Information Retrieval using the Boolean Model

1
Information Retrieval using the Boolean Model
2
Query

• Which plays of Shakespeare contain the words
  Brutus AND Caesar but NOT Calpurnia?
• Could grep all of Shakespeares plays for Brutus
  and Caesar, then strip out lines containing
  Calpurnia?
• Slow (for large corpora)
• NOT Calpurnia is non-trivial
• Other operations (e.g., find the phrase Romans
  and countrymen) not feasible

3
Term-document incidence
1 if play contains word, 0 otherwise
4
Incidence vectors

• So we have a 0/1 vector for each term.
• To answer query take the vectors for Brutus,
  Caesar and Calpurnia (complemented) ? bitwise
  AND.
• 110100 AND 110111 AND 101111 100100.

5
Answers to query

• Antony and Cleopatra, Act III, Scene ii
• Agrippa Aside to DOMITIUS ENOBARBUS Why,
  Enobarbus,
• When Antony found
  Julius Caesar dead,
• He cried almost to
  roaring and he wept
• When at Philippi he
  found Brutus slain.
• Hamlet, Act III, Scene ii
• Lord Polonius I did enact Julius Caesar I was
  killed i' the
• Capitol Brutus killed me.

6
Bigger document collections

• Consider N 1million documents, each with about
  1K terms.
• Avg 6 bytes/term incl spaces/punctuation
• 6GB of data in the documents.
• Say there are M 500K distinct terms among these.

7
Cant build the matrix

• 500K x 1M matrix has half-a-trillion 0s and 1s.
• But it has no more than one billion 1s.
• matrix is extremely sparse.
• Whats a better representation?
• We only record the 1 positions.

Why?
8
Inverted index

• For each term T store a list of all documents
  that contain T.
• Do we use an array or a list for this?

Brutus
Calpurnia
Caesar
13
16
What happens if the word Caesar is added to
document 14?
9
Inverted index

• Linked lists generally preferred to arrays
• Dynamic space allocation
• Insertion of terms into documents easy
• Space overhead of pointers

2
4
8
16
32
64
128
2
3
5
8
13
21
34
1
13
16
Sorted by docID (more later on why).
10
Inverted index construction
Documents to be indexed.
Friends, Romans, countrymen.
11
Indexer steps

• Sequence of (Modified token, Document ID) pairs.

Doc 1
Doc 2
I did enact Julius Caesar I was killed i' the
Capitol Brutus killed me.
So let it be with Caesar. The noble Brutus hath
told you Caesar was ambitious
12

• Sort by terms.

Core indexing step.
13

• Multiple term entries in a single document are
  merged.
• Frequency information is added.

Why frequency? Will discuss later.
14

• The result is split into a Dictionary file and a
  Postings file.

15

• Where do we pay in storage?

Terms
Pointers
16
The index we just built
Todays focus

• How do we process a Boolean query?
• Later - what kinds of queries can we process?

17
Query processing

• Consider processing the query
• Brutus AND Caesar
• Locate Brutus in the Dictionary
• Retrieve its postings.
• Locate Caesar in the Dictionary
• Retrieve its postings.
• Merge the two postings

128
Brutus
Caesar
34
18
The merge

• Walk through the two postings simultaneously, in
  time linear in the total number of postings
  entries

128
2
34
If the list lengths are x and y, the merge takes
O(xy) operations. Crucial postings sorted by
docID.
19
Basic postings intersection
20
Boolean queries Exact match

• Queries using AND, OR and NOT together with query
  terms
• Views each document as a set of words
• Is precise document matches condition or not.
• Primary commercial retrieval tool for 3 decades.
• Professional searchers (e.g., Lawyers) still like
  Boolean queries
• You know exactly what youre getting.

21
Example WestLaw http//www.westlaw.com/

• Largest commercial (paying subscribers) legal
  search service (started 1975 ranking added 1992)
• About 7 terabytes of data 700,000 users
• Majority of users still use boolean queries
• Example query
• What is the statute of limitations in cases
  involving the federal tort claims act?
• LIMIT! /3 STATUTE ACTION /s FEDERAL /2 TORT /3
  CLAIM
• Long, precise queries proximity operators
  incrementally developed not like web search

22
Query optimization

• What is the best order for query processing?
• Consider a query that is an AND of t terms.
• For each of the t terms, get its postings, then
  AND together.

Brutus
Calpurnia
Caesar
13
16
Query Brutus AND Calpurnia AND Caesar
23
Query optimization example

• Process in order of increasing freq
• start with smallest set, then keep cutting
  further.

This is why we kept freq in dictionary
Execute the query as (Caesar AND Brutus) AND
Calpurnia.
24
Query optimization
25
More general optimization

• e.g., (madding OR crowd) AND (ignoble OR strife)
• Get freqs for all terms.
• Estimate the size of each OR by the sum of its
  freqs (conservative).
• Process in increasing order of OR sizes.

26
Exercise

• Recommend a query processing order for

(tangerine OR trees) AND (marmalade OR skies)
AND (kaleidoscope OR eyes)
27
Beyond Boolean term search

• What about phrases?
• Proximity Find Gates NEAR Microsoft.
• Need index to capture position information in
  docs. More later.
• Zones in documents Find documents with (author
  Ullman) AND (text contains automata).

28
Evidence accumulation

• 1 vs. 0 occurrence of a search term
• 2 vs. 1 occurrence
• 3 vs. 2 occurrences, etc.
• Need term frequency information in docs.
• Used to compute a score for each document
• Matching documents rank-ordered by this score.

29
Evaluating search engines
30
Measures for a search engine

• How fast does it index
• Number of documents/hour
• (Average document size)
• How fast does it search
• Latency as a function of index size
• Expressiveness of query language
• Speed on complex queries

31
Measures for a search engine

• All of the preceding criteria are measurable we
  can quantify speed/size we can make
  expressiveness precise
• The key measure user happiness
• What is this?
• Speed of response/size of index are factors
• But blindingly fast, useless answers wont make a
  user happy
• Need a way of quantifying user happiness

32
Measuring user happiness

• Issue who is the user we are trying to make
  happy?
• Depends on the setting
• Web engine user finds what they want and return
  to the engine
• Can measure rate of return users
• eCommerce site user finds what they want and
  make a purchase
• Is it the end-user, or the eCommerce site, whose
  happiness we measure?
• Measure time to purchase, or fraction of
  searchers who become buyers?

33
Measuring user happiness

• Enterprise (company/govt/academic) Care about
  user productivity
• How much time do my users save when looking for
  information?
• Many other criteria having to do with breadth of
  access, secure access more later

34
Happiness elusive to measure

• Most common proxy relevance of search results
• But how do you measure relevance?
• Will detail a methodology here, then examine its
  issues
• Requires 3 elements
• A benchmark document collection
• A benchmark suite of queries
• A binary assessment of either Relevant or
  Irrelevant for each query-doc pair

35
Evaluating an IR system

• Note information need is translated into a query
• Relevance is assessed relative to the information
  need not the query
• E.g., Information need I'm looking for
  information on whether drinking red wine is more
  effective at reducing your risk of heart attacks
  than white wine.
• Query wine red white heart attack effective

36
Standard relevance benchmarks

• TREC - National Institute of Standards and
  Testing (NIST) has run large IR benchmark for
  many years
• Reuters and other benchmark doc collections used
• Retrieval tasks specified
• sometimes as queries
• Human experts mark, for each query and for each
  doc, Relevant or Irrelevant
• or at least for subset of docs that some system
  returned for that query

37
Precision and Recall

• Precision fraction of retrieved docs that are
  relevant P(relevantretrieved)
• Recall fraction of relevant docs that are
  retrieved P(retrievedrelevant)
• Precision P tp/(tp fp)
• Recall R tp/(tp fn)

Relevant Not Relevant
Retrieved tp fp
Not Retrieved fn tn
38
Accuracy a different measure

• Given a query an engine classifies each doc as
  Relevant or Irrelevant.
• Accuracy of an engine the fraction of these
  classifications that is correct.

39
Why not just use accuracy?

• How to build a 99.9999 accurate search engine on
  a low budget.
• People doing information retrieval want to find
  something and have a certain tolerance for junk.

Snoogle.com
Search for
0 matching results found.
40
Precision/Recall

• Can get high recall (but low precision) by
  retrieving all docs for all queries!
• Recall is a non-decreasing function of the number
  of docs retrieved
• Precision usually decreases (in a good system)

41
Difficulties in using precision/recall

• Should average over large corpus/query ensembles
• Need human relevance assessments
• People arent reliable assessors
• Assessments have to be binary
• Nuanced assessments?
• Heavily skewed by corpus/authorship
• Results may not translate from one domain to
  another

42
Information RetrievalPrabhakar RaghavanYahoo!
Research

• Lecture 1
• From Chapters 1,8 of IIR
