Dry Ice Blasting

1
Dry Ice Blasting
2
Examples of Dry Ice Blasting
Before
After
Welding equipment
3
Permanent Services

• 3 Years of specialized cleaning services
• Steam cleaning of restrooms, kick plates, tracks,
  kitchens, A/C vents, rolling stock, stainless
  steel equipment
• New state of the art line Dry Ice Blasting

4
Examples of Dry Ice Blasting
Before
After
Valves
5
Dry Ice Blasting

• CO2 dry ice pellets are blasted out at sonic
  speed to capture unwanted contaminants
• Dry Ice is harder than concrete
• Rapid Sublimation of CO2 Gas
• Solid CO2 expands 400-800 times its volume
• At -110oF there is a thermal shock effect
• Rapidly expanding CO2 gas creates a mini shock
  wave
• Foreign body freezes at a faster rate than host
• Falls off
• Loses adhesive properties

6
Examples of Dry Ice Blasting
Before
After
Wood
7
Dry Ice Blasting - Benefits

• Non conductive
• Non abrasive
• Non corrosive
• No solvents
• No water
• No detergents
• Environmentally friendly
• Faster
• Financially Smarter

• Will not profile metal surfaces
• Reduces Productive Down-Time

8
Examples of Dry Ice Blasting
Before
After
Rust and mold on ceiling
9
Dry Ice Blasting - Industries

• Aviation
• Pharmacology
• Rubber molding
• Shipping
• Fire restoration
• Printing
• Bakery

• Automotive
• Electrical
• Mold remediation
• Packaging
• Wood
• Hospitality
• Health

10
Examples of Dry Ice Blasting
Before
After
Screw
11
Dry Ice Blasting - Applications

• Motors
• Pipes
• Walls
• Concrete floor chewing gum

• Fire
• Rusted metals
• Nicotine stains
• Production lines
• Façade restoration

12
Examples of Dry Ice Blasting
Before
After
Copier
13
Method Comparison
Issue Traditional Dry Ice Blasting
Equipment Downtime Cleans in dedicated cleaning area Disassembly required Drying time required In-place equipment cleaning Restart equipment right after cleaning
Hazardous Waste Intensive hand scrubbing Lengthy cleaning Follow-up cleaning cumbersome Dramatically reduced Process time is 75 less
Cleaning Quality Poor to average Excellent
14
Examples of Dry Ice Blasting
Before
After
Rubber Molding
15
Method Comparison
Issue Traditional Dry Ice Blasting
Equipment Damage Grit abrasion Grit contamination Movement of equipment is damaging No equipment damage Preventive maintenance
Safety Health threats from solvents Water residue hazards for electrical Threats to environment Standard safety precautions Safe around electrical equipment
Cost Cleaner is additional haz waste Expensive solvents Additional labor Down-time cost is minimal
16
Examples of Dry Ice Blasting
Before
After
Electrical Box
17
Method Comparison
Cleaning Technique Waste for Disposal Abrasive Toxic Electrically Conductive
Dry ice No No No No
Sand Yes Yes No No
Glass beads Yes Yes No No
Walnut shells Yes Yes No No
Steam No No No Yes
Solvents Yes No Yes Yes
18
Examples of Dry Ice Blasting
Before
After
Industrial Bakery
19
Examples of Dry Ice Blasting
Before
After
Paint
20
Examples of Dry Ice Blasting
Engine Exhaust
21
Examples of Dry Ice Blasting
Building Exterior
22
Examples of Dry Ice Blasting
Paint Stripping
23
Examples of Dry Ice Blasting
Insulators
24
Examples of Dry Ice Blasting
Restoration of Utah State Seal
25
Examples of Dry Ice Blasting
Printing inkers
26
Examples of Dry Ice Blasting
Transformer
Semiconductor
27
