Computer Engineering Department Research Profile

1
Computer Engineering Department Research Profile

• Dr. Sadiq M. Sait
• Computer Engineering Department
• King Fahd University of Petroleum Minerals

2
Computer Engineering Faculty

• 20 Professorial Rank faculty members
• 2 Full Professor
• 2 Associate Professor
• 16 Assistant Professor
• 6 lecturers

3
COE Research Areas

• Data Communications Computer Networks.
• Computer Applications Robotics, Interfacing,
  Data acquisition, Machine learning, Data Mining.
• Digital Design Automation VLSI System Design
  Test.
• Computer Architecture Parallel Processing.
• Computer Arithmetic Cryptography.

4
COE Recent Research Projects Data Communications
Computer Networks

• Wireless Multi-hop Voice over IP over Wi-Fi using
  Client-Server UDP.
• Mobile Patient using sensor network.
• Wireless Local Area Networks Integration for
  Mobile Networks Operators.
• E-Tourism Promoter An Internet Assisted
  Location Tracker and Map Reader for Tourists.
• A Framework for Integration of Web-based Network
  Management and Management by Delegation.
• Radio Resource Management and QoS Control for
  Wireless Integrated Services Networks.
• Adaptive TCP Mechanisms for Wireless Networks.
• Engineering Modern Iterative Heuristics to Solve
  Hard Computer Network Design Problems.

5
Wireless Multi-hop Voice over IP

• Objectives
• Setting up and implementing a wireless mobile ad
  hoc infrastructure-less environment.
• Imitating the cellular network topology (Virual
  Base Stations)
• Engergy Aware protocols
• Maximizing the number of hops within the 200 ms
  constraint
• IP telephony (protocols, basic and advanced
  services)
• Reconfiguring IEEE 802.11 wireless cards
• Impelementing H 323 protocol in MANET
• Sending data and voice over UDP/IP

6
Wireless Multi-hop Voice over IP
Energy Aware Gateways
7
Mobile Patient

• Objectives
• Introduce mobile health as the future of
  medicine.
• Cost effective solution.
• Facilitate the use of both medical sensors and
  wireless mobile network in health applications.
• Building a sensor network to monitor patients
  effectively
• Providing doctors with easy access to the
  database
• Providing immediate help to patients

8
Mobile Patient
MS5536

• Compatible with most existing microcontrollers
• Uses 3-wire serial interface (SPI)
• Low voltage/low power consumption
• SPI programmable

1. Full TCP/IP v4/v6 support
2. 10/100 Base-T Ethernet MAC
3. Built in OS
4. Three serial ports
5. Java programmable
6. Built in web-server and FTP

9
Wireless Local Area Networks Integration for
Mobile Networks Operators

• Motivation
• Address capacity requirements in hotspot areas.
• Provide seamless service continuity.
• Objective
• Integrate WLANs with 3G wireless data networks
  leading to hybrid mobile data networks.
• Describe possible architectures and integration
  solutions relevant to existing and future Saudi
  Telecom Company (STC) wireless networks.
• Present a typical deployment scenario of a WLAN
  into an STC wireless network
• Specify required network elements
• Provide corresponding commercially available
  products

10
WLAN Integration Methodology Planned
Deliverables

• Survey and classify existing solutions
• Identify most suitable solution or introduce new
  solution
• Tailor the solution to suit the particular local
  environment and network

• Case study Provide a typical deployment scenario
  in King Fahd Airport in Dammam
• Specify required network elements and the
  corresponding commercial available product

11
E-Tourism Promoter An Internet Assisted
Location Tracker and Map Reader for Tourists

• Motivation
• Vehicle tracking and path identification
• E-directory (databased) for public service areas
  and centers of interest (hotels, hospitals,
  police stations, etc.)
• Encouragement and promotion of tourism
• Functionality
• Advanced Arabic/English-based graphical user
  interface
• Real-time display of information and manipulation
  of map
• Communication with infrastructure networks (PSTN
  or GSM/GPRS) using email/SMS/voice
• Possible extensions service/product
  advertisements, shortest path instructions, etc.

12
E-Tourism Specification, Methodology and Planned
Product

• Integrated database system to position on the map
  and query service centers and areas of interest
• Minimum requirement is to identify these
  facilities of interest and display their
  attributes (phone , email, website, etc.)
• Communication using PSTN, mobile GSM network, or
  GPRS/internet
• Additional features may include identification of
  shortest path

Project Architecture

• Development JAVA and .NET framework
• GPS communication System
• Map application
• Bluetooth serial support port SSP
• GSM/GPRS modem support
• An integrated software/hardware system that may
  be running on a PocketPC, laptop, or a PC for
  demonstration purposes

13
A Framework for Integration of Web-based Network
Management and Management by Delegation

• Network Management is mainly based on a
  centralized architecture. This causes the manager
  and its segment to become a bottleneck. The most
  widely used protocol is SNMP, which lacks
  flexibility and efficiency.

• XML provides a more flexible and standard
  representation and exchange of data. Load
  balancing techniques provide a more efficient
  data processing How can these techniques
  improve existing network management systems?

• Objective Develop an XML-based network
  management system using JPVM to dynamically
  distribute the management load across multiple
  XML/SNMP gateways.

14
Approach Integration of XML and Different Load
Balancing Techniques

• A master gateway distributes the management load
  across multiple XML/SNMP gateways
• A gateway translates XML to SNMP and SNMP to
  XML.
• XML-based network management approaches using
  Java Parallel Virtual Machine (JPVM)
• Dynamic load balancing
• Adaptive load balancing
• Static weighted load balancing
• Equal work non-weighted load balancing

• Achievements
• Standard representation and exchange of data
• Efficient distribution of tasks adaptive and
  dynamic
• Delegation of tasks to other gateways
• Increased processing efficiency of management
  data
• Decreased communication time between the manager
  and the agents

15
Proposed Work related to Intels RD

• The project is being extended through the
  investigation of the following issues
• New load balancing approaches that adapt
  dynamically in function of the network load
• Reliable and fault-tolerant network management
• Hierarchical network management
• Adaptive Distributed and Reliable XML-based
  Network Management can prove useful in areas such
  as
• Automated and remote provisioning techniques
• Remote and reliable operations such as secure
  reset and power cycling
• Remote and distributed network management
  applications such as monitoring, control,
  topology discovery, and performance evaluation

16

Computer Applications Embedded Systems, Machine
Learning, Robotics
17
COE Recent Research Projects Computer
Applications

• Design  of  a  wireless  safety  system  for
  smart kitchen.
• Predicting log properties from seismic data using
  abductive networks.
• Design of an Intelligent Telerobotic System.
• Designing and building a mobile emergency warning
  system for patients under health care.
• Context aware energy  management system.

18
Designing and Implementing a Safety Health
Check System for Home Environment

• Motivation
• Preventing children accidents.
• Keep a record of children encounters access to
  hazardous appliances.
• Provide immediate help for children when needed.
• Utilize the advances in Web technology to keep an
  eye on children.
• Enhance the level of safety at home.
• Objectives
• Introduce a safety system for the kitchen
  environment.
• Cost effective solution.
• To inform childs parents of his status in case
  of emergency.
• Building a sensors network to gather real time
  Information of events in the kitchen
• Detection of hazards and generating Alarms
• Identification of children to disable access to
  hazardous appliances and tools

19
Proposed Solution

• Contributions
• Remote live alert of hazardous gas.
• Low cost smart kitchen for safety of children.
• Controlled access to hazardous kitchen tools.
• Web enabled solution for monitoring of children
  in real time.
• Alert when gas barrel is empty.

20
Predicting Log Properties from Seismic Data using
Abductive Networks

• Modeling well log parameters in terms of seismic
  data gives a more complete picture of rock
  properties over a reservoir.
• A large number of seismic features exist- Which
  ones are relevant?
• Objective Use abductive networks to select an
  optimum subset of seismic attributes and model
  rock porosity.

21
Approach Self-Organizing Abductive (Polynomial)
Networks
- Easier to train Self organization - Algorithm
selects Significant inputs, Function elements,
Connectivity, Coefficients - Automatic stopping
criteria with complexity control - More
transparent models. Analytical input-output
relationships
y w0 w1 x1 w2 x2 w3 x12 w4 x22
w5 x1 x2 w6 x13 w7 x23

• Achievements
• Several porosity models at various degrees of
  complexity.
• Accuracy comparable with previous neural network
  models obtained using much larger datasets.
• Significant reduction in the number of input
  features needed.

22
Proposed Work related to Intels RD

• COE has a wide experience in abductive network
  modeling for science, engineering, medical
  informatics, and the environment.
• A project is being initiated for FPGA realization
  of abductive networks.
• VLSI implementations of abductive models should
  prove useful in areas such as
• Intelligent processing in communication networks
• Intelligent health care monitoring and control
• Environmental and weather monitoring and
  forecasting
• Inferential monitoring and control of industrial
  processes
• Predictive maintenance for machinery

23
TELEROBOTICS FOR OIL EXPLORATION AND DRILLING

• PROPOSED RESEARCH
• Supervisory and automatic inspection in oil
  exploration and drilling (OED).
• Develop standards in computer and software
  architectures for telerobotics.
• Handles real-world and communication
  uncertainties and respond to expected and
  unexpected events.
• Develop a universal master workstation and
  application-oriented slave robots.
• Develop computer-aided telerobotic tools to
  promote man-machine interfacing and quality of
  telerobotic work.
• Use of inexpensive, light, easily maintainable,
  telerobotic systems.

Communication uncertainties
24
TELEROBOTICS FOR OIL EXPLORATION AND DRILLING

• Standards hardware and software architectures
• New Processor architecture (effective
  multithreading)
• Multithreading and multi-streaming
• Interfacing sensing (mobility, video, force,
  etc) and 3D visualization
• Communication real-time wireless networking
• Software architecture (uncertainties in task and
  communication)
• Reactivity supervisory and linguistic control,
  supervised-autonomy, shared-control, cooperative
  and collaborative control
• Advanced real-time motion coordination and
  mobility
• Task planning graphical modeling/simulation
  using VR and augmented reality
• Reliability and exception handling agent-based
  reactive behavior using multi-sensor fusion

Graphic modelling
25
TELEROBOTICS FOR OIL EXPLORATION AND DRILLING

• Applications
• Scaled telerobotics a manned station
  teleoperating (wired or wirelss) a scaled slave
  robot for remote operations and routine
  maintenance in inaccessible areas like tubes,
  pipes, equipment, well, drilling hole, etc.
• Hazardous a manned station teleoperating a
  stationary or mobile robot (vehicle) for remote
  operations and inspection in harsh environments
  like high temperature, high pressure, poisonous
  (gaz or other), high pollution, underground,
  underwater, etc.
• Tight safety a manned station teleoperating a
  slave robot carrying out security patrol tasks,
  disposal of dangerous material, rescue, fire
  fighting and clearance, oil platform inspection
  and repair, operating in emergency cases as
  surveillance and reconnaissance, etc.

Underwater,excavation, and drilling
26
Warning and Monitoring Medical System Designing
and implementation

• Motivation
• The remote system ensures high quality service to
  the patients.
• Keep a record of your patient encounters.
• Improve information efficiency and manageability
  of knowledge sources.
• Overcome nurse negligence.
• Provide better health care and medication
  support.
• Objectives
• Introduce mobile health as the future of
  medicine.
• Cost effective solution.
• To facilitate improved productivity using mobile
  health solutions.
• Building a sensor network to monitor patients
  effectively
• Providing doctors with easy access to the
  database
• Providing immediate help to patients

27
Proposed Solution
Blood Pressure Sensor Circuit
28
Digital Design Automation VLSI System Design
Test
29
COE Recent Research Projects Design Automation
VLSI System Design Test.

• Iterative Heuristics for Timing Low Power VLSI
  Standard Cell Placement.
• Parallelization of Iterative Heuristics for Low
  Power VLSI Standard Cell Placement.
• Efficient Test Relaxation Based Static Test
  Compaction Techniques for Combinational and
  Sequential Circuits.
• Efficient Test Data Compression Techniques for
  Testing Systems-on-Chip.
• Segmented Addressable Scan Architecture for
  Effective Test Data Compression.

30
COE Recent Research Projects Design Automation
VLSI System Design Test.

• Development of Digital Circuit Techniques for
  Clock Recovery and Data Re-Timing for High Speed
  NRZ Source-Synchronous Serial Data
  Communications.
• Fast context switching configurable architectures
  supporting dynamic reconfiguration for
  computation intensive applications.
• Development of Integrated Micro-electronic Heavy
  Metal Sensors for Environmental Applications.
• Multi-objective Finite State Machine Encoding
  using Non-Deterministic Evolutionary Algorithms
  targeting area, low power and testability.
• Design and Implementation of Scalable
  Interconnect Efficient LDPC Error Correcting
  Codes.

31
Parallelizing Non-Deterministic Iterative
Heuristics to Solve VLSI CAD Problems

• CAD Problems such as Floorplanning, Placement,
  Routing, Scheduling, etc., require an enormous
  amount of computation time.
• Iterative Heuristics such as Genetic Algorithms,
  Tabu Search, Simulated Evolution, and others have
  been found effective in solving several NP-hard
  optimization problems.
• Objective To use a cluster of PCs to solve
  multi-objective VLSI CAD problems in order to
  improve quality and reduce run-time.

32
Approach To employ a Cluster of PCs to
Distribute Computationally Intensive Tasks

• Clusters of low end PCs are easy to build.
• Tools such as MPI and PVM are available for
  message passing.
• Tools such as gprof, Intels VTUNE Performance
  Analyzer, etc., are used for generating profiles
  for serial codes and determining the part of the
  code that has the bottlenecks.
• Iterative algorithms are non-deterministic, and
  dividing work load, i.e. partitioning the search
  space, is a challenge.
• The parallelizing model (i.e., Partitioning,
  Communication, Agglomeration and Mapping) is very
  well-defined for numerical problems, which are
  mostly deterministic. This is not the case for
  Iterative heuristics, which are non-deterministic.

33
Tools used in our Current Cluster

• MPICH Library provides a flexible
  implementation of MPI for easier message-passing
  interface development on multiple network
  architectures.
• Intel Trace Collector 5.0 applies event-based
  tracing in cluster applications with a
  low-overhead library. Offers performance data,
  recording of statistics, multi-threaded traces,
  and automatic instrumentation of binaries on
  IA-32.
• Intel Trace Analyzer 4.0 provides visual
  analysis of application activities gathered by
  the Intel Trace Collector.
• TotalView (MPICH) is also used for observing
  communication between processors.
• Also used in Condor (for scheduling jobs on the
  cluster).

34
Relationship to Intels RD

• COE Department has faculty experienced in VLSI
  Design.
• Two books in the area of iterative algorithms and
  VLSI Design have been authored by the department
  faculty.
• The Technology Center being proposed in RI will
  have the state-of-art tools and equipment.
• Faculty and students currently interested in HPC
  and parallelization of heuristics can work
  together to address industrial and real-world
  problems.

35
Efficient Test Compaction Compression
Techniques for Comb. Seq. Circuits

• SOC Testing Challenges
• Reduce amount of test data.
• Reduce time a defective chip spends on a tester.
• Test Compaction Compression
• Reduce the size of a test set as much as
  possible.
• Test vector reordering for combinational
  circuits.
• Steepen the curve of fault coverage vs. number of
  test vectors.

36
Efficient Test Compaction Compression
Techniques for Comb. Seq. Circuits

• Efficient Test Relaxation for Combinational
  Sequential circuits
• Enabling technology for test Compaction
  Compression
• Test power reduction
• Developed efficient test compaction techniques
  based on test relaxation.
• Test Vector Decomposition
• Maximizes test compaction by vector clustering
  techniques
• Maximizes test width-based compression techniques.

37
Segmented Addressable Scan Scan Test Challenges

• Test data volume challenge
• Limited IOs unlimited increase in transistors
• Exponential increase in test data volume
• Tester pin count challenge
• Tester cost is almost linear in number of pins
• Test time challenge
• Critical path
• Hard to parallelize test loading massively
• Test power challenge
• High activity leading to high power consumption.

38
Segmented Addressable Scan

• Aggressive parallelization of scan chains
• Reconfigurable partial compatibilities
• Special SAS decoder

• ? Data volume 10x 20x compression with small
  designs for both SAF and TDF
• Bigger designs have higher compression

• ? Pin count 2?? log2S ?1 pins,
• can be reduced to ONLY 2

• ? Overhead
• few gates per scan chain

? Test time aggressive parallelization ? test
time reduction

• ? Power consumption
• selective clocking

39
Test Data Volume Test Time (Delay test)
Total Data Volume Total Data Volume 98 Mb Compression Ratio
SAS Data Volume 32 Segments 7.7 Mb 12x
SAS Data Volume 64 Segments 5.3 Mb 17x
SAS Data Volume 128 Segments 4.5 Mb 22x
SAS Data Volume 256 Segments 3.6 Mb 27x
Ms of annual test cost savings
40

• Computer Architecture Parallel Processing

41
COE Recent Research Projects Computer
Architecture Parallel Processing

• Load Balancing for Parallel Visualization of
  Blood Head Vessel Angiography on Cluster of PCs.
• Shared Channels in Interconnection Networks.
• Study of modified Multistage Interconnection
  Networks for Networks-on-Chips.
• Design of a Simulator for a Class of Dynamic
  Execution Processors.
• Beyond Instruction-Level Parallelism in Processor
  Architecture.
• Design and Performance Evaluation of a
  Distributed Crossbar Scheduler.
• Software Pipelining for Reconfigurable
  Instruction Set Processors.

42
Scalable Cache Memory Design forLarge-Scale SMT
Architectures

• Scalable front end
• Multiple i-caches
• Scalable i-cache capacity
• Scalable i-cache bandwidth
• One-level scalable and shareable data cache
• Split into multiple block-interleaved banks
• Each bank is single-ported and shared by all
  threads
• Parallel access to different banks through
  interconnect
• Complexity grows with number of ports and banks

• Modular and Scalable SMT (not a pure SMT)
• Most hardware resources have limited thread
  sharing
• I-caches, Decode logic, Queues, Registers, FUs

43
Simulation and Performance

• SPEC 2000 Simulation
• 8 simultaneous threads
• Simulation Parameters
• Issue/retirement width 32 instructions / cycle
• Scheduling Queue 128 entries
• Load-Store Queue 64 entries
• Other Resources
• 24 simple ALUs
• 8 fully pipelined FPUs
• 4 cycle-latency for FP add and FP multiply

• Related Publications
• Mudawar M. and Wani J., One-Level Cache Memory
  Design for Scalable SMT Architectures, in
  Proceedings of the 17th ISCA International
  Conference on Parallel and Distributed Computing
  Systems, September 15-17 2004, San Francisco,
  California.
• Mudawar M., Scalable Cache Memory Design for
  Large-Scale SMT Architectures, ACM International
  Conference Proceedings Series, Vol 68 also in
  Proceedings of the 3rd Workshop on Memory
  Performance Issues in conjunction with 31st
  IEEE/ACM International Symposium on Computer
  Architecture, June 20-23 2004, Munich, Germany.

• Conclusions
• Large-scale SMT can tolerate latencies
• Parallel D-cache banks improve capacity and
  bandwidth, but increase hit latency

44
Proposed work related to Intels R D

• Wide experience in processor simulation and
  evaluation of micro-architectures.
• A project is being initiated for the automatic
  generation of simulators from the formal
  description of the instruction set architecture.
• We are currently investigating
• A formal language for the concise description of
  an instruction set architecture.
• Automatic generation of a simulator from a formal
  description.
• Generation of an assembler from a formal
  description.
• We are considering using this tool in
• Proposing new instruction set architectures for
  research and development.
• Education in related Computer Architecture
  courses.

45
Study of Modified Multistage Interconnection
Networks for Networks-On-Chips

• Past Networks-On-Chips (NoCs) Solutions
• Reproduce what has been learned in the area of
  inter-chip networks,
• Focus on the router architecture alone to achieve
  certain goals in latency
• Asynchronous design of NoCs, mainly GALS
• Circuit switching techniques introduced to
  provide a certain guarantee for the latency.
• Did not fully take advantage of the fact that the
  network is on-chip where the main gain is no-pin
  limitation.
• Router architectures directly derived from
  inter-chip architectures where the routers were
  implemented on a single chip. This implies a
  substantial overhead.
• Added complexity to achieve guaranteed latency is
  an overkill in the on-chip context.
• Analysis
• Low throughput. Means latency cannot be
  guaranteed above the maximum throughput levels
• Cannot prevent contention from happening.
  Contention makes router architectures more
  complex because they need to integrate buffering
  and prioritization logic.
• Routers that implement both packet and circuit
  switching makes the architecture even more
  complex.

46
Modified Multistage

• Idea
• Contention free
• Router architecture bufferless because
• no contention no need to buffer
• Which network is almost contention free?
• Crossbar with Virtual Output Queues
• Crossbar non-scalable
• What topology resembles a crossbar?
• Banyans or Multistage Interconnection Networks.
• Unidirectional Wire Routing issue.
• Bidirectional multistage or folded multistage
  networks Good
• Bidirectional multistage are two entities
• The MIN, so-called fat-tree network
• The butterfly.
• MIN better than butterfly (previous work)
• How to modify the MIN so that it becomes
  contention free?
• Routing in a MIN
• Going up adaptive
• Going down deterministic. Means a high
  probability of contention.

Regular MIN
Modified MIN
47
Proposed work related to Intels R D

• Large Experience in Interconnection Networks
  Evaluation.
• Large Experience in ASIC/SoC Design.
• System C based simulation/performance evaluation
  environment under development.
• Future investigations
• Customized automatic generation of topologies and
  routers that implement bufferless approach.
• Investigate the automatic generation of
  bandwidth-asymmetric network for non-equal
  requirements on the side of the IP-core clients.
• Mathematical Analysis to Determine Maximum
  Latency Levels in the context of bufferless
  architecture routers.

48

• Computer Arithmetic Cryptography

49
COE Recent Research Projects Computer Arithmetic
Cryptography

• High-Performance Arithmetic for Cryptographic
  Applications.
• Design of efficient integrated circuits for the
  inverse computation in different finite fields.
• Design of Elliptic Curve Cryptography
  Architectures using parallel multipliers.
• Secure reliable storage system.
• Design, Analysis, and FPGA prototyping of
  High-Performance Arithmetic for Cryptographic
  Applications.

50
High-Performance Arithmetic Circuitry for
Cryptography

• New Modulo Multiplication Algorithm Circuitry
  ? Patent Application Pending.
• New High-Radix Multiplier Divider Algorithm and
  Hardware performing the operation (AB/N) with
  hardware complexity close to that of Division
  operation ? Patent in Preparation.
• Efficient Parallel Implementations of Elliptic
  Curve Cryptosystems.

51
Aladdin Modulo Multiplier

• Public-Key Encryption/Decryption Algorithms
  Largely depend on the computation of Modulo
  multiplication (AB mod N).
• Current Dominant Method is Montgomerys
• Circuitry have been modeled and verified using
  VHDL

52
High-Radix Multiplier Divider

• Theory Fully Developed
• For n-bit operands, with k-bit radix system (k gt
  8), computing (AB/N) requires (n / k) steps
  instead of n.
• Research is continuing to study full exploitation
  of such processor for faster performance of
• Pure multiplication
• Pure division

53
ECC Efficient Implementations

• Efficient High-Speed computation of the Scalar
  Multiplication operation (ECC) through exploiting
  parallelism.
• Improved Resistance against Side Channel Attacks
  (SCA)
• Parallelism
• Randomized computation order starting
  Least-2-Most or Most-2-Least
• Randomized Number of Processors
• Randomized coordinate system (affine vs
  projective)
• Hardware will be implemented on an FPGA platform.

54
Available Experience.

• COE has a wide experience in digital circuits and
  VLSI design.
• Work is verified on FPGA platform but can readily
  be ported onto dedicated VLSI processors.
• Developed Circuits Algorithms can be readily
  used by INTEL.
• Our Needs
• Professional CAD Tools for VLSI design,
  verification, and synthesis tools e.g. Mentor
  Graphics tools, Cadence, etc.

55
Computer Engineering Faculty Research Profile
56
Dr. Sadiq Sait, Professor

• Research Interests
• Digital Design Automation, VLSI System Design,
  High Level Synthesis, and Iterative Algorithms.
• Recent Projects
• Parallelization of Iterative Heuristics for Low
  Power VLSI Standard Cell Placement', KFUPM,
  2003-2005.
• Iterative Heuristics for Timing Low Power VLSI
  Standard Cell Placement, KFUPM, 2001-2003.
• Recent Publications
• Sadiq M. Sait and Junaid A. Khan, "Simulated
  Evolution for Timing Low-Power VLSI Standard
  Cell Placement", Engineering Applications to
  Artificial Intelligence (EAAI), Vol. 16, Sep.
  2003, pp. 407-423.
• Sadiq M. Sait and H. Youssef. Iterative Computer
  Algorithms with Applications in Engineering
  Solving Combinatorial Optimization Problems.
  December 1999, IEEE Computer Society Press,
  California.
• Sadiq M. Sait and H. Youssef. VLSI Physical
  Design Automation Theory and Practice,
  McGraw-Hill Book Co., Europe, December 1994. Also
  Co-published by IEEE Press, USA, January 1995
  (Hard bound edition).

57
Dr. Mayez Al-Muhammad, Professor

• Research Interests
• Computer Architecture, Parallel Processing and
  Algorithms, Computer Networks, and Robotics.
• Recent Projects
• Design of a Simulator for a Class of Dynamic
  Execution Processors, KFUPM, 2003-2004.
• Design of an Intelligent Telerobotic System, King
  Abdulaziz City for Science and Technology
  (KACST). 2000-2004.
• Recent Publications
• M. Al-Mouhamed, M. Kaleemudding, and H. Youssef,
  Evaluation of Pipelined Dilated Switch
  Architectures for ATM Networks, IEEE/ACM Trans.
  on Networking, Vol. 7, No. 5, October 1999, pp.
  724-740.
• M. Al-Mouhamed, O. Toker, and A-K Al-Harthy, A
  3D Vision-Based Man-Machine Interface For
  Hand-Controlled Telerobot, IEEE Transactions on
  Industrial Electronics, Vol 52, No 1, 2005, pp.
  306-319.
• M. Al-Mouhamed, Array Organization in Parallel
  Memories, International Journal of Parallel
  Programming (IJPP), Vol 32, No.2, April, 2004,
  pp.123-163.

58
Dr. Alaaeldin Amin, Assoc. Professor

• Research Interests
• VLSI Integrated Circuit design, MOS Memory Design
  and Testing, Computer Arithmetic Cryptography,
  Digital System Testing and Asynchronous Design.
• Recent Projects
• High-Performance Arithmetic for Cryptographic
  Applications
• Industrial Experience
• 8 Years in MOS Memory Design (National
  Semiconductor MOS Memory RD)
• Patents
• 4 US Patents in Flash Memory architectures,
  circuits cells
• 2 Patent Applications for High Performance
  Arithmetic for Cryptographic Applications.
• Publications
• Double-rail encoded self-timed adder with matched
  delays (IEEE ICEC 2003).
• Asynchronous Modulo Multiplier for Cryptosystems,
  (IEEE GCC, 2004 ).
• Fault Models and Efficient BIST Algorithm for
  Dual Port Memories (IEEE TCAD 1997).

59
Dr. Radwan Abdel-Aal, Assoc. Professor

• Research Interests
• Multidisciplinary applications of abductive
  networks machine learning in science, engineering
  and medicine , Data acquisition and analysis for
  experimental and nuclear physics, Testing of
  digital systems.
• Recent Projects
• Predicting log properties from seismic data using
  abductive networks. 1 Feb-31 Oct 2005, Client
  Saudi Aramco, Value SR 272,646.
• Industrial Experience
• 4 Years in Digital Systems Design (Microwave
  Associates Inc., Bedfordshire, UK).
• Recent Publications
• Abdel-Aal, R. GMDH-based feature ranking and
  selection for improved classification of medical
  data, Journal of Biomedical Informatics, 2005.
• Abdel-Aal, R. Improving electric load forecasts
  using network committees, Electric Power Systems
  Research, v. 74, pp. 8394, 2005.
• Abdel-Aal, R. Hourly temperature forecasting
  using abductive networks, Engineering
  Applications of Artificial Intelligence, v. 17,
  pp. 543-556, 2004.
• Abdel-Aal, R. Short term hourly load forecasting
  using abductive networks. IEEE Trans on Power
  Systems, v. 19, pp. 164-173, 2004.

60
Dr. Aiman El-Maleh, Assist. Professor

• Research Interests
• Testing and Synthesis of Digital Systems, Error
  Correcting LDPC Codes.
• Recent Projects
• Multi-objective Finite State Machine Encoding
  using Non-Deterministic Evolutionary Algorithms,
  KFUPM, 2005-2007.
• Efficient Test Relaxation Based Static Test
  Compaction Techniques for Combinational and
  Sequential Circuits, KFUPM, 2004-2005.
• Industrial Experience
• Member of Scientific Staff, Mentor Graphics Corp.
  Oregon, USA (1995-1998).
• Patents
• Test Pattern Generation for an Electronic Circuit
  Using a Transformed Circuit Description, US
  Patent 5,528,604.
• Recent Publications
• A. El-Maleh, S. Khursheed, S. Sait, Static
  Compaction Techniques for Sequential Circuits
  Based on Reverse Order Restoration and Test
  Relaxation IEEE 14th Asian Test Symp., 2005 .
• A. El-Maleh and K. Al-Utaibi, An Efficient Test
  Relaxation Technique for Synchronous Sequential
  Circuits, IEEE Transactions on Computer Aided
  Design of Integrated Circuits, Vol. 23, pp.
  933-940, June 2004.
• A. El-Maleh and Y. Osais, "Test Vector
  Decomposition Based Static Compaction Algorithms
  for Combinational Circuits", ACM Transactions on
  Design Automation of Electronic Systems, Vol. 8,
  pp. 430 - 459, Oct. 2003.

61
Dr. Muhamed El-Rabaa, Assist. Professor

• Research Interests
• Low-Power Digital Circuits, Digital Communication
  Circuits, Configurable Computing.
• Recent Projects
• Development of Digital Circuit Techniques for
  Clock Recovery and Data Re-Timing for High Speed
  NRZ Source-Synchronous Serial Data
  Communications, KFUPM, 2005-2007.
• Fast context switching configurable architectures
  supporting dynamic reconfiguration for
  computation intensive applications, 2005-2007.
• Industrial Experience
• Senior Component Design Engineer, Intel Corp.,
  Oregon, USA (1995-1998).
• Patents
• Two US patents in BiCMOS design No. 5,602,774
  (1999) and No.5,966,032 (1997).
• Recent Publications
• Muhammad E. S. Elrabaa, "A New Static
  Differential CMOS Logic with Superior Low Power
  Performance," Analog Integrated Circuits and
  Signal Processing, Vol. 43, No. 2, pp. 183-190,
  May 2005.
• Muhammad E. S. Elrabaa, "An All-Digital Clock
  Recovery and Data Retiming Circuitry for High
  Speed NRZ Data Communications," IEICE
  Transactions on Electronics (Japan), Vol. E85-C,
  No. 5, P. 1170, May, 2002.
• Muhammad E. S. Elrabaa, Mohab Anis, and Mohamed
  Elmasry, "A Contention-Free DOMINO Logic For
  Scaled-Down CMOS," IEICE Transactions on
  Electronics, Vol. E85-C, No. 5, P. 1177, May,
  2002.

62
Dr. Ahmad Al-Yamani, Assist. Professor

• Research Interests
• VLSI Design and Test (Test Compression and BIST),
  Fault Tolerance, Iterative Heuristics.
• Recent Projects
• Lead the VLSI test experiments at Stanford
  between 01 and 05.
• Test data compression using compatibility
  classes.
• Industrial Experience
• Lead a major test cost saving operation with
  millions of annual savings.
• Patents
• Four US patents filed (all related to VLSI test).
• Recent Publications
• Al-Yamani, A., E. Chmelar and M. Grinchuk,
  "Segmented Addressable Scan Architecture," 23rd
  IEEE VLSI Test Symposium (VTS'05), Palm Springs,
  CA, May 1-5, 2005. PATENT PENDING TECHNOLOGY
• Al-Yamani, A., and E.J. McCluskey, "BIST-Guided
  ATPG," 6th IEEE International Symposium on
  Quality Electronics Design (ISQED'05), San Jose,
  CA, March, 05.
• Al-Yamani, A., and E. McCluskey, "Test Quality
  for High Level Structural Test," ACM Transactions
  on Design Test of Electronic Systems
  (TODAES'05), Oct. 05.
• McCluskey, E.J., Al-Yamani, Li, Tseng, Volkerink,
  Ferhani, Li, and Mitra,"ELF-Murphy Data on
  Defects and Test Sets," 22nd IEEE VLSI Test
  Symposium (VTS04), Napa Valley, CA, Apr. 25-28,
  2004. STANFORD TEST EXPERIMENT.

63
Dr. Adnan Gutub, Assist. Professor

• Research Interests
• Modeling, simulating, and synthesizing VLSI
  hardware for cryptography and computer arithmetic
  operations.
• Recent Projects
• Design of efficient integrated circuits for the
  inverse computation in different finite fields.
• Design of Elliptic Curve Cryptography
  Architectures using parallel multipliers.
• Recent Publications
• Adnan Abdul-Aziz Gutub and Alexandre F. Tenca,
  Efficient Scalable VLSI Architecture for
  Montgomery Inversion in GF(p), Integration, the
  VLSI Journal, Vol. 37, No. 2, pages 103-120, May
  2004.
• Adnan Abdul-Aziz Gutub, VLSI CORE ARCHITECTURE
  FOR GF(P) ELLIPTIC CURVE CRYPTO PROCESSOR, IEEE
  10th International Conference on Electronics,
  Circuits and Systems (ICECS 2003), pages 84-87,
  University of Sharjah, United Arab Emirates,
  December 14-17, 2003.
• Adnan Abdul-Aziz Gutub and Alexandre F. Tenca,
  Efficient Scalable Hardware Architecture for
  Montgomery Inverse Computation in GF(P), IEEE
  Workshop on Signal Processing Systems (SIPS03),
  pages 93-98, Seoul, Korea, August 27-29, 2003.

64
Dr. Abdelhafid Bouhraoua, Assist. Professor

• Research Interests
• ASIC/SoC Design and Verification Methodologies,
  Digital System Design, Interconnection Networks,
  Switch Architectures, Telecommunication
  protocols, Computer Cryptography and Asynchronous
  Design.
• Recent Projects
• Study of modified Multistage Interconnection
  Networks for Networks-on-Chips.
• Design and Performance Evaluation of a
  Distributed Crossbar Scheduler.
• Industrial Experience
• 6 years experience in ASIC Design/Verification,
  mostly as Chip Architect for AMCC and Zarlink
  Semiconductor. Worked on Network Processors,
  SONET, Digital Wrapper, Reed Solomon Codecs, VDSL
  PHY Chipset, ATM framers, TDM and Ethernet
  Switches.
• Directed product and field testing at Lambda
  Opticalsystems Corp building an all-optical
  MEMS-based carrier-class switch.
• Patents
• Patent Applications for VDSL aggregation
  line-rate circuitry.
• Publications
• Experimental Study of a Generic Router
  Architecture under MILE, IASTED'97
• Adaptive Message Routing for Compact
  Reconfigurable Router, IEEE ICECS'97.

65
Dr. AbdulRahim Naseer, Assist. Professor

• Research Interests
• Design Automation and FPGA based Synthesis,
  Reconfigurable Computing, Hardware Software
  Co-Design and Embedded Systems, Computer
  Architecture, Parallel and distributed processing
• Recent Projects
• Software Pipelining for Reconfigurable
  Instruction Set Processors
• Design and Implementation of a Reconfigurable
  Network Interface
• Load Balancing for Parallel Visualization of
  Blood Head Vessel Angiography on Cluster of PCs
• Recent Publications
• A. .R. Naseer, et al., Adaptive Pre-Task
  Assignment scheduling strategy for heterogeneous
  distributed raytracing system, Journal IEICE EE
  , vol. 1, No. 13, October 2004, pp 373-379
• A. R. Naseer, et al., Direct Mapping of RTL
  Structures onto LUT-Based FPGAs, IEEE
  Transactions on Computer Aided Design of
  Integrated Circuits and Systems, Volume 17, July
  1998, pp. 624-631
• A. R. Naseer, "FAST FPGA Targeted RTL
  Structure Synthesis Technique", Proc. of IEEE/ACM
  7th International Conference on VLSI Design'94
  January 1994, pp. 21-24 (bagged the BEST PAPER
  AWARD)

66
Dr. Muhamed Mudawar, Assist. Professor

• Research Interests
• Processor Micro-architecture, Multiprocessors and
  Interconnection Networks, Parallel programming
  environments and compilation techniques
• Recent Projects
• Beyond Instruction-Level Parallelism in Processor
  Architecture, AUC, 2002-2003.
• Shared Channels in Interconnection Networks, AUC
  1999-2000.
• Recent Publications
• Mudawar M., Scalable Cache Memory Design for
  Large-Scale SMT Architectures, Proc. of the 3rd
  Workshop on Memory Performance Issues, June 20-23
  2004, Munich, Germany .
• Mudawwar M. and Saad A., The k-ary n-cube Network
  and its Dual a Comparative Study, in Proceedings
  of the 13th IASTED International Conference on
  Parallel and Distributed Computing and Systems,
  August 21-24, 2001, Anaheim, California, pages
  254-259.
• Mudawwar M. and Mameesh R., Region Broadcasting
  in k-ary m-way Networks, in Proc. of the ISCA
  13th International Conference on Parallel and
  Distributed Computing Systems, August 8-10, 2000,
  Las Vegas, Nevada, pages 268-274.

67
Dr. Ashraf Mahmoud, Assist. Professor

• Research Interests
• 3G/4G wireless networking Wi-Fi and Wi-Max
  networks, Performance analysis and capacity for
  wireless networks, Simulation and modeling
• Recent Projects
• Wireless Local Area Networks Integration for
  Mobile Networks Operators, 2005.
• E-Tourism Promoter An Internet Assisted
  Location Tracker and Map Reader for Tourists,
  2005.
• Industrial Experience
• 5 years with Nortel Networks, Ottawa, Canada
• Patents
• 3 Patent applications in the area of radio
  resource managements
• Recent Publications
• Performance of Inter-Base Station Soft Handoff
  for 3G CDMA Networks, ICMSAO05.
• Non-blocking FCFS algorithm for Data Services
  over Wireless CDMA Networks, ICMSAO05
• Buffer Occupancy Analysis For A Broadband
  Polling-Based WLAN, Net-Con'2003)

68
Dr. Mohammed H. Sqalli, Assist. Professor

• Research Interests
• Network Design, Network Management, Iterative
  Heuristics, Constraint Satisfaction Problems
  (CSP), and Case-Based Reasoning (CBR).
• Recent Projects
• A Framework for Integration of Web-based Network
  Management and Management by Delegation,
  2004-2006.
• Web Engineering Modern Iterative Heuristics to
  Solve Hard Computer Network Design Problems,
  2004-2005.
• Industrial Experience
• Senior Automation Testing Specialist, Siemens,
  Ottawa, Canada (1999-2002).
• Recent Publications
• M. H. Sqalli, and S. Sirajuddin, Static Weighted
  Load-balancing for XML-based Network Management
  using JPVM, Proceedings of the 8th International
  Conference on Management of Multimedia Networks
  and Services (MMNS 2005), Barcelona, Spain,
  October 24-26, 2005.
• S. Sirajuddin, and M. H. Sqalli, Comparison of
  CSV and DOM Tree Approaches in XML-based Network
  Management, Proceedings of the 12th
  International Conference on Telecommunications
  (ICT 2005), Cape Town, South Africa, May 3-6,
  2005.
• C. Marling, M. H. Sqalli, E. Rissland, H.
  Muñoz-Avila, and D. Aha, Case-Based Reasoning
  Integrations, AI Magazine, Volume 23, Issue 1,
  Spring 2002, 69-86.

69
Dr. Tarek Sheltami, Assist. Professor

• Research Interests
• Wireless Ad Hoc and Sensor Networks, Wireless
  mobile Multi-hop voice/video over IP, Pervasive
  Computing, Heterogeneous Netowrks, Wireless
  Communication Protocols.
• Recent Projects
• Wireless Multi-hop Voice over IP over Wi-Fi using
  Client-Server UDP, 2005.
• Mobile Patient using sensor network, 2005.
• Recent Publications
• T. R. Sheltami and H. T. Mouftah, Average
  waiting time of Clusterhead Controlled Token for
  Virtual Base Station On-demand in MANETs, ACM
  Ad Hoc Networks of the journal Cluster
  Computing, Kluwer Academic Publisher, July 2005,
  vol. 8, no. 2-3, pp. 157-165(9).
• T. R. Sheltami and H. T. Mouftah, A Warning
  Energy Aware Clusterhead (WEAC) for MANETs,
  IEEE Trans. on Wireless Communications, 2005
• T. R. Sheltami and H. T. Mouftah, Power Aware
  Routing for the Virtual Base Station On-demand
  Protocol in MANETs, The Arabian  Journal for
  Science and Engineering., Vol 28, number 2C,
  2003.
• T. R. Sheltami and H. T. Mouftah, Minimum
  Power-Routing for the Virtual Base Station
  On-demand Protocol in MANETs, Computer Networks
  The Intern. Journal of Computer and
  Telecommunications Networking 2003.

70
Dr. Uthman Baroudi, Assist. Professor

• Research Interests
• Radio Resource Management, Ad hoc Networking,
  Multiple Access Schemes.
• Recent Projects
• Radio Resource Management and QoS Control for
  Wireless Integrated Services Networks 75KSAR,
  KFUPM from Sep. 2005-Dec. 2006
• Adaptive TCP Mechanisms for Wireless Networks,
  75KSAR, KFUPM, from Sep. 2005-Dec. 2006.
• Recent Publications
• U. Baroudi and A. Elhakeem, A Simulation Study
  for Adaptive Admission/Congestion Control
  Policies for CDMA Based Wireless Internet
  Wireless Communications and Mobile Computing
  Journal, 2006.
• Yaser Al-Jarbou and U. Baroudi, Performance of
  Heterogeneous Traffic in Roaming Based Sharing
  Multi Operator 4G WCDMA 2nd International
  Symposium on Wireless Communication Systems 2005,
  Italy.
• U. Baroudi and A. K. Elhakeem, "A Hybrid
  TDMA/MC-CDMA Utilizing Multiuser Detection for
  Integrated Wireless Networks" IEICE Transactions
  on Communications, Vol.E83-B, No. 6, pp.
  1308-1320, June 2000.

71
Dr. Marwan Abu Amara, Assist. Professor

• Research Interests
• 3G/4G wireless networking, Fault-tolerance in
  wireless computer networks, Network analysis,
  planning, and design.
• Recent Projects
• Wireless Local Area Networks Integration for
  Mobile Networks Operators, 2005.
• E-Tourism Promoter An Internet Assisted
  Location Tracker and Map Reader for Tourists,
  2005.
• Industrial Experience
• Senior Wireless Technical Advisor, Nortel
  Networks, Richardson, USA (1995-2003).
• Patents
• CDMA Inter-Mobile Switching Center Soft
  Hand-Off, with S. Sides, A. Jalali, J. Boppana,
  S. Doctor, US Patent 5,930,714, 1999, US Patent
  6,173,183, 2001.
• Recent Publications
• A. Mahmoud and M. Abu-Amara, Performance of
  Inter-Base Station Soft Handoff for 3G CDMA
  Networks, Proceeding of the First International
  Conference on Modeling, Simulation and Applied
  Optimization, Sharjah, U.A.E. February 2005.
• M. Abu-Amara, Minimum Traffic Inter-BS SHO
  Boundary Selection Algorithm for CDMA-Based
  Wireless Networks, Proceedings of the 2004 IEEE
  Radio and Wireless Conference, Atlanta, Georgia,
  September 2004, pp. 51-53.

72
Dr. Wasim Raad, Assist. Professor

• Research Interests
• Embedded systems, Smart cards applications, Real
  time DSP systems
• Recent Projects
• Context aware energy  management system
• Design  of  a  wireless  safety  system  for
  smart kitchen
• Designing and building a mobile Emergency warning
  system for patients under health care.
• Recent Publications
• M.W. Raad, J.M. Noras, M. Shafiq and A. Aksoy,
  Gamma-Ray Peak Detection Algorithms Using
  Embedded DSP, ESS Conference, October 2004, UK.
• M.W. Raad, J.M. Noras and M. Deriche, Parameter
  Estimation and Digital Peak Localization
  Algorithms For Gamma Ray Spectroscopy, In the
  proceedings of the fourth International Symposium
  on Communication systems, Networks and Digital
  Signal Processing, University of Newcastle,
  UK,20-22 July 2004.
• M.W.Raad and J.M. Noras, Moment Preserving
  parameter estimation and digital online peak
  localization algorithms for Gamma Ray
  Spectroscopy, IEEE Nordic Signal Processing
  Symposium, June 13-15, 2000, Kolmarden,Sweden.

73
Dr. Talal Alkharobi, Assist. Professor

• Research Interests
• Design automation, neural networks, fuzzy logic,
  information and network security.
• Recent Projects
• Secure reliable storage system, 2004-2005.
• Design, Analysis, and FPGA prototyping of
  High-Performance Arithmetic for Cryptographic
  Applications, 2005.
• Recent Publications
• Hand Writing recognition using Artificial neural
  network, ICANN96 Italy.
• Secret Sharing using Artificial neural network ,
  Ph.D. dissertation 2004, Texas AM university -
  College Station Texas USA .
