Title: Bitumen Overview India


1
Bitumen OverviewIndia
2
CONTENTS
  • OIL SECTOR OVERVIEW
  • INDIAN ROAD SECTOR
  • BITUMEN AND ITS PROPERTIES
  • VALUE ADDED BITUMEN

3
OIL INDUSTRY OVERVIEW
1st year of deregulation
4
PETROLEUM PRODUCTS DEMAND
Historical
Going forward
  • Consumption grew at a CAGR of 3.4 p.a. over the
    last 5 years
  • Production registered a CAGR of 12.5 p.a. during
    the same period
  • Demand expected to grow at a CAGR of 3.7 p.a.
    during next 5 years
  • Demand registered over 5 growth during FY2003

Source Company estimates FY03 MOPNG Sub-group
report for X Plan submitted to Planning Commission
Source PPAC, FY03 company estimates
5
CRUDE SELF SUFFICIENCY
The gap being met through imports
  • Self sufficiency levels declined over the years

Source Hydrocarbon Vision 2025
6
INDIAN ROAD SECTOR
7
INDIAN ROAD NETWORK
Length ( km )
NATIONAL HIGHWAYS 58,112
STATE HIGHWAYS 1,37,119
DISTRICT ROADS 4,70,000
RURAL ROADS 26,50,000
Total 3.3 MILLION Kms
INDIAN ROADS CARRY 85 OF PASSENGER TRAFFIC
70 OF FREIGHT TRAFFIC
8
ROAD CONSTRUCTIONSHIFTS TO HIGHER GEAR
  • HIGHWAYS BUILT 1947-97 2 Kms / Day
  • PROPOSED NHDP LENGTH 14000 Kms
  • DAILY PROGRESS 1998-03 5 Kms / Day
  • DAILY EXPENSES OF NHDP 10 ML. USD
  • FINAL PROGRESS OF NHDP 11 Kms/Day
  • ASSURED FUNDING MECHANISM IN PLACE

9
MAJOR PROJECTS
  • JAN 1999 TARGET OF DEC 2004 FOR 4/6-LANING OF
    5846 KMs HIGHWAY IN FIRST PHASE - GOLDEN
    QUADRILATERAL
  • SECOND PHASE ON 7300 KMs NE-SW CORRIDOR TO BEGIN
    ON JAN 2004 WITH TARGET OF DEC 07
  • SIMULTANEOUS DEVELOPMENT OF PORT ROADS, RURAL
    ROADS, STATE ROADS INTENSIFIED
  • B.R.O. PROJECTS

10
(No Transcript)
11
BITUMEN AND ITS PROPERTIES
12
BITUMEN DEMAND GROWTH
  • Bitumen demand is likely to grow at 12 per year
    for next five years
  • At this rate the demand in year 2004-05 would be
    3900 TMT

13
BITUMEN SEASONALITY
14
Bitumen - An introduction
  • LAST RESIDUE OF CRUDE OIL TREATED TO PRODUCE
    BITUMEN.
  • USED IN BUILDING AND PAVING SINCE ANCIENT TIMES.
  • OLDEST ADHESIVE KNOWN TO MAN.
  • USED IN 3500 B.C. AS MORTAR FOR BUILDING STONES
    AND PAVING BLOCKS IN MESOPOTAMIA.
  • USED FOR WATER TIGHTENING OF RESERVOIRS, CANALS,
    BATHING POOLS EMBANKMENTS OF RIVERS IN INDUS
    VALLEY.

15
Bitumen - An introduction (Contd.)
  • Streets of Babylon constructed in 2000 B.C. still
    in good shape.
  • Used for Mummification in 300 B.C.
  • Rock Asphalt used for flooring/sidewalks in
    France in 1800 A.D.
  • First road surfacing done in New Jersey in 1870
    A.D.
  • From 1900 onwards Bitumen produced from
    Refineries being used extensively.

16
Types of Bitumen
  • Conventional Bitumen
  • Paving Grade Bitumen
  • Industrial Grade Bitumen
  • Bitumen Emulsions
  • Modified Bitumen

17
Production Process
  • Produced by fractional distillation of Crude oil.
  • Crude Oil heated to 300 350OC in distillation
    column. Lighter fractions separated at different
    column heights. Bottom product called long
    residue.
  • Long residue heated upto 450OC in Vacuum
    distillation column. Bottom residue (short
    residue) used for manufacturing Bitumen.
  • Hot air is blown through short residue OR
    blended with superior quality bottom products to
    achieve desired consistency / penetration.

18
Advantages of Bituminous Roads
  • Initial saving fast construction low cost.
  • Ageless rehabilitation is inexpensive.
  • Stage Construction - in ribbons, not in slabs.
  • Safe High skid resistance Good Visibility
  • Better riding quality Less wear tear of
    vehicle, Low noise while cruising
  • Can be fully recycled.

19
Engineering Properties of Bitumen
  • A visco-elastic material Deformation under
    stress a function of temperature loading time.
  • At high temperature loading it behaves as
    viscous liquids, whereas at very low temperature
    or low loading it behaves as elastic solids.
  • In the intermediate range of temperatures /
    pressure, more typical of the conditions in road
    service, bitumen has visco-elastic behaviour.

20
Elemental Analysis
  • Carbon 82 - 88
  • Hydrogen 8 - 11
  • Sulphur 0 - 6
  • Oxygen 0 - 1.5
  • Nitrogen 0 - 1

21
Composition of Bitumen
  • Chemical composition depends on origin of Crude
    Oil and refining process.
  • Chemical composition is extremely complex.
    Astronomically large number of Molecules with
    different chemical structures. Not feasible to
    attempt a complete analysis of Bitumen.
  • Elemental composition of Bitumen provides little
    information of the types of molecular structure
    present in Bitumen.

22
Properties of BitumenIS 73 1992
  • Characteristics 80/100 60/70 30/40
  • Specific gravity at 27OC 0.99 0.99
    0.99
  • Softening Point OC 35 to 50 40
    to 55 50 to 65
  • Penetration at 25OC, 100gm, 80 to 100 60
    to 70 30 to 40
  • 5 secs., 1/10 mm
  • Ductility at 27OC, in cm min. 75 75 50

23
BITUMEN TESTS AND THEIR SIGNIFICANCE
  • PENETRATION TEST / SOFTENING PT.
  • INDICATES CONSISTENCY
  • LOSS ON HEATING / THIN FILM OVEN TEST
  • RATE OF HARDENING ON ROAD
  • DUCTILITY TEST
  • AFFINITY FOR AGGREGATES

24
Tests..
  • TRICHOROETHYLENE SOLUBILITY
  • INDICATES PURITY OF BITUMEN
  • VISCOSITY / SPECIFIC GRAVITY

25
Penetration
  • TRAVEL IN dmm OF A SPECIFIED NEEDLE UNDER 100 g
    Wt. FOR 5 SECONDS INTO BITUMEN AT 25 C.
  • DENOTES CONSISTENCY

26
Softening Point
  • 3.5 GM STEEL BALL PLACED ON SAMPLE OF BITUMEN IN
    BRASS RING
  • BATH TEMP RAISED AT 5 DEGREES PER MINUTE

27
DUCTILITY
  • Gives an indication of the extent to which a
    sample of the material can be stretched before
    breaking.
  • Length in cm. at breaking point is ductility

28
FLASH POINT
  • Used to measure the temperature to which a sample
    of bitumen may be safely heated
  • The flash point is the temperature reached when
    the vapour causes an instantaneous flash.

29
Recommended Handling Temperatures
  • Characteristics 80/100 60/70 30/40
  • Min. Pumping Temp.27OC 105 110 125
  • Mixing/Coating Temp. OC 150 to 163 150 to
    163 160 to 175
  • Laying Temp.OC 130 to 160
    130 to 160 140 to 160
  • Spraying Temp.OC 170 - -
  • Max. Safe Hdlng. Temp. OC 175 175 175

30
Selection of Grade of Bitumen
  • Choice of Bitumen is based on
  • Climatic Conditions - Maximum Minimum
    temperature rainfall.
  • Intensity of Traffic - Number of vehicles per
    day axle load of vehicles.

31
Applications of 80/100 Grade
  • Less viscous grade.
  • Used in all climatic conditions.
  • Suited for traffic load of less that 1500
    commercial vehicles/day.
  • Better suited for high altitude/snow bound
    regions irrespective of traffic intensity.

32
Applications of 60/70 Grade
  • More viscous grade. Higher softening point.
  • Suited for traffic intensity of more than 1500
    commercial vehicles/ day.
  • Can withstand heavier axle loads.
  • Suited for areas where difference between min.
    max. temp. is more than 25 o C.
  • Reduced stripping of Bitumen from Aggregate in
    presence of water.
  • Better suited for highways, expressways
    urban roads.

33
Applications of 30/40 Grade
  • Suited for traffic intensity of more than 1500
    commercial vehicles/ day.
  • Suited for areas where difference between min.
    max. temp. is less than 25 o C.
  • Used in metropolitan areas / airport runways.

34
VALUE ADDED BITUMEN
  • Binder of the future

35
RELATIVE PRICING OF VALUE ADDED BINDERS
  • BITUMEN 10000
  • EMULSION 11000
  • CRMB 12500
  • NRMB 13500
  • PMB 17000

36
WHY MODIFIED BITUMEN?
  • INCREASING DEMANDS ON ROAD
  • INCREASING NUMBER OF VEHICLES
  • INCREASING AXLE LOAD
  • INSISTENCE BY CLIENTS
  • DESIRE TO MAINTAIN HIGHER SERVICEABILITY LEVEL
  • CHANGING PATTERN OF CONTRACTS
  • INCLUDES LONG TERM MAINTENANCE

37
Modifiers under use
Synthetic Elastomers SBS, SBR etc.
Polymers
Rubbers
Plastics
Crumb Rubber
Natural Rubber (Latex)
Plain
Chemically Treated
Thermoplastic EVA
38
EMERGING DEMANDAN ASSESSMENT
39
CURRENT MARKET FEATURES
  • DOMINATION BY CRMB
  • VALUE FOR MONEY BINDER
  • TEST TRACKS / RESEARCH WORK SHOW EXCELLENT
    RESULTS
  • HIGH COST OF PMB A DAMPENER
  • INSISTENCE BY CLIENTS ON REFINERY MODIFIED
    BINDERS
  • HIGH GROWTH RATE ASSURED
  • EMULSION MARKET STAGNATED
  • TACK COAT ORIENTED
  • HIGH VOLUME APPLICATIONS YET TO BEGIN

40
CRUMB RUBBER MODIFIED BITUMEN
41
Crumb Rubber Modified Bitumen
  • Bitumen
  • Additives (Modifiers/Treated Crumb Rubber)

42
What is Crumb Rubber Modified Bitumen?
  • Crumb Rubber Modified Bitumen is Conventional
    Bitumen with treated Crumb Rubber Additive at
    high temperature which results in
  • Lower susceptibility to temp. variation
  • Higher resistance to deformation at high
    temperature
  • Better Age Resistance Properties
  • Higher Fatigue Life of Mixes
  • Better Adhesion Properties

43
Why Treat Crumb Rubber?
  • Be compatible with Bitumen.
  • Blend with Bitumen properly thoroughly.
  • Improve temperature resistance of Bitumen.
  • Resist degradation of Bituminous mix.
  • Be capable of being processed by conventional
    mixing plants and laying machinery.
  • Produce coating viscosity at application temp.
  • Maintain premium properties during
    storage,application and in service.
  • Be cost-effective considering life cycle cost.

44
Test and Trials with CRMB
  • Central Road Research Institute, New Delhi.
  • Highway Research Station, Chennai.
  • Gujarat Engineering Research Institute, Vadodara.
  • Indian Institute of Technology, Kharagpur.
  • Municipal Corporation of Delhi.
  • Research Station, P.W (RB) Dept., Hyderabad.,
    Andhra Pradesh.

45
Circular Test track study conducted by Highway
Research Station, Chennai
46
Tests conducted in Circular Test Track Study
  • Surface Evaluation
  • Skid resistance
  • Texture depth
  • Depletion values

47
STUDY RESULT
  • CRMB mixes indicate better resistance to
    deformation at high temperature - 1.5 times
    higher values of stability, Marshall quotient and
    stiffness modulus.
  • Higher indirect tensile strength and stiffness
    modulus - better resistance to cracking in
    structural layers.
  • Modified mixes in structural layers take higher
    traffic stresses due to higher values of
    stiffness modulus.
  • Tensile strength ratio before and after
    conditioning in water is higher - superior
    resistance to moisture damage.

48
CIRCULAR TEST TRACK STUDY CONCLUSION
  • The Highways Research Station has opined that
    the performance of modified bitumen stretch
    improves by 1.7 times than the conventional
    bitumen stretch.

49
Guidelines on use of Modified Bitumen
  • MORTH letter No. RW/NH-34041/36/90-SR(Vol. II)
    dated April 21, 1999 advised all States/UTs to
    use Modified Bitumen upto 10 for all works as
    it has been proved by field trials that the life
    of the road increases by 1.5 times.
  • IRC released new Specifications vide publication
    No. IRC-SP532002 FOR USE OF MODIFIED BITUMEN in
    road development activities in India.
  • MORTH vide letter No. RW/NH-34041/36/90-SR(Vol.
    II) dated 17, January 2000 requested all States
    to start using MODIFIED BITUMEN.
  • MORTH letter No. RW/NH-34041/36/90-SR(Vol. II)
    dated April 14, 2000 requested MOPNG to start
    Modified Bitumen production at Refinery level.

50
Guidelines on use of Modified Bitumen
  • MORTH vide their letter No. RW/NH-35072/1/2001-SR
    ( R ) dated June 21, 2001 has requested all
    States to encourage use of Modified Bitumen in
    view of its various advantages and improved
    performance over conventional Bitumen.
  • MORTH vide their letter No. RW/NH-33041/3/2001-SR
    dated June 13, 2002 has stated that It has been
    decided that keeping in view its advantages,
    polymer/rubber modified bitumen may be adopted in
    surfacing for the whole length, subject to
    availability.

51
CRMB Performance on Road
52
DEFORMATION OF SURFACE IN UNMODIFIED SECTION
53
PATCH WORK IN UNMODIFIED SECTION
54
POT HOLE IN KM-144 UNMODIFIED
55
TRANSVERSE CRACKING UNMODIFIED SECTION
56
A VIEW OF MODIFIED (CRMB) SECTION
57
CLOSE-UP OF MODIFIED SURFACE
58
GOOD SURFACE CONDITION OF MODIFIED SECTION
59
GOOD SURFACE OF MODIFIED BC
60
Grades of CRMB
61
Tests on Crumb Rubber Modified Bitumen
  • Penetration
  • Softening Point
  • Elastic Recovery
  • Thin Film Oven Test
  • Penetration
  • Softening Point
  • Elastic Recovery

62
Selection Criteria
63
Recommended Handling Temperatures
Stage of Work Viscosity, Poise Temp. Range, OC
Binder at Mixing lt 2 170 - 180
Mix at Mixing Plant lt 4 145 - 165
Mix at Laying Site lt 5 130 - 150
Rolling at Site 10 1,000 115 - 135
64
HANDLING OF CRMB
  • CRMB should ideally be used in hot condition.
  • When supplied in drums, it shall be agitated
    properly in melted condition for 10 - 15 minutes
    before use.
  • Mixing rolling temperature should be approx.
    10OC higher than conventional temperature.
  • Pneumatic tyre rollers should be avoided.

65
Field Trials Carried on CRMB
  • NH-1 NEAR AMBALA
  • SECUDERBAD-KUKATPALLI ROAD
  • BLR-KANAKAPURA HIGHWAY
  • NH-4,CHENNAI-BANGALORE ROAD
  • NH-5,CHENNAI-CALCUTTA
  • NH-8 at RAJIV CHOWK,NEAR GURGAON
  • NH0-1 A at UDHAMPUR, JAMMU
  • NH-25,LUCKNOW-JHANSI
  • INNER RING ROAD, HYD
  • INSIDE HRS CAMPUS,CHENNAI

66
Satisfied Clientele
  • P W D - Maharashtra
  • P W D - Madhya Pradesh
  • Major Private Contractors in Maharashtra
  • Ketan Constructions Ahmedabad Vadodara
    Expressway
  • Contractors in Orissa, A.P. Gujarat.

67
BITUMEN EMULSIONS
68
EMULSIONS IN DAILY LIFE
  • MILK
  • MEDICINES
  • PAINTS
  • ICE CREAM

69
BITUMEN EMULSIONS ??
  • BITUMEN EMULSION BITUMEN EMULSIFIER/ADDITIVES
    WATER
  • WATER CONTINUOUS PHASE
  • BITUMEN DISEPERSED PHASE
  • FREE FLOWING DARK BROWN LIQUID

70
EMULSIFICATION
  • BITUMEN MILLED INTO FINE PARTICLES HELD IN
    MOLECULAR SPACES OF WATER
  • USE OF CORRECT EMULSIFIER / CHEMICALS FACILITATE
    PROPER EMULSIFICATION

71
COLAS S.A. OF FRANCE
  • LARGEST CONSTRUCTION COMPANY IN THE WORLD
  • EXPERTS IN ROAD CONSTRUCTION
  • MANPOWER 40,000
  • TURNOVER
  • gt 40, 000 CRORES

72
HINDUSTAN COLAS LIMITED
  • INCORPORATED IN JULY 1995 AS A JOINT VENTURE
    COMPANY.
  • HINCOL EMULSIONS VERY WELL RECEIVED ALL OVER
    INDIA
  • FIRST PLANT AT MUMBAI IN 1996.
  • SECOND PLANT AT DELHI IN 1998.
  • THIRD PLANT AT CHENNAI IN 1999.
  • FOURTH PLANT BEING COMMISSIONED IN VIZAG.

73
PROJECTED DEMAND IN 000 MT
  • BITUMEN EMULSION
  • YEAR DEMAND DEMAND
  • 2002-03 2900 70 2.4
  • 2003-04 3500 105 3.0
  • 2004-05 4000 160 4.0
  • INTERNATIONAL NORM - 15 AVERAGE

74
WHY LOW CONSUMPTION IN INDIA ???
  • QUALITY
  • AWARENESS
  • INCLUSION OF SPECS IN DSR
  • GEOGRAPHICAL CONSTRAINTS
  • MYTH OF EXPENSIVENESS
  • NO MAJOR MANUFACTURER

75
TYPICAL USESOF EMULSIONS IN FRANCE
  • TACK COAT 12
  • SURFACE DRESSING 40
  • PATCH WORK 15
  • GROUTING 13
  • OTHER 20

76
WHY USE EMULSIONS ??
  • ECONOMY
  • ALL WEATHER APPLICATION (IDEAL FOR MONSOON
    APPLN.)
  • WORKER FRIENDLY
  • ENVIRONMENT FRIENDLY
  • EFFICIENCY

77
TYPES OF EMULSIONS
  • RAPID SETTING
  • MEDIUM SETTING
  • SLOW SETTING

78
APPLICATIONS
  • POT HOLE REPAIRS
  • TACK COAT
  • PRIME COAT
  • SURFACE DRESSING
  • PREMIX / LIQUID SEAL COAT
  • 20 MM PREMIX CARPET
  • FOG SPRAY/FOG SEAL/SLURY SEAL

79
PACKAGING
  • RECONDITIONED DRUMS
  • NEW DRUMS
  • BULK

80
THANK YOU
81
FUTURE ENERGY SCENARIO
Gas to replace the demand for oil and is expected
to constitute 20 of the energy supply by 2025
82
INITIATIVES BY GOVERNMENT
  • GOVERNMENTS VISION TO CREATE ROAD NETWORK
    WHICH IS BEST IN THE WORLD.
  • INITIATIVES
  • LEVY OF Rs. 1 PER LTR. CESS ON DIESEL AND PETROL
    EFFECTIVE 1999 FOR CENTRAL ROAD FUND ( 1.2
    BILLION PER YEAR) PLUS FUNDING BY ADB / WB PLUS
    PRIVATE SECTOR
  • SPECIFIC FUND ALLOCATION FOR NATIONAL HIGHWAYS,
    STATE HIGHWAYS, RAIL OVER BRIDGES, RURAL ROADS
    ETC.
  • SPECIAL FINANCIAL INCENTIVES PACKAGE FOR TAXES
    AND DUTIES APPLICABLE FOR ROAD PROJECTS
    ANNOUNCED
  • HIGH TRANSPARENCY AND FAST DECISIONS

83
FUNDING OF NHDP
84
MAJOR CHANGES INDIAN ROAD SECTOR
  • TILL 15 YEARS AGO - ROADS MADE BY STATE AND
    CONTRACTORS ONLY PROVIDED LABOUR / MACHINERY ETC.
  • DURING 1990s GOVERNMENT INCLUDED MATERIAL
    PROCUREMENT IN CONTRACTORS SCOPE
  • CHANGES FURTHER ACCELERATED BY MASSIVE
    INVESTMENTS PROPOSED IN ROAD SECTOR 1998 ONWARDS

85
COTRACTS AWARD METHODOLOGYMAJOR OVERHAUL
  • CHANGE FROM GOVT. SUPERVISED WORKS TO REWARD
    ORINETED EPC (ENGG, PLNG CONSTRN) WITH PMC
  • INCENTIVE FOR EARLY COMPLETION - 1 - 6
    DISINCENTIVE FOR DELAY
  • SEPARATE OM CONTRACTS FOR MAINTENANCE
  • ANNUITY BASED PROJECTS INCLUDING MAINTENANCE
    EXPERIMENTED

86
NORMAL BITUMEN DEMAND ?
  • INDIAS ANNUAL BITUMEN DEMAND 2800 TMT
  • PERIODICAL RENEWALS / MR NORMALLY NOT PER
    SCHEDULE
  • ADDITIONAL REQMT FOR NEW PROJECTS

87
Grades/Types of Bitumen
  • PAVING BITUMEN 80/100, 60/70, 30/40
  • Used in Road Construction worldwide.
  • Conforms to IS73 of 1992.
  • Industrial Bitumen
  • Conforms to IS702 of 1988.
  • Harder grades.
  • Used in water proofing, cable insulation, gunny
    bags, rubber industries, etc.
  • Not marketed by Oil Companies.

88
CLASSIFICATION OF BITUMEN EMULSION
  • ANIONIC - BITUMEN PARTICLE HAS NEGATIVE CHARGE
  • CATIONIC - BITUMEN PARTICLE HAS POSITIVE CHARGE
  • CATIONIC EMULSION HAS REPLACED ANIONIC EMULSION
    WORLDWIDE IN ROAD APPLNS.

89
BREAKING
  • ELECTROSTATIC ATTRACTION CAUSES BREAKING OF
    EMULSION
  • BITUMEN ve CHARGE
  • AGGREGATE -ve CHARGE
  • RESULT EXCELLENT BONDING / ANTISTRIPPING
    BETWEEN BITUMEN AGGREGATE

90
ECONOMY
  • NO HEATING COSTS
  • REDUCED MANPOWER COST
  • FASTER EXECUTION
  • ECONOMICAL IN APPLICATIONS LIKE TACK COAT

91
ENVIRONMENT / SAFETY
  • EMULSIONS RESPECT PEOPLE AND ENVIRONMENT
  • NO SMOKE/POLLUTION
  • CONSERVES WOOD/FUEL
  • IDEAL FOR CITY APPLICATIONS
  • WORKER FRIENDLY

92
MANUFACTURING
  • IMPORTED PLANTS
  • COLAS FORMULATIONS
  • PROPRIETARY PROCESS
  • IMPORTED RAW MATERIALS

93
QUALITY CONTROL
  • SOPHISTICATED LABORATORY
  • PARAMETERS CHECKED VISCOSITY BINDER
    CONTENT COATING PROPERTY SHELF
    LIFE PARTICLE CHARGE COAGULATION RE
    SIDUE ON 600 MICRON IS SIEVE

94
BIS SPECS 8887-1995
  • OBSOLETE SPECS 8887-1978 REVISED IN 1995
  • MAJOR CHANGES MADE IN BINDER CONTENT, SHELF LIFE
    AND QUALITY CONTROL CHECKS.
  • ALL HINCOL GRADES MEET OR EXCEED BIS 8887-1995
    SPECS

95
MOST REV.SPEC -2000
96
WHERE TO USE EMULSION?
  • FOLLOW THE THUMB RULE.
  • THUMB RULE IS BASED ON INTERNATIONAL PRACTICE AND
    ALSO AS PER MOST/ IRC SPECS.

97
APPLICATION OF HINCOL EMULSIONS
  • SESSION 2

98
RS - RAPID SETTINGAPPLICATIONS
  • TACK COAT
  • LIQUID SEAL COAT
  • GROUTING
  • SURFACE DRESSING
  • PATCH WORK

99
MS - MEDIUM SETTING APPLICATIONS
  • POTHOLE FILLING (PRE-MIX)
  • PATCH WORK
  • PRIME COAT
  • TACK COAT

100
SS - SLOW SETTINGAPPLICATIONS
  • PRIME COAT
  • SLURRY SEAL
  • PREMIX SEAL COAT
  • FOG SPRAY/FOG SEAL

101
PRIME COAT
  • OBJECTIVES PLUG CAPILLARY HOLES HARDENS /
    TOUGHENS BASE COURSE BONDS LOOSE
    PARTICLES ASSISTS ADHESION WITH NEXT LAYER
  • QUANTITIES RECOMMENDED LOW POROSITY SS TYPE
    6-9 KG / 10SQMT MED. POROSITY MS TYPE 9-12 KG
    / 10 SQMT HIGH POROSITY MS TYPE 12-15 KG / 10SQMT

102
SURFACE DRESSING
  • A THIN LAYER OF WEARING COURSE MADE OF
    SUPERIMPOSED LAYERS OF EMULSION AND METAL
  • FUNCTIONS
  • 1. PROVIDING WEARING SURFACE
    2. REHABILITATES WORN SURFACES 3. SHOULDERS ON
    A HIGHWAY 4. LOW VOLUME / LOAD OR
    REMOTE AREA ROADS

103
20 MM PREMIX CARPET
  • WEARING COURSE FOR LOW VOLUME ROADS
  • ECONOMICAL
  • FASTER EXECUTION
  • EMULSIONS OBVIOUS CHOICE PREPARING PRE-MIX ON
    THE SITE.

104
SEAL COAT
  • PROVIDES A SEAL TO STOP WATER ENTRY INTO ROAD
  • LIQUID SEAL COAT RS TYPE 12-14 KG / 10
    SQMT ONLY EMULSIONS RECOMMENDED
  • PREMIX SEAL COAT SS TYPE 10 - 12 KG / 10
    SQMT
About PowerShow.com
