Integrated Silicon Photonics An Overview
Aniruddha N. Udipi
2
Whats wrong with electrical signaling?

• Power and delay fundamentally increase with
  length
• Repeaters can help with delay, but further
  increase power cannot afford this
• Signal integrity issues
• Limits on the number of drops (DIMMs, say)
• Long, fast, wide pick any two
• Very slow growth of pin count and per pin
  bandwidth
• Chip-edge and socket-edge bandwidth severely
  limited
• Increasing pressure due to increasing
  communication requirements with multi-thread,
  multi-core, multi-socket
• We need a disruptive new technology

3
Say Hello to Silicon Photonics

• Simply put, replace wires and electrons with
  waveguides and photons
• Advantages
• Lower energy consumption, distance independent
• Higher bandwidth, Dense Wavelength Division
  Multiplexing (DWDM)
• Better scalability, no pin limits
• In some cases, you simply cannot use electrical
  connections to satisfy the projected requirements
• Where?
• Started with large distances (Atlantic ocean
  large)
• Increased viability over smaller distances as
  technology improves and matures
• Next, interconnect inside datacenters - between
  racks
• Eventually, intra-rack, intra-board, intra-chip

4
Photonic Interconnect Basics
Laser
Detector
Channel
Modulator
01010001110 1
101110001010
Design Space Laser, modulation, channel,
detection
5
Photonic Components
6
On-chip Laser

• Vertical Cavity Surface Emitting Laser (VCSEL)
• One of the largest volume (and hence, cheapest)
  lasers currently in use
• Is often integrated on-chip
• Enables direct modulation
• You directly turn the laser on or off in
  accordance with the data being transmitted
• Not fully CMOS compatible
• Also, does not support DWDM

7
Off-chip Laser

• Distinct component, actual construction not
  important
• A single laser source can feed multiple channels
• You just have a power splitter with the laser
• Potential to be cost-effective in systems with
  multiple transmission channels (multiple memory
  channels, say)
• Needs external modulation
• Laser is on continuously, but you either block
  the light or not, depending on the data being
  transmitted
• Supports DWDM
• Under active consideration

8
Modulator
Courtesy D. Fattal and R. Beausoleil, HP Labs
output
output
Waveguide
input
input
OFF STATE
ON STATE
9
Modulator Operation

• How do you go between ON and OFF?
• Charge injection (HP Labs)
• Charge depletion (Sun)
• These rings can be made wavelength selective
  with proper sizing during fabrication
• There are also disc modulators similar
  operational principle, only the physical
  implementation is different

Courtesy Xu et al. Optical Express 16(6),
43094315 (2008)
10
Channel

• Silicon waveguide
• Used on-chip
• Moderate loss, crossover issues
• Hollow metal waveguide
• Used for slightly longer distances, at the board
  level
• Low loss, ease of fabrication
• Free space
• Just use air!
• Bunch of micro-mirrors and micro-lenses guide the
  light around
• On-chip use
• Fiber optic cable
• Off-chip interconnect

11
Miscellaneous Components

• Power splitters Y splitter divides the total
  power among several channels
• 12, 14, and 18 splitters available
• Other than drop in strength, signal is unaffected
• Detectors Seem to be simple photodetectors, I
  havent seen much variation or focus on this
  component
• Power guides
• Mux/Demux
• Couplers

Courtesy Beamer et al. ISCA 2010
12
Features / Design Considerations
13
Dense Wavelength Division Multiplexing

• One of the primary advantages of photonics
  excellent bandwidth density
• Each wavelength of light transmits one bit,
  supported by a bunch of wavelength selective
  ring resonators
• Each wavelength can operate independently
• Total number of supported wavelengths limited by
  increasing coupling losses between rings as
  spacing is tightened
• Up to 67 wavelengths theoretically possible
• Each wavelength can run at 10Gbps, giving a
  total of 80 GB/s of bandwidth per channel

14
Laser Power Considerations

• The detectors need to receive some minimum amount
  of photonic power in order to reliably determine
  0/1
• Depends on their sensitivity
• Going from source to destination, there are
  several points of power loss the waveguide, the
  rings, splitters, couplers, etc.
• Work backwards to determine total input laser
  power required
• Also some concerns about non-linearity, when
  total path loss exceeds a certain amount
• Rule of thumb 20dB

15
Static Power Considerations

• Modulating rings are sized at fabrication time to
  be tuned to a particular wavelength
• However, this tends to drift during operation
• Not only will this hurt this specific wavelength,
  but may also drift into adjacent wavelengths in
  DWDM systems, causing interference
• This drift can be controlled by heating, called
  trimming
• These heaters consume non-trivial amounts of
  power
• Large static power, cannot under-utilize or leave
  idle

16
Applications
17
My personal research focus

• Application to the processor-memory interface
• Ideal candidate in many respects
• Scalability, bandwidth, energy
• The questions were trying to answer
• how can we best apply photonics to the memory
  subsystem?
• Should we replace all interconnects with
  photonics?
• what would the role of electrical signaling be?
• how invasive would the required memory (DRAM)
  modifications be?
• Off-chip laser, external ring-based modulation,
  off-chip fiber and on-chip silicon waveguides

18
Interconnects in the Memory system
19
Photonics vs. electronics

• Photonics
• Lower dynamic energy
• Higher static energy
• Cannot be over-provisioned or left idle
• Perfect for the shared off-chip interconnect,
  helps break the pin barrier
• Electronics
• Higher dynamic energy
• Lower static energy
• Can be over-provisioned or left idle

20
How deep should photonics go on die?
Photonic Energy
Electrical Energy
21
Single-die system (Prior work)
Argues for specialized memory dies with photonics
deep inside in this case, one stop for each
quarter of the chip
22
But..

• Realistic systems cannot have a single die per
  channel
• You simply need more capacity
• 3D stacking
• Daisy-chaining of these 3D stacks
• Many more rings
• The effect of photonics static energy much more
  pronounced
• Argues for reducing photonic use
• How?

23
Proposed design
24
Proposed Design

• Introduce a 3D Stacked Interface Die
• This die contains all photonic components
• All further traversal is electrical
• TSVs to move between dies vertically
• Efficient low-swing wires on-die
• Helps break the pin-barrier
• Uses photonics on the heavily used shared
  off-chip interconnect, amortizes static energy
• Uses electrical signaling locally, where activity
  is low

25
An analogy
26
Realistic System
Use a single stop per stack, on the interface die
27
Advantages of the proposed system

• Energy consumption
• Fewer photonic resources, without loss in
  performance
• Rings, couplers, trimming
• Industry considerations
• Does not affect design of commodity memory dies
• Same memory die can be used with both photonic
  and electrical systems
• Same interface die can be used with different
  kinds of memory dies DRAM, PCM, STT-RAM,
  Memristors

28
Final System

• Compared to the best fully-optical extension of
  the state-of-the-art photonic DRAM design
• 23 reduced energy consumption
• 4X capacity per channel
• Potential for performance improvements due to
  increased bank count
• Non-disruptive to commodity memory design

29
High-radix Datacenter Routers (HP Labs)
30
Simplify!

• Need high dimension network to reduce hop count
• Bandwidth per port has to scale over time
• Photonics are perfect..
• Switch size unconstrained by device IO limits
• Port bandwidth scalable by increasing number of
  wavelengths
• Optical link ports can directly connect to
  anywhere within the data centre
• Greatly increased connector density, reduced
  cable bulk
• 64-128 DWDM port router possible

31
Macro-chips (Sun Labs, Oracle)

• Die sizes are limited by process yield
• For a given compute power requirement, therefore,
  you need several smaller chips
• Large bandwidth requirement between these chips
• With photonics, such a macro-chip design can
  approach a large chip performance

32
On-chip Interconnect (Rochester)
33
Ok, but when will all of this see light of day?

• Adoption will be gradual, over smaller distances
• km scale its already happened Under-sea
  cables
• 100m scale in progress
• m scale just starting
• cm scale in the lab but relatively ready
• mm scale also in the lab but not ready for
  prime time
• Technology exists, constantly being improved by
  smart people in labs all over the world
• Maturity, manufacturing infrastructure and cost
  are the big barriers
• Catch 22!
• First products expected in 1year (Intel Light
  Peak) USB replacement
• Optical backplane for server racks 2 years
• Fancier applications will likely take 5-8 years
