Applications of Large and Custom Made Caps by www.kelvindale.com.au

1
Welcome To Kelvindale Products Pty
Ltd. www.kelvindale.com.au
2
Applications of Large and Custom Made Caps

• Pipes and other packaged products can be sealed
  effectively using large caps.
• The shape, design and other features of these
  caps are made to ensure that it provides a tight
  seal that protects the packaged pipes or liquids
  flowing in pipes.

3
Special Design Features of Large Caps

• Large caps are specially designed so that they
  seal large diameter pipes.
• They are specially constructed so that they can
  be easily fitted and removed with the human hand.

• Use of tools may destroy the cap. Large caps are
  made with flexible plastics such as vinyl which
  allows it to fit snugly on the pipe.
• Large caps can be made up to a diameter of two
  meters.
• This means that they can effectively fit on most
  of the pipes used in industrial applications.

4
Types of Large Caps

• They are many different types of caps which are
  specially designed for different applications.

5
SFP series caps

• SFP series caps are specially constructed to fit
  snugly on hydraulic flanges ensuring that the
  surface is well protected.

6
NB series cap

• NB series cap are specially constructed so that
  they fit at the end of most BSP pipes and protect
  the threads.

7
FDN caps

• The FDN caps are made from high density
  polyethylene and are used for general purpose
  flange protection. They have a flat surface which
  fits on the pipe flange surface protecting it
  from corrosion and dirt.

8
LC series caps

• The LC series caps are used to protect taper or
  bevel edged pipes. Their construction allows them
  to be easily fitted and removed. They protect
  large diameter pipes which are very expensive.

9
Application of Large Caps in Packaging and
Covering Pipes and Flanges

• Large caps are widely used to cover pipes and
  protect them from dirt, moistures and other
  corrosion agents.
• They are also used to protect the pipe thread and
  flanges from rusting and mechanical damage.
• These caps are also be used to cover materials
  and large containers.
• They are also used to seal pipe ending.
• They form end caps which prevent materials
  flowing in pipes and other containers from being
  contaminated.

10
Design and Use of Customized Caps for Packaging
and Other Applications

• Most factory manufacture large customized caps
  for special sealing purposes. These caps are
  specially constructed to the requirement of the
  client.
• Various materials such as vinyl, ethylene vinyl
  acetate, polyethylene copolymer and silicon are
  carefully controlled to produce rubber caps with
  special properties such as hardness, ability to
  resist high temperature and pressure and many
  other properties.

11
Color of the Caps

• The color of the caps is also customized to suit
  different plumbing applications. Clients can
  request for special color cording on their caps.
  Different color cording assist plant technicians
  and operators identify different types of pipes.
• Customized caps can also be tapered or threaded
  depending on the clients requires. Other special
  features such as length, diameter and width can
  be adjusted so that they suit the clients
  applications.

12
Conclusions

• Large cap are extensively used to protect pipes,
  pipe flanges and threads. They are specially
  designed to provide a covers which can easily be
  fitted and removed from the pipes. They protect
  them from dirt, moisture and other corrosion
  agents.

13
Contact Us Kelvindale Products Pty Ltd. 32
Clyde Street RYDALMERE NSW 2116 Australia Phone
- 61-2-9638 0100 Email sales_at_kelvindale.com.au
