Performance Based Navigation leading towards a performance based Airspace concept

1
Performance Based Navigationleading towards a
performance based Airspace concept

• Erwin Lassooij
• Manager
• Performance Based Navigation Programme
• ICAO

2
Presentation overview

• PBN background
• PBN - Concept
• RCP and RSP
• Overview of presentations on Thursday

3
Aviation challenges

• Growing demands for RNAV approaches (safety,
  accessibility)
• Growing demands for solution airspace congestion
• Growing fuel efficiency requirements
• Growing Environmental requirements
• Can be met with most of current technology, but
  standardization and operational requirements have
  to be put into place

4
BackgroundICAO RNP concept

• FANS identified need for performance based
  navigation and developed Required Navigation
  Performance capability concept
• To avoid need for ICAO selection between
  competing systems
• Manual on Required Navigation Performance (doc
  9613)
• Emphasize on the en-route phase of flight (RNP-10
  and RNP-4) for oceanic and remote applications
• No ICAO RNP requirements for continental enroute
  and terminal applications.
• Proliferation of national standards
• Wide variety of functional requirements
• Variety of required navigation sensors
• Differing air crew requirements
• Lack of global harmonization

5
Approachproliferation of types
Non-Precision Approach Precision Approach
Definition of operations become very blurred Need
for performance requirements and possibly need
for reclassification
Etc. Etc. Etc.
6
BackgroundIndustry s RNP concept

• RNP concept has continued to evolve outside ICAO
• RTCA/EUROCAE defined performance and functional
  requirements
• Industry s RNP requires performance monitoring
  and alerting
• Conflict
• Current ICAO concept does not require performance
  and alerting
• Now we have two RNP concepts.

7
Are we now going the right way?
P R E S E N T
RNP
RNP/RNAV
Not safe, not efficient, costly, confusing

8
ICAO Recognizes the problems

• Need for focal point in ICAO to address problems
  experienced with RNP Concept (GNSSP/4
  recommendation 1/1)
• ANC (163/9) approves establishment of Required
  Navigation Performance Special operational
  requirements Study Group (RNPSORSG) as
  coordinating group

9
What needs to be done

• Original RNP concept in principle good, however
• Adjustment to the RNP concept required.
• Clear distinction between operations that require
  performance monitoring and alerting and
  operations that dont require
• Harmonization of current RNAV and RNP operations
• Development of new navigation specification to
  meet operational demand.
• Need for clear operational approval requirements
• Clear implementation guidance

10
Agreeing PBN

• PBN specifies RNAV system performance i.e.
  accuracy, integrity, continuity, availability
  functionality - written up in navigation
  specifications

This is different than the RNP concept, which
stressed navigation accuracy and stopped at
required performance. However, PBN is anchored in
detailed navigation specifications, which contain
performance and functionality requirements.
RNAV X specifications
RNP X specifications
11
Harmonization of existing navspecs

Simplification results in lower costs for
Operators and ANSP



12
Harmonization of RNAV operations not covered by
existing nav specs

1-0.1


13
Harmonization of existing RNAV operations not
covered by nav specs


• RNP approach for lowest common denominator
• Meets RNP0.3 in final segment
• Basic GNSS/SBAS
• Functionalities VNAV optional
• No Special authorization required

1-0.1


14
Harmonization of existing RNAV operations not
covered by nav specs


• RNP approach for lowest common denominator
• Meets RNP0.3 in final segment
• Basic GNSS/SBAS
• Functionalities VNAV optional
• No Special authorization required

• Scaleable RNP (0.3 0.1NM)
• Functionalities VNAV, RF legs
• Authorization required (small protection area)
• Operational approval
• Aircraft qualification

1-0.1


15
RNP SORSGPerformance Based Navigation Concept
Perf. Monitor and alerting
No perf. monitor and alerting
RNP 4, Basic RNP 1 RNP APCH, RNP AR APCH
RNAV 10

16
ICAO ProvisionsPerformance Based Navigation
Manual

• PBN Manual to provide a one-stop shop for
  States on how to implement RNAV and RNP in their
  airspace
• PBN Manual being developed Two Volumes
• Volume I An Application of RNP and RNAV
• Concept of PBN and how it is used
• Implementation Guidance to States / Regions
• Volume II Compendium of Navigation
  Specifications

RNAV 10 RNAV 1 RNP APCH
RNAV 5 RNP 4 RNP AR APCH
RNAV 2 Basic RNP 1 Advanced RNP1 RNP 2
Work in progress
17
PBN Convergence.
F U T U R E
P R E S E N T
PBN
PBN
RNPSORSG initiatives
18
Context of PBN
Airspace Concept
Airspace Concept
ATM
COM
NAV
SUR
19
Required Communication Performance (RCP)

• Initiation
• Response to Recommendation 2/2 of the fourth
  meeting of the Aeronautical Mobile Communications
  Panel (AMCP/4, Montreal, April 1996).
• Air Navigation Commission tasked the Automatic
  Dependent Surveillance Panel (renamed as the
  Operational Data Link Panel (OPLINKP) in 2000) to
  develop the concept of RCP.

20
Required Communication Performance (RCP)

• Achievements
• In 2001, the OPLINKP completed its Concept of
  Required Communication Performance document which
  became the basis for the Manual on Required
  Communication Performance (RCP) (Doc 9869)
  (available on the ICAO NET).
• In 2003, a continuation of the work on RCP was
  endorsed at the Eleventh Air Navigation
  Conference in the light of the urgent need for
  global harmonization of communication performance
  measures and support the efforts of States to
  transition to performance-based operations, a
  critical aspect of evolving to a safer and more
  efficient global ATM environment.

21
Required Communication Performance (RCP)

• Critical elements of the
  concept
• Required communication performance (RCP). A
  statement of the performance requirements for
  operational communication in support of specific
  ATM functions.
• RCP is performance-based, human-centred,
  operationally significant, independent of
  specific technologies and applicable to both
  voice communications and data link
  communications.
• ICAO
  provisions
• Recent amendments to Annex 6, 11 and the PANS-ATM
  include the initial high-level provisions
  necessary to support the introduction of RCP.
  (Applicable 22 November 2007).

22
Required Surveillance Performance (RSP)

• Initiation
• Need identified by ICAO to complement PBN and RCP
• Work programme currently established by ICAO
• RSP can be used for both existing and future
  surveillance applications, airborne as well as
  terrestrial. It is envisaged that RSP will
  interact with other performance parameters (PBN,
  RCP) in meeting Required Total System Performance
  levels.

23
Detailed presentations

• Introducing PBN
• Mr. Alex Hendriks, EUROCONTROL,
• Mr. Jeff Williams, US FAA
• Mr. John Mc Graw US FAA
• Stake Holders perspective on PBN
• Mr. Yoshiki Imawaka, JCAB
• Mr. Dave Nakamura, ICCAIA
• Mr . Dave Behrens, IATA
• PBN The future
• Mr. Erwin Lassooij, ICAO
• Progress on RCP
• Mr. Tom Kraft, US FAA
• Progress on RSP
• Mr. Massoud Paydar, ICAO

24
END

• Thank you for your attention!
