Integrated Precision X-Y-Z-T Stages

• Integrated XYZ Stage And Rotary Stage Solutions
  To Meet Precision Motion Control Requirements
  Without Backlash Or Hysteresis.

3

• Kensingtons integrated precision xyzT stage and
  rotary stage solutions have addressed the needs
  for precision motion control for more than a
  quarter century. The multiple axis stages
  position samples, silicon wafers and photonic
  devices, quickly with precision and repeatable.

4
Features

• Integrated precision xyzT stage rotary stage
  systems
• Wafer Handling Stages
• Smooth rapid movement immune to linkage backlash
• Hysteresis and wear eliminated by non-contacting
  read-head design
• Real-time force-sensing with programmable soft
  limits for safe operation
• EMO features halts motion immediately
• System initialization not required to restart
  after EMO
• Quite operation without resonances or excessive
  heat
• No PID parameter tuning with high step-and-settle
  performance via mechanical controls and design
• Vacuum ballast Z Wedge designs for smooth and
  precise vertical movement
• Heavy payload capability for vertical movement
  over long distances

5

• Integrated photonic and wafer stage designs range
  from dual axis to 4 axis (x, y, z, T) designs.
  Vertical axis designs utilize the Mini-z stage
  for small movements or can be fully integrated
  with vacuum ballast z-wedge for long travel and
  heavy pay loads.

Contact Kensington Today For Technical Details of
Precision Motion Control Solutions To Obtain a
Quotation For Integrated Precision XyzT Stage.
6
Looking for a partner thats dedicated to your
business?

• Contact Kensington for proven, robust products
  and solutions to enhance the performance and
  reliability of your products or to increase the
  operating life of equipment which already uses
  Kensington products.
