APCON INTELLAPATCHTM Switches

1
APCONINTELLAPATCHTM Switches
INTELLAPATCH Switches
TM
The Leader in Physical Layer Switching
Automation
2
Corporate Headquarters

• Established 1993
• Portland, OR
• Hardware Engineering
• Software Development
• PCB Manufacturing
• Privately held
• 80 Revenue Growth in FY 2003

The Leader in Physical Layer Switching
Automation
3
INTELLAPATCHPhysical Layer Switches

• Layer 1 OEO Switch
• Protocol Independent, Data Rate Specific
• Does not read packets or modify data
• Up to 144 Ports, Non-blocking, Any-to-Any
  connections, Wire-speed
• Point-to-Point (full duplex), Multicast (1 to N),
  and Loop Topologies
• Remote switch management via a LAN (TCP/IP) or
  Serial port

4
INTELLAPATCH Models

• Fiber Optic (LC connectors)
• Multi-Rate
• (100 Mb/s 3.2 Gb/s)
• Fibre Channel (1 Gb/s, 2 Gb/s, 4 Gb/s, 10
  Gb/s)
• Ethernet
• (100 Mb/s, 1 Gb/s, 10 Gb/s)
• SONET OC-3, OC-12, OC-48 (155 Mb/s, 622 Mb/s,
  2.488 Gb/s)
• FDDI

• Copper
• T1/E1/J1 (RJ-48C)
• 10/100/1000 Ethernet (RJ-45)
• Fibre Channel (HSSDC-2)

5
INTELLAPATCH Software Products
// Start of Custom C/C Program include
"ApconAPI.h" include ltstdio.hgt // other part
of programs code /// // program entry point int
_tmain(int argc, TCHAR argv, TCHAR envp)
int nResult, nSwitchHandle, nModel char
szIPAddress "10.1.1.160" // open switch 1
on the IP Address nSwitchHandle
OpenNetSwitch(szIPAddress, 1) if (-1
nSwitchHandle) fprintf(stderr, "Cannot
open switch on s\n", szIPAddress) return 1
nModel GetSwitchModel(nSwitchHandle)
printf("Switch Model d\n",nModel) if (-1
! ConnectSwitchPorts(nSwitchHandle, 1, 16))
printf("Port Change Successful!\n") CloseSwitch(n
SwitchHandle) // more program code /// // End
of custom C/C Program

• Windows GUI Software
• APCON CONTROL Software
• Programming Software Tools
• CmdX Menu mode and command line interface
• ASCII Command Set
• C/C API (Application Programming Interface)
• SNMP
• Agent for Windows NT/2000/XP
• INTELLAZONE Software
• Multi-User Proxy, Security, Zoning Logging

6
Windows Control Software

• Intuitive drag drop, real time switching
• Presets instantly configure testing topologies
• Port naming eliminates cabling confusion
• Password Security LAN/Serial port lockout
• Temperature and power supply alarms

7
INTELLAZONE Software

• Zoning
• Assign users access to zones or specific groups
  of ports
• Switch Proxy
• Allows multiple users to access a single switch
  via TCP/IP or serial port
• Security
• User name and password required for switch
  control
• Read only, Full access, No access
• Logging
• Logs users, switch changes, and commands

8
INTELLAPATCH Sales Markets

• Test Lab Automation
• SAN
• Ethernet
• Telecom/Service Providers
• Military/Government
• Enterprise
• Equipment Sharing
• Security
• Avocent Digital Desktops

9
Test Lab Automation Benefits

• Automate and schedule system test routines
• Decrease testing costs
• Decrease testing time
• Accelerate product time to market
• Increase test repeatability
• Remote access via TCP/IP

Interoperability Compatibility Test Lab
10
Test Lab Applications Reconfiguration

• Reconfiguration of test topologies through
  software
• Wire once, no manual patching
• Electronically move hosts targets, trunking
  tests, move switch blades

11
Test Lab Applications Reconfiguration Sharing
12
Test Lab Applications Cable Breaks/Port Failover

• Electronic simulation of circuit or line failure
• Up to 144 ports simultaneously
• Schedule and script connect/disconnect sequences
• Hard node failover does not continue to
  transmit frame or packet data
• APS or fabric testing

13
Test Lab Applications Analyzer Sharing

• IntellaPatch functions as Electronic Tap
• Electronic sharing of analyzers, probes and
  sniffers
• Schedule and share devices
• Across same test bed
• Different test beds
• Non-intrusive or direct connect

14
Test Lab Applications Analyzer Sharing

• IntellaPatch functions as Electronic Tap
• Electronic sharing of analyzers, probes and
  sniffers
• Schedule and share devices
• Across same test bed
• Different test beds
• Non-intrusive or direct connect

15
Test Lab Applications Mirroring Data to Multiple
Analyzers
16
Test Lab Applications Multicast Traffic
Generators

• Stress routers, switches and networks
• Multicast feature sends Tx port 1 to Rx ports
  2-144
• 1 Return path to analyzer
• Wire speed multicasting
• Reduce traffic generator costs

Multicasting to Multiple Ports
17
Test Lab Applications Media Conversion

• Singlemode to Multimode media conversion
• Fibre channel SM to MM
• Gigabit Ethernet SM to MM
• OC-3 SM to MM
• OC-12 SM to MM
• Optical to Copper media conversion
• Fibre Channel optical to copper
• Gigabit Ethernet optical to copper
• Regenerates signal at full strength
• Zero insertion loss

18
Enterprise Benefits

• Decrease capital equipment costs
• Decrease maintenance costs
• Decrease operational costs
• Increase productivity
• Remote access via TCP/IP

19
Enterprise Applications Equipment Sharing
Switch Sniffers to Different Span Ports
20
Enterprise Applications Equipment Sharing
Share Sniffers Across Buildings
21
Enterprise Applications Multicast Span Ports to
Devices
Replicate Data to Multiple Devices
22
Enterprise ApplicationsIntrusion Detection
Systems

• Amplify tapped signal to IDS
• Mirror traffic to multiple IDS
• Look for different signatures
• Load balancing
• Hard network shutdown from IDS threats

23
Enterprise ApplicationsSecurity/Access Control

• Physical level security
• Electronically unplug network connections
• Disconnect individual workstations network
  printers
• Presets control access to entire floors,
  departments or buildings
• Military bases, government facilities, secure LANs

24
Enterprise ApplicationsAvocent Cstation

• Software allows electronic moves, adds, changes
  within seconds
• No wiring or infrastructure changes required
• Increase security
• Limit access to individual or groups of Cstations

• Data cannot flow through ports turned off
• Remote software management via TCP/IP
• Direct physical access to workstations is not
  needed

25
Enterprise ApplicationsAvocent Cstation

• Cold spare protection
• 1N or multiple protection configurations
• Spare switching within seconds
• IntellaPatch connects Cstations to centralized
  workstations
• Remote software management via TCP/IP
• Direct physical access to workstations is not
  needed

26
Enterprise Applications Media Conversion
Amplification

• Optical to Copper media conversion
• Gigabit Ethernet optical to copper
• Fibre Channel optical to copper
• Singlemode to Multimode media conversion
• Fibre channel SM to MM
• Gigabit Ethernet SM to MM
• OC-3 SM to MM
• OC-12 SM to MM
• Regenerates signal at full strength
• Zero insertion loss

27
Who Uses INTELLAPATCH?
