Title: MATLAB Input-Output Statements


1
MATLAB Input-Output Statements
Nafees Ahmed Asstt. Professor, EE Deptt DIT,
DehraDun
2
Introduction
  • Data Input
  • Three methods
  • 1. Assign data to variables through an
    assignment statement
  • 2. Input data from Keyboard
  • 3. Read data from a file stored in computer memory

3
Data Input
  • 1. Assign data to variables through an
    assignment statement
  • gtgtx2
  • gtgty34.2
  • gtgtnameRaheel Sufyaan
  • or
  • gtgtx2 y34.2 nameRaheel Sufyaan

4
Data Input
  • 2. Input data from Keyboard (Interactive input)
  • Input Function
  • Keyboard Command
  • menu function
  • pause command

5
Data Input
  • I. Input Function See different version of this
    function
  • gtgtrinput(Enter radius in meters)
  • Enter radius in meters56 r will become integer
  • r
  • 56
  • Enter radius in meters ninety six r will
    become string , Note compulsory
  • r
  • ninety six
  • gtgtrinput(what is your fathers name, s) r
    string,
  • what is your fathers name Nafees Ahmed Note
    not required
  • r
  • Nafees Ahmed

6
Data Input
  • II. Keyboard return command
  • keyboard command when included in a script
    file returns control to the keyboard at the point
    where command occurs. The command window prompt
    is prefixed by the letter k. This command is
    used for
  • Check the intermediate results in the program
  • Make changes in variables value if required
  • Add new MATLAB commands in the program
  • Exp Make a .m file for the following code and
    run it
  • A10
  • B16
  • XAB
  • YX/2
  • Keyboard check the value of Y and change Y10,
    after finishing write return command, it
    will execute rest program
  • ZA-B

7
Data Input
  • III. menu function
  • for pictorial selection. Syntax is
  • Imenu(title, option1, option2,..)
  • Exp Make a .m file for the following code and
    run it
  • imenu('Select your favorite name','Teenu','Sumbul
    ','Humera')
  • if i1
  • disp('Teenu is your wife')
  • elseif i2
  • disp('Sumbul is yr sis-in-low')
  • elseif i3
  • disp('Humera is yr sis-in-low')
  • else
  • disp('Bewakoof kuch to select karo')
  • end

8
Data Input
  • IV. pause command
  • pause command temporarily halts the current
    computation and waits for the user to give a
    command to resume the computations. Pressing any
    key resumes the computation.
  • pause(k) command stops the computation for k
    seconds.
  • Exp Make a .m file for the following code and
    run it
  • P1 2 3 4 Q5 5 7 8
  • disp('The matrix P is given as')
  • disp(P)
  • disp('Program is paused, please press any key to
    display matrix Q')
  • pause
  • disp('The matrix Q is given as')
  • disp(Q)
  • ZPQ
  • disp('Program is paused, please press any key to
    display sum of P Q')
  • pause
  • disp(Z)
  • disp('Again program is pausing for 5 sec')
  • pause(5)

9
Reading and storing file data
  • There are many functions which are used to get
    data from the files.
  • 1.load function To load variables/data in
    workspace from the disk file
  • Different syntax are
  • load load matlab.mat (default) file
  • Load(filename) load complete file whose name
    is given
  • Load(filename, x, y, z) load only
    variables x, y, z of given file
  • Load filename x, y, z same as above
  • Note-
  • No extension with file name means .mat file
  • If file name has extension other than (.mat) it
    will be treated as ASCII data file
  • Load function is use only if data file contains
    numeric data

10
Reading and storing file data
  • Exp
  • gtgtedit abc.txt
  • Write following and save it
  • 3 4 5 7
  • 7 8 0 9
  • gtgtload abc.txt it will load this file in
    workspace with a variable name abc, to check
    it write abc
  • gtgtabc
  • 3 4 5 7
  • 7 8 0 9
  • If we want to change the variable name write
    following command
  • gtgttestload (abc.txt) now data abc.txt will
    store in variable test

11
Reading and storing file data
  • 2.save function To save variables/data from
    workspace to disk file
  • Different syntax are
  • save save all workspace data in matlab.mat
    file
  • save(filename) save complete workspace data
    in specified file name
  • save(filename, x, y, z) save only
    variables x, y, z in a file
  • save filename x, y, z same as above
  • Note-
  • No extension with file name means .mat file
  • If file name has extension other than (.mat) it
    will be treated as ASCII data file
  • To save variables to a directory other than
    current directory, full pathname of the file has
    to be specified.

12
Reading and storing file data
  • 3.dlmread function To read numeric text data
    separated by character other than
    space.(dlmgtdelimiter, by default delimiter is
    comma )
  • Different syntax are
  • datadlmread(filename) read numeric data from
    ASCII delimited file named filename
  • datadlmread(filename, delimiter) read
    numeric data from ASCII delimited with other
    delimiter
  • i.e.
  • var_namedlmread(abc.txt, ) this will
    read the data from file abc.txt till it
    encounters delimiter.
  • For example see next slide

13
Reading and storing file data
  • 4.dlmwrite function To write numeric text data
    separated by character other than space.
    (dlmgtdelimiter, by default delimiter is comma )
  • Different syntax are
  • dlmwrite(filename,A) write matrix A on a
    specified file name with default delimiter (,)
  • dlmwrite(filename, A, D) write matrix A
    on a specified file name with default delimiter
    D
  • i.e.
  • gtgtA1 2 3 4 5 6 7 8 9
  • gtgtdlmwrite(abcd.txt, A,D) this will write
    matrix A on file abcd.txt with delimiter D.
    Open this file See.
  • Now try
  • gtgtBdlmread(abcd.txt,D)

14
Reading and storing file data
  • 5.textscan and textread functions If a text
    file contains numeric as well as other
    characters. The file need to be opened for read
    operation using fopen command then read using
    textscan command.
  • Different syntax are
  • fidfopen(abc.txt, r) Open abc.dat file
    for reading
  • var_nametextscan(fid, f c .) here f
    for float, c for char etc
  • Note var_name will be cell array
  • The command textread can be used to read the data
    into separate variables.
  • a, b, c, dtextread(abc.txt, f c .)
  • i.e.
  • name, types, a, b, ctextread(abc.txt, s s
    f f f)

15
Output commands
  • 1. Output may be formatted or unformatted
  • Default format
  • gtgta7
  • a 7
  • gtgtb1.01
  • b 1.0100 4 digit after decimal
  • gtgt2100.34
  • c 2.1003e003 2.1003x103
  • Format command to change default format
  • gtgtxpi
  • x 3.1416
  • gtgtformat long similarly we can have other
    format also see help
  • x
  • 3.141592653589793

16
Output commands
  • disp function
  • gtgtA1 2 3 4 to display variable
  • gtgtdisp(A)
  • 1 2
  • 3 4
  • gtgtdisp(The largest number is) to display a
    message
  • The largest number is

17
Low-level input-output functions
  • There are a number of low-level file input-output
    function in MATLAB taken from ANSI Standard C
    Library. These are
  • 1. File opening and closing functions
  • 2. Binary input-output functions
  • 3. Formatted input-output functions

18
Low-level input-output functions
  • 1. File opening and closing functions
  • fopen function To perform any operation on
    file the first step is open it. Syntax are
  • fidfopen( filename, permission_code)
  • where
  • fidfile id
  • permission_code read or write or append
  • fid, message fopen(filename,
    permission_code)
  • where
  • message error msg if file doesnt open
    properly otherwise it is empty string
  • fid, message fopen(filename,
    permission_code, format)
  • where
  • format optional string specifying the
    numeric format of the data in the file

19
Low-level input-output functions
  • Standard file identifier values
  • Note As more files are opened fids are allotted
    in continuation and if a particular file is
    closed, the fid assigned to it is released.

fid Meaning
-1 Fid opening fails
0 Standard input (keyboard)
1 Standard output (monitor screen)
2 Standard error
3 onwards Assign to file opened successfully
20
Low-level input-output functions
  • Permission code
  • Note As more files are opened fids are allotted
    in continuation and if a particular file is
    closed, the fid assigned to it is released.

Permission text string Meaning
r Open a file(default) for reading, if not exist error occurs
r Open a file(default) for reading writing, if not exist error occurs
w Delete the contents of an existing file or create a new file, and open it for writing.
w Delete the contents of an existing file or create new file, and open it for reading and writing.
a Create and open a new file or open an existing file for writing, appending to the end of the file.
a Create and open new file or open an existing file for reading and writing, appending to the end of the file.
21
Low-level input-output functions
  • Other use of fopen function
  • fidsfopen(all)
  • where
  • fidsa vector showing file ids of all opened
    files
  • filename, permission_code, format fopen(fid)
  • This function provieds filename,
    permission_code format for open file specified
    by fid

22
Low-level input-output functions
  • fclose function After performing operations on
    file the last step is to close it. Syntax are
  • status fclose( fid)
  • where
  • status 0 if successfully closed
  • -1 otherwise
  • status fclose(all)
  • It closes all open files except for standard
    output(fid 1) standard error (fid 2)
  • Note Standard input, output error cant be
    opened or closed with fopen fclose functions

23
Low-level input-output functions
  • Formatted input-output functions These are used
    to print, scan or get data in desired format.
    Different functions are
  • fprintf function
  • fscanf function
  • fgetl function
  • fgets function

24
Low-level input-output functions
  • fprintf function Syntax is
  • fprintf(fid, format, data)
  • Exp Create a file having following code and rut
    it.
  • x 0.11 y x exp(x)
  • fid fopen('exp.txt','w')
  • fprintf(fid,'6.2f 12.8f\n', y)
  • fclose(fid)
  • Now open the file exp.txt and see the data
  • Note 1. Here 6.2f .
  • it always starts with sign
  • 6 total width of field
  • 2 no of digits after decimal
  • f fixed point
  • 2. fprintf(6.2f 12.8f\n, y ) will print on
    monitor,
  • here fid 0 i.e monitor

25
Low-level input-output functions
In general format may be written as a.be Or
a.be always print with sign character
( or -) Or -a.be - left justified Or
0a.be pad zeros in starting Here a
field width b digits after decimal point e
conversion character (c for char, s for string,
d for int, e for exponential, f for fixed
point etc) Note 1. '6.2f 12.8f\n
here note the space b/w to formats 2. \n means
new line 3. fprintf displays only real
portion of complex value
26
Low-level input-output functions
  • fscanf function Syntax is
  • fscanf(fid, format)
  • And
  • A, count fscanf(fid, format, sizeA)
  • Where
  • A variable to store data
  • count no of values reads from the files
  • sizeA size of matrix A
  • Exp Read the data of previously created file
    exp.txt. Create a file having following code
    and rut it.
  • fid fopen('exp.txt')
  • A fscanf(fid, 'g g', 2 inf) A is 2
    row x inf column matrix
  • AA transpose to get the
    original matrix
  • fclose(fid)

27
Low-level input-output functions
  • fgetl function Reads the next line of the
    specified file, removing the newline characters.
  • Syntax is
  • statementfgetl(fid)
  • Exp Read and display the file fgetl.m one line
    at a time
  • fid fopen('fgetl.m')
  • tline fgetl(fid)
  • while ischar(tline)
  • disp(tline)
  • tline fgetl(fid)
  • end
  • fclose(fid)

28
Low-level input-output functions
  • fgets function Reads the next line of the
    specified file, including the newline characters
  • Syntax is
  • statementfgets(fid)
  • Exp Read and display the file fgetl.m one line
    at a time
  • fid fopen('fgetl.m')
  • tline fgets(fid)
  • while ischar(tline)
  • disp(tline)
  • tline fgets(fid)
  • end
  • fclose(fid)

29
Low-level input-output functions
  • Binary input-output functions The formatted
    input-output functions works with human readable
    text in a file. This file is also called an ASCII
    text file. These files require more disk space as
    compared to binary files.
  • Different functions for binary files system are
  • fwrite function
  • fread function

30
Low-level input-output functions
  • fwrite function Syntax is
  • countfwrite(fid, array, percision)
  • Where
  • count no of values (data) written to file
  • fid file id
  • array array of values to be written
  • precision format of storing the values (char,
    uchar, short, int, long, float, double)

31
Low-level input-output functions
  • Exp Please make a .m file of following code and
    run it.
  • clear all clear
    all variable in workspace
  • fidfopen('check.txt','r')
  • A, count1fread(fid, 2,3, 'double') A is
    double 2x3 matrix
  • B, count2fread(fid, 1, 'int') B is an
    int constant
  • C, count3fread(fid, inf, 'char') C is a
    char string
  • CC'
    transpose of C
  • Cchar(C) Convert
    numeric values into character string
  • fclose(fid

32
Low-level input-output functions
  • fread function Syntax is
  • variable, countfread(fid, size, percision)
  • Where
  • variable values to be read from file
  • size dimensions of data to be read
  • Note To read binary data from a file correctly,
    it must be know how it was written

33
Low-level input-output functions
Exp Please make a .m file of following code and
run it. a2 3 6 3 5 7 b105 c'IPL has
started' fidfopen('check.txt',r') A,
count1fread(fid, 2,3, 'double') A is
double 2x3 matrix B, count2fread(fid,
1, 'int') B is an int constant C,
count3fread(fid, inf, 'char') C is a char
string fclose(fid)
34
Write a Comment
User Comments (0)
About PowerShow.com
