ADM291 A Tour of Sysinternals Tools

1
ADM291A Tour of Sysinternals Tools

• Mark RussinovichWinternals Software

2
About The Speaker

• Co-author of Inside Windows 2000, 3rd Ed.
  (Microsoft Press) with David Solomon
• Contributing Editor and NTInternals columnist
  forWindows and .NET Magazine
• Creator of www.sysinternals.com
• Co-founder and chief softwarearchitect of
  Winternals Software (www.winternals.com)
• Co-creator of Inside Windows 2000An interactive
  internals tutorial (on DVD streaming Windows
  media)

3
Outline

• About Sysinternals
• Monitoring Tools
• Systems Administration Tools
• File System Tools

4
About Sysinternals

• Started with NTFSDOS, Regmon and Filemon hosted
  on Andrew Schulmans site in mid-1996
• www.ntinternals.com went live in late 1996
• Under a dozen tools
• 1500 unique visitors/day

5
Sysinternals Today

• Interesting statistics
• 75 tools, 2-dozen technical articles
• 25,000 unique visitors/day
• 30,000 downloads/day (4 GB of data)
• 150,000 unique visitors/month
• 36,000 newsletter subscribers
• Almost 4-dozen KB-article references
• Everything on the site is freeware
• Cant redistribute without a license
• Source code is licensed for use in commercial
  products

6
Outline

• About Sysinternals
• Monitoring Tools
• Systems Administration Tools
• File-Related Tools

7
Monitoring

• Filemon
• Regmon
• Process Explorer
• TCPView

8
Filemon/Regmon

• Watch all file system or Registry accesses in
  real-time
• Ideal for troubleshooting broken application
  installations
• Useful for developers tracking down bugs or
  performance tuning file system access
• Work on all Windows OSs, including 64-bit
  Windows XP
• Used extensively within Microsoft
• PSS
• Windows XP Application Compatibility
• Microsoft Office 2000

9
Using Filemon/Regmon

• Requires no install or reboot
• Just start using them
• Includes filters for including, excluding, and
  highlighting output
• Cant include/exclude filter result codes on
  Filemon for WinNT/2K/XP
• Requires admin privilege to run
• Trick run once as admin and then you can use
  them as unprivileged users

10
How Filemon Works

• Filemon uses a driver to intercept file I/O
  access
• A VxD on Windows 9x/Me
• A file system filter driver on Windows
  NT/Windows 2000/Windows XP

Application
Filemon GUI
User Mode Kernel Mode
Filemon Driver
File System Driver
11
How Regmon Works

• Regmon uses a driver to intercept Registry
  operations
• A hook VxD on Windows 9x/Me
• A system-call intercepting driver on Windows
  NT/Windows 2000/Windows XP

Application
Regmon GUI
User Mode Kernel Mode
Regmon Driver
Registry Subsystem
12
Process Explorer

• Process Explorer (formerly HandleEx) starts where
  Task Manager ends
• See detailed information about running processes,
  including their paths and command-lines
• Description of EXE
• SID from process security token
• View the DLLs processes have loaded, including
  version numbers
• See what handles processes have opened
• Examine services running within service processes
• Process Explorer works on all Windows platforms

13
Common Process Explorer Uses

• Detect DLL versioning problems
• Compare the output from a good system with that
  of a broken system
• Use the search feature to determine what process
  is holding a file or directory open
• View the state of synchronization objects
  (mutexes, semaphores, events)
• Detect handle leaks using refresh difference
  highlighting

14
How Process Explorer Works

• Uses undocumented functions for
• Enumerating loaded modules with full path names
• Enumerating processes and handles
• Obtains handle names using the aid of a driver
• Related Tools
• Handle command-line handle viewer
• Listdlls command-line DLL viewer

15
TCPView

• GUI version of Netstat
• Works on all Windows platforms
• Lists active TCP and UDP endpoints
• Shows endpoint owner on Windows NT/2000/Windows
  XP/.NET Server
• Includes auto-refresh and difference highlighting
• You can close established TCP/IP connections
• Works using documented and undocumented IPHelper
  library functions

16
Other Monitoring Tools

• DebugView
• Monitor application debug output
• Diskmon
• Monitor hard disk activity
• Pmon
• Monitor process and thread activity
• Portmon
• Monitor serial and parallel port traffic
• Tokenmon
• Monitor security-related activity

17
Outline

• About Sysinternals
• Monitoring Tools
• Systems Administration Tools
• File-Related Tools

18
Systems Administration

• PsTools
• PsList
• PsKill
• PsInfo
• PsLogList
• PsService
• PsExec
• PsSuspend
• More
• BgInfo
• Autoruns

19
PsTools

• PsTools consists of a total of 11 tools
• They all work on Windows NT/Windows 2000/Windows
  XP
• They all work remotely as well as locally
• None require manual remote software installation
• Whered the Ps come from?
• The UNIX process listing tool is named ps
• The first PsTool was a UNIX ps-equivalent,
  PsList

20
PsList

• View detailed information about running
  processes
• Similar to tlist and pulist
• Default view is mix of CPU and memory information
• Other views show thread details, memory details,
  or full information
• Use the s switch to run it in a Task
  Manager-type mode
• Works using the performance counter API
• WMI is only available by default on Windows
  2000/Windows XP, not on Windows NT 4

21
PsKill

• The perfect complement to PsList is PsKill
• Similar to Resource Kit Kill and Remote Kill
• See a process running on a remote (or local)
  system with PsList, kill it with PsKill
• Unlike Task Manager, PsKill lets you kill any
  process if youre an admin
• Uses Debug privilege
• Uses auto-installed remote service and
  TerminateProcess API

22
PsInfo

• Get detailed information about a system
• OS version
• type (pro, server, etc.)
• Service Pack
• Hot-fixes
• CPU and memory
• Uptime
• Volume information
• Uses documented APIs
• Registry (remote, if applicable)
• WMI for XP product activation query

23
PsLogList

• Dump and optionally clear event logs
• Like eloglist from the Resource Kit
• PsLogList lets you dump logs using alternate
  credentials
• Gets event strings from remote system
• Like eloglist, dumps in tab-delimited format for
  easy import into spreadsheets
• Has extensive support for filtering on record
  type and date range
• Uses documented Event Log APIs, which work
  remotely

24
PsService

• Control Win32 services
• Like the Resource Kits and XP/Server 2003s SC
• Unlike SC, doesnt make you remember and manually
  specify a resume handle
• Same syntax as SC
• Omits several esoteric SC options
• Search the network for active instances of a
  service
• Uses documented Service Control Manager APIs,
  which work remotely

25
PsExec

• Remotely execute programs
• Executes console programs interactively
• Allows you to start programs as yourself , in
  alternate user credentials, or in the System
  account
• With PsExec you can
• Launch a remote command prompt to effect a
  light-weight telnet
• Remote-enable local only command-line tools
  like IpConfig
• Uses auto-installed remote service

26
PsExec

• Options of interest include
• -s Run in System account (instead of account of
  user running PsExec)
• -i Show GUI windows on interactive console
• -d Dont wait for remote process to terminate
• -c Copy an executable to the remote system

27
PsSuspend

• Microsoft provides no process-suspend utility
  like PsSuspend for pausing a process thats using
  a resource
• Memory
• CPU
• Network
• Windows NT and 2000 have no suspend process
  capability, so PsSuspend suspends individual
  threads

28
BgInfo (Background Info)

• If you manage more than a handful of systems,
  youve run into the what machine is this
  syndrome
• BgInfo creates an auto-generated informative
  desktop background
• System name
• Memory
• IP Address
• OS version
• Whatever you want!

29
Autoruns

• There are almost 2-dozen places that can be used
  to configure automatically started applications
• Autoruns shows you all of the locations and
  displays programs configured to run in them
• Double-click a folder or key to jump to it in
  Explorer or Regedit
• Double-click a configured application to view its
  properties

30
Outline

• About Sysinternals
• Monitoring Tools
• Systems Administration Tools
• File-Related Tools

31
File-Related Tools

• Contig
• PageDefrag
• Streams
• Strings

32
Contig

• Command-line Windows NT/Windows 2000/Windows XP
  file defragmenter
• Useful for
• Defragmenting specific files
• Creating new contiguous files
• Defragmenting entire disks
• Uses Windows NT/Windows 2000/Windows XP
  defragmenting API, documented at Sysinternals

33
PageDefrag

• Defragments paging files and Registry hives at
  boot time
• Implemented as native application
• Launched by Session Manager because listed in
  HKLM\System\CurrentControlSet\Control\Session
  Manager\BootExecute value
• Uses native API
• Uses Contig defragmentation engine
• Supports command-line options for scripted install

34
Streams

• Streams, which require NTFS, used to be rarely
  used
• Now there are several components that make use of
  them
• Services for Macintosh
• Explorer
• Viruses
• Streams can search directories for files with
  streams and display their names

35
Strings

• Some executables do not identify themselves with
  version information or descriptive names
• Strings will look inside a file image for
  printable text that include
• Registry key and value names
• Debug strings
• File names
• Internal build information

36
After Hours

• The Sysinternals Bluescreen Screen Saver

37
Check The Site Often

• There are updates, bug fixes, new tools and
  articles on a regular basis
• Im always open to tool suggestions
• Sign up for the newsletter to get inside
  information on the tools and Windows internals

38
For More Info...

• Video Inside Windows 2000 An Interactive
  Tutorial (on DVD Windows Media)
• 11 hours of instruction with hands-on lab
  exercises
• Book Inside Microsoft Windows 2000, Third
  Edition (Microsoft Press)
• Class Come to London Sep 23-25
• Dont forget to complete the on-line Session
  Feedback form on Attendee Web site
