8
Why Use a Magnetic lock?

• High traffic openings.
• High security openings.
• Fail safe egress.
• Outdoor applications.
• Delayed egress systems.

9

• Dual monitoring points
• Unmatched defeat resistance
• No visual difference from standard model
• Increased weather/corrosion protection
• SPDT output
• Replaces SC on M32/62/82, M34R, SAM, IMXD
• Add B to part number

10
Electromagnetic Lock Terms

• BONDstat
• Lock status sensing signal which positively
  indicates that the door is secure.
• LED
• Extends through the back of the maglock to give
  visual status of the lock. With
• Senstat, green indicates powered and not secured
  while red indicates secured.
• Without Senstat, green indicates maglock is
  powered.
• Door Position Switch
• Provides remote signal indicating if the door is
  open or closed.
• Anti-Tamper Sensor
• Indicates if the wire access chamber has been
  tampered with or removed.
• Offset Strike
• Moves the mounting hole in the strike off center
  for doors with narrow top rail.
• Split Strike
• Two half strikes for one maglock for a pair of
  doors without center mullion. Holding force
• of each half reduced to ½ of full strike.
• Aerospace Collapsing Blind Nut
• Threaded nut that crimps onto frame and holds
  1000 lbs tensile strength per nut.

11
Direct Mount Magnalocks
M62
M32
M82B
12
Direct Mount Magnalocks
Features Benefits

• Blind nuts
• Steel machine screws
• Stainless steel case
• Completely sealed
• Instant release circuit
• Built in noise suppression
• Low current draw
• Smart dual voltage

• More mounting strength
• Adds to mounting strength
• Corrosion resistant
• Can be used outdoors
• No residual magnetism
• For access control systems
• Less power required
• Auto switching

13
M32600 lb Electromagnetic Lock

• Dual voltage Magnalock recommended for
  applications where physical assault on the door
  is not expected, such as controlled interior
  rooms and secure areas of a building.

• Voltage Rating
• 300mA _at_ 12VDC
• 150mA _at_ 24VDC

14
M621200 lb Electromagnetic Lock

• Dual voltage Magnalock recommended for exterior
  and perimeter doors through which criminals could
  gain entrance to cause substantial economic loss.

• Voltage Rating
• 250mA _at_ 12VDC
• 125mA _at_ 24VDC

15
DM62Double 1200 lb Electromagnetic Lock

• For double doors without a center mullion, the
  DM62 supplies two model M62 Magnalocks in a
  single brushed stainless steel housing.

• Voltage Rating
• 500mA _at_ 12VDC
• 250mA _at_ 24VDC

16
M821800 lb Electromagnetic Lock

• Dual voltage Magnalock with BondSTAT monitoring
  function standard. Preferred by prisons and
  detention facilities and also functions best on
  large, high security gates.

• Voltage Rating
• 350mA _at_ 12VDC
• 175mA _at_ 24VDC

17
M32/62/82B Ordering Information

• Holding force (600,1200,1800)
• In-swing or out-swing door (F type lock Z
  bracket)
• Type of mounting brackets needed
• Lock options (G,B,F)
• Armature options (SS,OS)

18
M34R600lb Recessed Magnalock
Designed for mounting in sliding doors. This
results in an aesthetically appealing finished
appearance. Recommended for applications where
physical assault on the door is not expected,
like access controlled interior doors and secure
areas within buildings.

• Voltage Rating
• 350mA _at_ 12VDC
• 175mA _at_ 24VDC

19
Bracket Mount Magnalocks
M68
M38
20
Why Use a Bracket Mounted Maglock?

• High traffic openings
• High security openings
• Fail safe egress
• Outdoor applications
• Delayed egress systems
• Adjustable mounting bracket
• Wiring to locks terminal block
• Available LED
• Available DPS
• Same lock used for in swing and out swing
  openings

21
Bracket Mounted Magnalock
Features Benefits

• Blind nuts
• Steel machine screws
• Dove tail bracket
• Aluminum case
• Splice chamber
• Available LED
• Available DPS
• Available tamper switch
• Instant release circuit
• Built in noise suppression
• Low current draw
• Smart dual voltage

• More mounting strength
• Adds to mounting strength
• No mounting bolts visible
• Common with competitors
• Easy electrical hook up
• Visible monitoring
• External DPS not required
• Alerts to tampering
• No residual magnetism
• For access control systems
• Less power required
• Auto switching

22
M38600 lb Electromagnetic Lock

• Dual voltage Magnalock with built in wire access
  chamber and bracket mount design for a unique
  method of installation. Recommended for
  applications where physical assault is not
  expected, like access controlled interior rooms
  and secure areas within buildings.

• Voltage Rating
• 350mA _at_ 12VDC
• 175mA _at_ 24VDC

23
M681200 lb Electromagnetic Lock

• Dual voltage Magnalock with built in wire access
  chamber and bracket mount design for a unique
  method of installation. Recommended for exterior
  and perimeter doors through which criminals could
  gain entrance to cause substantial economic loss.

• Voltage Rating
• 325mA _at_ 12VDC
• 175mA _at_ 24VDC

24
M38/68 Ordering Information

• Holding force (600,1200)
• In-swing or out-swing door (TJ bracket)
• Type of mounting brackets needed
• Lock options (D,L,S,T)
• Armature options (SS,OS)

25
(No Transcript)
26
SAM1200 lb Shear Electromagnetic Lock

• 1200 lb. holding force Shear Aligning Magnalock
  mounts fully concealed into wood, hollow metal or
  aluminum doors. SAM can be installed in any
  position on the door top, side or bottom and is
  ideal for swing through or sliding doors.

• Voltage Rating
• 350mA _at_ 12VDC
• 175mA _at_ 24VDC

27
SAM2-24600 lb Shear Electromagnetic Lock

• 600 lb. holding force 24VDC Shear Aligning
  Magnalock. SAM2-24 can be installed in any
  position on the door top, side or bottom and is
  ideal for swing through or sliding doors.
  Recommended for applications where physical
  assault is not expected, like access controlled
  interior rooms and secure areas within buildings.

• Voltage Rating
• 62mA _at_ 24VDC

28
SAM/SAM2-24 Features and Benefits

• Unique ramp up design, never binds
• Timing to apply power to lock is not an issue (no
  DPS or timer required)
• Self aligning operation
• Universal mounting in every door
• Optional magnetic bond sensor available (SAM
  only)
• The Instant Release Circuit
• Built in noise suppression
• Low current draw
• Smart dual voltage - auto switching (SAM only)

29
SAM/SAM2-24 Ordering Information

• Holding force (600,1200)
• Lock options (N,B) SAM only
• Surface mount kit (SMLS, SMSS) SAM only

30
SAM/SAM2-24
31
Magnalock Accessories
32
Magnalock Accessories
33
Maglock Mounting Brackets and Accessories
34
Magnetic LockMounting Brackets
Most maglocks require 2-1/2 in. Of flat mounting
space
35
Aluminum Shim Bracket (ASB)

• Needed on most aluminum doors.
• Used when blade stop requires maglock to be
  lowered.
• Comes pre-drilled for the mounting bolts and the
  wire
• Provides a blind nut for surface installation of
  the strike.
• Must specify model 32/62/82

36
Stop Filler Plates (SFP)

• Needed on most steel and wood frames
• Used to fill or extend a door stop
• Available in various thickness' (1/4, 3/8, 1/2,
  5/8)
• SFP-8 for models 32/62
• SFP-12 for model 38/68/82
• Does not come pre drilled

37
Universal Header Brackets (UHB)

• Used to extend the header 1 to 1-1/2
• Creating enough header to mount the magnet
• Also provides concealed wiring chamber
• UHB-8 for models 32/62
• UHB-12 for model 38/68/82

38
S.F.P. And U.H.B. Combination
39
Concrete Wood Bracket (CWB)

• Used on concrete filled metal frames
• Used on wood frames
• Easier than blind nuts in some cases
• Concealed wire run chamber
• Heavy duty wood and metal fasteners included
• Must specify 32/62/82

40
S.F.P. And C.W.B. Combination
41
Z Bracket and TJ Brackets

• Used on inswing doors
• Use face mount maglocks with Z bracket
• Use TJ bracket for bracket mounted maglocks
• Cover finish in brushed stainless, black or
  aluminum
• Must specify lock model

42
TJ Bracket and Z Brackets
43
MM15 4000lb E-Mag
The MM15 is a Maglock designed for interior or
exterior door where ultra-high security or
compact size are required. Using a hybrid design
with two spring loaded, hardened steel jaws. In
the event of a forced entry attempt, the jaws
rotate inward, clamping down and capturing the
edges of the armature.

• Voltage Rating
• 100mA DC, 130mA AC _at_ 12V
• 200mA DC, 250mA AC _at_ 24V

44
MM15 Features and Benefits

• 4000 lb holding force
• 12/24 volts AC/DC
• Mounting plate for ease of installation
• Optional DPS and tamper switch
• Optional ½ conduit prep.
• Compact size
• Indoor use only
• Dress covers available (black, polished brass,
  satin brass)
• SFP, HEB and Z brackets available
• Magnacare warranty
• UL/ ULC listed

45
MM15 Ordering Information

• Conduit fitting (G)
• Door Position/Tamper Switch option (DT)
• Conduit and Door Position/Tamper Switch option
  (GDT)

46
UNLUnLatch Strike
The UnLatch is for any application where an
electric strike would be used for a
cylindrical/tubular lockset. UnLatch supports
full dead latch function, releases under pressure
and includes a latch status monitoring output.

• Voltage Rating
• 40mA cont. 300mA min. when operating _at_ 12VDC
• 40mA cont. 200mA min. when operating _at_ 24VDC

47
UNL Features and Benefits

• Fits standard ANSI 4-7/8 strike cutout
• No cutting or alternating of the jamb required
• Motorized, no solenoids
• Fully concealed installation
• Maintains full dead latch function
• Continuous duty
• Releases under pre-load
• Latch status sensor standard (SPDT)
• UL listed for fire rated doors
• Available in Polished Brass (US03)

48
MUNLMortis UnLatch Strike
The Mortise UnLatch is for any application where
an electric strike would be used for a mortise
type lockset. The mortise UnLatch includes field
adjustability for latch and dead latch positions,
releases under pressure and includes a latch
status monitoring output.

• Voltage Rating
• 40mA cont. 700mA min. when operating _at_ 12VDC
• 40mA cont. 500mA min. when operating _at_ 24VDC

49
MUNL Features and Benefits

• Adjustable for use with most US mortise locks
• Fits standard ANSI 4-7/8 strike cutout
• No cutting or alternating of the jamb required
• Motorized, no solenoids
• Fully concealed installation
• Maintains full dead latch function
• Continuous duty
• Releases under pre-load
• Latch status sensor standard (SPDT)
• UL listed for fire rated doors
• Available in Polished Brass (US03)

50
Ordering Information

• Mortise or cylindrical hardware (UNL,MUNL)
• Voltage (12 VDC,24 VDC)

51
UnLatch
52
Mortise UnLatch
53
SASM Shock Absorbing Strike Mount
Kit
Features and Benefits

• Eliminates impact damage to lock
• Provides 1-1/8 of compression
• For all types of gate installations
• Converts standard M32/62/82 armature

54
GL1 2000lb Gate Lock
The GL1 Electromechanical Gate Lock is designed
to secure a wide variety of vehicle and
pedestrian gate applications where security and
weather resistance are required. The GL1
functions equally well in both electrically and
manually operated gate installations and can be
used for swing gates, sliding gates, stock cage
gates or other applications.

• Voltage Rating
• 290mA 870mA max (peak) _at_ 12VDC
• 170mA 720mA max (peak) _at_ 24VDC

55
GL1 Features and Benefits

• 2000 lb. holding force
• Operates under preload up to 100 lbs
• Automatic dual voltage
• Fail safe and fail secure versions available
• Self aligning receiver, /- ½ horizontally and
  vertically
• Threaded conduit fitting (1/2 ID)
• Hardened steel latch
• SPDT latch monitor switch
• Manual key override
• Weather resistant

56
MCL-24 200lb Magnalock
Typical applications include jewelry cases,
museum cases, gun cabinets, cash drawers and any
type of door or drawer which will physically
accommodate the lock.
Features and Benefits

• Fail Safe lock
• Easy installation using provided bracket
• Releases under pre-load
• Weatherproof

• Voltage Rating
• 62mA _at_ 24VDC

57
SCL 600lb Cabinet Lock
Typical applications include jewelry cases,
museum cases, gun cabinets, cash drawers and any
type of door or drawer which will physically
accommodate the lock.
Features and Benefits

• Fail Secure solenoid
• Easy installation
• Intermittent duty only
• Indoor use only

• Voltage Rating
• 400mA _at_ 12VDC
• 200mA _at_ 24VDC

58
M32SS Split Strike Cabinet Lock
300 lb holding force per strike. Typical
applications include retail display cases,
inventory cages and other openings that utilize
out-swing doors with a common center latching
point.
Features and Benefits

• Weatherproof
• Bond status output available
• Operates on 12 or 24 VDC

• Voltage Rating
• 150mA _at_ 12VDC
• 300mA _at_ 24VDC

59
TSB-3Touch Sense Bar
For use on magnetically locked, non fire-rated
doors. Touching the bar, even through light
gloves or clothing, trips an electronic sensor
which releases the lock. For indoor use only, the
TSB-3 can be installed on metal, aluminum, or
wood frame doors of all types. Meets no special
tools or knowledge code requirements.

• Voltage Rating
• 40mA max _at_ 12VDC
• 40mA max _at_ 24VDC

60
TSB-3 Features and Benefits

• Great for high traffic openings
• Cost effective compared to a mechanical bar w/
  switch
• 36, 42 and 48 standard lengths
• Can be field cut to length
• Aluminum and black finishes available
• Activates a DPST 2 amp relay when touched
• Backup emergency button on back of bar
• 16 ft. cable and armored door cord included
• Operates on 12 or 24 VDC
• UL listed

61
TSB-3 Ordering Information

• Opening width for TSB (36,42,48)
• Finish (CL,BK)
• TCP needed to cover panic bar holes

62
TSHTouch Sense Handle
For use on magnetically locked, non fire-rated
doors. Touching the handle, even through light
gloves or clothing, trips an electronic sensor
which releases the lock. For indoor use only, the
TSH can be installed on metal, aluminum, or wood
frame doors of all types. Meets no special tools
or knowledge code requirements.

• Voltage Rating
• 40mA max _at_ 12VDC
• 40mA max _at_ 24VDC

63
TSH Features and Benefits

• Great for high traffic openings
• For use on any push, pull or swing-through door
• Aluminum and black finishes available
• Activates a DPST 2 amp relay when touched
• Backup emergency button on back of bar
• 16 ft. cable and armored door cord included
• Operates on 12 or 24 VDC
• UL listed

64
SP-1Touch Sense Plate
The SP-1 uses patented touch sensing technology
to create a push panel with no moving parts. For
indoor use only, the unit is oversized so that it
can be mounted over a single gang cut-out. A
vinyl decal is included and a red LED is included
in the back box.

• Voltage Rating
• 40mA max _at_ 12VDC
• 40mA max _at_ 24VDC

Features and Benefits

• DPST 2 Amp relay
• Internal 0-25 second timer

65
SABLStand Alone Battery Lock
Engineered for high-traffic access control, the
SABL is perfect for new construction, or
retrofitting educational facilities, commercial
buildings or hospitals. Tampering with or even
destroying the keypad will not release the door.

• Batteries
• 6 AA alkaline batteries (included)

66
SABL Features and Benefits

• Based on the popular DK-26 Programming
• Tested to over 100,00 cycles on 6 AA batteries
  (included)
• Fits in standard ANSI 2-3/4 backset
• Weatherproof keypad with true 10 digit
  functioning
• Grade 1 lock, Clutched and vandal resistant
• Non-handed, available with PB handle (standard)
• UA handle available in 26D only
• 55 user codes, 2 passage and 2 lockout codes
• Rex input for hard wiring
• Four attractive architectural finishes available
• Several keyways available

67
SABL Ordering Information

• Keyway SC1, Yale, SGT, Best (SFIC) in all
  finishes
• Keyway Corbin RC, ASSA RC, Medeco RC Schlage
  SI RC in 26D only
• Finish (26,26D,03,10B)
• Handle type PB (AU 26D only)
• Without lock (NLK)
• Privacy function available (contact factory)

68
DK-26Digital Keypad System
The DK-26 is a indoor/outdoor weatherproof
digital keypad system designed for medium/high
security control of electric locks. It consists
of two components the narrow stile keypad and
CPU board. This allows the CPU board to be
mounted within the protected area for higher
security. Tampering with or even destroying the
keypad will not release the door.

• Voltage Rating
• 160mA max _at_ 12VAC/DC
• 190mA max _at_ 24VAC/DC

69
DK-26 Features and Benefits

• Cast stainless steel mullion mount keypad with
  rubber keys
• True10 digit keypad
• Red, green and yellow LED indicators bell
  button
• Remote CPU in metal enclosure for added security
• 59 user codes (expandable to 119)
• Wiegand output available
• User code and/or hard code disable feature
• 5 Amp DPDT lock/alarm shunt relay output
• Operates on 12 or 24 VAC or VDC
• REX input

70
DK-16Digital Keypad System
The DK-16 is an indoor single gang type digital
keypad system designed for medium/high security
control of electric locks. It consists of two
components the keypad and CPU board. This allows
the CPU board to be mounted within the protected
area for higher security. Tampering with or even
destroying the keypad will not release the door.

• Voltage Rating
• 160mA max _at_ 12VAC/DC
• 190mA max _at_ 24VAC/DC

71
DK-16 Features and Benefits

• Single gang true10 digit keypad
• Red, green and yellow LED indicators
• Remote CPU in metal enclosure for added security
• 59 user codes (expandable to 119)
• Wiegand output available
• User code and/or hard code disable feature
• 5 Amp DPDT lock/alarm shunt relay output
• Operates on 12 or 24 VAC or VDC
• REX input
• Weatherproof cover (WCC) and Back box (WBB)
  available

72
DK-16/26 Ordering Information

• Keypad type (DK-16,DK-26)
• Finish on DK-26 style keypad (SS,BK)
• Standard or expanded electronics (XP)

73
DK-11Digital Keypad
The DK-11 is a one piece unit designed for lower
security requirements. While primarily intended
for indoor operation, an optional rain cover
(WCC) and weatherproof back box (WBB) allow
reliable use for exterior areas not exposed to
direct rain.

• Voltage Rating
• 70mA max _at_ 12VDC
• 70mA max _at_ 24VDC

74
DK-11 Features and Benefits

• Single gang true10 digit keypad
• Red and green LED indicators
• One piece low security keypad
• 4 user codes
• 5 Amp SPDT lock relay output
• Operates on 12 or 24 VDC
• REX input
• Weatherproof cover (WCC) and Back box (WBB)
  available

75
Pushbuttons

• Various styles available (PB, PB2, PB3, PB4, PB5)
• Momentary and latching versions (A)
• Illuminated and non-illuminated versions (E)
• Single gang, narrow stile and surface mount
  versions (N, R)

76
EEBEmergency Exit Buttons
Features and Benefits

• When pushed, releases door for 30 seconds
• For use with XMS to meet life safety codes
• Single gang (EEB2)
• Narrow stile (EEB3N)
• SPST 3 amp wet NC contacts
• Operates on 12 or 24 VDC (must be same as lock)
• UL listed (indoor use only)

77
Keyswitches

• Various styles available (MK, KP1))
• Momentary and latching versions (A)
• Single gang and narrow stile versions (N)
• DPDT Versions (2) MK only
• Additional switch (MKS)
• Optional cylinder (MKC)

78
IMXDIntegrated Movement Exit Delay

• iMXD installation requires no alteration or
  replacement of existing fire rated or non fire
  rated latching hardware. False triggering is
  eliminated by the ample door movement.
  Applications include dementia wards, hospitals,
  dormitories, airports, child care facilities and
  retail stores.

• Voltage Rating
• 340mA max _at_ 12VDC
• 220mA max _at_ 24VDC

79
IMXD Features and Benefits

• Reverse action plunger with true door movement.
• Adjustable alarm point
• 12 or 24 VDC version available
• Allows door travel up to one inch
• Indoor use only
• 1200 lbs holding force magnalock
• Form C relay for remote monitoring
• Input for interfacing key switch, digital keypad,
  card reader or remote release switch
• Input to allow reset from secondary location
• UL Listed

80
IMXD
81
SB-MXDInitiate Device
The SB-MXD consists of several components which
will allow door movement to produce an initiate
signal for delayed exit as controlled by
Securitrons XDT logic timer.
82
Modular Exit Delay
83
BPS/BPSHBoxed Power Supply

• Recommended when an interface with a fire alarm
  system or back-up battery is needed. All BPS
  models are UL Class 2 listed, allowing for wire
  runs without the use of conduit from power supply
  to door. The BPS operates with 110VAC input and
  BPSH operates with 220VAC input.

84
BPS/BPSH Features and Benefits

• BPS (110VAC input) / BPSH (220VAC input)
• 1, 4 or 8 separate output circuit breakers based
  on model
• LEDs monitor zone status (voltage/no voltage)
• Slide switches connect/disconnect load from power
• Internal battery charging circuit standard
• Fire alarm interface standard
• Clean linear power
• Rugged steel enclosure
• UL Class 2 listed
• No conduit needed to run power from supply to
  load

85
BPS/BPSH Available Sizes
86
BPS/BPSH Ordering Information

• Voltage (12VDC, 24VDC)
• Amperage (1-15_at_ 12VDC, 1-10 _at_ 24VDC)
• Monitoring outputs for AC and battery (BPSM
  series)
• Low current fire alarm release (BPSM series)

87
BPSMMonitoring Power Supply
When interfacing with a fire alarm system Where
the systems auxiliary relay cannot handle the
full current potential of the power supply, or
when monitoring the power system for AC failure
or DC battery failure, the BPSM linear power
supply is the right choice. The power supplies
LED indicators and SPDT 3 Amp relay outputs
combine with BPS features to offer the next stage
of protection.
88
PMPower Supply

• The PM Series linear power supplies are regulated
  1 Amp DC supplies using plug in transformers.
  The PM Series includes AC fusing, DC output,
  automatic circuit breakers, battery charging and
  fire alarm compatibility.

89
PM Features and Benefits

• Emergency fire alarm release
• Separate plug in transformer
• Circuit board housed in a steel enclosure
• Does not require the services of an electrician.
  Regulated, adjustable power with connectors for
  lead acid/gel cell battery
• Clean linear power for flawless operation with
  all sensitive active electronic components

90
PSMPower Supply Monitor
The Power Supply Monitor can operate with all BPS
power supplies having capacities of 2 Amp or more
and functions as a power supply alarm system,
monitoring all key functions and reporting any
trouble.
Features and Benefits

• 12 and 24 VDC versions available
• Audio, visual and remote relay indicators
• Monitors 110V, DC output and load tests batteries

91

• PSP TP Series
• AC Power Supplies
• Batteries
• BR-7
• CCB Control Boards

92
Power Transfer Devices

• Armored door cord (TSB-C, TSB-CXL)
• Electrical Power Transfer (EPT, EPTL)
• Electric Hinge (EH-40, EH-45)

93
ZLPZone Light Panels

• Visual status of a lock or other device
• Red and green LEDs
• Versions (ZLP-1, ZLP-2, ZLP-4)

SLP-4 Switch Light Panel

• Control and monitor locks
• Momentary and latching versions (A)
• Red LEDs and green illuminated buttons

94
DT-77 Day Digital Timer

• 10 Amp DPDT relay contacts
• 12 on/off functions
• First Man In feature
• 12 or 24 VAC or VDC

TM-2Multi Function Timer

• 12 or 24 VAC or VDC operation

TM-9 Release Hold Timer

• 3 AMP SPDT relay energizes for 2-36 sec.

95
RLPRelay Logic Pack

• Used for latching relay or 2 door interlocks
• 1 Amp DPDT relay
• 12 and 24 VDC versions

RB-4Relay Board

• Four DPDT 2 Amp relays

DPA Door Prop Alarm

• Used to deter a door from being propped
• Activated by DPS or Mag bond status
• 12 and 24 VDC versions

96
MSS Maximum Security Switch
Used to monitor the open/closed status of doors,
windows, gates, safety barriers or other moving
assemblies.
MSS-1
Features and Benefits

• High security balanced door contacts
• Weatherproof
• Surface mount (MSS-1)
• Concealed (MSS-1C)
• Surface mount w/ armored cord (MSS-1G)
• Optional remote test feature (RT)

MSS-1C
MSS-1G
97
DPS-MDoor Position Switch for Metal Doors

• 500mA NC (SPST) contacts
• Larger magnet for metal doors/frames

DPS-WDoor Position Switch for Wood Doors

• 500mA NC (SPST) contacts

J-1055-04F Door Position Switch
for Wood Doors

• 500mA SPDT contacts

98
LM Latch Monitors
LML-1
The LM series is designed for reporting back to
an alarm system to indicate that a door is
latched, thereby reducing the possibility of
false alarms.
LML-2
Features and Benefits

• Easy to install
• SPDT 2 Amp contacts
• LMS-1 fits ANSI 2-3/4 cut out
• LML-1 fits ANSI 4-7/8 cut out
• LML-2 fits ANSI 4-7/8 cut out (SPDT x2)
• LMD for aluminum door deadbolt type locks

LMS-1
LMD
99
XMSExit Motion Sensor
The XMS Passive Infrared Request to Exit Device
is a motion detector specifically designed to
reliably release magnetic locks. A person
approaching the door is seen by the XMS just
before reaching the door.

• Voltage Rating
• 50mA max _at_ 12VDC
• 50mA max _at_ 24VDC

100
XMS Features and Benefits

• True Passive Infrared Request to Exit Device
• Designed to reliably release magnetic locks via
  transistor
• Separate SPDT REX output relay
• Easily adjustable pattern
• Adjustable release time
• Operates on 12 or 24 VDC
• For use with EEB to meet life safety codes
• UL listed

101
FARFire Alarm Reset
The Far is designed to work in conjunction with
Securitrons BPS and BPSM power supplies and the
fire alarm panel (by others). When the fire alarm
is activated the FAR will switch off the power
supplies outputs, the power will remain off even
if the fire alarm is reset. Power is restored
only when the FAR is manually reset.
102
LCPLock Control Panels

• Control and monitors any DC electric lock
• Desktop, rack mount and flush or
  surface wall mounted versions
  available
• Upgrade options available

ZAP Zone Annunciation Panels

• Monitors any NC switch
• Desktop and flush mounted versions
  available
