A Natural Extension: Using the Com-plete HTTP Server for Web-Enablement

1
A Natural ExtensionUsing the Com-plete HTTP
Server for Web-Enablement

• David Wimberly
• Project/Program Director, University of Arkansas
• wdw_at_uark.edu

2
Presentation Overview

• The Com-plete HTTP server
• A Natural tool for web enablement
• Web-Enablement at the University of Arkansas
• Enhancing existing applications with web
  technologies
• Implementation considerations
• Tips and techniques
• Examples

3
The Com-plete HTTP Server

• A Natural tool for web-enablement
• Com-plete 6.1 architecture
• Natural and the HTTP server
• Natural programmers view
• System view
• Advantages of this native MVS web and application
  server

4
Com-plete 6.1 Architecture
5
Natural and the HTTP Server
6
Natural Programmers View

• Simple CALL interface

Read user input from the web CALL HAANUPR
CGI-STATUS / Return code and reason code
CGI-ACTION / GET-DATA or PUT-DATA
FIELD-NAME / HTML form field name
FIELD-VALUE / User input value
FIELD-LENGTH / Length anticipated/returned SEPAR
ATE FIND EMPLOYEE WITH
7
System View

• Natural programs
• Run in the buffer pool
• Access ADABAS and other resources
• Call external module HAANUPR
• To read HTML form inputs and controls (GET or
  POST)
• To send dynamically generated HTML to the browser
• Configuration parameters for default user ID,
  library, buffer sizes, etc.
• Automatic EBCDIC/ASCII translations and url
  encoding/decoding

8
Native MVS Web and Application Server
9
Web-Enablement with the Com-plete HTTP Server

• Enhancing existing applications with web
  technologies
• Objectives
• Background
• Web session examples

10
U of As Objectives

• To enhance and extend our mainframe applications
• Reach new audiences
• Employees and vendors
• Enhance the presentation of information
• Consolidate information and dress it up
• Simplify access for infrequent users
• Not to replace all or even most 3270 functions
• Not to literally move a 3270 application to the
  web

11
U of A Background

• Natural and ADABAS mainframe shop since 1986
• BASIS Business Administrative Strategic
  Information Systems
• Custom inhouse developed applications
• Everything but student systems
• Separate groups doing Java web development and
  screen scraping web deployment
• Preference for Natural application code
• Timing was right for the Com-plete HTTP Server

12
Logon
13
Menu
14
Browse PO selection screen
15
Help for Date-Close-Anticipated
16
Help for PO status, selection
17
Help for PO status, window
18
PO status returned
19
Budgetary Unit help
20
BU help search
21
Browse PO for Status and BU by Date
22
Browse result and PO selection
23
View of PO, top
24
View of PO, bottom
25
Select a PO to Browse Invoices for PO
26
Browse Invoices for PO
27
View Invoice
28
Select a PO to e-mail
29
E-mail the PO
30
PO list, vendor help
31
Vendor name search
32
Select vendor
33
PO search by vendor and date, initiated
34
PO search by vendor and date, results
35
Main menu, select pay activity
36
Browse pay activity
37
View earnings statement
38
Main menu, select addresses
39
3270 Addresses, etc. equivalent
40
Addresses, etc
41
Enter changes, view errors and previous values
42
Correct errors and update
43
Update confirmation screen
44
Logoff screen
45
Implementation Considerations

• How to maintain state
• Back button
• Back button vs Return
• Data security
• Configuration
• Essential JavaScript
• Techniques for generating HTML
• Coding tips, debugging tips, and more
• Example HTML and Natural code

46
How to Maintain State

• The web is stateless
• Each interaction (submission) is self contained
• No provision for a continuous user session
• To maintain state
• Use conversational mode, or
• Create a session ID (TIMESTMP)
• Place it on the form as a hidden field
• Save and restore user session information using
  ADABAS

47
Back Button

• Can subvert your state information
• User reappears not from where you left him
• We considered
• Disabling it
• Running in a window without the toolbar or
  menubar
• Issuing errors if they used it
• Limit the state information you maintain
• Not the active position within a READ loop
• Instead, hide the first and last ISN on a page
• Have one entry point -- a dispatcher program
• actionuwowdis

48
Back Button vs Return
Browse A objects at level 1
Browse B objects at level 2
Browse C objects at level 3
As 1 - 10
Bs 1 - 10
Cs 1 - 10
Object selection or Paging
Cs 11 - 20
Bs 11 - 20
Back button
Return
Bs 21 - 30
49
How to Return

• Save program hierarchy information in hidden
  fields
• Our browse functions stack for each level
• Program ID
• Search type in effect
• ISN and MU/PE occurrence of first record on the
  screen
• Whether page back was valid
• A Return
• Pops one of these from the stack
• Executes the program and re-initiates the browse

50
Data Security

• Sensitive data requires encryption
• Com-plete HTTP server does not do SSL
• Proxy server introduced to do all encryption and
  decryption
• To avoid mixing document types and client side
  warnings
• Style sheets and graphics are delivered from a
  separate web server using HTTPS

51
U of As Environment
HTTPS
HTTP
Proxy Server for SSL encryption
IBM OS/390 running ADABAS, Natural, and Com-plete
6.1
Client with SSL enabled Web Browser
Web Server for .gif and .css files
52
Com-plete HTTP Server Configuration

• HAANCONF
• SERVPOOLYES
• Uses a shared logon or session
• NATLIBdefault library
• Natural CGI programs in other libraries require
  an implicit logon
• HTTPUSERdefault user ID
• URL processing user exit
• Restrict access to specific hosts or domains

53
Essential JavaScript

• Cursor placement
• Selection processing and linking to different
  services
• Set hidden form element to selected value
• Submit form
• Window management
• Open and Close windows
• Pass and return values

54
Techniques for Generating HTML

• Output your HTML to the Source Work Area
• Use Natural ISPF macros
• But macros cannot be invoked directly as a
  Natural CGI program
• Use Natural
• DEFINE PRINTER (1) OUTPUT 'SOURCE'
• FORMAT (1) PS0 LS133
• EJECT OFF (1)
• SET CONTROL 'Z
• WRITE (1) NOTITLE
• Send the generated HTML to the browser
• HNANCGIP is provided, but limited to 72 character
  lines
• Create your own using longer lines via the
  USR1035N interface

55
Coding Tips

• Develop an architecture and generate your Natural
  CGI programs using Natural ISPF macros
• Fast delivery of new functions
• Consistent
• Easy to implement changes -- REGEN
• To simplify making changes in page appearance
• Use copy code, subprograms, constants defined in
  an LDA, and an external style sheet
• HTML form fields can have dashes, but javascript
  cannot reference them
• Translate them to under-scores

56
HAANUPR Tips

• Field names
• Must end with a blank character
• Field values
• Are not blank filled, reset them before your CALL
• Field length
• Passed in the largest value you will receive
• Returned the actual size of the field entered
• CALL HAANUPR
• CGI-STATUS / Return and reason code
• CGI-ACTION / GET-DATA or PUT-DATA
• FIELD-NAME / HTML form field name
• FIELD-VALUE / User input value
• FIELD-LENGTH / Length anticipated/returned

57
Debugging Tips

• You cant sprinkle WRITEs into your code
• You cant run the Natural debugger
• Trap and log errors on a data base file
• Note ERROR-TA always starts as HNANERR and can
  only be changed by an assignment statement
• Output your debugging information with your web
  page using HTML
• This may mean holding information until you reach
  the page ltbodygt

58
Code Reuse

• Develop a Natural subprogram to output the core
  HTML document for an object (Purchase Order,
  Earnings Statement, etc.)
• Call from your Com-plete web application (Natural
  CGI program)
• Call from online 3270 session to generate an HTML
  e-mail attachment
• Read the source work area and send to SMTP using
  ESS PROCESS WRITE-SPOOL
• Call from batch to generate an HTML e-mail
  attachment

59
HTML for UWOMENU, part 1
60
HTML for UWOMENU, part 2
61
Natural code, UWCSBH
62
Natural code, output Action
63
Natural code, output table of Services
64
Natural code, read HTML form fields
65
Enhancement Proposal 958

• Efficient browsing of ADABAS data (no wasted I/O)
• Forward or backward (descending)
• Possible due to STARTING WITH ISN
• Regular descriptors
• MU type descriptors
• Unique PE type descriptors
• It is not possible with non-unique PE type
  descriptors!
• Vote for FIND DESCENDING, enhancement proposal 958

66
Presentation Review

• The Com-plete HTTP server
• A great run time environment for Natural, and now
  an enabler for Natural based web applications
• Web-Enablement at the University of Arkansas
• Examples of what can be done with the Com-plete
  HTTP server
• Implementation considerations
• Tips and examples from the University of Arkansas

67
Thank You!
