Installation Training

1
Installation Training
2
Introduction

• Welcome to HAIs Training Course. In this day
  long course, we will show you how to install,
  set-up and program a home automation system.

3
Agenda

• Specifications
• Connections
• PC Access Connections
• Programming
• Setup
• Codes
• Programs Dial
• Arming
• Names/Voices
• Miscellaneous
• Installer Setup
• Control
• Zones
• Communicator
• Areas
• Temperature
• Miscellaneous
• Expansion
• Lifestyle Applications

4
Specifications
OMNIPRO II
SPECIFICATIONS Controller Maximum Group Current
Outputs Console backlight off - 35 mA
backlight on - 100 mA OUTPUTS 1 - 8 100
mA Devices AUX 12 VDC, SWITCH 12 VDC, CONSOLE,
and OUTPUTS 1 - 8 1 A Horn INT HORN and EXT
HORN 1 A Controller Maximum Individual Current
Outputs Devices (Do not exceed 1 A total) AUX
12 VDC 1 A SWITCH 12 VDC 1 A CONSOLE 1
A Operating 32 - 122 degrees F (0 - 50 degrees
C) Transformer 24 VAC, 1.67 amps, 40 VA Battery
Rechargeable Lead-Acid, 12 Volts, 7 Ah
5
Specifications cont.
OMNI II SPECIFICATIONS Typical
Current Consumption at Nominal Voltage Console
backlight off - 35 mA backlight on - 100
mA Controller Maximum Group Current
Outputs Devices AUX 12 VDC, SWITCH 12 VDC,
CONSOLE, and OUTPUTS 1 - 8 1 A Horn INT HORN
and EXT HORN 1 A Controller Maximum Individual
Current Outputs Devices (Do not exceed 1 A
total) AUX 12 VDC 1 A SWITCH 12 VDC 1 A CONSOLE 1
A OUTPUTS 1 - 8 100 mA Operating 32 - 122 degrees
F (0 - 50 degrees C) Transformer 24 VAC, 1.67
amps, 40 VA Battery Rechargeable Lead-Acid, 12
Volts, 7 Ah
6
Specifications cont.
OMNILT SPECIFICATIONS Typica
l Current Consumption at Nominal
Voltage Console backlight off, 35 mA backlight
on, 100 mA CONTROLLER OUTPUTS UL RATINGS
MAXIMUM Devices AUX 12 VDC, CONSOLE, and OUTPUTS
1 and 2 200 mA 500 mA Bell BELL 350 mA 1
A Outputs OUTPUTS 1 and 2, each, maximum 100 mA
100 mA Backup Required battery backup hours 24
hours Battery Recommended Battery 12 Volts, 7
Ah Operating 32 - 122 degrees F (0 - 50 degrees
C) Transformer 16.5 VAC, 40 VA, 50/60 Hz
7
Connections
8
Ground Connection
1)


Ground the Controller Earth Ground
terminal to a cold water pipe or to a 4-foot
ground rod to preserve its built in transient
protection.
9
Transformer Connection Omni II / OmniPro II
24vac 40 VA Transformer
Connect a 24 volt 40 VA transformer to the
24VAC Input (2nd 3rd input) in the left corner
of the first terminal strip. Note a) Be
sure you connect wires to inputs 2 3. Do not
connect transformer to the
first input (Ground). b) Do not
plug in transformer until all devices are wired
to Controller c) Make sure controller
is not plugged into a switched outlet.
10
Transformer Connection Omni LT
2)
16.5vac 40 VA Transformer
Connect a 16.5 volt 40 VA transformer to the
16VAC Input (2nd 3rd input) in the left corner
of the first terminal strip. Note a) Be
sure you connect wires to inputs 2 3. Do not
connect transformer to the
first input (Ground). b) Do not
plug in transformer until all devices are wired
to controller c) Make sure controller
is not plugged into a switched outlet.
11
Battery Hookup


-

_

Connect the BLACK battery wire to the minus (-)
terminal on the Battery. DO NOT connect the
red wire at this time. DO NOT reverse the
connections the battery fuse will blow.
7 Ah Battery required
12
Console/ OmniTouch Hookup
4)
BLACK
YELLOW
GREEN
RED
Use 4-conductor 22 gage wire minimum, 1000
feet maximum length. Consoles can be homerun or
daisy chained. This length shall be divided by
the total number of consoles at the end of the
run.
Maximum current draw from Auxiliary and Console
terminal is 1 Amp for Omni II and OmniPro II and
for the Omni LT it is a Maximum of 500mA. Be sure
to add total current draw from all power devices.
If above the limit, an Auxiliary power supply is
required. Power supply must have common ground
with controller. See current draw listings below
for consoles Omni Console- 33A00-1 40mA
100mA (active) OmniTouch- 32A00-1 350mA
Red
12V Terminal
Black GND
Terminal
Yellow (A)
Terminal
Green (B)
Terminal
13
Phone Connection Omni LT
Connect to Green and the Red wires to the
incoming line and the Brown and gray to the
return to the house phones. If
required connect a RJ31X jack as shown in the
following diagram Note Make sure all
house phones come after controller. The
polarity must be correct for proper operation of
the phone access feature.
14
Phone Connection Omni II OmniPro II
Connect to Green and the Red wires to the
incoming line and the Brown and gray to the
return to the house phones. If
required connect a RJ31X jack as shown in the
following diagram Note Make sure all
house phones come after controller. The
polarity must be correct for proper operation of
the phone access feature.
15
Sounder ConnectionsOmni LT

• Sounders can draw up to 1 amp MAXIMUM on the
  Bell output
• Use a relay connected to an auxiliary power
  supply if a higher current draw is required.
• If there there is a slight hum coming from the
  Siren, strap the bell output out with a 1k
  resistor.
• If a siren is not being used, Strap bell outputs
  out with a 1k resistor.
• When system is not in an alarm, the siren output
  will measure 10.40VDC. When in alarm, it will
  measure 13.75. The small amount of voltage is how
  we supervise the output

16
Sounder ConnectionsOmni II OmniPro II

• Sounders can draw up to 1 amp MAXIMUM, split
  between the Interior and Exterior Horn Outputs.
• Use a relay connected to an auxiliary power
  supply if a higher current draw is required.
• If there there is a slight hum coming from the
  Siren, strap the bell output out with a 1k
  resistor.
• If a siren is not being used, Strap bell outputs
  out with a 1k resistor.
• When system is not in an alarm, the siren output
  will measure 10.40VDC. When in alarm, it will
  measure 13.75. The small amount of voltage is how
  we supervise the output.

17
Two Wire Smoke ConnectionOmni LT
All two wire smokes must be run in parallel and
have an EOL resistor at the end of the line. Be
sure to move jumper to SMK position. All two
wire smokes must be wired to zone 8 only.
18
Two Wire Smoke ConnectionOmni II OmniPro II
All two wire smokes must be run in Parallel and
have an EOL resistor at the end of the line. Be
sure to move jumper to SMK position. All two
wire smokes must be wired to zones 1 4 only.
19
4-Wire Smoke ConnectionOmni LT

• Use normally open (closed for alarm) four-wire
  12volt smokes
• An End of Line Power Supervision Relay Module is
  required for UL installations.
• Install a 1000-ohm End-of-Line resistor as shown
• Power the smoke detector from Aux 12V or Output 2
  as a SWITCHED POWER OUTPUT
• When connected to Zone 8, the Jumper must be in
  SMK position

If 4 wire smokes are going on the same zone, they
must be wired in Parallel. 4 wire smokes can be
placed on their own zone and can be wired to all
zones.
20
4-Wire Smoke ConnectionOmni II OmniPro II

• Use normally open (closed for alarm) four-wire
  12volt smokes
• An End of Line Power Supervision Relay Module is
  required for UL installations.
• Install a 1000-ohm End-of-Line resistor as shown
• Power the smoke detector from Switch 12V or an
  Output configured as a SWITCHED POWER OUTPUT
• When connected to Zones 1-4, the appropriate Zone
  Jumper must be in SMK position

If 4 wire smokes are going on the same zone, they
must be wired in Parallel. 4-wire smokes can be
placed on their own zone and can be wired to all
zones. EOL resisters are required for all smokes
and must be placed at the last smoke. A Power
Supervision relay is required if power
supervision is necessary
21
RC Series Thermostat ConnectionOmni LT

• Run a 3 or 4 conductor wire from the HAI system
  to the Omni-stat.
• All Omni-Stats are connect to the controllers
  TSTAT input.
• Make sure black and red wire are securely
  connected to each other. If they are not, you
  will have communication problems.
• Address each Thermostat separately in order to
  communicate to HAI.
• (press Program 3X, then press Fan, use down arrow
  key to change address)
• Under Setup/Installer/ Temps in the HAI
  programming, enable thermostats being used.
• Disable Internal thermostat programming in
  thermostat section 03.

22
RC Series Thermostat ConnectionOmni II OmniPro
II

• Run a 3 or 4 conductor wire from the HAI system
  to the Omni-stat.
• All Omni-Stats are connect to the controllers
  zone 16 and Output 8
• Make sure black and red wire are securely
  connected to each other. If they are not, you
  will have communication problems.
• Address each Thermostat separately in order to
  communicate to HAI.
• (press Program 3X, then press Fan, use down arrow
  key to change address)
• Under Setup/Installer/ Temps in the HAI
  programming, enable thermostats being used.
• Disable Internal thermostat programming in
  thermostat section 03.

23
31A00-2 Outdoor Temperature Humidity Sensor

• Each Model 31A00-2 requires one zone input for
  temperature and one zone input for humidity. Run
  a 4-conductor wire from the controller location
  to each Model 31A00-2. The humidity sensor can be
  used without using the temperature sensor.
• If a high and a low Set point is Desired for
  temperature or Humidity, connect a jumper wire
  from the positive of one zone to the positive of
  another zone.
• Program the zone type for the temperature output
  as an Outdoor Temperature (Type 81), Temperature
  (Type 82), or Temperature Alarm (Type 83) based
  on the application. Only one zone can be defined
  as an Outdoor Temperature zone.

24
Remote Surface/Recessed Temperature Sensor

• Run a twisted pair, shielded cable from the
  OmniStat to the Remote Temperature Sensor
  location. For distances up to 100 feet, typical
  twisted pair, PVC-insulated, shielded cable may
  be used. For distances from 100-150 feet,
  twisted pair with polypropylene insulated
  conductors, shielded must be used. For distances
  from 150-250 feet, twisted pair with
  foam-polyethylene insulated conductors, shielded
  must be used. Wire runs must not exceed 250
  feet.
• Disconnect the thermostat from the base. Locate
  the 3 solder holes on the lower right side of the
  thermostat PCA marked J4.
• Using a clean soldering iron and safety glasses,
  carefully solder the supplied connector to the
  soldering holes as shown.
• Open cover to the Model 23A00-1 Remote
  Temperature Sensor. Connect the data wires of the
  shielded cable to the terminal block on the
  temperature sensor. Wrap the shield around the
  jacket of the cable and tape.
• At the OmniStat location, connect the Black
  conductor of the supplied cable to the shield
  using the supplied wire splices. Connect the
  Green conductors of the supplied cable to the
  data wires using the supplied wire splices.
• Carefully clip off the existing thermister
  (temperature sensing device) from the thermostat
  using a pair of wire cutters

25
Hardwire Expander Omni LT
Ribbon Cable
If adding more than one Expansion Module, be sure
to address it with jumper JP1
When connecting 1st 3rd expansion module, such
as an ALC, Zone Expander, or Serial module
connect ribbon cable from J1 to J1
When connecting 2nd 4th Expansion Module
connect ribbon cable from J2 to J2

• When adding a expansion modules, secure them to
  stand offs and connect them using supplied ribbon
  cables.
• To add more than one expansion Module, connect to
  J2 and address board using address jumper JP1

26
Hardwire Expander Omni II
OmniPro II
When connecting 2nd 4th Expansion Module
connect ribbon cable from J2 to J2
Ribbon Cable
If adding more than one Expansion Module, be sure
to address it with jumper JP1
When connecting 1st 3rd expansion module, such
as an ALC, Zone Expander, or Serial module
connect ribbon cable from J1 to J1
J2
J1

• When adding a Expansion Module, secure them to
  stand offs and connect them using supplied ribbon
  cables.
• To add more than one Expansion Module, connect to
  J2 and address board using address jumper JP1

27
Two-Way Voice ModuleOmni LT
Red Wire faces to the left
When connecting the Two-Way Voice Module to an
Omni LT, route the cable(model 10A11) to the
left side of the controller into J2. Make
sure red wire on cable should be to the Left of
the connector Make sure that the
connector is aligned with the pins on
J2 Mount Two-way Voice Module to side of
can using double stick tape or by drilling holes
and using stand-offs supplied
28
Two-Way Voice ModuleOmni II OmniPro II
Red Wire
J2
When connecting the Two-Way Voice Module to an
Omni Pro II, route the cable(model 10A11) to the
left side of the controller into J2. Make
sure red wire on cable should be to the top of
the connector Make sure that the
connector is aligned with the pins on
J2 Mount Two-way Voice Module to side of
can using double stick tape or by drilling holes
and using stand-offs supplied
29
Expansion EnclosureOmniPro II Only
12)

• The Expansion Enclosure communicates with the
  controller using the same wires that connect the
  consoles to the controller.
• The communications wires for the Expansion
  Enclosure and consoles may be homerun to the
  controller or daisy-chained to each other.
• Connect the terminals marked "A" and "B" on the
  Expansion Enclosure to the corresponding
  terminals on the controller or console.
• The Expansion Enclosure may be located up to 1000
  feet away from the controller.
• A common ground wire must be wired to the
  controller.

B
A
Ground wire
30
Installing PC Access
31
Installing PC Access
Make sure to Register your copy of PC Access.
Free upgrades are only available for registered
software
When installing PC Access, you will see this
screen show up. Enter your Name, Company name,
and Serial number to continue. Your serial number
can be found on the CD sleeve of your PC Access.
32
Installing PC Access
After following the prompts and loading the
software, double click on the PC Access Icon on
your Desktop. You will receive this window. Enter
the default Password which is password. Then
press OK
33
Installing PC Access

• When Running the program for the first time, you
  will receive this window after logging in. Enter
  a code that you can remember.
• DO NOT FORGET THIS CODE!!!!


34
Connecting PC to Omni Controller

• After Starting the program, Go to File then
  choose New. A Save File screen will pop up.
  After creating a name and choosing save, this
  window will come up. Choose the type of Omni
  controller you are programming. Be sure you enter
  the correct Controller type.

35
Connecting PC to Omni Controller

• This is your first screen. It contains contact
  information on your client. Enter in the
  customers name, Address Phone number and any
  remarks you may have for this account.

36
Connecting PC to Omni Controller

• If you are connecting through a serial port, go
  to your Windows device manager then to ports and
  find out what port your communications port is.
  Then go to your PC Access / configure and then
  Serial. You will see this screen. Enter your Com
  port and baud rate. The baud rate of 9600 is
  standard.

37
Connecting PC to Omni Controller

• In the bottom right hand corner, it should say
  ON-LINE.
• If you are not receiving this statement, one of
  four things can be wrong.
• Your Com Port is incorrect
• Your DB-9 Connector is broken or not plugged in
• A program has taken over your comport and is not
  releasing it
• Your Com port is broken.
• The System does not have to be connect to the PC
  in order to get an online Status.

38
Connecting PC to Omni Controller
If you are connecting through a modem, go to your
Device manager and find out what port your modem
is on. Then enter that port number in this window
under configure then modem. Make sure you put
your baud rate on 9600 , 2400, or 300 baud rate.

• You may have to contact your modem manufacturer
  to find out what the string commands are that
  disables error correction and Data
  compression. Once you get those commands, enter
  them in Initialization 2 3 and then enable
  them in the bottom right corner.

39
Connecting PC to Omni Controller

• To connect using Telephone access from off site
  follow the following steps
• With a phone ,on the same line that your PC is
  connected to, call the number the controller is
  connected to. Let it ring once and then hang up.
• Count to ten and then call the number again.
• Once you hear a beep, enter Code 1 or the
  installer code. You will hear a menu.
• When you hear the menu, press 1
• The system will ask you for a code again. Enter
  your code again. After entering your code, the
  system will begin to communicate. On your PC
  Access, press connect, then modem , then online.
  After you hear your modem connect, hang up the
  phone. You will be connected about 10 seconds
  later.

40
(No Transcript)
41
Setup - Codes

• All Omni security codes are 4 digits in length.
  To set up a code from the Setup menu from the
  console, press the 1 (CODES) key. (Valid codes
  0001-9999) (0000 Disable)
• Assign an Authority Level. Choose from Master,
  Manager, and User.
• Choose the Areas that the codes can access
• Choose the valid times these cards can be used.

42
Basic Programming

• HAI controllers are time and event driven
• A program will execute when
• Time match occurs
• An Event match occurs
• The controller is constantly searching for a time
  match or a change of state.

43
Program Line Structure

• When A time match or an event kicks off
  execution of a program line.
• Command Every program has a command to perform
  as a result of the When.
• AND IF The IF statement is optional in all
  programming lines. It is used as a conditional.
  As the controller watches all of the inputs to
  the system, it is constantly looking for matches
  for the When. When the match occurs, the system
  looks for a conditional (IF), to see if the
  condition is true or is NOT true. If the
  condition is true it executes the Command. If
  the conditional is NOT true the Command is not
  executed.

44
When, Command, If

• WHEN
• Time of day, sunrise, sunset
• User buttons (Romantic Eve)
• Control (a unit goes on or off)
• Security (mode changes)
• Zone (zone opens or closes)
• All On
• All Off
• Alarm
• X-10 (incoming)
• Misc..
• Phone Dead / Phone Line Ring
• Phone On Hook / Off Hook
• AC ON / AC OFF
• Battery Low / Battery OK
• DCM Fail / DCM OK

• COMMAND
• Control (on, off, dim, level)
• Security (mode, bypass, restore)
• Button (run a button)
• All On/ All Off
• Scene (activate a scene)
• Temperature settings
• Message (show, say, send, phone)
• IF
• Unit (on or off)
• Security (mode)
• Zone (open or closed)
• Time (within a window)
• Misc
• None, Never, Light, Dark, Phone Dead / Ring, On
  Hook / Off Hook, AC On / Off, Battery Low / OK

45
When Time Programs

• Two types Day of Week or Date
• Weekly Has one or more days (MTWTFSS)
• Example 1 Sunset MTWTFSS Front Porch Light On
• Example 2 1030 PM MTWTF Front Porch Light Off
• Date Has a day and month (12/03)
• Run Once
• Example 300PM 6/05 Thermostat cool setting to
  74.
• Run Annually
• Example 730AM 12/03 Show Jays Birthday

46
When Event Programs

• Run program line when something happens
• When Front Door Not Ready (open) Entry Light On
• When Hall Motion Not Ready (open) Hall Light On
  for 10 minutes
• When Arm Away Set Downstairs Heat to 65
• When Arm Away Set Downstairs Cool to 85
• When Romantic Eve Dining Lights to 50

47
Commands

• Control (on, off, dim, level)
• Security (mode, bypass, restore)
• Button (run a button)
• All On
• All Off
• Scene (activate a scene)
• UPB Link
• RadioRA Phantom
• Temperature settings
• Message (show, say, send, phone)

48
Conditionals

• AND IF
• When Front Door Not Ready (open) IF DARKEntry
  Light On
• When 400 PM MTWTF--IF AWAYDownstairs Cool
  Setting 75

49
Workshop

• WHEN Front Door NOT READY IF DARK Front Entry
  Lt ON
• The controller has the above line of programming
• 558 PM the Front Entry light is off
• 559 PM the homeowner walks in the Front Door and
  leaves the door open
• 600 PM Sunset occurs
• 601 PM is the Front Entry light on or off?

• It is OFF. The line is only executed when
  the Front Door is opened. At that
  moment sunset had not occurred.
• What would we do to make it go on at sunset
  if the front door was open?
• WHEN Sunset MTWTFSS IF Front Door NOT READY
  Front Entry Lt ON

50
Buttons Creating a Scene (Macro)

• When EXIT Security AWAY
• When EXIT All lights Off
• When EXIT All Thermostats Cool set back 80
• When EXIT All Thermostats Heat set back 60
• When EXIT IF Dark RUN Lights On
• When Lights On, Kitchen Light On 50
• When Lights On Family Room on 40
• When Lights On Master BedRm ON 25 26

51
PC Access

• Create programs in PC Access
• Review, edit delete, cut, paste, copy

• Search for programs
• Download to controller

52
PC Access Tips
53
Setup Dial

• Settings
• Telephone access This option allows you to turn
  the local (in-house) and remote telephone control
  feature on and off
• Answer outside call- allows access from outside
  through telephone. Choosing No will prevent
  this but still allow local access
• Remote commands OK- allows commands to be
  performed through a remote telephone. Local
  access can still issue commands when set to No
• Dial mode Specifies the type of dialing used
  when the Omni dials out.
• Rings before Answer The amount of rings before
  Omni series controller will pick up phone.

• My Phone Number the phone number that will be
  announced when the Omni dials out in the event of
  an alarm
• Dial Order The dial order in which call all
  will be placed if an alarm is activated

54
Setup Dial cont..

• Phone numbers
• Phone numbers 1-8 These numbers are stored in
  the system. In the even of an alarm, these
  numbers are dialed in the order that is set up in
  the Dial Out Order for the particular type of
  alarm
• You can cause the system to pause for 2 seconds
  between digits of numbers by Putting a (T) in the
  number or by pressing the DAY key on the console.
  For () press the NIGHT key and for () press
  the AWAY key.
• Phone numbers can be up to 24 digits in length

55
Setup Arming

• Entry Delay Program the Entry delay for each
  Area. This delay will be the time you get to turn
  off the system.
• Exit Delay - Program the Exit delay for each
  Area. This delay will be the time you get to exit
  the secured area
• Audible exit delay- This feature is an audible
  indication from the console beeper while the exit
  delay is in effect.
• Entry/Perimeter Chime When an Entry or
  Perimeter door is opened, the consoles will beep
  once.
• Quick Arm allows you to press the desired mode
  key without having to enter a code
• Auto Bypass allows the controller to bypass an
  open zone when the system is armed.
• All on for alarm- This option will instruct the
  Omni system to execute an X-10 All on command in
  the event any alarm occurs.

• Beep on trouble If the Controller detects any
  troubles with
• itself ot one of the zones connected to it, it
  will display a message
• on the screen and beep the console twice per
  second, continuously.
• To silence, press the key.

56
Setup- Names/Voices

• Names The system can be set up to display
  descriptive names such as FRONT DOOR, JOHNS
  BEDROOM etc for zones, units buttons, codes,
  temperatures, areas, and messages. If you are
  using an OMNITOUCH, you must name anything you
  want to be viewed or controlled.
• Voices The Omni series controllers can be
  set up to speak descriptive names such as Front
  Door for control zones, units, buttons, codes,
  temperatures, areas, and messages.

57
Setup Miscellaneous

• Settings
• High Security In this mode, the master or
  manager code is always required to do the
  following functions
• Any Control functions
• Any Temperature Control
• View Event Log
• Access system from a local phone
• Freeze Alarm If there are one or more
  Thermostats or PESMs in a system, they can also
  be used to detect a freeze condition. Alarm is
  activated when temperature falls below 40
  degrees. Alarm will not clear until it reaches 45
  degrees.
• Announce Alarms- If the HAI Two-way Audio Module
  is being used in a system, this option enables
  the system to speak the type of alarm and zone
  over a speaker on the premises.

• Location Enter in the correct Latitude,
  Longitude , Time zone and side of the Prime
  Meridian the system is on so it can properly
  calculate the time of sunrise and sunset.
• Flash for Alarm - You may enter one unit number
  that will flash on and off continuously when the
  alarm is activated.

58
Setup Miscellaneous

• Control - House codes
• Enable All Off This feature allows you to
  choose if X-10 House Code will respond to All Off
  Commands.
• Enable All On This feature allows you to choose
  if X-10 House Code will respond to All On
  Commands.
• Format- Choose from Standard (Preset Dim
  Commands), Extended (Level Command), Lightoliers
  Compose, UPB (Universal Power Bus), and RadioRA

59
Setup Miscellaneous

• Time Clocks
• TC1, TC2, TC3 There are three Time Clocks in
  the system that are used to conditionalize
  programs. They are used solely to define time
  periods during the week when certain programs
  should be enabled or disabled to execute.

60
Setup Miscellaneous

• Daylight Savings Time
• DST The Omni Series automatically calculates
  the day of daylight savings time each year. It
  also adjusts the time of day each time daylight
  saving time begins and ends

61
Installer Programming

• The Following pages can only be programmed with
  the Dealer configuration Software or through the
  console with the Installer code.
• PC ACCESS 1105W

62
Setup Installer Control

• Control
• House Code The base house code for units 1-16
  and is referenced as house code 1. The house code
  for units 17-32 is the next house code after the
  base house code, or house code B if the base
  house code is A
• X-10 3 Phase This setting whether the X-10
  signal is transmitted only at zero crossing for
  single phase electrical systems or transmitted at
  0, 60, and 120 degrees for three phase electrical
  systems.
• UPB Network-
• Address Network address that the UPB
  devices are programmed to in the UPB Upstart
• Password Password programmed in the
  UPB Upstart for the Network
• Output Types An Output type must be specified
  for each of the voltage outputs and for the
  interior and exterior horn outputs.

63
Setup Installer - Zones

• Zone resistors This item is used to specify if
  the 1000-ohm end-of-line zone resistors will be
  used with the inputs on the controller and zone
  expanders (this does not effect Expansion
  Enclosures or Fire applications)
• Expansion enclosures Expansion Enclosures can
  be used to add additional zones to the OmniPro II
  system. Each enclosure adds 16 zones to the
  system and eight Outputs. You must specify the
  amount of enclosures.
• Zone Types This option specifies the zone type
  for each zone. If the zone is being used for
  security purposes, it cannot be programmed to
  auxiliary.

64
Setup Installer Communicator

• Account
• Phone number 1 Enter the First Phone number
  that will be dialed for Central Station
  Monitoring.
• Phone number 2 - Enter the second Phone number
  that will be dialed for Central Station
  Monitoring.
• DCM Type- This item is used to select the
  transmitting parameters of the digital
  communicator.
• Two-way Audio this item enables hands free
  audio communication between your customers
  premises and the central station or off site
  phone.
• Test Time The DCM can be programmed to
  automatically send a test code to the Monitoring
  facility on a periodic basis.

65
Setup Installer Communicator

• General
• General listed are reporting codes for 4/2
  format, however if you want to disable reporting
  of any of these codes for contact ID, just enter
  (00) in the field to disable.
• Report Bypass/Restore - When using Contact ID,
  the Omni series controller automatically sends a
  reporting code when a zone is automatically
  bypassed or restored by the controller. To
  disable this, choose No.
• Test code- This code is sent to the monitoring
  facility when using 4/2 format. To disable enter
  00
• Cancel code This code is sent to the monitoring
  facility when using 4/2 format. To disable enter
  00

66
Setup Installer Communicator

• Zone
• Zone listed are reporting codes for 4/2 format,
  however if you want to disable reporting of any
  of these codes for contact ID, just enter (00) in
  the field to disable reporting (this feature is
  only valid in Firmware Version 2.6 or higher).

67
Setup Installer Communicator

• Open /Close
• Report open/close The communicator can be setup
  to send an opening and a closing report by user
  code.
• Other - This is the reporting code for 4/2
  format. To disable type 00.

68
Area

• Areas
• Number of areas choose the number of areas
  needed for your application
• Assign areas Next, choose what areas the Units,
  zones, buttons, messages, and thermostats are
  going to belong to.
• Console Last, choose what area the console will
  be assigned to and whether or not it is a global
  console.
• (global means that the console will be
  able to control all areas)

69
Temperature

• Temperature Format choose the format that needs
  to be used
• Thermostat types Choose between Auto/heat/cool
  , Cool only, Heat Only, or Not Used.

70
Setup Installer - Miscellaneous

• Page 1
• Installer code The installer code allows the
  installer access to the installer setup menu.
• Enable PC Access This enables or disables the
  PC Access feature
• PC Access Code- This code allows Dealers to put
  an access code in the system that is separate
  from the customers Master code and Installer
  code. This code can be used on PC Access
• Callback number In response to a request for
  remote PC Access using Pc Access code, the system
  will hang up and dial this number back
• Out Siren Delay This delay helps reduce false
  alarms by signaling the inside first .
• Dialout delay This is the number of seconds
  that the Omni series controllers waits before
  making an emergency dial out to the Monitoring
  facility.
• Alarm Reset- This is the time it takes before the
  Alarm system resets after an alarm
• Arming Confirmation This is a quick pulse given
  by the outside siren when the alarm system is
  armed into a security mode.

• Verify Fire Alarms When a zone configured as a
  fire/Gas is activated, the system will cycle the
  switched power outputs off for 10 seconds. The
  switched 12V power output will then be restored
  and 5 seconds later the zones will be monitored
  again. If the zone is tripped again within a 2
  minute window, the fire alarm will be activated.

71
Setup Installer - Miscellaneous

• Page 2
• Enable Emergency Keys This enables or disables
  the functionality of emergency keys on the
  Console.
• Time format Allows you to choose between AM/PM
  or 24 hr.
• Date format- allows you to choose between Month
  /Day and Day/ Month
• AC Power Frequency Set this so appropriate AC
  power line frequency
• Dead line Detect This option detects if there
  is a dial tone. If the system will not have a
  phone line connected to it, set this feature to
  (0)
• Off hook detect This item adjusts the
  threshold that is used to determine when the
  phone line is going off hook.
• Pickup after hangup- This item is used to disable
  the Omni from picking up the phone line after
  the called party hangs up the line.

• Clock Adjust If the clock on the controller is
  running faster or slower than the actual time,
  you can have the controller automatically
  compensate up to 29 seconds per day. The
  controller will add or subtract the selected
  amount of time daily.

72
Setup Installer - Miscellaneous

• Page 3
• Supervise int sndr This Enables or disables
  supervision of the Interior Horn Output, which
  monitors the wiring to the connected sirens.
• Supervise ext sndr This Enables or disables
  supervision of the Exterior Horn Output, which
  monitors the wiring to the connected sirens.

73
Setup Installer - Expansion

• Expansion
• Modules 1-4 The Module Type defines the
  function of each expansion module on the
  controller. Module 1 is the module with the ADDR
  jumper set to 1.
• Rate Serial rate selects the baud rate used
  for the built-in serial interface on the
  controller. Select the baud rate for the built-in
  interface from the list.
• Function- The serial Function selects the
  communication protocol used for the built-in
  serial interface. To send a message through the
  serial interface, set it to Pro-Link.

• !!!!!!! Serial Address DO NOT TOUCH THIS
  OPTION. Leave it set to 0 !!!!!!

74
(No Transcript)
75
Security and Safety

• The porch lights will flash upon a burglary alarm
  and remain on until the system is reset. (set up
  item)

• Well, guess what its already a trick question!
  Flash for Alarm is actually a set up item
  that function is built in. You dont have to
  program anything to make that happen.

76
Security and Safety

• Fire alarm will shut down HVAC fan, all lights
  will turn on for safe exit. (3 programs)
• When Fire Alarm all thermostats Mode OFF
• When Fire Alarm, all thermostats FAN AUTO
• When Fire Alarm, ALL ON

77
Lighting

• Master Bedroom Lamp will come on at 600 AM and
  go off at 730 AM Weekdays. Console will beep and
  show Rise and Shine! (3 programs) But not on
  holidays! (Make a Holiday Flag)
• When 600 AM MTWTF-- Master Lamp On for 90
  minutes. When 600 AM MTWTF-- SHOW Rise and
  Shine!
• When 730 AM MTWTFSS Clear message rise and
  shine! (we have to do this so it will beep next
  morning)
• continued

78
Lighting

• Now lets introduce a FLAG.
• Unused unit numbers are flags.
• They dont control anything, but they can be on,
  off, timed.
• Lets put in some programs to turn the flag on
  for holidaysWhen 1201 AM 12/25 Holiday Flag
  On
• And a program to turn the flag off every night at
  the end of the dayWhen 1200 am MTWTFSS,
  Holiday Flag OFF
• Conditionalize the first two programsIF
  Holiday Flag OFF

79
Lighting

• Hallway ceiling lights turn on at 65 at sunset
  and go off when Night Sleep Mode is activated.
  (2 programs)
• When Sunset Hall Lights Level 65. When NIGHT
  Hall lights OFF.

80
Energy Management

• When Night Mode, set downstairs thermostat to 60
  degrees heating and 82 degrees cooling. (2
  programs)
• When Night Downstairs Heat setting 60 degrees.
  When Night Downstairs Cool setting 82
  degrees.(You could write two more to bring it
  to comfort levels early in the morning IF in the
  night mode not away or vacation, since well
  have it set back more.)

81
Energy Management

• Set Upstairs thermostat to 65 degrees heating, 78
  degrees cooling at 1130 weekdays IF were in
  Night Mode. (2 programs)
• 1130 pm MTWTF IF NIGHT Upstairs Heat Setting
  65.
• 1130 pm MTWTF IF NIGHT Upstairs Cool Setting
  78.

82
Energy Management

• When it is mild outside, turn on the fan to
  circulate air. (2 programs)
• The outdoor sensor has a high and a low setting
  you can set. Set the low to 65, high to 75. If
  the outdoor temp is between these values, the
  outdoor temp zone is secure. If not, its not
  ready.
• When Outdoor Temp Not Ready Thermostat Fan On.
• When Outdoor temp Secure Thermostat Fan Auto.
• This keeps the air moving during times when the
  heat or air is not likely to run much.

83
Energy Management

• When Vacation, turn off the electric water
  heater.
• When Vacation, Water Heat OFF.When Security
  OFF, Water Heat ON.
• (2 programs)
• You can call in and turn the water heat on
  without turning security off)

84

What are the next steps?

• Align yourself with an HAI Distribution Partner
• Purchase a system to install in your home or
  office
• Sell only what you know have tested
• Keep it simple
• Complete training special forms
• Meet requirements to be listed on HAI web-site
• Use Automation Simplified Manual HAI Web-site
  as reference tools

85
We would like your Feedback
In Order for us to provide you with the best
possible training available we would appreciate
it if you would fill out the Training Program
Evaluation form. This form will help us adjust
our training format so that you may understand
our great product better and help you with your
install and sales.It will also allow us to
provide a more comfortable area for you to learn
in. Thank You
86
Contacts
87
(No Transcript)
