Adoption of New Technology a Utility Perspective

1
Adoption of New Technology a Utility Perspective

• CPUC Technology Workshop
• San Francisco, CA
• January 22, 2009
• Randy Hopkins
• Pacific Gas and Electric Company

2
PGE Transmission System
70,000 sq. mile service territory
3
PGE System

• 4.9 million electric accounts
• 3.9 million gas accounts
• Approximately 14 million customers
• Deliver Gas and/or Electric Service to
  approximately 1 out of every 22 Americans

4
PGE System

• 96,500 Circuit-Miles of OH Electric Distribution
• 23,900 Circuit-Miles of UG Electric Distribution
• 18,025 Circuit-Miles of OH Transmission
• 165 Circuit-Miles of UG Transmission
• 45,800 Miles of Natural Gas Pipelines

5
PGE Has Adopted and Continues to Assess New
Technologies

• ACSS
• 1056 circuit-miles of ACSS in service
• First installation in our system was in 1977
• Most utilities have yet to adopt this technology
• ACCR (3M)
• 1220 circuit-feet installed in May, 2005
• First ACCR installation in California
• ACCR is in the PGE toolbox

6
Extensive Use of Real-Time Monitoring

• Used to validate static ratings on critical
  circuits
• 23 CAT-1s installed on 11 circuits
• First installed in 1999
• 1 Sagometer
• Installed on 500 kV river crossing in 2006
• Working collaboratively with the CEC and CAISO to
  establish methods of real-time operations

7
What the Utility Needs

• Utilities are tasked with
• Protecting the safety of the public and workers
• Providing reliable service
• Being cost effective
• Protecting the environment
• Their facilities are
• Difficult to permit
• Costly to construct
• Need to be long-lived (40 years until forever!)
• If they are not long-lived, there is an
  environmental impact as utilities repair or
  replace

8
Pre-requisites for New Technology

• Understanding of the Risk vs. Benefit
• Confidence that the technology will work
• It has to pass a high standard of reliability and
  safety
• Confidence that the technology wont be orphaned
• The know how to correctly apply the technology
• Design, installation, handling, storage, etc.
• A need that is not being met by existing
  technologies
• Opportunity
• It has to be the right solution for the
  application
• It has to be compatible with our existing systems

9
Risk vs. Benefit

• Benefits have to be shown to exceed the costs
  associated with Risk
• Utilities need to understand the risk associated
  with new technologies in order to manage it
• Service life
• Failure modes
• Failure rates
• Even with due diligence, problems may show up
  years later

10
So How Do We Know It Will Work?

• Usually comes with knowledge and experience
• Nothing gives you that warm fuzzy feeling like a
  technology with a long track record of success
• With innovation comes risk
• Leading edge vs. bleeding edge
• Lacking experience, how is confidence obtained?
• Testing
• Monitoring
• Industry guidance (IEEE, ASCE, EPRI)

11
So, What Can Help Lower the Barrier to HTLS
Conductors?

• Thorough testing
• On-going monitoring
• Industry efforts
• IEEE Guide for Qualifying High Temperature
  Conductors for Use on Overhead Transmission
  Lines
• EPRIs HTLS Conductor Demonstration Project

12
IEEE Guide

• IEEE Guide for Qualifying High Temperature
  Conductors for Use on Overhead Transmission
  Lines
• Task force chaired by 3Ms Herve Deve
• Intended to provide guidance to utility engineers
  for the testing and acceptance of new High
  Temperature Conductors
• Fill the gap when industry standards (ASTM, etc.)
  lag behind new products and developments
• IEEE guide addresses methodology for qualifying
  conductors that are not on the market yet
• Currently in draft form

13
The Guide Will Provide Recommendations on

• Strand evaluation
• Conductor evaluation
• Accessory evaluation
• Qualification for installation
• Field testing

14
Strand Evaluation

• Tensile Strength
• Density
• Tensile Modulus (with additionally - Strain to
  Failure)
• Coefficient of Thermal Expansion (CTE)
• Fatigue Strength (axial direction)
• Creep at room temperature and use temperature
• Corrosion
• Moisture
• Strength after UV Exposure
• Hot/Wet (humidity)
• Resistance to brittle fracture
• Electrical Conductivity / Resistivity
• Strength Retention after 1000 hours exposure at
  use temperature.
• Strength Retention after 100 hours exposure at
  maximum rated temperature 50 C
• Bend Radius
• Shear Strength
• Compression Strength, (radial direction)
• Thermal Cycling
• Onset of Dielectric Breakdown

15
Conductor Evaluation

• Breaking Strength
• Stress-Strain (include Modulus of Elasticity)
• Electrical Resistance
• Creep
• Conductor Thermal Expansion
• Weight
• Sheave
• Axial Impact, Radial Crush
• Torsional Ductility
• Sag-tension-temperature
• Aeolian Vibration
• Galloping
• Corrosion (Salt Spray)
• Fault Current Load
• Thermal Cycling
• Long Period Thermal Resistance
• Lightning Strike
• Corona
• Moisture and UV radiation

16
Also, Includes

• Protocols for accessory evaluation
• Clamps, splices, dampers, spacers
• Qualification tests for installation
• Sag and tension
• Stringing and handling
• Field tests
• Installation, measurement, and monitoring

17
EPRI HTLS Demonstration Project

• Managed by EPRIs John Chan
• 3 years of laboratory and field tests to validate
  manufacturers claims
• Includes ACSS, ACCR, ACCC, Gap, and Invar
• EPRI considering market-ready, or near
  market-ready, conductors

18
Why Do We Need These Efforts?

• Many utilities lack the in-house technical
  expertise to evaluate new conductors
• Complete test data is not available for all
  manufacturers of HTLS conductors, etc.
• Manufacturers claims can be optimistic
• AND, the responsibility to make sound decisions
  is still the utilitys
• The results have to be safe and reliable
• Due diligence is necessary, but what does it look
  like?

19
What Could Go Wrong?
Annealed aluminum strands of ACSS show greater
susceptibility to fatigue damage than
conventional conductors
20
Non-Ceramic Insulators

• Widely deployed new technology of the 1980s
  and 1990s.
• Subsequent to wide-spread installation, several
  new modes of failure were discovered
• Water droplet corona
• Water intrusion into the end fittings leading to
  brittle fracture
• Internal arcing due to presence of water in the
  rod
• Now, many in the industry are rethinking the
  expected service life and restricting the use of
  NCIs.

21
Non-Ceramic Insulators
Water droplet corona damage led to failure
This type of failure was never even considered
when the new technology was implemented
22
New Technology Must Meet a Need

• The SLiM (Sag Line Mitigator) Device is an
  example of a technology that works, but where
  market penetration may be difficult due to a
  perceived lack of need.
• The SLiM Device is used to improve ground
  clearance in critical spans during periods of
  high sag by reducing the effective length of the
  conductor, thereby reducing sag
• This is important since lines are typically
  thermally constrained by ground clearance
  requirements

23
SLiM During Testing
Full scale tests performed at PGEs Livermore
facility in 2002. Fault current tests performed
at Kinetric.
24
SLiM (cont.)

• However, the SLiM must compete with traditional
  methods of improving sag in critical spans
• re-sagging the conductors
• raising towers
• These traditional methods are often less costly
• They are reliable and elegant solutions (i.e., no
  moving parts)

25
New Products Often Have Special Requirements
Special post insulator deadend plate and formed
wire deadend grip to accommodate the larger
minimum bending radius of ACCR
26
Other Considerations

• Logistics
• Does it make sense to have one of everything new?
• How do you store and track special materials
• How do you respond to emergencies
• Maximizing your system
• Standardize on the conductors that maximize your
  structure capacity

27
What Can Utilities and Regulators Do to Help?

• Encourage and support research programs like the
  CECs TRP and EPRI HTLS
• Encourage utility participation in industry
  groups to develop technical expertise
• Recognize the risk inherent in new technologies
  and manage it through comprehensive testing and
  on-going monitoring

28
Conclusions

• New technology must pass a very high standard of
  safety and reliability
• Must fill a need and do it better than other
  available options
• Bad technologies have the potential for both
  systemic and catastrophic impact
• Deployment of poor technologies can be costly to
  correct

29
Questions?
