1
SCP A System Call Protector against Buffer
Overflow Attacks

• dove
• ???

2
Outline

• Introduction
• Attacking Method
• Related Work
• SCP System Design
• Experimental Result
• Conclusion
• Future Work

3
Introduction (1)

• Buffer Overflow Attack
• Easily launched
• Huge amount of targets
• Strongly damage
• The most dangerous threat in the internet

4
Introduction (2)

• Many countermeasures were publishedBut also were
  defeated
• Developing an efficient and effective approach
  becomes a critical and emergent issue

5
Attacking Method (1)

• Stack Overflow Attack
• Overflow the return address to launch injected
  code (shell code)

6
Attacking Method (2)

• Return-into-libc Attack
• Overwrite the return address to execute
  system() function call

High Address
/bin/sh
Pointer to system()s arg
Fake RA
ESP
system()
EIP (RA)
EBP
buffer
Low Address
AAA address to system() system()s return address pointer to system()s arg
String format
7
Attacking Method (3)

• Heap Overflow Attack
• Similar to stack overflow, but on the heap area

8
Attacking Method (4)

• Scanning Code Attack
• After overflow, scan the process image to find
• patterns and then jump into it
• Usually used to bypass some protections

9
Related Work (1)

• Some Countermeasures
• StackGuard / StackShield
• Address Obfuscation
• Exec Shield
• Binary Obfuscation
• PointGuard
• Instruction Set Randomization
• RAD

10
Related Work (2)

• StackGuard -- add canary word before return
  address
• StackShield --copy return address to confirm when
  return
• Bypassing StackGuard and StackShield

Low Address
11
Related Work (3)

• Address Obfuscation
• PaX ASLR project
• - Randomize the base address of memory regions
• -- Randomize the base address of stack/heap
• -- Randomize the starting address of
  dynamic-linked
• libraries
• -- Randomize the locations of routines and static
  data
• ASLP
• Internal fragmentation problem
• Derandomization Attack

12
Related Work (4)

• Bound Checking
• Bound Checking for C
• Require source code / recompile
• Runtime overhead are huge
• - 4x / 5x when best case
• - 10x general case
• - 100x worst case

13
Related Work (5)

• Exec Shield
• Data/Stack section non-executable
• Code section non-writable
• Compatibility problem
• - ELF file format
• -- Add PT_GNU_STACK and PT_GNU_HEAP
• - Nested function
• - Recompile / porting
• - sigreturn() system call
• Return into libc attack can be launched

14
Related Work (6)

• Binary Obfuscation
• Change ELF layout (add new section)
• Add new system call to notify the return address
• Insert junk code in binary object
• Attacker may use the new system call
• Return into libc attack / scanning code attack
  can be launched

15
Related Work (7)

• PointGuard
• Encrypt pointer, decrypt when reference object

16
Related Work (8)

• Instruction Set Randomization
• Hardware solution, encrypt / decrypt CPU
  instructions
• porting binaries

17
Related Work (9)

• RAD
• Return Address Defender
• Compiler solution
• Push return address to RAR when prologue
• Pop return address from RAR when eprologue
• Need recompile

18
SCP System Design (1)

• Principles
• Prevent attacker from executing int 80 offered by
  attacker
• Prevent attacker from executing int 80 existed in
  system
• Goal
• Low overhead
• Efficient to protect
• Do not require source code
• Compatibility
• Use less system resource
• Easy to maintain

19
SCP System Design (2)

• Assumptions
• Malicious code have to use system call to damage
  system
• vulnerable program is dynamic linked

20
SCP System Design (3)

• System overview
• protect int 0x80s return address
• Use secure enter kernel instead of all sysenter

  (int 0x80)

movl sys, eax movl arg1, ebx int 0x80
21
SCP System Design (4)

• The system call path

22
SCP System Design (5)

• The system call path

High Address
( kernel ) sys_open()
Kernel Space
5. return
4. trap into kernel
( libc wrapper routine ) __libc_open()
User Space
3. call wrapper routine
( GOT entry ) Address of __libc_open
2. lookup GOT
6. return
( PLT ) jmp GOT__libc_open
1. go to PLT
( user program ) open()
Low Address
23
SCP System Design (6)

• Pseudo Code

(b) Trap Code
(a) Secure Enter Kernel
save_all_registers page 0 size 0 if ( page
0 ) page mmap2() size
copy_trap_code(page) notify_kernel(size6)
restore_all_registers call page
restore_sys_in_eax int 0x80
(sysenter) return_to_libc machine
code \x8B\x44\x24\x04 \xCD\x80 \x83\xC4\x08 \xC3
24
SCP System Design (7)

• New system call path (with SCP system)

High Address
( kernel ) sys_open()
6. return
Kernel Space
sys_read()
5. trap into kernel
( libc wrapper routine ) __libc_open()
( trap page ) int 0x80
4. call trap page
User Space
__libc_read()
7. return
3. call wrapper routine
( GOT entry ) Address of __libc_open
Address of __libc_read
2. lookup GOT
8. return
( PLT ) jmp GOT__libc_open
jmp GOT__libc_read
1. go to PLT
( user program ) open()
read()
Low Address
25
SCP System Design (8)

• Example with SCP system (lazy binding)

Glibc printf() here
4. Call printf()
6. Normal system call
5. Notify kernel the RA
3. Load libc.so.6
kernel
Loader (ld-linux.so.2)
1. Notify kernel the RA
Inject code
2. Loading program
program
26
SCP System Design (9)

• Example with SCP system (lazy binding)

Glibc printf() here
4. Call printf()
6. Normal system call
5. Notify kernel the RA
3. Load libc.so.6
kernel
Loader (ld-linux.so.2)
1. Notify kernel the RA
Inject code
2. Loading program
program
27
SCP System Design (10)

• Modify kernel
• Add new system call notify_kernel()
• - It can only be called 2 times per process
• Add new structures in task_struct to restore
  addresses
• - loader_return_address
• - syscall_return_address
• do_fork()
• - Addresses copied from parent process
• sys_execve()
• - loader_return_address 0
• - syscall_return_address 0

28
SCP System Design (11)

• Introduce fake pages

29
SCP System Design (12)

• Attack analysis
• Attacker can launch scanning code attack to trace
  real int 0x80
• Possible solution
• - Non-readable but executable code segment
• - future work

30
SCP System Design (13)

• SCP system analysis
• Allow executable stack - General debugger
  support
• - Nested function
• - Do not require ELF modified
• - Do not require to recompile
• Allow execute programs without ASLR
• - No internal fragment problem
• - Process crashes are decided by process owners
• - Easy to maintain

31
Experimental Result (1)

• Efficiency test
• Buffer overflow attack with injected code

32
Experimental Result (2)

• Efficiency test
• Calling notify_kernel test

33
Experimental Result (3)

• Micro test
• 10,000,000 times per system call

System Call Original libc Kernel (usec) Secure libc Secure Kernel (usec) Increment
mmap 4.83598861 5.04285570 4.28
open 5.70100183 12.31045995 115.93
read 4.44757121 4.65731530 4.72
write 28.61905470 28.86815789 0.87
34
Experimental Result (4)

• Original libc kernel

execve("./micro-test.open", "./micro-test.open",
/ 29 vars /) 0 time seconds
usecs/call calls errors syscall ------
----------- ----------- --------- ---------
---------------- 49.40 828.885786 41
20000000 gettimeofday 25.81
432.1044308 43 10000003 1 open
24.59 411.1630811 41 10000002
close 0.04 0.700248 700248 1
brk 0.04 0.700211 700211
1 mprotect 0.04 0.700202
700202 1 read 0.02
0.402909 201455 2 write
0.02 0.400418 200209 2
munmap 0.01 0.201221 33537 6
old_mmap 0.01 0.100622 33541
3 fstat64 ------ -----------
----------- --------- ---------
---------------- 100.00 1677.766736
40000021 1 total
35
avg timediff 0.000007321626584231853457525318606
9687672 sec 7.32162658 usec Command exited with
non-zero status 81 Command being timed
"./micro-test.open" User time (seconds)
0.69 System time (seconds) 122.31
Percent of CPU this job got 100
Elapsed (wall clock) time (hmmss or mss)
203.00 Average shared text size
(kbytes) 0 Average unshared data size
(kbytes) 0 Average stack size (kbytes)
0 Average total size (kbytes) 0
Maximum resident set size (kbytes) 0
Average resident set size (kbytes) 0
Major (requiring I/O) page faults 82
Minor (reclaiming a frame) page faults 7
Voluntary context switches 0 Involuntary
context switches 0 Swaps 0 File
system inputs 0 File system outputs 0
Socket messages sent 0 Socket
messages received 0 Signals delivered
0 Page size (bytes) 4096 Exit
status 81
36
Experimental Result (5)

• Modified libc kernel

execve("./micro-test.open", "./micro-test.open",
/ 29 vars /) 0 time seconds
usecs/call calls errors syscall ------
----------- ----------- --------- ---------
---------------- 47.44 821.1515639 41
20000000 gettimeofday 28.54
494.834607 49 10000003 1 open
23.82 412.936479 41 10000002
close 0.04 0.700382 700382 1
read 0.04 0.700380 700380
1 brk 0.02 0.403299 201650
2 write 0.02 0.400813
200407 2 mmap2 0.02
0.400782 200391 2 munmap
0.02 0.400761 200381 2
utimes 0.01 0.202308 33718 6
old_mmap 0.01 0.101257 33752
3 mprotect 0.01 0.101186
33729 3 fstat64 ------
----------- ----------- --------- ---------
---------------- 100.00 1733.697893
40000027 1 total
37
avg timediff 0.000012353462404431775006701486885
3298992 sec 12.35346240 usec Command exited
with non-zero status 82 Command being
timed "./micro-test.open" User time
(seconds) 0.68 System time (seconds)
173.26 Percent of CPU this job got 99
Elapsed (wall clock) time (hmmss or
mss) 253.94 Average shared text size
(kbytes) 0 Average unshared data size
(kbytes) 0 Average stack size (kbytes)
0 Average total size (kbytes) 0
Maximum resident set size (kbytes) 0
Average resident set size (kbytes) 0
Major (requiring I/O) page faults 104
Minor (reclaiming a frame) page faults 13
Voluntary context switches 0
Involuntary context switches 0 Swaps 0
File system inputs 0 File system
outputs 0 Socket messages sent 0
Socket messages received 0 Signals
delivered 0 Page size (bytes) 4096
Exit status 82
38
Experimental Result (5)

• Macro test
• 100,000 times per command

Command Original libc Kernel (sec) Secure libc Secure Kernel (sec) Increment
ls 0.00781023 0.00922095 18.06
make 0.01481522 0.01697969 14.61
sysctl 0.02905236 0.03447007 18.65
tar 0.00804451 0.00940219 16.88
gcc 0.98855523 1.00293709 01.45
39
Conclusion

• We propose a new method to protect system calls
  by registering valid int 80 on premise
• Without recompile
• Allow executable stack
• Use ASLR optionally
• Compatible with other protections

40
Future Work

• More secure
• Implement executable but non-readable region in
  segment section on i386
• The NX Bit chip
• AMD 64 CPU

41

• Thanks
• Q A
