Welcome at Kaschke

1
Welcome at Kaschke

• We provide solutions

2

• Milestones of more than 50 years innovation
  customer orientation

Establishing the company by Mr. Kurt Kaschke in
Göttingen. Production of carbonyliron powder
cores
Start of ferrite production
Beginning of winding activities with HF-filters
for entertainment electronics
Establishing Kaschke Tunisie S.a.r.l. _at_ Menzel
Bou Zelfa/Tunisia - Production of inductive
components
Opening of the new logistics center in Göttingen
Establishing Kaschke Electronic _at_ Küllstedt /
Thuringia in Germany
2012
Increasing of the sinter capacity to 1000 t/a
2011
Introduction of filter chokes for airbag
applications for automotive electronics
2010
Increase capacity for AC/DC power chokes up to
8000 pcs/week (equal to 2 GW inverter power)
2009
2007
Silke Baumgartner,Joachim Priess Dr. Franz
Bötzl represend the management board
1995
1994
Introduction of the KLL-high power AC/DC choke
platform for solar inverters
1991
1978
1970
1958
1955
Establishing an injection moulding departement
for customised coilformers housings
3
Our strong market position

• We provide solutions

• Market activities are focused on five
• business areas, with major interest in
• industrial, medical and automotive electronics
• Worldwide sales sourcing network
• Balanced risk management due to a wide
• customer base
• No business area shares more
• than 40 of the annual turnover
• Stable financial situation within a family
• owned company

4

• Our mission our focus

• We provide inductive solutions for
• renewable energies
• smart grid
• energy efficiency

5
Business areas

• We provide inductive solutions for

6
Industrial electronics

• SMPS transformers
• PFC chokes
• Storage - chokes
• EMC-chokes for CM DM interference
• AC/DC POWER chokes based on
• Kaschke KLL technology up to 150amps
• Trigger transformers for IGBT MOS-FET
• Current sensors

7
Kaschke KLL- chokes for PV-inverter

• Launch in 2007
• Capacity 4 production lines 2000 chokes/week
• 100 final check
• - inductivity
• - high-voltage - impulse withstand voltage
  (Baker-Test)
• - acoustic measurement
• 5 years warranty
• Until now ca. 500.000 chokes have been
  manufactured for inverters lt 10KW
• 7 PV-customers for AC/DC chokes
• Until today there are only 4 known problems with
  the acoustic (ppm gt 10)
• 0 failure because of electrical parameters

8
Automotive electronics

• Body-electronics
• Powertrain
• Interior Infotainment
• Induktive Components for
• TPMS
• Immobilizer
• Keyless Go/Entry
• Electronic Powered Assisted Steering (EPAS/EPHS)
• eMobility

9
Lighting technology

• SELV transformers for halogen converters
• Driver transformers
• PFC- storage chokes
• Safety transformer for LEDs
• Lamp chokes for electronic ballasts
• EMC chokes for CM DM interference
• Ignition transformers for HID

10
Consumer electronics

• SmartPower safety transformers for
• stand-by low power supplies
• 2D - chokes for wireless energie transmission
• EMC chokes for CM DM interference
• PFC - chokes
• Current sensors
• Ferrite segments and bars for
• inductive cooking

11
Communication electronics

• SMPS - transformers
• SmartPower safety transformers for
• Stand-by low power supplies
• Hf-antennas
• Splitters baloons
• EMC - chokes for CM DM interference
• PFC - chokes
• Storage chokes

12

• The Kaschke headoffice at Göttingen

• Administration
• Sales sourcing departements
• R D
• Engineering departement
• Tool shop process control
• Powder- ferrite production (app. 1000t/a)
• Injection moulding department
• Logistics shipping center
• App. 200 employees

Göttingen
13

• Benefits of our Tunisian location

• European time zone (MEZ)
• Only two hours flight distance via Frankfurt
• Weekly shipments to Germany
• Online-communication with all production plants
• Upcomming industrial country with high education
  level and perfect infrastructure
• At German universities educated Tunesian
  executives German language
• Centuries old handcraft tradition meets
• state of the art production level

Frankfurt
3 DAYS
2 HOURS.
Genua
Tunis
14

• Kaschke Tunisia

• Production of the complete range of inductive
• components - more than 1500 different
• partnumbers/a
• App.1200 employees at two production locations,
  working two shifts per day
• - 6 fully automized production lines
• - app. 140 single head winding machines- 16
  multispindle winding machines
• - app. 70 toroid winding machines
• app. 130 mio. inductive components/a
• Continuous inspection after every production
  step -100 final test

Menzel Bou Zelfa
Tabarka
Tunis
Hammamet
Zaghouan
Sousse
Mahdia
Djerba
200 km
15

• Kaschke Tunesia

16

• Our Küllstedt plant

• Highly automated production of transpondercoils
  for automotive industrial applications
• RFID _at_125 kHz
• Keyless Go/Entry
• Immobilizers
• TPMS
• Antenna coils for hearing aid devices (_at_13 MHz)
• App. 40 employees
• App. 20 mio. transponder coils/a
• Fully supervised working steps
• 100 inspection according to poka yoke
• procedure AOI

Küllstedt
17

• Our Küllstedt plant

18

• Guaranteed quality

• 1990 Production supervision of all Tunisian

• plants by the German VDE
• 1993 Certification of the German location

• acc. to DIN EN ISO9000 ff.
• 1999 Certification of all Kaschke
  locations acc. to QS 9000
• 2001 Certification of all Kaschke
  locations acc. to ISO/TS16949
• 2005 Kaschke fulllfills the RoHS
• 2002/95/EG directive
• 2005 Kaschke offers an own class B F
  Insulationssystem acc. to UL 1446
• 2009 Kaschke Components certified acc. to
  ISO 90012008
• Kaschke Electronics certified acc. to
  ISO/TS 169492002

19

• Our first class service your benefit!

• Key account manangement worlwide operating
  sales team
• Strong R D engineering team supports
  customers at the start of theirdevelopment cycle
  Design to cost
• Close exchange with local universities
• Cooperation with silicon manufacturers
  e.g.Power Integrations, ST, Infineon
  Fairchild
• App. 98 customer specific designs
• We support logistc concepts i.e.
• - Canban systems
• - EDI
• - Consignment stock
• - Safety Stock management
• - VMI vendor managed inventory

20
Kaschke.de we provide solutions

• Thank you for your attention
