded lines
• Can use EXCLUDE primary command
• NX says to search only lines not excluded
• If not specified, all lines are searched
• col-1
• Starting column number
• If col-2 not specified, string-1 must begin in
  this column to satisfy the search
• Default is current left boundary

46
CHANGE Parameters (cont.)

• col-2
• Ending column number
• If specified, string-1 must be found between
  col-1 and col-2 to satisfy the search
• Default is current right boundary

47
Excluding and Redisplaying Lines

• X - excludes a single line
• Xn - excludes n lines
• XX - excludes this line and all lines between
  two XX commands
• F - Shows the first line of the excluded text
• Fn - Shows the first n lines
• L - Shows the last line of the excluded text
• Ln - Shows the last n lines
• S - Shows one line of the excluded text
• Sn - Shows n lines

48
EXCLUDE Primary Command

• Locates lines with a specific character and
  excludes the lines from the display
• Command Syntax
• EXCLUDEstring-1range NEXT / PREV / FIRST /
  LAST / ALL CHARS / PREFIX / SUFFIX / WORD
  col-1 col-2

49
EXCLUDE Parameters

• EXCLUDEstring-1range NEXT / PREV / FIRST /
  LAST / ALL CHARS / PREFIX / SUFFIX / WORD
  col-1 col-2

50
EXCLUDE Parameters (cont.)

• string-1
• Text string to be found
• Use apostrophes or quotes if contains spaces or
  commas
• Hex string as Xhex-digits
• Text string as Ttext-string
• Picture string as Ppicture-string
• Range
• Range of lines identified by two labels
• Default is first and last lines of the file

51
EXCLUDE Parameters (cont.)

• NEXT
• Starts at current line and locates next
  occurrence of string-1
• The default
• PREV
• Starts at current line and locate the previous
  occurrence of string-1
• Search backwards
• FIRST
• Starts at top and locates first occurrence of
  string-1

52
EXCLUDE Parameters (cont.)

• LAST
• Starts bottom and locates first occurrence of
  string-1
• Search backwards
• ALL
• Same as FIRST, but indicates count of the
  occurrences of string-1
• CHARS
• Any occurrence of string-1 satisfies the search
• Default

53
EXCLUDE Parameters (cont.)

• PREFIX
• String-1 must be at the beginning of a word to
  satisfy the search
• SUFFIX
• String-1 must be at the end of a word to satisfy
  the search
• WORD
• String-1 must be surrounded by spaces or special
  characters to satisfy the search

54
EXCLUDE Parameters (cont.)

• col-1
• Starting column number
• If col-2 not specified, string-1 must begin in
  this column to satisfy the search
• Default is current left boundary
• col-2
• Ending column number
• If specified, string-1 must be found between
  col-1 and col-2 to satisfy the search
• Default is current right boundary

55
DELETE Primary Command

• Used to delete excluded or non-excluded lines
• Command Syntax
• DELETEALLRANGEX/NX

56
DELETE Parameters

• ALL
• Delete all lines within specified range or are
  excluded or not excluded
• Cant specify ALL by itself
• Range
• Range of lines identified by two labels
• Default is first and last lines of the file

57
DELETE Parameters (cont.)

• X
• Delete only excluded lines
• NX
• Delete only non-excluded lines

58
DELETE Parameters (cont.)

• X
• Delete only excluded lines
• NX
• Delete only non-excluded lines

59
LOCATE Primary Command

• Used to position the display at a known point in
  the file
• Command Syntax
• LOCATE NEXT / PREV / FIRST / LASTCHANGE
  /LABEL / EXCLUDED / ERROR / COMMAND /
  SPECIALRANGE

60
LOCATE Parameters

• NEXT
• Starts at current line and locates next
  occurrence of the specified line type
• PREV
• Starts at current line and locate the previous
  occurrence of the specified line type
• FIRST
• Starts at top and locates first occurrence of
  specified line type

61
LOCATE Parameters (cont.)

• LAST
• Starts bottom and locates first occurrence of
  specified line type
• CHANGE
• Search for line with a change flag (CHGgt) in
  the line command area
• LABEL
• Search for a line with a label

62
LOCATE Parameters (cont.)

• EXCLUDED
• Search for an excluded line
• ERROR
• Search for a line with an error flag (ERRgt) in
  the line command area
• COMMAND
• Search for a line with a pending line command
• Tabs line

63
LOCATE Parameters (cont.)

• SPECIAL
• Search for any of the following special lines
• Bounds lines
• Column identification line
• Information line
• Mask line
• Message line
• Note line
• Profile line
• Range
• Range of lines identified by two labels
• Default is first and last lines of the file

64
Shifting Source Text

• Used to shift the contents of a line or group of
  lines one or more positions to the left or right
• Two types
• Column
• Data moves a specified number of columns left or
  right
• Data shifted beyond margins in lost
• Spaces inserted where needed
• Data
• Non-blank characters not deleted
• Words are not combined
• Spaces with apostrophes are not deleted

65
Data and Column Shift Syntax
66
Working with External Data Sets (Merging and
Segmenting)

• Data sets other than the one youre editing
• Copy or move lines from another data set or
  member
• Copy or move lines
• To another data set or member
• To create another data set or member

67
Related Commands

• COPY member AFTER/BEFORE Label
• Copy member to position marked by an A or B line
  command or the specified label
• MOVE member AFTER/BEFORE Label
• Copy member to the position marked by an A or B
  line command or the specified label
• Delete the member from its original location

68
Related Commands (cont.)

• CREATE member range
• Create member with the range of lines marked by C
  or M commands or the specified labels
• REPLACE member range
• Create member or replace existing member with the
  range of lines marked by C or M commands or the
  specified labels
• If member name omitted
• Panel displays to enter the data set or member

69
Parameters

• AFTER
• Data placed after line that contains the label
  you specify
• BEFORE
• Data placed before line that contains the label
  you specify
• LABEL
• User defined
• To declare
• Scroll file so the line appears top of screen
  window
• Enter a period followed by a one- to
  eight-character label in the command area
• Period is required when defined

70
Recursive Editing

• Done from within current edit session
• EDIT command
• Syntax
• EDIT member
• Alternative to Split Screen

71
Summary

• Basic Edit Operation
• Specify a file or member
• Basic edit commands
• Save edited data
• Edit Profile
• What is it?
• Changing a profile
• Save a profile
• Advanced Edit Commands
