Ferris State University GIS project: integration of spatial data technologies

1
Ferris State University GIS project integration
of spatial data technologies

• Yaron Felus, Robert C. Burtch and Sayed R.
  Hashimi
• Department of Surveying Engineering
• Ferris State University, MI

2
FERRIS SURVEYING PROGRAM

• Surveying program established in 1957
• Associate Degree
• Bachelor degree established in 1972
• Response to Michigans requirement for a BS
  degree as minimum requirement for licensure

3
FERRIS SURVEYING PROGRAM

• Mathematics, science civil engineering and
  general education basic core
• Core surveying knowledge
• Surveying instrumentation, techniques, mapping
  and field procedures
• Computer applications to surveying including
  AutoCAD, Into. to GIS and programming

4
FERRIS SURVEYING PROGRAM

• 3. Advanced surveying tracks
• Advanced surveying applications
• Geodetic surveying
• Adjustments and statistical analysis of data
• Modern Cartography
• Professional track
• Legal principles of surveying
• Professional practices, ethics
• Land and urban development
• Imaging sciences
• Photogrammetry and remote sensing
• And advanced geographic information systems

5
The problems

• Given these many courses in geospatial
  technology, we would like to design an
  undergraduate level GIS course which is tailored
  to Surveying Engineering applications
• How to integrate the different courses, challenge
  the students and display a practical spatial
  information systems case study

6
GIS study areas.
Mathematical Statistical methods. Transformation
s, Data analysis
GIS
7
The Life Cycle of a Spatial Database the Ferris
State University project
8
The different steps of the project included

• Establishing a geodetic network using GPS
  techniques.
• Acquiring Remote Sensing images rectification and
  enhancement.
• Data compilation from existing resources
  (University architect)
• Additional data collection using photogrammetry
• Field completion and field data collection using
  total-stations and land surveying methods.
• Preparation of Metadata report or data quality
  description.
• Spatial data analysis, change detection, parking
  space etc.
• Map composition and cartographic design.
• Creating an on-line spatial data dissemination
  gateway.

9
Monuments established in conspicuous locations
with visibility between them to allow convenient
leveling
Establishing a geodetic network using GPS
techniques
F.G.R.N. Recon Team 2001
10
Global Positioning Systems (GPS), technology in
static mode was used to calculate new coordinates
using a set of MDOT known points
Establishing a geodetic network using GPS
techniques
11
(No Transcript)
12
Using OPUS Service

• During the project the students used OPUS
• Online Positioning User Service.
• Operated by the National Geodetic Survey as a
  means to provide GPS users easier access to the
  National Spatial Reference System (NSRS).
• OPUS allows users to submit their GPS data files
  in RINEX format to NGS, where the data will be
  processed to determine a position using NGS
• computers and software.

13
Ferris Geodetic Reference Network growing every
year
AFTER
BEFORE
14
IKONOS of SpaceImaging 1-meter resolution and
QuickBird of DigitalGlobe acquiring
61-centimeters (2-foot) resolution images.
Remote Sensing the use of satellite images for
mapping and information systems.
15
(No Transcript)
16
The GIS LAB during this step the students used
ArcView 3.x and now ArcGIS

• Data compilation from existing resources
  (University architect and Web resources)

17
The Michigan Geographic Data Library

• Aerial Imagery
• Base Features (MIRIS-DLG)
• Contamination Sites
• Geology
• Hydrology
• Land Ownership
• Land Use/Land Cover
• Management Unit Boundaries
• Place Features

• Plant and Animal Locations
• Political Features
• Public Land Survey Features
• Satellite Imagery
• Soils
• Topography
• Transportation
• Utilities

18
Michigan CGI Online

• The MIRIS Base was digitized from 124,000-scale
  USGS 7.5 minute quadrangle maps in Microstation
  using an error of .02 and range in date from
  1959 - 1986
• Accuracy /- 80 feet.
• Michigan GeoRef Coordinate System is employed,
  unlike Michigan State Plane, GeoRef was designed
  to project the State using a single zone rather
  than three zones.

?
19
Challenges in data compilation

• How to integrate spatial databases with different
  computer format (Shape, geodatabases, CAD- .DWG
  Microsoft Access etc.
• Files with different coordinates systems
  (projection and transformation)
• Different accuracy and spatial resolution
• Building topology, correcting errors and checking

20
Photogrammerty - Accurate mapping ( aerial photographs using advanced technology
Additional data collection using photogrammetry
21
(No Transcript)
22
Advance data collection techniques RTK GPS,
electronic notebooks and Total Stations

• Field completion and field data collection

23

• Various alpha numerical databases were compiled
  from field and existing University/City
  databases.
• Some features in the FSU GIS database had more
  then 25 fields, for example fire hydrant

24
MetaData report, key issue

• MetaData- Data about data.
• While we would not think of purchasing a
  microwave oven or video recorder without an
  instruction booklet and a warranty against
  defects, geographic data most often is purchased
  without receiving any quality documentation.
• Data documentation protects the organization's
  investment in that data.
• Without knowledge of the data's accuracy,
  provenance, and age, we cannot have a high level
  of confidence in decisions based upon that data.

25
Metadata Data quality

• Data_Quality_Information Attribute_Accuracy
• Logical_Consistency_Report
•
  Completeness_Report
•
  Positional_Accuracy
• Lineage
• Each of the elements in this equation is defined
  and should be provided as part of the metadata
  report

26
(No Transcript)
27
Example solutions
28
Metadata Data quality

• Estimation of positional accuracy
• Relative Compare 10 distances between distinct
  points on the map and on the ground
• Absolute Compare 10 coordinates of distinct
  points on the map and on the ground.
• Calculate the RMS of the results

29
Metadata Data quality

• Estimation of completeness and attribute
  accuracy
• Subdivide the area into small sections, examine
  the map in the field and check for
  omitted/wrongly classified entities
• Thorough analysis of the spatial database to
  estimate logical consistency

30
Map composition and cartographic design
Spatial data analysis and urban studies
31
Parking lot distribution per group (faculty and
staff, students, public etc.)
32
Parking lot distribution per group (faculty and
staff, students, public etc.)
33
Advanced visualization techniques such as fly
through and stereo modeling
Digital elevation models, 3D analysis and Virtual
Reality
34
Building a 3D image using Laser Scanning
Technologies
Created using Cyra 3D laser scanning system by
Sterling Systems Consulting, Inc
35
Campus temporal analysisImages from 1970- in an
8 years interval were studied ( 1980)
36
Campus temporal analysisImages from 1970- in an
8 years interval were studied(1988)
37
Campus temporal analysisImages from 1970- in an
8 years interval were studied(2001)
38
Temporal analysis

• Using vector overlaid on raster different
  temporal aspect of the campus and city were
  evaluated for example
• How many new roads were developed since 1974?
• How many new buildings?
• Growing patterns of the city etc.

39
