Water Activity, Drying

1
Water Activity,Drying

• FSN 661
• April 2009

2
Reducing water

• Third major method of food preservation
• Makes water less available to microorganisms
• Reduces mobility of water slows reactions
• Reduces the weight and volume of foods

3
History

• Drying is one of the oldest methods of
  preservation
• Sun and wind drying
• Smoking, and salting
• Drying herbs, meats, fruits and vegetables.
• Historians have credited the ability to store
  foods with the start of civilization.
• Today, it is still the simplest, cheapest, and
  most widely used method in the World.

4
History

• Sun drying around the Mediterranean
• Figs, raisins, dates, apricots
• Andes potatoes Chuno
• Native Americans Pemmican
• Central Asia pastrami

5
Simple drying system
6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
Fish drying on beach
11
(No Transcript)
12
Rack systems
13
(No Transcript)
14
Drying Fish Heads
Geothermal energy is used (Iceland)
15
Water in foods

• Constituents in foods bind water in varying
  degrees
• Hygroscopic (salt, sugars, proteins.)
• Non-hygroscopic (lipids)

16
Water activity

• In the equilibrium state
• mo RT ln(f / fo)
• where m (J mol-1) is the chemical potential of
  the system i.e. thermodynamic activity or energy
  per mole of substance
• mo is the chemical potential of the pure
  material at the temperature T(K)
• R is the gas constant (8.314 J mol-1 K-1)
• f is the fugacity or the escaping tendency of a
  substance
• fo is escaping tendency of pure material

17
Water activity

• The activity of a species is defined as
• a f/fo
• fugacity is closely approximated by the vapor
  pressure (f p) so
• aw f/fo _at_ p/po
• partial pressure of water over
  food
• Water activity ---------------------------------
  -------------
• vapor pressure of water
  at the same T

18
Partial pressure
Pure water
Solution
P, T
P, T
When there is a solute in water, it lowers the
vapor pressure of water over the solution
19
Partial Pressure

• For ideal, very dilute solutions, Raoults law

pwater po,water xwater
p partial pressure of water po vapor pressure
of water (from the steam tables) X mole
fraction of water
pwater / po,water xwater
20
Raoults law
1.0
Pure water
Ideal dilute
X Mole fraction water
Non-ideal concentrated
0.0
1.0
0.0
p/po
21
State of water

• Free water (available to microorganisms,
  available to chemical reactions either as a
  reactant, or as the transport medium for the
  reactants to move together, and the products to
  move away).
• Bound water (Tightly bound to individual sites
  hydroxyl groups of polysaccharides, carbonyl and
  amino groups of proteins, hydrogen bonding sites,
  ion-dipole sites, and other strong interactions
  not available as a solvent).

22
Isotherms

• (Constant temperature)
• Correlation between water activity of food and
  its water content.
• Water content is generally expressed in dry
  weight basis.

23
Dry basis / wet basis

• M wet basis moisture content
  (water/total100)
• X dry basis moisture content (water/solid100)

solid
total
water
24
(No Transcript)
25
Hysteresis

• When a dry food is re-hydrated, its aw is higher,
  at the same moisture level, than a wet food.
• Drying causes irreversible changes in food, so
  adding water does not bring it back to its
  original state.
• Ink bottle theory

26
(No Transcript)
27
Effect of Temperature

• For most foods, when T increases, then the aw
  increases at the same moisture level.
• For some food with much sugar, increase in T may
  increase the solubility of sugar, and therefore
  decrease aw.

28
Isotherm Equations

• Not possible to theoretically predict aw of any
  food for a given water content
• Measure the aw vs moisture content
• Fit isotherm equations, select the best.
• Isotherm equations are empirical

29
Halseys equation
X d.b. moisture content B1, B2 experimental
parameters
30
Bradleys equation
X d.b. moisture content B1, B2 experimental
parameters
31
Hendersons equation
X d.b. moisture content B1, B2 experimental
parameters
32
Iglesias/Chirife equation
X d.b. moisture content B1, B2 experimental
parameters X0.5 X at aw0.5
33
Kuhns equation
X d.b. moisture content B1, B2 experimental
parameters
34
Oswins equation
X d.b. moisture content B1, B2 experimental
parameters
35
Smiths equation
X d.b. moisture content B1, B2 experimental
parameters
36
BET equation
X d.b. moisture content Xm monolayer
moisture C experimental parameter BET should
not be used for awgt0.5
37
GAB equation
k correction factor for multilayers Xm
monolayer moisture content C Guggenheim constant
Hl Heat of condensation of pure water vapor, at
T, kJ/Kg mol Hq Total heat of sorption of the
multilayers, kJ/Kg mol Hm Total heat of sorption
of the first layer on primary sites, kJ/Kg mol R
gas constant, 8.314 kJ/Kg-mol K T
temperature, must be in K
38
Changes with temperature

• Most isotherm equations do not have a parameter
  that involves temperature.
• GAB has temperature parameters
• Other isotherm equations can be modified
  (extended) to include temperature

39
Extended Equations
Modified Chung-Pfost Modified
Halsey Modified Oswin Modified Henderson
40
aw and microorganisms

• The lowest aw at which the majority of food
  spoilage bacteria will grow is about 0.90.
• Staphylococcus aureus under anaerobic conditions
  is inhibited at an aw of 0.91, but aerobically
  the aw level is 0.86.
• The aw for mold and yeast growth is about 0.61
  with the lower limit for growth of mycotoxigenic
  molds at 0.78 aw

41
(No Transcript)
42
Effects of aw

• Enzymatic reactions slow down and stop as aw is
  reduced mobility, reactant (hydrolysis)
• Non-enzymatic reactions as aw increases,
  reaction rates increase mobility then decrease
  (dilution effects)

43
(No Transcript)
44
Effects of aw

• Lipid oxidation
• In dry food as water increases O2 absorption
  increases
• -Peroxide formation decreases as water increases
  below monolayer. H bonds to hydroperoxides reduce
  their rate of decomposition
• Trace metal are hydrated
• Metals form insoluble hydroxides
• At monolayer, oxidation rate is minimum.
• As moisture increases, oxidation rate increases
• Mobility, reactant, swelling of matrices

45
Drying

• The removal of water from fish muscle to extend
  shelf life
• Requires input of thermal energy
• Sun, wind, flame, electrical etc.

46
(No Transcript)
47
(No Transcript)
48
Drying mechanisms

• Drying is a sequence of events that take place in
  two main phases
• Phase 1 (constant rate period)
• Water is being removed from the fish surface
• Phase 2 (falling rate period)
• Water is removed from the fish muscle
• Water migrates to the fish surface
• Water is removed from the fish surface
• Water is removed from the atmosphere surrounding
  the fish surface
• If too rapid we can get case hardening

49
(No Transcript)
50
Constant Drying Rate Period

• There must be free, contiguous water at the
  surface.
• Then, the air sees water, and not the food.
  Rate of drying depends on air properties
• This period may or may not exist in foods

51
(No Transcript)
52
Falling drying rate period

• After the free water layer is partially
  evaporated, there are dry patches at the
  surface
• The water molecules are more tightly bound to the
  food, and are more difficult to remove
• Drying rate falls

53
(No Transcript)
54
Co-current / counter-current

• The air and the food exchange
• Heat (the air supplies heat)
• Moisture (the food loses moisture)
• Contact can happen co-currently, or
  counter-currently.

55
(No Transcript)
56
(No Transcript)
57
Types of driers

• Belt driers
• Tunnel driers
• Spray driers
• Drum driers
• Fluidized bed driers
• Freeze driers

58
(No Transcript)
59
(No Transcript)
60
Advanced automated driers
61
(No Transcript)
62
Tray Drier
63
Solar Driers
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
(No Transcript)
68
(No Transcript)
69
(No Transcript)
70
(No Transcript)
71
(No Transcript)
72
(No Transcript)
73
(No Transcript)
74
Tray drier
Vortex drier
75
Quality

• Irreversible changes in dried foods
• Vitamin C can be oxidized easily
• Lipids can be oxidized
• Case hardening (too fast a drying rate may dry
  the outer layers that become impermeable to
  water, and further drying stops)

76
Problems with dried fish

• If environmental T is too high and fish is too
  wet
• Molds (Awgt0.75)
• Grow very well when drying in tropical areas
• Black spots, which can be scraped off (fish not
  unfit for consumption)
• Aerobic spoilage bacteria (if non-salted)
• If salted (solar salt) can get halophiles growing
• Pink colonies
• Major problem with salted and dried cod
• Insects
• Insect parts and eggs a major quality problem
• Flies (Dipteria) lay eggs and can spread disease
• Larvae feeds on the fish
• Less problem with fish pre-drying
• Salting can deter flies
• Some use insecticides on fish!
• Also beetles (India) and roaches (post-drying)
• Rodents and birds are a constant problem

77
Problems with dried fish (cont.)

• Lipid oxidation (rancidity)
• Protein denaturation
• Get muscle fragmentation
• Case hardening
• Flesh soft on the inside and spoiled by bacteria
  (extreme putrid odor)

78
Pilot plant / lab

• See the water activity meter
• Observe the air drier
• Observe the drum drier
• Observe the spray drier
