FMD simulation status

1
FMD simulation status
Alexei Kurepin, Alla Maevskaia INR RAS, Moscow
17 September 2002
2
Simulation output
Signal/background coefficient for each
0.1 h interval
Number of disk number of sector number of
ring energy deposited in this pad
17 September 2002 Alla Maevskaia INR RAS, Moscow
3
Occupancies of charged particles per strip for
one HIJINGpara (8000 particles per unit of
pseudorapidity) event vs number of ring
17 September 2002 Alla Maevskaia INR RAS, Moscow
4
Deposited energy spectra from one strip for one
HIJINGpara event
17 September 2002 Alla Maevskaia INR RAS, Moscow
5
Primary / total coefficient comparison for
magnetic field 0.2T and 0.4 T
17 September 2002 Alla Maevskaia INR RAS, Moscow
6
Digitization from GEANT Hits to DAQ tape
For each pad read Hits
If deposited energy gt threshold
Convert energy losses to ADC signal
Add noise
Simulated DAQ tape
17 September 2002 Alla Maevskaia INR RAS, Moscow
7
Reconstruction from DAQ tape to number of
particles
Read Digits
Subtract pedestals
Calculate number of empty pads for each 0.1 h
If number of empty pad number of pads gt0.1
Use Poisson method
Use threshold method
Multiply reconstructed number of particles by
signal/background coefficient
Number of charged particles in 0.1 h
8
Comparison number of particles in one pad from
HIJING and from Poisson distribution
17 September 2002 Alla Maevskaia INR RAS, Moscow
9
Reconstruction accuracy for 40 event HIJINGpara,
B0.2T
17 September 2002 Alla Maevskaia INR RAS, Moscow
10
Reconstruction accuracy for 40 event HIJINGpara,
B0.2T
17 September 2002 Alla Maevskaia INR RAS, Moscow
11
Occupancy per pad for 100 HIJING events
b0-8.6fm, B0.4T
17 September 2002 Alla Maevskaia INR RAS, Moscow
12
Reconstruction accuracy for 100 HIJING events
B0.4T(Nreal - Nreconstructed)/Nreal
17 September 2002 Alla Maevskaia INR RAS, Moscow
13
Occupancy per pad for 2500 PYTHIA events
17 September 2002 Alla Maevskaia INR RAS, Moscow
14
Reconstructed accuracy for 2500 PYTHIA events
without signal/background corrections.
17 September 2002 Alla Maevskaia INR RAS, Moscow
15
Primary / total coefficient for 2500 pp PYTHIA
event
17 September 2002 Alla Maevskaia INR RAS, Moscow
16
Primary / total coefficient for all units of
pseudorapidity for 2500 pp collisoins
17 September 2002 Alla Maevskaia INR RAS, Moscow
17
Summary
Now we are close to reality after HIJING
simulation with different impact
parameters Poisson and threshold methods of
reconstruction are consistent Reconstruction
of multiplicity for PP collisions was made
17 September 2002 Alla Maevskaia INR RAS, Moscow
