Nuclear Cardiology: Myocardial Perfusion Studies and Ventriculography

1
Nuclear CardiologyMyocardial Perfusion Studies
and Ventriculography

• Croft Stone
• Nuclear Medicine

2
Basics of MPI

• Radionuclide injected at rest and/or stress
• Radionuclide taken up by myocardium and gamma
  rays emitted
• Rest images compared with stress images
• Decreased perfusion stress and rest MI
• Decreased perfusion at stress, normal with rest
  ischemia
• Area indicates the coronary artery, size
  correlates with severity of CAD

3
Basics

• Two conditions necessary for blood flow deficit
  measurement
• 1) coronary flow must be elevated to near maximal
  levels
• 2) radiotracer whose myocardial extraction is
  proportional to coronary artery blood flow must
  be used

4
(No Transcript)
5
Stress

• Exercise and pharmacologic agents are used to
  achieve maximal coronary dilation and flow.
• Exercise stress gives additional information
• Degree of exercise tolerance
• Time to maximal heart rate
• Blood pressure response

6
Pharmacologic stress

• Agents
• Dipyridamole (persantine)
• Dobutamine
• Adenosine

7
Indications for Pharmacologic Stress Imaging

• Inability to perform adequate exercise
• Left bundle branch block
• Ventricular pacemaker
• CCBs or Beta blockers
• Evaluation of patients very early after acute MI
  (lt3 days) or very early after stenting (lt2 weeks)

8
Physics

• Radioactive decay
• Alpha particles (ionized helium nuclei)
• Beta particles (high energy electrons or
  positrons)
• Gamma rays (photons)
• Electron capture (x-rays)

9
Gamma Camera
10
Camera

• Multiple images taken at different rotation
  angles to obtain 3-D information
• Lead collimator excludes photons not traveling in
  direction of holes in the collimator
• 3-D picture can be reconstructed using a
  mathematical model
• Projection system modeled as system of
  simultaneous linear equations matrix is then
  inverted to reveal the source distribution.

11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
Protocols
15
Radionuclide Properties
Property Thallous Chloride Tc-Sestamibi
Chemistry 1 cation, hydrophilic 1 cation, lipophilic
Shelf life 6 days 6 hours
Photon energy 68-80 keV 140 keV
Uptake Active Na-K ATPase pump Passive diffusion (if intact membrane potentials)
Extraction fraction 85 66
Heart uptake 4 1.2
Redistribution Redistributes Fixed
16
Comparison of 201Tl and 99mTc for Myocardial
Perfusion Imaging
Property 201Tl 99mTc
Photon energy 69-80 keV Scatter and absorption Low resolution 140 keV Less scatter and absorption High resolution
Half life 73 hours Low dosage (2-3 mCi) Low count densities High dosage (20-30 mCi) High count densities
Effective dose 1.3 rad 1.1 rad
Availability Cyclotron-commercial mfr Generator - local
17
Tc-99m

• Technetium chelated to to a molecule that will be
  absorbed by the myocardium
• Tc-99m-methoxyisobutyl (setamibi)
• Tc-99m 1,2bisbis (2-ethoxyethyl)phosphinoethane
  (tetrofosmin)
• During stress, metabolism changes polarization of
  cell membrane, driving agent into cell
• Also readily absorbed by liver and bowel

18
Tc-99m preparation
19
Tc-99m
20
Quality control

• 1. Motion -- There is no evidence of patient
  motion.2. Alignment --The alignment is very
  good.3. Count Increase --The myocardial max
  counts increases in the stress study as
  expected.4. Normalization --Both studies are
  normalized to the portion within the myocardium
  with the highest uptake.5. Extra-Cardiac
  Activity --There is no significant extra cardiac
  activity.6. Soft tissue attenuation minimized
• 7. Protocol consistency

21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
ECG Gated SPECT imaging(MUGA multi gated
acquisition)

• Simultaneous assessment of perfusion and function
  in a single injection, single acquisition
  sequence.
• Tc-99m permits evaluation of regional myocardial
  wall motion and wall thickening throughout the
  cardiac cycle
• Quantitates LV volume and EF

30
Technique

• Stannous pyrophosphate injected
• Tc-sodium pertechnetate injected
• Pertechnetate enters RBCs, becomes reduced by
  the intracellular stannous ion, and is bound to
  hemoglobin
• RBCs now tagged with radioisotope hence
  blood pool image

31
Technique

• Images of heart are triggered (gated) on the R
  wave of the ECG
• 32 or more frames taken per cardiac cycle
• Many cardiac cycles imaged and stored for
  statistical significance
• Total amount of activity stored in frames at each
  gated time point plotted vs. total time cycle

32
(No Transcript)
33
Technique

• Heart rate variations can result in temporal
  blurring (mixing of counts in adjacent frames).
• Beat rejection window usually set at 20

34
Sources

• Cerqueira, Manuel D. Nuclear Cardiology, 1994, pp
  93 100, 103-109.
• Crean, Andrew and Coulden, Richard. Cardiac
  Imaging using nuclear medicine and positron
  emission tomography. Radiologic Clinics of North
  America, 42 (2004) 619-634
• Heller,Gary V. and Hendel, Robert C. Nuclear
  Cardiology Practical Applications, 2004. pp
  1-312.
• Kowalsky, Richard J. and Falen, Steven W.
  Radiopharmaceuticals in Nuclear Medicine and
  Nuclear Pharmacy, 2004 pp 515 555.
