Title: CRIME%20PREVENTION%20PART%20I%20SECURITY


1
CRIME PREVENTION PART I SECURITY ALARMS
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2010)

2
OBJECTIVES
  • Learning Objective The student will be able to
    identify the three basic components of an alarm
    system.
  • Learning Objective The student will be able to
    define and describe the proper use of the
    following alarm sensors space or motion
    detectors, microwave, infrared, ultrasonic,
    magnetic switches, glass breakage and impact
  • Learning Objective The student will be able to
    describe the basic circuitry of an alarm system.
  • Learning Objective The student will be able to
    define local annunciator and remote annunciator.
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

3
OBJECTIVES
  • Learning Objective The student will be able to
    define the following terms multiplexing,
    microwave transmission and dialers
  • Learning Objective The student will be able to
    explain the parts of an alarm control unit.
  • Learning Objective The student will be able to
    define the requirements of an alarm system.
  • Learning Objective The student will be able to
    explain the common problems associated with alarm
    systems, contributing factors to those problems
    and recommendation to solve problems identified.
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

4
ALARM HISTORY
  • Consider what you are protecting life or -
    value
  • Crime prevention geese390 BC Romans
  • 1900's fire alarmsinsurance companies had own
    fire companies respond to their customers only
    term fire company

5
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

6
ALARM HISTORY
  • ALARM AS A DETERRANT
  • A physical deterrent by the noise and attention
  • A psychological deterrent if a perpetrator knows
    or beliefs a building has an alarm system
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

7
WHY PEOPLE NEED AN ALARM SYSTEM
8
ALARM HISTORY
  • McCULLOUGH LOOP
  • McCullough Loop basically a single telephone line
    that is linked from site to site with a
    transmitter at each site.
  • When the alarm is tripped at that site, the
    transmitter signals a series of signals (similar
    to a telegraph key).
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

9
ALARM HISTORY
  • 80 percent of existing alarms today are still on
    existing phone lines
  • Microwave and satellitefuture of business
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

10
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

11
ALARM SYSTEM
Three main components of an alarm
  • Control Unit (Brain)
  • Power supply
  • Circuitry
  • Sensory controls
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

12
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

13
ALARM SYSTEM
Three main components of an alarm
  • Annunciation System
  • Local
  • Bell
  • Light
  • Siren
  • Remote monitoring station
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

14
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

15
ALARM SYSTEM
Three main components of an alarm
  • Sensors Detectors
  • Touch or feel (Contact type)
  • Audio hear (Noise)
  • Sight (PIR)
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

16
  • TOUCH CONTACT SENSOR
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

17
ALARM SYSTEM
  • Key to reliable alarm system is proper
    application and use (informed users) of proper
    equipment
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

18
ALARM SYSTEM
Three main components of an alarm
  • Control or brain
  • Annunciation or reporting device siren, bell or
    light
  • Sensors or detector see, hear feel
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

19
ALARM SYSTEM
CONTROL UNIT
  • Receiving, transmitting, interpreting messages
  • Links all parts of the system
  • Power supply
  • Access control
  • Sensitivity adjustments
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

20
ALARM SYSTEM
CONTROL UNIT Contd
  • Time delay
  • Anti-tamper devices
  • Sensor control
  • Signal transmission to remote station
  • Battery backup
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

21
  • CONTROL UNIT
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

22
ALARM SYSTEM
SENSORS DETECTORS
  • Imitating mechanically, electrically,
    electronically human senses
  • Touch or feelmagnetic switch, spring switch,
    mercury switch, pressure sensitive mat, foil,
    wire lacing, trip wire, vibration detection
    (seismic)
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

23
ALARM SYSTEM
SENSORS DETECTORS
  • Imitating Hearingultrasonic (Doppler) audio
    senses
  • Sightphotoelectric beams, light intensity
    changes, microwave, CCTV
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

24
  • DOPPLER (Hearing) SENSOR
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

25
ALARM SYSTEM
SENSORS DETECTORS
  • Intrusion Sensing Devices
  • Hardwire switches
  • Magnetic switches
  • Plunger switches
  • Metal foil switch
  • Glass breakage - Vibration
  • Mercury switches - tilt windows or overhead
    doors, screen or grill wires
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

26
  • GLASS BREAKAGE SENSOR
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

27
  • Screen Sensor
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

28
ALARM SYSTEM
SENSORS DETECTORS
  • Space or Motion detectors
  • Photoelectric invisible beam sender receiver or
    combination of both bounce or refract off
    detected objects
  • Ultrasonic Doppler shift detect motion radar,
    sonar
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

29
  • MOTION DETECTOR SENSOR
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

30
ALARM SYSTEM
SENSORS DETECTORS
  • Space or Motion detectors
  • Microwave detect motion from interruption of
    waves
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

31
ALARM SYSTEM
SENSORS DETECTORS
  • Space or Motion detectors
  • Passive Infrared (PIR) invisible light detects
    ambient temperature changes
  • Avoid direct sunlight
  • Used a lot in combination with microwave and
    ultrasonic best for reducing false alarms

32
  • INFRARED
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

33
ALARM SYSTEM
SENSORS DETECTORS
  • Audio
  • Impact
  • Frequency
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

34
ALARM SYSTEM
SENSORS DETECTORS
  • Today many sensors are used in tandem to lower
    potential for false alarmsexample impact and
    glass breakage.
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

35
UNDERWRITER LABRATORIES
  • Underwriters Laboratories Inc. (UL) is a U.S.
    privately owned and operated, independent, third
    party product safety testing and certification
    organization. Based in Northbrook, Illinois, UL
    develops standards and test procedures for
    products, materials, components, assemblies,
    tools and equipment, chiefly dealing with product
    safety.
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

36
ALARM SYSTEM
MINIMUM REQUIREMENTS
  • Property is equipped with an electronic burglar
    alarm that meets the following requirements
  • All exterior structure openings are contacted
  • The system includes an interior and exterior siren
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

37
ALARM SYSTEM
MINIMUM REQUIREMENTS
  • Continued
  • All equipment is U.L. approved and is monitored
    by a U.L. approved central station
  • Appropriate alarm permit (if applicable based on
    applicable statute and/or ordinance)
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

38
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

39
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

40
ALARM SYSTEM
CONTROL UNIT Contd
  • Time delay
  • Anti-tamper devices
  • Sensor control
  • Signal transmission to remote station
  • Battery backup
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

41
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

42
TAKE A 15-Minute BREAK
43
ALARM SYSTEM
Basic Alarm Circuitry
  • In a normally open loop there is not a complete
    loop from one side of the power source to the
    other
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

44
(No Transcript)
45
ALARM SYSTEM
Basic Circuitry Contd
  • In order for the loop to become a closed loop,
    the switch (or sensor) needs to be activated and
    moved to the closed position. When this switch
    is closed, we have a complete or closed loop
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

46
ALARM SYSTEM
Basic Circuitry Contd
  • When the loop is closed, electronic pulse flows
    from one side of the control unit through the
    loop to the other side. With signal now flowing
    through the loop, the relay is energized and the
    alarm activates
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

47
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

48
ALARM SYSTEM
Basic Circuitry Contd
  • The biggest problem with this type of loop is any
    part of the loop may be cut without detection.
    For this reason, a normally open loop is referred
    to as unsupervised and is not commonly used by
    itself in alarm systems.
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

49
ALARM SYSTEM
Basic Circuitry Contd
  • This configuration allows pulses to flow in the
    loop and keeps the relay energized. In this
    loop, as long as the relay is energized, there is
    no alarm. However, when the relay is
    de-energized, by activating the switch, the alarm
    alerts
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

50
ALARM SYSTEM
Basic Circuitry Contd
  • If additional switches sensors are added to the
    normally closed protected loop, they must be
    inserted in such a way that opening any one of
    them causes an open circuit. To provide this
    feature the switches are hooked in series to one
    another (i.e., one right after another).
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

51
ALARM SYSTEM
Basic Circuitry Contd
  • A normally closed loop is referred to as a
    supervised circuit since cutting any of the wires
    in the protective circuit activates an alarm
    condition.
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

52
ALARM SYSTEM
Basic Circuitry Contd
  • A normally closed loop is referred to as a
    supervised circuit since cutting any of the wires
    in the protective circuit activates an alarm
    condition.
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

53
ALARM SYSTEM
Basic Circuitry Contd
  • A basic weakness in a normally closed system is
    the switches may be "jumped out" or shorted
    across without initiating an alarm when that
    particular switch is activated. This
    characteristic of the closed loop is used when
    installing a device known as a shunt lock or
    shunt switch.
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

54
Shunt switch diagram
55
ALARM SYSTEM
Basic Circuitry Contd
  • The shunt switch is used to bypass a selected
    detector or zone, for instance, on the front
    door, so the premise is entered by authorized
    persons without sounding an alarm. By turning
    the shunt lock to the unlocked position a jumper
    or shunt is created around the selected
    detector(s).

56
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

57
ALARM SYSTEM
Basic Circuitry Contd
  • A normally closed loop is referred to as a
    supervised circuit since cutting any of the wires
    in the protective circuit activates an alarm
    condition.
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

58
ALARM SYSTEM
Basic Circuitry Contd
  • Supervised Loop can be combination of open and
    closed loops monitored by computer that is
    constantly checking each individual sensor every
    few seconds. Cutting or splicing wires will not
    disarm the supervised loop
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

59
ALARM SYSTEM
Basic Circuitry Contd
  • Remember that a Shunt Switch is used to bypass
    selected zone or detector for closed alarm
    system to allow entry into a zone without
    setting off the alarm.
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

60
WHO TO CALL WITH QUESTIONS
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

61
REMOTE ALARM SYSTEM
TRANSMISSION CIRCUITS
  • Most use existing phone lines.
  • Direct connect
  • Multiplexingparty lines many users instead of
    dedicated phone line or radio frequency
    broadcasting of data
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

62
REMOTE ALARM SYSTEM
TRANSMISSION CIRCUITS
  • Dialers must have override capability as (the
    same as) a priority (911) call to Sheriffs
    Office or Police Department.
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

63
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

64
ALARM SYSTEM
FALSE ALARMS
  • Common problems
  • User error or negligence 60 by far most common
    cause of false security alarms
  • 25 percent poor installation or defective
    equipment
  • Ten percent use for purposes other than for which
    it was intended
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

65
ALARM SYSTEM
FALSE ALARMS
  • Loose contacts loose or bad wiring
  • Building vibration battery replacement
  • Lack of consistent Ordinances fees and fines
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

66
ALARM SYSTEM
NEW TECHNOLOGY
  • There is continually new alarm technology within
    the security industry. The following is a brief
    slide show to allow you to see some of the new
    alarm technology available
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

67
Security Alarm Lamp
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

68
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

69
New Macintosh with built in alarm
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

70
SOURCES
Handbook of Loss Prevention and Crime Prevention
(Fourth Edition) Lawrence J. Fennelly.
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

71
DEFINE PROCESS
  1. Identify the three basic components of an alarm
    system.
  2. Define and describe the proper use of the
    following alarm sensors space or motion
    detectors, microwave, infrared, ultrasonic,
    magnetic switches, glass breakage and impact
  3. Describe the basic circuitry of an alarm system.
  4. Explain local annunciator and remote annunciator.
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

72
DEFINE PROCESS
  1. Define and explain the following terms
    multiplexing, microwave transmission and dialers
  2. Explain the parts of an alarm control unit.
  3. Define the requirements of an alarm system.
  4. Explain the common problems associated with alarm
    systems, contributing factors to those problems
    and recommendation to solve problems identified.
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

73
QUESTIONS
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

74
Contact Information
  1. INSTITUTE for CRIMINAL JUSTICE STUDIES
  2. 350 N. Guadalupe, Suite 140, PMB 164
  3. San Marcos, Texas 78666.
  • www.criminaljusticestudies.com
  • 512-245-6232
  1. TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

75
TEAM VISIT
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

76
HOME DEPOT LOWES VISIT
  • TEAM ASSIGNMENTS
  • TEAM I - LOCKS
  • TEAM II DOORS
  • TEAM III WINDOWS
  • TEAM IV LIGHTING
  • TEAM V SECURITY ALARMS
  • TEAM VI FENCING
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

77
HOME DEPOT LOWES VISIT
  • INSTRUCTIONS
  • Each team will not spend more than 10-minutes per
    area
  • Teams will rotate every 10-minutes
  • Make brief (bullet) notes of your observations on
    your assigned area.
  • Prepare one combined Team report
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)

78
SEE YOU ALL TOMORROW
  • 800 AM (SHARP) WEDNESDAY MORNING
  • TCLEOSE Course 2101 Crime Prevention Part I
    Curriculum is the intellectual property of ICJS
    (2009)
About PowerShow.com
