Standard Linear AMPS Analog Mixed Products

1
Standard LinearAMPSAnalog Mixed Products
Services
October 2008
2

• AMPS Applications
• AMPS Products
• Operational Amplifiers
• Comparators
• Voltage References
• Power Management
• Video Buffers and High Speed Amplifiers
• Audio Amplifiers
• Gamma Correction ICs

3
AMPS Applications

4
STB / DVD Players and Recorders
Video Outputs RGB, YPrPb, Y/C, CVBS Video Line
drivers
Power Management
TSH6x, TSH7x, TSH8x, TSH9x, TSH103, TSH173,
TSH122 SD TSH11x, TSH340/341, TSH343/344,
TSH345/346 HD

Voltage References TL431,TL1431, TS2431,TS3431
Others
Stereo Audio Outputs Low Noise Op-amps
Filtering/Amplification TSV321/358/324
LMV321/358/324 Mono/dual/quad general purpose R2R
op-amps

LM833, MC33078, TJM4558, LMV358, TSH62, TSH72
New Products
5
Printers
Others
Power Management
General purpose amps/comps LM358/LM324,
LM393/LM339 Medium-end amplifiers LMV321/358/324
High performance R2R amplifiers TSV91X,
TSV99X High Precision amplifier TS507 High
Speed amplifiers TSH310, TSH350, TSH330
Voltage References TS431, TS432, TS821 TS4431,
TS4436
Motor Control Current sensing
TSC101
Audio Speakers Audio Power Amplifiers
New Products
TS4871, TS4990, TS4962
6
NoteBook/Desktop/Server
Power Management
Video Output (RGB) High-Speed Amplifiers
Voltage References TS431, TS432, TS821,
TS4431 TS4436
TSH173, TSH120 (SD), TSH34X (HD)
Micropower Comparators TS861/2/4,
TS7211/7221 High performance R2R
amplifiers TSV91X, TSV99X Current Sensing/Battery
Mgt TSC101, STW4102
Audio Speakers Audio Power Amplifiers
Others
TS4871, TS4990, TS4994/5, TS4974, TS4997,
TS4984/5, TS4962, TS2007, TS4961, TS2012, TS4982
Filtering/Amplification LMV321/358/324
Mono/dual/quad general purpose R2R op-amps Gamma
Correction TSL1014, TSL1018, TSL1020
Headset Audio Amplifiers
Microphone Audio Pre-Amplifiers
New Products
TS482, TS486/7, TS488/9 TS419, TS421, TS4909,
TS4601
TS461/2/4, TS971/2/4, TS472
7
Mobile Phones Portable Consumer (PDA, GPS, DSC,
MP3)
To Jack Connector
Power Management
Voltage References TS431, TS432, TS821,
TS4431 TS4436
Video Output (CVBS) High-Speed Amplifiers
Micropower Comparators TS861/2/4,
TS7211/7221 Micropower R2R amplifiers TS93x,
TS94x Current Sensing/Battery Mgt STW4102
TSH120
Audio Speakers Audio Power Amplifiers
Others
TS4871, TS4990, TS4994/5, TS4974, TS4997,
TS4984/5, TS4962, TS2007, TS4961, TS2012 ASSP
TS4973, TS4855, TS4956
Filtering/Amplification LMV321/358/324
Mono/dual/quad general purpose R2R op-amps
Microphone Audio Pre-Amplifiers
Headset Audio Amplifiers
New Products
TS461/2/4, TS971/2/4, TS472
TS482, TS486/7, TS488/9 TS419, TS421, TS4909,
TS4601
8
Portable DVD Players / PMP
Video Outputs R/G/B, Y/C, CVBS High-Speed
Amplifiers
TFT-LCD Panel Static Gamma Correction
TSH6x, TSH7x, TSH8x, TSH9x, TSH173, TSH120
SD TSH11x, TSH340/341, TSH343/344 HD
TSL1014, TSL1018
Power Management
Stereo Audio Outputs Low Noise Op-amps
Voltage References TS431, TS432, TS4040/1,
TS4431, TS4436 Battery Management STW4102
LM833, MC33078/9, TJM4558, LMV358, TSH62, TSH72
Audio Speakers Audio Amplifiers
Others

TS4871, TS4990, TS4994/5, TS4974, TS4997,
TS4984/5, TS4962, TS4961, TS2012, TS4982
Filtering/Amplification LMV321/358/324
Mono/dual/quad low consumption R2R op-amps
Headset Audio Amplifiers
TS482, TS486/7, TS4909, TS488, TS489, TS4601
New Products
9
CRT and FLAT PANEL TVs
Video Inputs/Outputs High-Speed Amplifiers
TFT-LCD Panel Static Gamma Correction
TSH6x, TSH7x, TSH8x, TSH9x, TSH173, TSH120
SD TSH11x, TSH340/341, TSH343/344 HD
TSL1014, TSL1018, TSL1020
Power Management
Stereo Audio Outputs Low Noise Op-amps

Voltage References TL431,TL1431, TS2431,TS3431
LM833, MC33078, TJM4558, LMV358, TSH62, TSH72
Others
Headset Audio Amplifiers

Filtering/Amplification TSV321/358/324
LMV321/358/324 Mono/dual/quad general purpose R2R
op-amps
TS482, TS486, TS487, TS4909, TS488, TS489, TS4601
10
Factory Automation --- Motor Control
Example current mode monitoring
Update Out
PWM
Op-Amp
Force turn-off of PWM
R
Comparator
r
-
-
Blanking Window
Event Filter

r

Iref
Rshunt
11
Chassis Safety --- ABS system
-

Battery
Power supply Vref
Brakes system
Front wheels Sensors (x2
MCU
Valve Control
Filter
Comp
Rear wheels Sensors (x2)
Filter
Comp
Flash Memory
ECU
Available soon
12
AMPS Products

13
Linear Product Portfolio
Multi Segment
Application Specific

• ASSPs (speaker driverHeadsetdig.vol.ctrl)
• (TS4855, TS4956, )
• Speaker driver (Class AB, Class D, Stereo, 3D)
• (TS4995,TS4997, TS4998,TS2007, TS2012, TS4962,
  TS4961 )
• Headset driver
• (TS488/9, TS4909, TS4601)
• Power Management
• (STW4102)

Mobile Phone

• Industry Std.

• LMV3xx, TSV3xx
• LM29xx, LM3xx
• Current Sensing
• TSC101, TSC888
• LM833
• MC33078
• TL431
• TL1431
• TS2431
• TS3431

Telecom
Op-Amp

• Low Noise

• Sensor signal conditioning
• ( TS9xx, TSV9xx)
• Video signal driver filtering
• ( TSH103,TSH173, TSH120, TSH345, TSH346)
• Micropower comparators
• (TS86x, TS7211/7221 )
• Standard high-end Op-Amp and Vref
• (TS431, TS824, TS4040)

STB, DVD, Digital TV
Consumer

• General Purpose

Handheld device
Reference
Instrument Machine contr. Process contr. Chem.
sensors Alarm system Medical

• ADC Low Power 12bits
• (TSA1203/1204)
• Actuator driver
• (TS982)
• High-end Op-Amp
• (TSH3xx, TS507)
• Sensor signal conditioning
• (TS9xx, TSV9xx, TS507)

Industrial

• General Purpose

Display

• Gamma Correction ICs
• (TSL1014, TSL1018, TSL1020)
• Stereo Audio Speaker driver
• (TS4984/5, TS4997, TS4998)
• Microphone Pre-amplifier
• (TS472 )

Compaarator
Computer
ODD

• High speed

Peripherals

• General Purpose Op-Amps Comparators
• Rail2Rail OP-amps (TS9XX, TSV9XX)
• Voltage Reference
• Current Sensing
• And More..

Power Train Body Security Infotainment
Automotive Grade Portfolio
Auto
14
AMPS Portfolio

• OPERATIONAL AMPLIFIERS

• COMPARATORS

• VOLTAGE REFERENCES

• POWER MANAGEMENT

• VIDEO BUFFERS and HIGH-SPEED AMPLIFIERS

• AUDIO AMPLIFIERS

15
Portfolio

• OPERATIONAL AMPLIFIERS

• COMPARATORS

• VOLTAGE REFERENCES

• POWER MANAGEMENT

• VIDEO BUFFERS and HIGH-SPEED AMPLIFIERS

• AUDIO AMPLIFIERS

16
Industry Standard Amplifiers
Low Power
Precision op-Amp
General purpose
MC33171 (single, Icc200µA, Vcc/-22V) MC33172 (
dual, Icc200µA, Vcc/-22V) MC33174 (quad,
Icc200µA, Vcc/-22V)
OP07 (single, Vio150µV) TS512I (dual,
Vio500µV) TS514I (quad, Vio500µV) TS522I (dual,
Vio850µV) TS524I (quad, Vio950µV)
LM201A/301A (single) LM224/324(A) (quad,
Icc400µA) LM146/246/346 (quad,
CMR110dB) LM148/248/348 (quad,
SVR100dB) LM258/358(A) (dual, Avd100V/mV) LM2902
(quad, temp-40/125c) LM2904 (dual,
temp-40/125c) LM2902H (quad,
temp-40/150c) LM2904H (dual,
temp-40/150c) MC1458 (dual,
Avd200V/mV) MC3303/3403 (quad, SVR90dB) TS321
(single of LM324 in sot23-5)
TS272 (dual, Icc1mA) TS274 (quad, Icc1mA)
Low noise
TS27L1 (single, Icc10µA) TS27L2 (dual,
Icc10µA) TS27L4 (quad, Icc10µA)
LM833 (dual, en4.5nV/VHz) MC33078 (dual,
en4.5nV/VHz) MC33079 (quad, en4.5nV/VHz) MC455
8 (dual, en12nV/Vhz) LS204 (dual,
en8nV/VHz) LS404 (quad, en8nV/VHz)
TL061 (single, Icc200µA) TL062 (dual,
Icc200µA)TL064 (quad, Icc200µA)
Medium Speed
Temp range -55c to 150c Supply range 2.5 V
to 44V Pin to pin compatible Wide range of
applications DIp, SO, TSSOP, SOT23
LF247/347 (quad, GBP4MHz) LF251/351 (single,
GBP4Mhz) LF253/353 (dual, GBP4Mhz) LF255/355
(single, GBP2.5Mhz) LF256/356 (single,
GBP5Mhz) LF257/357 (single, GBP20Mhz) TL071
(single, SR16V/µs) TL072 (dual,
SR16V/µs) TL074 (quad, SR16V/µs) TL081
(single, Zin12Mohms) TL082 (dual,
Zin12Mohms) TL084 (quad, Zin12Mohms) TSH22
(dual, GBP25Mhz) TSH24 (qual,
GBP25Mhz)
17
RAIL-TO-RAIL OP-AMPS
GBP
Ideal to drive A/D, sensor signal conditioning,
low voltage application, -40c to 125c Miniso,
Tssop, So, single in SOT23
TSH7x
100 MHz
TSH8x
TSV99x
TS97x
10 MHz
TS46x
TSV91x
TS92x
5 MHz
TS982x
TS95x
TS507
TSV3xx
LMV3xx
1 MHz
TS187x
LEGEND
TS91x
Precision
500KHz
TS185x
Improved speed/power
Low Noise
TS93x
High Out Current
High speed
100KHz
TS94x
CMOS inputs
Icc
100µA
10µA
1mA
5mA
1. 0µA
18
TSV3xx and LMV3xx
Stability noise
Low Current consumption
TSV LMV Low Vio Rail to Rail I/O Extended temp
range Wide supply range Tiny package
TSV321/358/324 Improved output stage high
output current capability, able to drive 500pF
Capacitive load 32W load resistor
LMV321/358/324 improved merit factor for your
portable application GBP1.3MHz with Icc140uA
19
TSV321/358/324
Supply Voltage From 2.7V to 6V
3V

in
TSV3xx
out
-
600W
0V
Rail to Rail Input Extended Vicm (Vss - 0.2V to
Vcc 0.2V)
Rail to Rail Output
Gain Bandwith Product 1.3MHz High Stability -
load capacitor up to 500pF - load
resistor 600W
Output Source/Sink current 80 mA Input Offset
Voltage 100µV (typ)
20
LMV321/358/324
Other Key Parameters for LMVxxx

• Low Current Consuption 145µA Ideal for
  Portable Applications
• Input Offset Voltage 100µV (typ)
• Extended Temperature Range 40C/125C
• Wide Supply Range
• Tiny Packages

21
LMV321/358/324
5V
5V
MAIN APPLICATIONS FOR LMV3xx
Analog Signal
-
ADC
LMV3xx

• Battery Powered Systems
• Laptop, PDAs
• Personal Medical Care
• Digital Still Camera

0V
0V
Rail-to-Rail Input capability able to manage
signal ranging between power rails
Rail-to-Rail Output capability able to drive
input of ADC configured for full scale input
voltage
Low voltage applications
22
TSV911-912-914CMOS inputs, 8MHz, rail-to-rail
input/ouput op-amps

• Applications
• Battery-powered applications
• Portable devices
• Sensor signal conditioning
• Medical
• Automotive
• Active filtering, buffering

• High tolerance to ESD
• gt5kV for HBM model
• Extremely Low input Bias Current
• 1pA typ
• Single or dual supply operation
• 2.5 V to 5.5V
• High Merit factor GBP/Icc
• 8 MHz - 780µA per Amplifier
• Temperature Range
• -40, 125C
• Automotive qualification

SO14
SOT23-5
SO8
miniSO8
TSSOP14
23
TSV991-992-994CMOS inputs, 20MHz, rail-to-rail
input/ouput op-amps

• Applications
• Battery-powered applications
• Motor control
• Signal conditioning, active filtering
• Automotive
• Instrumentation, factory automation

• High tolerance to ESD
• gt5kV HBM
• Single or Dual Supply Operation
• From 2.5V to 5.5V
• Extremely Low input Bias Current
• 1pA typ
• Very high slew rate and GBP
• 20 MHz for gain above 3
• SR 10V/µs
• Icc780µA typ
• Temperature Range
• -40, 125C

Update Out
TSV994
PWM
Op-Amp
Force turn-off of PWM
Comparator
R
-
r
-

Iref
r

Blanking Window
Event Filter
Rshunt
Current loop regulation (motor control)
TSSOP14
SO14
SOT23-5
miniSO8
SO8
24
TS507High precision, Rail-to-Rail, single op-amp

• Applications
• Medical instrumentation
• Filters and sensors
• Automotive sensors conditioning
• Industrial measurements
• Portable devices

• Supply Voltage
• From 2.7V to 5.5V
• Ultra Low Offset voltage
• 100µV max
• High Open loop Gain
• 131dB
• Low Consumption
• 790µA max / 1.9MHz
• Temperature Range
• ( I ) -40c/125c
• (C) -40c/85c

SO8
SOT23-5
25
Portfolio

• OPERATIONAL AMPLIFIERS

• COMPARATORS

• VOLTAGE REFERENCES

• POWER MANAGEMENT

• VIDEO BUFFERS and HIGH-SPEED AMPLIFIERS

• AUDIO AMPLIFIERS

• GAMMA CORRECTION IC

26
Comparators
Note R2R stands for "Rail to Rail"
27
TS3021 / TS3022

• FEATURES
• Response time 33ns
• Low current consumption 64µA
• Rail-to-rail inputs Push-pull outputs
• Supply operation from 1.8V to 5V
• Wide temperature range -40C to 125C
• ESD tolerance 2kV HBM / 200V MM
• SC70 / SOT23 / SO8 / MiniSO8 (to come)

• Applications
• Telecom
• Networking
• Industrial
• Signal conditioning

TS302x Benefits - Best Response Time / Current
Consumption Ratio - Lowest Supply Voltage
28
Portfolio

• OPERATIONAL AMPLIFIERS

• COMPARATORS

• VOLTAGE REFERENCES

• POWER MANAGEMENT

• VIDEO BUFFERS and HIGH-SPEED AMPLIFIERS

• AUDIO AMPLIFIERS

29
Shunt Voltage References
Shunt voltage references
High power for SMPS
Micro power for Portable application
Precision gt 0.5
Precision lt/ 0.5
Adjustable output
Fixed output
TS824-1.2 1.225V 1 precision Ik40µA to 12mA
TL1431 Adj 2.5 to 36V 0.4 and 0.25
precision Ik1 to 100mA
TL431 Adj 2.5 to 36V 2 and 1 precision Ik1 to
100mA
TS431 Adj 1.24 to 6V 2 and 1 precision Ik40µA
to 30mA
TS821 1.225V 2, 1 and 0.5 precision Ik40µA to
12mA
TS2431 Adj 2.5 to 24V 2, 1 and 0.5
precision Ik1 to 100mA
TS432 Adj 1.24 to 10V 2, 1 and 0.5
precision Ik60µA to 12mA
TS4041- 1. 2 1.225V 2, 1 and 0.5
precision Ik60µA to 12mA
TS824-2.5 2.5V 1 and 0.5 precision Ik60µA
to15mA
TS4431 Adj 1.2 to 10V 0.5
precision Ik150µA to 20mA
TS3431 Adj 1.2 to 24V 2, 1 and 0.5
precision Ik 1 to 100mA
TS822 2.5V 2 and 1 precision Ik40µA to 15mA
TS4436 Adj 0.6 to 10V 0.5 precision Ik200µA
to 12mA
TS4040 - 2.5 2.5V 2 and 1 precision Ik40µA to
15mA
30
Portfolio

• OPERATIONAL AMPLIFIERS

• COMPARATORS

• VOLTAGE REFERENCES

• POWER MANAGEMENT
• Current Sensing Amplifiers
• Battery Management IC

• VIDEO BUFFERS and HIGH-SPEED AMPLIFIERS

• AUDIO AMPLIFIERS

31
Current Sensing TSC101

• Independent supply and input common-mode voltages
• Wide common-mode operating range 2.8 to 30V
• Wide common-mode surviving range -0.3 to 60V
• Wide supply voltage range 4 to 24V
• Low current consumption Icc max 300µA
• Internally fixed gain 20V/V, 50V/V or 100V/V
• Buffered output
• 2kV ESD protection
• SOT23-5 package
• -40 to 125C operating temperature range

• Applications
• Automotive
• Computer
• Battery monitoring
• Motor Control

Demonstration board available (bare PCB)
32
TSC101 Application example
33
Battery Management

• New ASSP family
• Primary focus 1-cell Li-Ion battery linear
  charger and gas gauge function
• Handheld applications Cellular Phones, PDA, MP3
  Players, GPS, Digital Camera, ...

34
STW4102Li-Ion Linear Battery Charger

• Advanced battery charger and monitoring IC for
  Li-Ion Battery applications
• Targeted marketsmedium and high-end mobile such
  as smart phones, PDA-phones, handheld
  applications
• Status Samples availableIn Production

35
STW4102Li-Ion Linear Battery Charger

• Integrated power switch used in linear modeto
  regulate the output current and voltage
• Charge from adapter or USB connector(USB bus is
  limited to 500mA)
• Status OutputsMain or USB Power Detected,End
  of charge
• Maximum charge current set by external resistor

36
STW4102

• Dual inputs (main and USB)Li-Ion Linear Battery
  Charger
• Gas Gauge system
• Battery Voltage Monitor
• Thermal regulation
• Highly configurable through I2C interface
• Support for 4.7V LDO to supplythe system when
  the battery is discharged or unplugged
• Option for using external power devices for
  charge currents gt 1A
• QFN 24 4x4mm package, exposed pad for good
  thermal performance

37
Portfolio

• OPERATIONAL AMPLIFIERS

• COMPARATORS

• VOLTAGE REFERENCES

• POWER MANAGEMENT

• VIDEO BUFFERS and HIGH-SPEED AMPLIFIERS

• AUDIO AMPLIFIERS

38
Video Amplifier s Portfolio
TSH345 SO14-TSSOP14
TSH346 SO8
TSH343TSH344 SO8
Full Production Oct 08
TSH173 TSH103 SO8
TSH73 SO14/TSSOP14
TSH82TSH72 TSH62 SO8
TSH122 (Icc2mA) SC70
TSH70 SOT23
39
High Speed Video Amplifiers
R2R stands for Rail to Rail
40
High Speed Amplifiers
41
Localization of the video amplifiers
RCA (or SCART in Europe)
DAC
R,Pr
TSH343 TSH344
LPF
HD
G,Y
LPF
B,Pb
LPF
TSH345 TSH346
RCA (or SCART in Europe for RGB)
DAC
R,Pr
LPF
TSH173 TSH103
G,Y
LPF
B,Pb
Standard
LPF
RCA
DAC
Cvbs
LPF
TSH120
42
TSH7x-8x
100-MHz, Rail-to-Rail In/Out Voltage Feedback
Op-Amp, Low Power Supply
Vcc3V to 12V
Vcc

_
TSH7x

• TSH7x Supply Range 3V to 12V (0/70C)
• TSH8x Supply Range 5V to 10V (-40/85C)
• High Speed
• Small Signal Bandwidth 100MHz (GBP)
• Slew Rate 100V/µs
• Input/Output Rail-to-Rail
• Video performance
• Differential gain 0.5
• Differential phase 0.5
• Gain Flatness on 0-6MHz 0.1dB (6dB gain)
• Noise 11nV/vHz
• Applications
• Standard Definition Video
• Video Signal Multiplexing
• High-end communications

0V
25mV
TSH80 TSH81 TSH82
SOT23-5 TSSOP8 SO8
TSSOP14-16 SO14-16
43
TSH11x
100-MHz, Very Low Noise Very Low
Consumption Current Feedback Op-Amp

• High Speed
• Bandwidth 100MHz (-3dB)
• Slew Rate 480V/µs
• Voltage Noise 3nV/vHz
• Low consumption
• Quiescent current 3.5mA
• Video performance
• Differential gain 0.5
• Differential phase 0.5
• Gain Flatness on 0-6MHz 0.1dB (6dB gain)
• Supply Voltage 5V to 12V
• Applications
• High Definition Video
• Signal Multiplexing

TSH110 TSH111 TSH112 TSH113 TSH114
SOT23-5 TSSOP8 SO8 TSSOP14
SO14
44
TSH300
200MHz Ultra Low Noise

• Bw200MHz (Gain5)
• en0.65nV/sqrtHz
• in3.3pA/sqrtHz
• Icc15mA
• Stable for Gainsgt5
• Voltage Feedback Amplifier

• Applications
• Instrumentation
• ADC driver
• Sensor System

Noise
MEDICAL INSTRUMENTATION
small input signal
very good SNR
5V

Riso
Ggt5
ADC
-
50W
Bandwidth
Output noise level for a gain of 20 (Rfb510W,
Rg27W)on a band of 10kHz - 1MHz 20.5µVrms
SNRgt90dB on 1Vppon a band of 10kHz - 5MHz
45.8µVrms SNRgt85dB on 1Vpp
Rfb
Rg
45
TSH310
130-MHz for 400µA Very Low Consumption Current
Feedback
2.5V
-
TSH310
in
out
1kW
3.3kW
-2.5V

• High Speed
• Small Signal Bandwidth 130MHz (GBP)
• Slew Rate 120V/µs
• Voltage noise 7.4nV/vHz
• Very Low Consumption
• Quiescent current 400µA
• Distortion
• Fin1MHz, Vout2Vp-p, Load1kohms
• SFDR -87dBc
• Fin10MHz, Vout2Vp-p, Load1kohms
• SFDR -55dBc
• Supply Voltage /-2.5V or 0/5V
• Applications
• Battery Powered Applications
• Instrumentation
• ADC driver

High R-Load
Rg
MEDICAL INSTRUMENTATION
46
TSH330
1.1-GHz, Low Noise High Speed Op-Amp Current
Feedback

• High Speed
• Small Signal Bandwidth 1.1-GHz (GBP)
• Slew Rate 1800V/µs
• Voltage noise 1.3nV/vHz
• Consumption
• Quiescent current 16mA
• Distortion
• Fin20MHz, Vout0.6Vp-p, Load100ohms
• H2-65dBc
• H3-83dBc
• Supply Voltage /-2.5V or 0/5V
• Applications
• InstrumentatioN
• Professional Video
• Medical Imaging
• ADC Driver

MEDICAL INSTRUMENTATION
47
TSH350
420-MHz for 4mA Current Feedback
2.5V
-
TSH350
in
out
150W 100W

• High Speed
• Small Signal Bandwidth 420MHz (Gain1)
• Slew Rate 940V/µs
• Voltage noise 1.5nV/vHz
• Very Low Consumption
• Quiescent current 4mA
• Distortion
• Fin10MHz, Vout1Vp-p, Load100-ohms
• SFDR -66dBc
• Fin20MHz, Vout1Vp-p, Load100-ohms
• SFDR -57dBc
• Supply Voltage /-2.5V or 0/5V
• Applications
• High-end Video
• Instrumentation
• ADC Driver

300W
-2.5V
Low R-Load
300W
MEDICAL INSTRUMENTATION
1
8
NC
NC
Output
1
5
VCC
_
2
7
Output
-IN
-VCC
2
VCC
-

3
6
IN
-IN
IN
3
4
-VCC
5
4
NC
SOT23-5
SO8
48
TSH340/341

• TSH340
• Bw 320MHz (internal gain2)
• Slew Rate 780V/us
• Distortion
• Fin10MHz, Vout2Vp-p, Load150-ohms
• H2-85dBc, H3-75dBc
• Fin30MHz, Vout2Vp-p, Load150-ohms
• H2-55dBc, H3-50dBc
• TSH341
• Bw 300MHz
• Slew Rate 780V/us
• Distortion
• Fin10MHz, Vout2Vp-p, Load150-ohms
• H2-64dBc, H3-59dBc
• Fin30MHz, Vout2Vp-p, Load150-ohms
• H2-47dBc, H3-40dBc
• TSH340-41

49
TSH343/344

• FEATURES
• Single 5V Supply
• gt250MHz Bandwidth
• Slew rate gt 750V/uS
• Internal 6dB gain
• Integrated DC shift (TSH343)
• Small package SO8
• No external input capacitor required

HIGH DEFINITION
50
TSH345 - TSH346 for HD1920x1080i
Set-Top-Box
HD
DVD P-R
HD
R-G-B outputs
R-G-B outputs
HIGH DEFINITION
75W cables
HD
TV
R-G-B outputs
51
TSH173 Triple video buffer with filter
Set-Top-Box
DVD P/R
R-G-BY-C-CVBS outputs
R-G-BY-C-CVBS outputs
STANDARD DEFINITION
75W cables
Standard Definition
R-G-BY-C-CVBS outputs
TV
52
TSH173 Triple video buffer with filter

• Triple SD buffer in S08
• Pin-compatible with FMS6143
• 5V single supply
• Internal filter
• -1dB_at_6MHz, -45dB_at_27MHz
• Internal DC shift
• Full production

STANDARD DEFINITION

• Pin to pin compatible
• FMS6143

Low cost version TSH103
53
TSH122 for CVBS
GPS
STANDARD DEFINITION
54
TSH122 Single video buffer with Filter

• Very low Icc 2mA
• Standby function
• Very low Vcc 2.2V to 5V(tested at 2.5V and
  3.3V)
• Very small package SC70
• 6th order Internal filter
• -1dB_at_7MHz, -46dB_at_27MHz
• SAG output
• Pin-compatible with OPA360

STANDARD DEFINITION
55
Portfolio

• OPERATIONAL AMPLIFIERS
• CURRENT SENSING AMPLIFIERS
• COMPARATORS
• VOLTAGE REFERENCES
• VIDEO BUFFERS AND HIGH-SPEED AMPLIFIERS
• POWER MANAGEMENT
• VOLTAGE REFERENCES
• AUDIO AMPLIFIERS

56
Low Voltage Audio Amplifiers family To bring
more Features to Multimedia Devices

• Functions
• Microphones Pre amplifiers
• Headphones Drive
• Audio Power Amplifiers
• Assps
• Applications
• Mobile phones
• Portable multimedia devices
• Notebooks

57
AUDIO AMPLIFIERS
New Products
POWER AMPLIFIERS
ASSPs
HEADPHONE DRIVERS
MICROPHONE AMPLIFIERS
MONO
STEREO
DIFFERENTIAL
MONO BTL
STEREO
TS4973
TS46x TS97x
TS4851
TS4994
TS4984
TS4990
TS482
TS472
TS419
TS4855
CLASS D
1.2W
2x1.2W
1W
TS421
100mW
300mW
TS4956
TS4974
TS4985
TS486/7
300mW
2x1.2W
1.2W With volume control
TS488/9
100mW
TS4962
TS4982
TS4997
100mW
TS4975
3W
TS4909
With 3D effect
TS2012
100mW With volume control
100mW with phantom ground
TS2007
TS4998
Stereo
3W, selectable gain
Stereo, Full diff
TS4601
Capaless outputs
