R12 Federal Financials Recent Enhancements and
Upgrade Impacts
Larry Baugh Apps Ingenuity LLC April 25,2012
3
Agenda

• Federal CGAC Enhancements
• Treasury Account Symbols, TAS BETC
• Budget Codes, FACTS Attributes, FACTS II Edit
  Codes
• Purge Treasury Account Symbols
• TAS/Fund/Bud Distributions Rollover
• GTAS
• Federal Multiple Cash Accounts and Treasury
  Confirmation Enhancement
• Managing SLA Changes in R12
• R12 Federal Payment Processing
• Web ADI Capability for FV Budget Distributions
• Expired Fund Distribution

Objective to share a variety of information on
R12 Updated functionality applicable to Federal
Financials customers.
4
Introduction

• Larry Baugh
• 13 years Oracle Federal Financials
  Functional/Technical Experience
• Emphasis Areas GL, Budget Execution, Fed Admin,
  AR, AP, Fed Reporting, PA, PO, iProc, Proc
  Contracts, XML/BI Publisher, Discoverer, SQL,
  PL/SQL, etc.
• Sample Federal Customers DOI-NBC,
  USAF/USTC-DEAMS, DFAS, TMA, SBA, Numerous DOE,
  DoD, and other Federal Civilian entities.
• Recent Role Solution Architect/Co-PM for US
  Dept. of Interior National Business Center
  (DOI-NBC) Shared Services Environment Release
  12.1.3 Upgrade

5
CGAC Enhancements

• The Common Government-wide Accounting
  Classification Structure (CGAC) is a new standard
  structure of financial data elements to be
  utilized within the US Federal Financial System
  environment.
• Oracle provided numerous enhancements to better
  support this CGAC integration. Patch 9000001
  should be installed to deploy this functionality.
  DO NOT just apply patch 9307787.
• MOS Note 1277072.1 Federal CGAC Enhancements

6
CGAC Enhancements
Treasury Account Symbols
Treasury Account Codes form is retired.
7
CGAC Enhancements
Treasury Account Symbols
8
CGAC Enhancements
Treasury Account Symbols
9
CGAC Enhancements
3-digit Agency Identifier values supported
10
CGAC Enhancements
Fund Attributes (aka Fund Parameters)
11
CGAC Enhancements
12
CGAC Enhancements
Business Event Type Codes (BETC)
13
CGAC Enhancements
Budget Codes
Budget Distributions
14
CGAC Enhancements
Purge Treasury Symbols
15
CGAC Budget Authority
The Enter Budget Authority form is quite similar
to the 11i Enter Appropriations form and Earlier
R12 form versions. The differences include

• Time Frame field replaced with Authority Duration
  Code
• Category field broken out into 2 distinct fields
  Apportionment Category Direct or Reimb
• Established FY field replaced with Beginning
  Period of Availability
• Transaction Code field replaced with Sub-Type

16
CGAC Funds Distributions
The R12 CGAC Enter Funds Distributions form.
Differences include

• Category field broken out into 2 distinct fields
  Apportionment Category Direct or Reimb
• From Distribution Description field added
• Transaction Code field replaced with Sub-Type

17
CGAC Budget Authority
When Checking Funds for Budget Distributions, R12
provides the capability to view specific
Budgetary Control Results Data.
18
CGAC Enhancements
Rollover Treasury Symbols
19
GTAS Enhancements
New Federal Financial enhancements are imminent
to provide agency capability for interfacing to
the Government wide Treasury Account Symbol
Adjusted Trial Balance System (GTAS) starting
Dec. 2012. References/Screenshots to Oracle
Federal Development GTAS info is taken from the
17-Apr-12 Oracle Federal Development Spring
Briefing. http//www.fms.treas.gov/gtas/index.htm
l
20
GTAS Enhancements
21
CGAC vs GTAS Enhancements
CGAC
GTAS
22
CGAC vs GTAS Enhancements
GTAS
CGAC
23
CGAC vs GTAS Enhancements
CGAC
GTAS
24
CGAC vs GTAS Enhancements
GTAS
CGAC
25
Key Federal-Related SLA Process Changes
11i R12
Dr 470001 179.94 Dr 470001 179.94
Cr 461051 179.94 Dr 461051 18.00
Dr 461051 197.94 Cr 480101 197.94
Cr 480101 197.94
The detail accounting entries for AutoCreated
Purchase Orders created in R12 is improved.
Instead of washing the transaction back and
forth through 46X051, the Commitment balance
will be liquidated and any price/quantity change
will impact Allotment Authority balances just for
the delta amount.
26
Key Federal-Related SLA Process Changes
Dr Cr
100 PO Manual Creation, Current Year BFY, Unexpired Dr 461051 100 Cr 480101 100
105 PO AutoCreation from 100 Req, Current Year BFY, Unexpired Dr 461051 5 Dr 470001 100 Cr 480101 105
Upward Revision of 5, to 100 Manually Created PO, Current Year BFY, Unexpired Cr 480101 100 Dr 461051 105 Dr 461051 100 Cr 480101 105
Upward Revision of 5, to 100 Manually Created PO, Prior Year BFY, Expired Cr 480101 100 Dr 465051 105 Dr 465051 100 Cr 480101 100 Cr 488101 5
Downward Revision of 5, to 100 Manually Created PO, Prior Year BFY, Expired Cr 480101 100 Dr 465051 95 Dr 487101 5 Dr 465051 100 Cr 480101 100
Upward/Downward Inflation Overstated PYA accounts
(e.g.4881), often due to various document
modifications, but not true Up/Down adjustments
The capability that SLA provides for
transaction-driven Upward/Downward Adjustment
entries is nice. However, there is currently not
a seeded solution for mitigating/correcting PYA
Inflation, other than through
Unreserve/Rereserve PYA suppression on the same
distribution_id.
27
FV Accounting Entry Journal Descriptions
As desired, the end-state GL journal entries from
Budget Distribution events (as well as others),
can contain enhanced journal line description
data which provides a quick glimpse of source
transaction detail attributes.
28
Viewing FV SLA Accounting Entries
Budget Distribution and Treasury Confirmation
accounting entries can now be viewed from the
subsidiary module, in addition to GL, via the
SLA User Main Menu available from Federal
Financial application responsibilities.
29
SLA Multiple Cash Accounts
Federal Multiple Cash Accounts and Treasury
Confirmation Enhancement MOS Doc ID 1314160.1
Oracles SLA solution for using different cash
accounts is tied to different bank account CCIDs
setup. There are other methods for this if
desired w/SLA, but these CCIDs must now be setup.
30
SLA AR Transaction Category Mapping
The seeded FV SLA AR design is dependent on the
AR Transaction Category Mapping.
31
Managing FV SLA Changes in R12

• Moving forward to uptake new enhancements is
  usually always a good thing, but due to the
  sensitivity and complexity of the R12 Federal SLA
  functionality, we must be a bit more careful with
  patching at this point in R12 than we might have
  been w/11i recently.
• Oracle makes mention of this issue in the patch
  9000001 readme
• "If customer has customized the following
  AADs, they might need to revisit the below AADs
  to make sure they have uptaken their Customized
  JLT per the new changes."
• however if you ask me, it should be in bold

32
Managing FV SLA Changes in R12

• Try to make sure your agency ( supporting
  contractors if applicable) get to know what is
  really going on with SLA under the hood. This
  will help you be able to identify what kind of
  patches could impact your SLA configuration and
  assess any level of rework required.
• Insulate your environment from changes to JLTs
  and ADRs by creating agency-specific versions.
• Although not easy, if youre in the process of an
  R12 upgrade project, try to baseline your SLA
  configurations objects as soon as possible, to
  mitigate re-work from additional changes that
  could come about from future SLA-related patches
  (rework would likely include reconfiguration time
  re-testing). Having to restart a R12 upgrade
  testing cycle due to a bunch of SLA Accounting
  updates wont make our R12 Upgrade Project
  Managers too happy.
• Once stable/in production, keep an eye out
  continually for patches that could throw your SLA
  rules for a loop, especially changes to the
  FV_SLA packages.

33
Managing FV SLA Changes in R12
34
Managing FV SLA Changes in R12
35
Managing FV SLA Changes in R12
36
R12 Federal Payment Processing

• With the new architecture of the core EBS Payment
  Processing solution in R12, Federal Payment
  Processing design has gone under wholesale
  change.
• Key changes include
• The introduction of the IBY Oracle Payments
  Manager GUI
• IBY Utilization of new XML and BI Publisher
  technology for payment file creation
• Introduction of new Payment Validation processes
  and edits
• Utilization of R12 Payment Reason Codes
• Any custom payment formats developed or tweaked
  in 11i will need to be recreated using the R12
  Oracle IBY/BI Publisher approach.

37
R12 Federal Payment Processing

• The new R12 Payments GUI is significantly
  different for creating Payment Process Requests
  (PPRs), i.e. the next generation of 11i Payment
  Batches

38
R12 Federal Payment Processing

• The Payment Formatting structure of a PPR is
  driven by the Payment Process Profile tagged to
  the PPR Instruction.

39
R12 Federal Payment Processing Design

• Payment Process Profile definitions are
  accessible via the Payment Administrator
  functionality.

40
R12 Federal Payment Processing Design

• Many standard US Treasury Federal Payment Formats
  are provided as seeded Payment Process Profile
  definitions in R12.
• Agency-specific Payment Process Profiles may need
  to be created to meet other requirements, e.g.
  ITS, Clearing, DoD Disbursing system integration,
  etc.

41
R12 Federal Payment Processing Design

• Payment Process Profile definitions are linked to
  IBY Payment Format records.

42
R12 Federal Payment Processing Design

• IBY Payment Formats are fundamentally comprised
  of BI Publisher Data Definitions and Templates.

43
R12 Federal Payment Processing Design

• This process flow does a great job of
  illustrating the new R12 IBY Payment Output flow.
• The Fund Disbursement XML extract is used as the
  baseline for all outbound payment formats,
  presented differently as required by the
  applicable eText BI Publisher Templates.
• Format Customization in Oracle Payments for
  Oracle Applications Release 12 ID 787467.1

44
R12 Federal Payment Processing Design

• Each R12 BI Publisher Payment format includes a
  mapping to the Funds Disbursement Extract as the
  Data Definition used, along with the eText BI
  Publisher template.

45
R12 Federal Payment Processing Design
The eText BI Publisher Templates are structured
similar to a Interface File Specification layout
and provides the capability for applying
additional functions to the XML data. A key
reference on eText BI Publisher Templates
is Oracle XML Publisher Report Designers
Guide, Chapter 4 Creating an eText Template
46
R12 Federal Payment Processing Design

• For agencies creating payment files for systems
  beyond the FV seeded list, there are multiple
  methods and components to address such
  requirements.
• If all the data required for outbound file
  creation is provided within the seeded Funds
  Disbursement XML Extract, then the requirement
  can likely be met through 1) creating a custom BI
  Pub Payment Format Template, registering the 2)
  Payment Format and 3) Payment Profile.
• If additional data is required beyond what is
  provided in the seeded Funds Disbursement XML
  Extract, then the IBY_FD_EXTRACT_EXT_PUB package
  can be used to extend the extract creation to
  include additional XML data elements as required.
• Key MOS Note Format Customization in Oracle
  Payments for Oracle Applications Release 12 ID
  787467.1

47
R12 Federal Payment Validations
R12 Payments provides new functionality of
Payment Validation processes. For Federal, a FV
Payment validation process is delivered for
seeded formats. Custom validations can also be
added. These seeded FV validation functions are
in the iby_payment_format_val_pvt package. In
11i, a number of these validations existed in the
Payment Format Code, but some have changed.
Example the TAS_VALIDATION function disallows
the use of dashes in FV Treasury Symbols any
further.
48
R12 Federal Payment Reason Codes
The R12 design to support required FV Payment
processing codes eliminates the 11i Paygroup-gtECS
Payment Type mapping and replaces it with Invoice
Payment Reason Codes.
Payment Reason codes are required on all PPD
Payments and some BD NCR Check Payments.
49
Creating FV Budget Dists with Web ADI
The new R12 Desktop Integration Framework
supports the capability to create a Web ADI
Integrator to load the fv_be_interface table
w/Budget Distribution details from an Excel ADI
worksheet.
50
Creating FV Budget Dists with Web ADI
51
Creating FV Budget Dists with Web ADI
Use the Desktop Integration Manager
responsibility to access the Wizard for creating
new integrators or maintaining.
52
Creating FV Budget Dists with Web ADI
Standard Interface or custom tables, as well as
PL/SQL APIs, can be populated via the R12 Desktop
Integration capability. The Desktop Integration
Wizard provides for configuring the integrator
characteristics of the target fields/parameters.
Fields can be enabled/disabled, defaulted, and
validated through the Wizard configuration.
53
Expired Fund Budget Distributions
For Federal Customers who need to move money
around in expired funds, this can now be done
through the Fed Admin Budget Distribution
Functionality instead of having to create manual
journal entries.
However, per 1356822.1, the FV BE Interface still
does not support Expired Year distributions.
54
Budgetary Control Result Details
Use the Check Funds function to view the detail
Budgetary Control Results for Budget
Distributions, Requisitions, Purchase Orders,
Releases and AP Invoices. Note not yet
available for iProcurement.
55
Can we get a MOS FV Community??
56
Additional Resources
Federal CGAC Related Enhancements ID 1277072.1
57
Thanks for attending
Larry Baugh Larry.Baugh_at_AppsIngenuity.com 303.351.
1130 Blog - http//www.OracleFedApps.com Twitter
- _at_OracleFedApps Be sure to check the blog for
the latest version of this presentation and other
info! Addl session R12 Federal Financials
Subledger Accounting Teardown Tuesday, 24-April,
1045 AM, South Seas A
