Chapter 3 INDUCTION MOTOR

BEE2133 ELECTRICAL MACHINE POWER SYSTEM

Learning Outcomes

- At the end of the lecture, student should be able

to - Understand the principle and the nature of single

phase and 3 phase induction machines. - Perform an analysis on induction machines which

is the most rugged and the most widely used

machine - in industry.

CHAPTER OUTLINE

- 3.1 Introduction
- 3.2 Overview of single phase IM
- 3.3 Overview of Three-Phase IM
- 3.4 Construction
- 3.5 Principle of Operation
- 3.6 Equivalent Circuit
- Armature reaction
- Power Flow, Losses and Efficiency
- Torque-Speed Characteristics
- 3.7 Speed Control

NJ

FKEE, UMP

3.1 INTRODUCTION

- A induction machine can be used as either a

induction generator or a induction motor. - IM transform electrical energy into mechanical

energy - IM is a type of asynchronous AC motor where power

is supplied to the rotating device by means of

electromagnetic induction

4

NJ

FKEE, UMP

3.1 INTRODUCTION

- popularly used in the industry and are used

worldwide in many residential, commercial,

industrial, and utility applications. - Main features cheap and low maintenance
- (absence of brushes)
- Main disadvantages speed control
- is not easy

5

NJ

FKEE, UMP

3.2 OVERVIEW OF SINGLE PHASE IM

- Construction similar to 3? induction motor
- A single-phase motor is a rotating machine that

has both main and auxiliary windings and a

squirrel-cage rotor. - Supplying of both main and auxiliary windings

enables the single-phase machine to be driven as

a two-phase machine.

6

MZS

FKEE, UMP

3.2 OVERVIEW OF SINGLE PHASE IM

- Home air conditioners
- Kitchen fans
- Washing machines
- Industrial machines
- Compressors
- Refrigerators

3.2 OVERVIEW OF SINGLE PHASE IM

- Types of 1? induction Motor
- Split Phase Motor
- Capacitor Start Motors
- Capacitor Start, Capacitor Run
- Shaded Pole Induction Motor
- Universal Motor (ac series motors)

3.3 OVERVIEW OF 3 PHASE IM

- Simple and rugged construction
- Low cost and minimum maintenance
- High reliability and sufficiently
- high efficiency
- The speed is frequency dependent
- ? not easily to control the speed
- ? thanks to power e

NJ

FKEE, UMP

3.3 OVERVIEW OF 3 PHASE IM

- can be part of a pump or fan, or connected to

some other form of mechanical equipment such as a

winder, conveyor, or mixer.

10

NJ

FKEE, UMP

3.4 CONSTRUCTION

- Basic parts of an AC motor rotor, stator,

enclosure - The stator and the rotor are electrical circuits

that perform as electromagnets.

NJ

FKEE, UMP

3.4 CONSTRUCTION (stator)

- The stator - stationary part of the motor.
- Stator laminations are stacked together forming a

hollow cylinder. - Coils of insulated wire are inserted into slots

of the stator core. - Each grouping of coils, together with the steel

core it surrounds, form an electromagnet.

3.4 CONSTRUCTION (rotor)

- The rotor is the rotating part of the motor
- It can be found in two types
- Squirrel cage (most common)
- Wound rotor

NJ

FKEE, UMP

3.4 CONSTRUCTION (rotor)

- Squirrel cage type
- Rotor winding is composed of copper bars embedded

in the rotor slots and shorted at both end by end

rings - Simple, low cost, robust, low maintenance

14

NJ

FKEE, UMP

3.4 CONSTRUCTION (rotor)

- Wound rotor type
- Rotor winding is wound by wires. The winding

terminals can be connected to external circuits

through slip rings and brushes. - (similar with DC motor, with the coils connected

together that make contact with brushes) - Easy to control speed, more expensive.

15

NJ

FKEE, UMP

3.4 CONSTRUCTION (enclosure)

- The enclosure consists of a frame (or yoke) and

two end brackets (or bearing housings). The

stator is mounted inside the frame. The rotor

fits inside the stator with a slight air gap

separating it from the stator (NO direct physical

connection)

NJ

FKEE, UMP

3.4 CONSTRUCTION (enclosure)

- The enclosure protects the electrical and

operating parts of the motor from harmful effects

of the environment in which the motor operates. - Bearings, mounted on the shaft, support the rotor

and allow it to turn. A fan, also mounted on the

shaft, is used on the motor shown below for

cooling.

NJ

FKEE, UMP

Nameplate

NJ

FKEE, UMP

3.5 PRINCIPLE OF OPERATION

19

NJ

FKEE, UMP

3.5 PRINCIPLE OF OPERATION

20

NJ

FKEE, UMP

Rotating Magnetic Field

- When a 3 phase stator winding is connected to a 3

phase voltage supply, 3 phase current will flow

in the windings, which also will induced 3 phase

flux in the stator. - These flux will rotate at a speed called a

Synchronous Speed, ns. The flux is called as

Rotating magnetic Field - Synchronous speed speed of rotating flux
- Where p is the number of poles, and
- f the frequency of supply

NJ

FKEE, UMP

Slip and Rotor Speed

- Slip s
- The rotor speed of an Induction machine is

different from the speed of Rotating magnetic

field. The difference of the speed is called

slip. - Where ns synchronous speed (rpm)
- nr mechanical speed of rotor (rpm)
- under normal operating conditions, s 0.01

0.05, which is very small and the actual speed is

very close to synchronous speed. - Note that s is not negligible

NJ

FKEE, UMP

Slip and Rotor Speed

- Rotor Speed
- When the rotor move at rotor speed, nr (rps), the

stator flux will circulate the rotor conductor at

a speed of (ns-nr) per second. Hence, the

frequency of the rotor is written as - Where s slip
- f supply frequency

NJ

FKEE, UMP

Principle of Operation

- Torque producing mechanism
- When a 3 phase stator winding is connected to a 3

phase voltage supply, 3 phase current will flow

in the windings, hence the stator is energized. - A rotating flux F is produced in the air gap. The

flux F induces a voltage Ea in the rotor winding

(like a transformer). - The induced voltage produces rotor current, if

rotor circuit is closed. - The rotor current interacts with the flux F,

producing torque. The rotor rotates in the

direction of the rotating flux.

NJ

FKEE, UMP

Direction of Rotor Rotates

- Q How to change the direction of
- rotation?
- A Change the phase sequence of the
- power supply.

NJ

FKEE, UMP

Equivalent Circuit of Induction Machines

- Conventional equivalent circuit
- Note
- Never use three-phase equivalent circuit. Always

use per- phase equivalent circuit. - The equivalent circuit always bases on the Y

connection regardless of the actual connection of

the motor. - Induction machine equivalent circuit is very

similar to the single-phase equivalent circuit of

transformer. It is composed of stator circuit and

rotor circuit

NJ

FKEE, UMP

Equivalent Circuit of Induction Machines

- Step1 Rotor winding is open
- (The rotor will not rotate)
- Note
- the frequency of E2 is the same as that of E1

since the rotor is at standstill. At standstill

s1.

NJ

FKEE, UMP

Equivalent Circuit of Induction Machines

NJ

FKEE, UMP

Equivalent Circuit of Induction Machines

- Step2 Rotor winding is shorted
- (Under normal operating conditions, the rotor

winding is shorted. The slip is s) - Note
- the frequency of E2 is frsf because rotor is

rotating.

Equivalent Circuit of Induction Machines

- Step3 Eliminate f2
- Keep the rotor current same

NJ

FKEE, UMP

Equivalent Circuit of Induction Machines

- Step 4 Referred to the stator side
- Note
- X2 and R2 will be given or measured. In

practice, we do not have to calculate them from

above equations. - Always refer the rotor side parameters to stator

side. - Rc represents core loss, which is the core loss

of stator side.

NJ

FKEE, UMP

Equivalent Circuit of Induction Machines

- IEEE recommended equivalent circuit
- Note
- Rc is omitted. The core loss is lumped with the

rotational loss.

NJ

FKEE, UMP

Equivalent Circuit of Induction Machines

- IEEE recommended equivalent circuit
- Note can be separated into 2 PARTS
- Purpose
- to obtain the developed mechanical

NJ

FKEE, UMP

Analysis of Induction Machines

- For simplicity, let assume
- IsI1 , IRI2
- (sstator, Rrotor)

NJ

FKEE, UMP

Analysis of Induction Machines

Note 1hp 746Watt

NJ

FKEE, UMP

EXAMPLE 1

- A 4 poles, 3? Induction Motor operates from a

supply which frequency is 50Hz. Calculate - The speed at which the magnetic field is rotating
- The speed of the rotor when slip is 0.04
- The frequency of the rotor when slip is 3.
- The frequency of the rotor at standstill

NJ

FKEE, UMP

EXAMPLE 2

- A 500hp, 3? 6 poles, 50Hz Induction Motor has a

speed of 950rpm on full load. Calculate the slip.

NJ

FKEE, UMP

EXAMPLE 3

- If the emf in the rotor of an 8 poles Induction

Motor has a frequency of 1.5Hz and the supply

frequency is 50Hz. Calculate the slip and the

speed of the motor.

NJ

FKEE, UMP

EXAMPLE 4

- A 440V, 50Hz, 6 poles, Y connected induction

motor is rated at 135hp. The equivalent circuit

parameters are - Rs0.084? RR0.066?
- Xs0.2? XR0.165?
- s 5 Xm6.9?
- Determine the stator current, magnetism current

and rotor current. - Solution
- Given V440V, p6, f50Hz, 135hp

NJ

FKEE, UMP

Example 4 (Cont)

Example 4 (Cont)

Example 4 (Cont 1st Method)

Example 4 (Cont 2nd Method)

Power Flow Diagram

Power Flow Diagram

- Ratio

Ratio makes the analysis simpler to find the

value of the particular power if we have another

particular power. For example

Efficiency

Example 5 (Cont from Ex 4)

- Calculate
- Stator Copper Loss
- Air Gap Power
- Power converted from electrical to mechanical

power - Output power
- Motor efficiency

- Solution

Example 5 (Cont from Ex 4)

Torque-Equation

- Torque, can be derived from power equation in

term of mechanical power or electrical power.

Torque-Equation

- Note that, Mechanical torque can written in terms

of circuit parameters. This is determined by

using approximation method

Hence, Plot Tm vs s

Torque-Equation

Example 6 (Cont from Ex 4)

- Calculate
- Mechanical torque
- Output torque
- Starting torque
- Maximum torque and maximum slip

solution

Example 6 (Cont from Ex 4)

Example 6 (Cont from Ex 4)

Speed Control

- There are 3 types of speed control of 3 phase

induction machines - Varying rotor resistance
- Varying supply voltage
- Varying supply voltage and supply frequency

Varying rotor resistance

- For wound rotor only
- Speed is decreasing
- Constant maximum torque
- The speed at which max torque occurs changes
- Disadvantages
- large speed regulation
- Power loss in Rext reduce the efficiency

Varying supply voltage

- Maximum torque changes
- The speed which at max torque occurs is constant

(at max torque, XRRR/s - Relatively simple method uses power electronics

circuit for voltage controller - Suitable for fan type load
- Disadvantages
- Large speed regulation since ns

Varying supply voltage and supply frequency

- The best method since supply voltage and supply

frequency is varied to keep V/f constant - Maintain speed regulation
- uses power electronics circuit for frequency and

voltage controller - Constant maximum torque
