Idealized numerical modeling of river plumes

1
Idealized numerical modeling of river plumes

• Rob Hetland
• and
• Rocky Geyer

2
Outline

• Estuary mouth conditions and estuarine scales
• Tides in the estuary
• Low resolution vs. High resolution
• Effect of winds.

3
(No Transcript)
4
Connection between estuaries and river plumes

• Estuarine circulation sets the strength and
  density anomaly of the flow at the estuary mouth.
• Yankovsky and Chapman (1997)
• Burger and Rossby (or Froude) numbers dependence
  at estuary mouth sets type of plume (i.e.,
  surface or bottom trapped)
• Yankovsky (2000)
• Baroclinic exchange at estuary mouth is important
  in upstream plume propegation.
• Garvine (2001)
• Outflow structure and coastal wall depth affect
  plume evolution.
• Nof and Pichevin (in press, JPO)
• Vorticity structure of outflow affects bulge
  evolution.

5
Idealized domain
6
Motivation

• Explicitly modeling the estuary would place
  severe constraints on model resolution.
• Question Is it possible to finesse the
  estuary such that the river plume will be
  accurately simulated, while ignoring the details
  of the estuarine circulation?
• YES

7
Estuarine scales

• Classic analytical models of estuaries i.e.,
  Hansen and Rattray (1965) and Chatwin (1976)
  give scales for estuarine length scale,
  stratification, and estuarine circulation.
• Numerical experiments corroborate these scalings
  for simple domains with constant vertical mixing.

8
Analytic scaling

• L Kv-1 QR-1/3
• ?S QR2/3
• Ue QR1/3

Not dependant on Kv!
9
Numerical results vs. scaling
Estuarine circulation
Length
Stratification
10
Estuarine scales - summary

• Stratification and estuarine circulation are not
  dependant on mixing -- only the length scale
  varies.
• Thus, for steady fresh water forcing, high mixing
  may be set in the estuary, so that the estuarine
  length is reduced, while the outflow properties
  remain unchanged.

11
Tides in the estuary

• If tides are weak on the shelf, tides may be
  finessed by varying the river discharge at a
  tidal frequency.
• Tides increase shear, which increases mixing,
  reducing the density anomaly of the plume.

12
Tidal estuary plume
13
Vertical salt flux
14
Froude number
15
Wind effects
16
Conclusions

• Estuaries may be shortened by increasing mixing
  in the estuary.
• Tides may be finessed by modulating the riverine
  discharge.
• Wind effects cannot be ignored in realistic
  simulations.
