Understanding Linux Kernel- Booting, Syscalls,
Interrupts Context Switching
By Jayant Upadhyay 2003CS50214 Pankaj K.
Sharma 2003CS50219 Sohit Bansal
2003CS50224 Akshay Gaur 2003CS50209
2
Overview of Booting

• The process can be divided into following six
  logical stages
• BIOS selects the boot device
• BIOS loads the boot sector from the boot device
• Boot-sector loads setup, decompression routines
  and compressed kernel image
• Kernel is uncompressed in protected mode
• Low level initialization is performed by the asm
  code
• High-level C initialization

3
BIOS POST

• POST Power On Self Test
• Power supply starts the clock generator and
  asserts POWERGOOD signal on the bus
• CPU RESET line is asserted
• POST checks are performed with interrupts
  disabled
• IVT initialized at address zero
• BIOS bootstrap function is invoked via INT 0x19.
  This loads track 0, sector 1 at physical address
  0x7C00(0x07C00000)

4
Boot-sector Setup

• The boot-sector to boot linux kernel could
  be either
• Linux boot-sector(arch/i386/boot/bootsect.S)
• LILO (or other bootloaders) boot-sector

5
Linux Boot-sector

• bootsector.S
• Firstly moves the bootsectors code from 0x7C00
  to 0x90000
• Then it jumps to the newly made copy of
  bootsector i.e. in segment 0x90000
• Prepares the stack at INITSEG0x4000-0xC
• This is where the limit on setup size comes from
• Setup sectors are loaded immediately after the
  bootsector i.e. at physical address using BIOS
  service INT 0x13

6

• If loading is failed due to some reason error
  code is dumped n it retry in endless loop
• If loading setup_sects sectors of setup code
  succeeded we jump to label ok_load_setup
• Kernel image is then loaded 0x10000. This is done
  to preserve the firmware data in low memory (
  0-64K )
• After the kernel is loaded we jump to
  SETUPSEG0(arch/i386/boot/setup.S)

7

• setup.S
• Once the data is no longer needed (e.g. no more
  calls to BIOS) it is overwritten by moving the
  entire (compressed) kernel image from 0x10000 to
  0x1000.
• sets things up for protected mode and jumps to
  0x1000 which is the head of the compressed
  kernel, i.e. arch/386/boot/compressed/head.S,misc
  .c
• This sets up stack and calls decompress_kernel()
  which uncompresses the kernel to address 0x100000
  and jumps to it.

8
How to load a big kernel?

• The setup sectors are loaded as usual at 0x90200,
  but the kernel is loaded 64K chunk at a time
  using a special helper routine that calls BIOS to
  move data from low to high memory.
• This helper routine is referred to by
  bootsect_kludge in bootsect.S and is defined as
  bootsect_helper in setup.S. The bootsect_kludge
  label in setup.S contains the value of setup
  segment and the offset of bootsect_helper code in
  it so that bootsector can use the lcall
  instruction to jump to it (inter-segment jump).
• This routine uses BIOS service int 0x15
  (ax0x8700) to move to high memory and resets es
  to always point to 0x10000. This ensures that the
  code in bootsect.S doesn't run out of low memory
  when copying data from disk.

9
Using LILO as bootloader

• There are several advantages in using a
  specialised bootloader (LILO) over a bare bones
  Linux bootsector
• Ability to choose between multiple Linux kernels
  or even multiple OSes.
• Ability to pass kernel command line parameters
• Ability to load much larger bzImage kernels - up
  to 2.5M vs 1M.
• Old versions of LILO (v17 and earlier) could not
  load bzImage kernels. The newer versions (as of a
  couple of years ago or earlier) use the same
  technique as bootsectsetup of moving data from
  low into high memory by means of BIOS services.

10
High Level Initialization

• By "high-level initialisation" we consider
  anything which is not directly related to
  bootstrap, even though parts of the code to
  perform this are written in asm, namely
  arch/i386/kernel/head.S which is the head of the
  uncompressed kernel. The following steps are
  performed
• Initialise segment values (ds es fs gs
  __KERNEL_DS 0x18).
• Initialise page tables.
• Enable paging by setting PG bit in cr0.
• Zero-clean BSS (on SMP, only first CPU does
  this).
• Copy the first 2k of bootup parameters (kernel
  commandline).
• Check CPU type using EFLAGS and, if possible,
  cpuid, able to detect 386 and higher.
• The first CPU calls start_kernel(), all others
  call arch/i386/kernel/smpboot.cinitialize_seconda
  ry() if ready1, which just reloads esp/eip and
  doesn't return.

11

• The init/main.cstart_kernel() is written in C
  and does the following
• Perform arch-specific setup (memory layout
  analysis, copying boot command line again, etc.).
• Print Linux kernel "banner" containing the
  version, compiler used to build it etc. to the
  kernel ring
• buffer for messages. This is taken from the
  variable linux_banner defined in init/version.c
  and is the same string as displayed by cat
  /proc/version.
• Initialise traps, irqs, data required for
  scheduler.
• Parse boot commandline options Initialise
  console.
• If module support was compiled into the kernel,
  initialise dynamical module loading facility.

12

• If "profile" command line was supplied,
  initialise profiling buffers.
• kmem_cache_init(), initialise most of slab
  allocator.
• Enable interrupts.
• Calculate BogoMips value for this CPU.
• Call mem_init() which calculates max_mapnr,
  totalram_pages and high_memory and prints out the
  "Memory ..." line.
• kmem_cache_sizes_init(), finish slab allocator
  initialisation.
• Initialise data structures used by procfs.
• fork_init(), create uid_cache, initialise
  max_threads based on the amount of memory
• available and configure RLIMIT_NPROC for
  init_task to be max_threads/2.

13

• Create various slab caches needed for VFS, VM,
  buffer cache, etc.
• If System V IPC support is compiled in,
  initialise the IPC subsystem. Note that for
  System V shm, this includes mounting an internal
  (in-kernel) instance of shmfs filesystem.
• If quota support is compiled into the kernel,
  create and initialise a special slab cache for
  it.
• Perform arch-specific "check for bugs" and,
  whenever possible, activate workaround for
  processor/bus/etc bugs. Comparing various
  architectures reveals that "ia64 has no bugs" and
  "ia32 has quite a few bugs", good example is
  "f00f bug" which is only checked if kernel is
  compiled for less than 686 and worked around
  accordingly.
• Set a flag to indicate that a schedule should be
  invoked at "next opportunity" and create a kernel
  thread init() which execs execute_command if
  supplied via "init" boot parameter, or tries to
  exe /sbin/init, /etc/init, /bin/init, /bin/sh in
  this order if all these fail, panic with
  "suggestion" to use "init" parameter.
• Go into the idle loop, this is an idle thread
  with pid0.

14
Interrupts and Exceptions

• Hardware support for getting CPUs attention
• Often transfers from user to kernel mode
• Nested interrupts are possible interrupt can
  occur while an interrupt handler is already
  executing (in kernel mode)
• Asynchronous device or timer generated
• Unrelated to currently executing process
• Synchronous immediate result of last instruction
• Often represents a hardware error condition
• Intel terminology and hardware
• Irqs, vectors, IDT, gates, PIC, APIC
• Interrupt handling data structures, flow of
  control
• Handlers softirqs, tasklets, bottom halves

15
Basic Ideas

• Similar to context switch (but lighter weight)
• Hardware saves a small amount of context on stack
• Includes interrupted instruction if restart
  needed
• Execution resumes with special iret instruction
• Structure top and bottom halves
• Top-half do minimum work and return
• Bottom-half deferred processing
• Handler code executed in response
• Possible to temporarily mask interrupts
• Handlers need not be reentrant
• But other interrupts can occur, causing nesting

16
Interrupts vs Exceptions

• Varying terminology but for Intel
• Interrupt (synchronous, device generated)
• Maskable device-generated, associated with IRQs
  (interrupt request lines) may be temporarily
  disabled (still pending)
• Nonmaskable some critical hardware failures
• Exceptions (asynchronous)
• Processor-detected
• Faults correctable (restartable) e.g. page
  fault
• Traps no reexecution needed e.g. breakpoint
• Aborts severe error process usually terminated
  (by signal)
• Programmed exceptions (software interrupts)
• int (system call), int3 (breakpoint)
• into (overflow), bounds (address check)

17
Vectors, IDT

• Vector index (0-255) into descriptor table (IDT)
• Special register idtr points to table (use lidt
  to load)
• IDT table of gate descriptors
• Segment selector offset for handler
• Descriptor Privilege Level (DPL)
• Gates (slightly different ways of entering
  kernel)
• Task gate includes TSS to transfer to (not used
  by Linux)
• Interrupt gate disables further interrupts
• Trap gate further interrupts still allowed
• Vector assignments
• Exceptions, NMI are fixed
• Maskable interrupts can be assigned as needed

18
PIC

• Programmable Interrupt Controller (PIC)
• chip between devices and cpu
• Fixed number of wires in from devices
• IRQs Interrupt ReQuest lines
• Single wire to CPU some registers
• PIC translates IRQ to vector
• Raises interrupt to CPU
• Vector available in register
• Waits for ack from CPU
• Other interrupts may be pending
• Possible to mask interrupts at PIC or CPU
• Early systems cascaded two 8 input chips (8259A)

19
Interrupt Handling Components
IRQs
Memory Bus
0
0
INTR
idtr
15
Mask points
255
20
IO-APIC, LAPIC

• Advanced PIC for SMP systems
• Used in all modern systems
• Interrupts routed to CPU over system bus
• IPI inter-processor interrupt
• Local APIC versus frontend IO-APIC
• Devices connect to front-end IO-APIC
• IO-APIC communicates (over bus) with Local APIC
• Interrupt routing
• Allows broadcast or selective routing of
  interrupts
• Need to distribute interrupt handling load
• Routes to lowest priority process
• Special register Task Priority Register (TPR)
• Arbitrates (round-robin) if equal priority

21
Intel Exceptions

• Architecture (processor) dependent
• Intel has about 20 (out of 32 possible)
• Most exceptions send signal to current process
• Default action often just kills process
• Page fault is the one exception very complex
  handler
• Some examples
• 0 SIGFPE Divide by zero error
• 3 SIGTRAP Breakpoint
• 6 SIGILL Invalid op-code
• 11 SIGBUS Segment not present
• 12 SIGBUS Stack overflow
• 13 SIGSEGV General protection fault (DPL
  violation)
• 14 SIGSEGV Page fault

22
Hardware Handling

• On entry
• Which vector?
• Get corresponding descriptor in IDT
• Find specified descriptor in GDT (for handler)
• Check privilege levels (CPL, DPL)
• If entering kernel mode, set kernel stack
• Save eflags, cs, (original) eip on stack
• -gt Jump to appropriate handler
• Assembly code prepares C stack, calls handler
• On return (i.e. iret)
• Restore registers from stack
• If returning to user mode, restore user stack
• Clear segment registers (if privileged selectors)

23
Nested Execution

• Interrupts can be interrupted
• By different interrupts handlers need not be
  reentrant
• No notion of priority in Linux
• Small portions execute with interrupts disabled
• Interrupts remain pending until acked by CPU
• Exceptions can be interrupted
• By interrupts (devices needing service)
• Exceptions can nest two levels deep
• Exceptions indicate coding error
• Exception code (kernel code) shouldnt have bugs
• Page fault is possible (trying to touch user
  data)

24
IDT Initialization

• Initialized once by BIOS in real mode
• Linux re-initializes during kernel init
• Must not expose kernel to user mode access
• start by zeroing all descriptors
• Linux lingo
• Interrupt gate (same as Intel no user access)
• Not accessible from user mode
• System gate (Intel trap gate user access)
• Used for int, int3, into, bounds
• Trap gate (same as Intel no user access)
• Used for exceptions

25
Exception Handling

• Some exceptions push error code on stack
• IDT points to small individual handlers
  (assembly)
• handler_name pushl 0 // placeholder if no
  error code pushl do_handler_name jmp
  error_code
• Common code sets up for C call
• Pops handler address from stack, calls
• All handlers check if kernel mode
• Exceptions caused by touching bad syscall params
• Return to userland with error code
• Other exceptions-gt die() // kernel Oops
• Most handlers just generate signal for current
• current-gttss.error_code error_code
• current-gttss.trap_no vector
• force_sig(sig_number, current)

26
Interrupt Handling

• More complex than exceptions
• Requires registry, deferred processing, etc.
• Some issues
• IRQs are often shared all handlers (ISRs) are
  executed so they must query device
• IRQs are dynamically allocated to reduce
  contention
• Example floppy allocates when accessed
• Three types of actions
• Critical Top-half (interrupts disabled
  briefly!)
• Example acknowledge interrupt
• Non-critical Top-half (interrupts enabled)
• Example read key scan code, add to buffer
• Non-critical deferrable Do it later
  (interrupts enabled)
• Example copy keyboard buffer to terminal handler
  process
• Softirqs, tasklets, bottom halves (deprecated)

27
IRQ, Vector Assignment

• PCI bus usually assigns IRQs at boot
• Vectors usually IRQ 32
• Below 32 reserved for non-maskable, execeptions
• Vector 128 used for syscall
• Vectors 251-255 used for IPI
• Some IRQs are fixed by architecture
• IRQ0 interval timer
• IRQ2 cascade pin for 8259A
• See /proc/interrupts for assignments

28
IRQ Data Structures

• irq_desc array of IRQ descriptors
• status (flags), lock, depth (for nested disables)
• handler PIC device driver!
• action linked list of irqaction structs
  (containing ISRs)
• irqaction ISR info
• handler actual ISR!
• flags
• SA_INTERRUPT interrupts disabled if set
• SA_SHIRQ sharing allowed
• SA_SAMPLE_RANDOM input for /dev/random entropy
  pool
• name for /proc/interrupts
• dev_id, next
• irq_stat per-cpu counters (for /proc/interrupts)

29
Interrupt Processing

• BUILD_IRQ macro generates
• IRQn_interrupt
• pushl n-256 // negative to distinguish syscalls
• jmp common_interrupt
• Common code
• common_interrupt
• SAVE_ALL // save a few more registers than
  hardware
• call do_IRQ
• jmp ret_from_intr
• do_IRQ() is C code that handles all interrupts

30
Low-level IRQ Processing

• do_IRQ()
• get vector, index into irq_desc for appropriate
  struct
• grab per-vector spinlock, ack (to PIC) and mask
  line
• set flags (IRQ_PENDING)
• really process IRQ? (may be disabled, etc.)
• call handle_IRQ_event()
• some logic for handling lost IRQs on SMP systems
• handle_IRQ_event()
• enable interrupts if needed (SA_INTERRUPT clear)
• execute all ISRs for this vector
• action-gthandler(irq, action-gtdev_id, regs)

31
Deferrable Functions

• Bottom-halves (deprecated)
• Old static array of function pointers that are
  marked for execution (can be masked temporarily)
• Executed on kernel to user transition
• Executed serially (globally) on SMP system
• Mostly for networking code
• Tasklets Different tasklets can execute
  concurrently
• Softirqs The same softirq can execute
  concurrently
• Layered implementation
• Bottom-halves implemented using tasklets
• Tasklets implemented using softirqs
• When executed? (pretty frequently)
• When last (nested) interrupt handler terminates

• When network packet receiver
• When idle per-cpu ksoftirqd kernel thread
• Lots of detail in book a bit complex

32
Return Code Path

• Interleaved assembly entry points
• ret_from_exception()
• ret_from_inr()
• ret_from_sys_call()
• ret_from_fork()
• See flowchart in text (Fig 4-5 page 158)
• Things that happen
• Run scheduler if necessary
• Return to user mode if no nested handlers
• Restore context, user-stack, switch mode
• Re-enable interrupts if necessary
• Deliver pending signals
• (Some DOS emulation stuff VM86 Mode)

33
System Calls
34
System Calls

• Interface between user-level processes and
  hardware devices.
• CPU, memory, disks etc.
• Make programming easier
• Let kernel take care of hardware-specific issues.
• Increase system security
• Let kernel check requested service via syscall.
• Provide portability
• Maintain interface but change functional
  implementation.

35
Mode, Space, Context

• Mode hardware restricted execution state
• restricted access, privileged instructions
• user mode vs. kernel mode
• dual-mode architecture, protected mode
• Intel supports 4 protection rings 0 kernel, 1
  unused, 2 unused, 3 user
• Space kernel (system) vs. user (process) address
  space
• requires MMU support (virtual memory)
• userland any process address space there are
  many user address spaces
• reality kernel is often mapped into user process
  space
• Context kernel activity on behalf of ???
• process on behalf of current process
• system unrelated to current process (maybe no
  process!)
• example interrupt context
• blocking not allowed!

35
36
POSIX APIs

• API Application Programmer Interface.
• Function defn specifying how to obtain service.
• By contrast, a system call is an explicit request
  to kernel made via a software interrupt.
• Standard C library (libc) contains wrapper
  routines that make system calls.
• e.g., malloc, free are libc routines that use the
  brk system call.
• POSIX-compliant having a standard set of APIs.
• Non-UNIX systems can be POSIX-compliant if they
  offer the required set of APIs.

37
Interrupts and Exceptions

• Interrupts - async device to cpu communication
• example service request, completion notification
• aside IPI interprocessor interrupt (another
  cpu!)
• system may be interrupted in either kernel or
  user mode
• interrupts are logically unrelated to current
  processing
• Exceptions - sync hardware error notification
• example divide-by-zero (AU), illegal address
  (MMU)
• exceptions are caused by current processing
• Software interrupts (traps)
• synchronous simulated interrupt
• allows controlled entry into the kernel from
  userland

37
38
Linux System Calls

• Invoked by executing int 0x80.
• Programmed exception vector number 128.
• CPU switches to kernel mode executes a kernel
  function.
• Calling process passes syscall number identifying
  system call in eax register (on Intel
  processors).
• Syscall handler responsible for
• Saving registers on kernel mode stack.
• Invoking syscall service routine.
• Exiting by calling ret_from_sys_call().

39
Linux System Calls

• System call dispatch table
• Associates syscall number with corresponding
  service routine.
• Stored in sys_call_table array having up to
  NR_syscall entries (usually 256 maximum).
• nth entry contains service routine address of
  syscall n.

40
Kernel Entry and Exit
exceptions (error traps)
trap
80h
boot
IPI inter- processor interrupt
device dialog
interrupt
page faults
40
41
Initializing System Calls

• trap_init() called during kernel initialization
  sets up the IDT (interrupt descriptor table)
  entry corresponding to vector 128
• set_system_gate(0x80, system_call)
• A system gate descriptor is placed in the IDT,
  identifying address of system_call routine.
• Does not disable maskable interrupts.
• Sets the descriptor privilege level (DPL) to 3
• Allows User Mode processes to invoke exception
  handlers (i.e. syscall routines).

42
The system_call() Function

• Saves syscall number CPU registers used by
  exception handler on the stack, except those
  automatically saved by control unit.
• Checks for valid system call.
• Invokes specific service routine associated with
  syscall number (contained in eax)
• call sys_call_table(0, eax, 4)
• Return code of system call is stored in eax.

43
Parameter Passing

• As the syscall number, user-space must relay the
  parameters to the kernel during the exception
  trap
• The parameters are stored in registers onx86,
  the registers ebx, ecx, edx, esi, and edi
  contain, in order, the first five arguments.
• In the unlikely case of six or more arguments, a
  single register is used to hold a pointer to
  user-space where all the parameters reside
• The return value is sent to user-space via
  register, eax on x86

44
Writing a system call for Linux

• Define its purpose, i.e., exactly one purpose
• Decide arguments, return value, and error codes
• Design the interface with forward compatibility
  in mind
• return appropriate error codes

• Verifying the Parameters The pointer points
  to a region of memory in user-space The
  pointer points to a region of memory in the
  processs address space If reading, the
  memory is marked readable. If writing, the memory
  is marked writable

45

• copy_to_user(usr_dst, krnl_src, len)
• copy_from_user(krnl_dst, usr_src, len)

• Asmlinkage long sys_scopy(unsigned long src,
  unsigned long dst, unsigned long len)
• unsigned long buf
• /fail if the kernel wordsize and user wordsize
  do not match /
• if (len ! sizeof(buf))
• return EINVAL
• if (copy_from_user(buf, src, len))
• return EFAULT
• if (copy_to_user(dst, buf, len))
• return EFAULT
• return len /return amount of data copied /

46
System Call Context

• In process context, the kernel is capable of
  sleeping (e.g., blocked on a call or calling
  schedule()) make use of the majority of the
  kernels functionality simplifying kernel
  programming
• In process context, the kernel is preemptible
  system calls must be reentrant (the current task
  may be preempted by another task that may then
  execute the same system call).

47
Blocking System Calls

• system calls may block in the kernel
• slow system calls may block indefinitely
• reads, writes of pipes, terminals, net devices
• some ipc calls, pause, some opens and ioctls
• disk io is NOT slow (it will eventually complete)
• blocking slow calls may be interrupted by a
  signal
• returns EINTR
• problem slow calls must be wrapped in a loop
• BSD introduced automatic restart of slow
  interrupted calls
• POSIX didnt specify semantics
• Linux
• no automatic restart by default
• specify restart when setting signal handler
  (SA_RESTART)

47
48
Linux Files Relating to Syscalls

• Main files
• arch/i386/kernel/entry.S
• System call and low-level fault handling
  routines.
• include/asm-i386/unistd.h
• System call numbers and macros.
• kernel/sys.c
• System call service routines.

49
arch/i386/kernel/entry.S

• Add system calls by appending entry to
  sys_call_table
• .long SYMBOL_NAME(sys_my_system_call)

50
include/asm-i386/unistd.h

• Each system call needs a number in the system
  call table
• e.g., define __NR_write 4
• define __NR_my_system_call nnn, where nnn is
  next free entry in system call table.

51
kernel/sys.c

• Service routine bodies are defined here
• e.g., asmlinkage retval
• sys_my_system_call (parameters)
• body of service routine
• return retval

52
Example System Calls

• sys_foo, do_foo idiom
• all system calls proper begin with sys_
• often delegate to do_ function for the real work
• asmlinkage
• gcc magic to keep parameters on the stack
• avoids register optimizations
• sys_ni_syscall
• just return ENOSYS!
• guards position 0 in table (catch uninitialized
  bugs)
• fills holes for obsolete syscalls or library
  implemented calls

52
53
Example System Calls sys_time

• kernel/time.c sys_time
• just return the number of seconds since Jan 1,
  1970
• available as volatile CURRENT_TIME (xtime.tv_sec)
• snapshot current time
• check user-supplied pointer for validity
• copy time to user space (asm/uaccess.hput_user)
• return time snapshot or error

53
54
Example System Calls sys_reboot

• kernel/sys.c sys_reboot
• require SYS_BOOT capability
• check magic numbers (0xfee1dead, Torvalds
  family birthdays)
• acquire the big kernel lock
• switch options
• shutdown in various ways restart, halt, poweroff
• user-specified shutdown command for some
  architectures
• toggle control-alt-delete processing
• go through reboot_notifier callbacks as
  appropriate
• unlock and return error if failure

54
55
Example System Calls sys_sysinfo

• kernel/info.c sys_sysinfo
• allocate a local struct to return info to user
  space
• disable (clear) interrupts to keep info
  consistent
• calculate uptime
• calculate 1, 5, 15 second load averages
• average length of run queue over interval
• use confusing int math to avoid floating-point
  inefficiency
• enable (set) interrupts
• return number of processes and some mem stats
• copy local struct values to user space
  (copy_to_user)

55
56
Context switch in Linux
57
Memory layout general picture
Process Y user memory
Process X user memory
Process Z user memory
Kernel memory
58
1 kernel stack after any system call, before
context switch
prev
ss
esp
eflags
cs
eip
orig_eax
es
ds
eax
ebp
edi
esi
edx
ecx
ebx
User Stack
User Code

TSS


tss-gtesp0
Schedule() function frame
Saved on the kernel stack during a transition to
kernel mode by a jump to interrupt and by
SAVE_ALL macro
task_struct
thread.esp0
59
2 stack of prev before switch_to macro in
schedule() func
prev

Schedule() saved EAX, ECX, EDX
Arguments to contex_switch()
Return address to schedule()
TSS
Old (schedules()) EBP
tss-gtesp0

60
3 switch_to save esi, edi, ebp on the stack
of prev
prev

Schedule() saved EAX, ECX, EDX
Arguments to contex_switch()
Return address to schedule()
TSS
Old (schedules()) EBP
tss-gtesp0

ESI
EDI
EBP
61
4 switch_to save esp in prev-gtthread.esp
prev

Schedule() saved EAX, ECX, EDX
Arguments to contex_switch()
Return address to schedule()
TSS
Old (schedules()) EBP
tss-gtesp0

ESI
EDI
EBP
62
5 switch_to load next-gtthread.esp into esp
next
prev


Schedule() saved EAX, ECX, EDX
Schedule() saved EAX, ECX, EDX
Arguments to contex_switch()
Arguments to contex_switch()
Return address to schedule()
Return address to schedule()
TSS
Old (schedules()) EBP
Old (schedules()) EBP
tss-gtesp0


ESI
ESI
EDI
EDI
EBP
EBP
esp
task_struct
thread.eip
1f
thread.esp
thread.esp0
63
6 switch_to save return address in the
prev-gtthread.eip
next
prev


Schedule() saved EAX, ECX, EDX
Schedule() saved EAX, ECX, EDX
Arguments to contex_switch()
Arguments to contex_switch()
Return address to schedule()
Return address to schedule()
TSS
Old (schedules()) EBP
Old (schedules()) EBP
tss-gtesp0


ESI
ESI
EDI
EDI
EBP
EBP
esp
task_struct
thread.eip
1f
1f
thread.esp
thread.esp0
64
7 switch_to save return address on the stack
of next
next
prev


Schedule() saved EAX, ECX, EDX
Schedule() saved EAX, ECX, EDX
Arguments to contex_switch()
Arguments to contex_switch()
Return address to schedule()
Return address to schedule()
TSS
Old (schedules()) EBP
Old (schedules()) EBP
tss-gtesp0


ESI
ESI
EDI
EDI
EBP
EBP
1f
esp
task_struct
thread.eip
1f
1f
thread.esp
thread.esp0
65
8 __switch_to func save the base of nexts
stack in TSS
next
prev


Schedule() saved EAX, ECX, EDX
Schedule() saved EAX, ECX, EDX
Arguments to contex_switch()
Arguments to contex_switch()
Return address to schedule()
Return address to schedule()
Old (schedules()) EBP
Old (schedules()) EBP


ESI
ESI
EDI
EDI
EBP
EBP
1f
esp
task_struct
thread.eip
1f
1f
thread.esp
thread.esp0
66
9 back in switch_to eip points to 1f
instruction label
next
prev


Schedule() saved EAX, ECX, EDX
Schedule() saved EAX, ECX, EDX
Arguments to contex_switch()
Arguments to contex_switch()
Return address to schedule()
Return address to schedule()
Old (schedules()) EBP
Old (schedules()) EBP


ESI
ESI
EDI
EDI
EBP
EBP
esp
task_struct
thread.eip
1f
1f
thread.esp
thread.esp0
67
10 switch_to restore esi, edi, ebp from the
stack of next
next
prev


Schedule() saved EAX, ECX, EDX
Schedule() saved EAX, ECX, EDX
Arguments to contex_switch()
Arguments to contex_switch()
Return address to schedule()
Return address to schedule()
Old (schedules()) EBP
Old (schedules()) EBP


esp
ESI
EDI
EBP
task_struct
thread.eip
1f
1f
thread.esp
thread.esp0
68
Thank you
