Title: A


1
AP I Exam 2 Review Slides
  • Lectures 5-8
  • Ch. 2, 3, and 24 (cell resp.)

2
A Closer Look at Mitochondria
Figure from Martini, Anatomy Physiology,
Prentice Hall, 2001
(Impermeable to charged or polar molecules)
  • Mitochondria
  • membranous sacs with inner partitions
  • contain their own DNA
  • generate energy

Strategically placed in cell where ATP demand is
high
Concentration of enzymes in the matrix is so high
that there is virtually no hydrating water.
Enzyme-linked reactions and pathways are so
crowded that normal rules of diffusion do not
apply!
3
Overview of Cellular Respiration
Figure from Martini, Anatomy Physiology,
Prentice Hall, 2001
Anaerobic
Cellular respiration (aerobic)
ATP
e-
Most ATP from here
e-
ETS
e-
ATP
e-
  • Structural Functional Relationship - Inner
    membrane
  • Contains Matrix where TCA cycle takes place
  • Has enzymes and molecules that allow Electron
    Transport System to be carried out

4
Overview of Glucose Breakdown
NAD
NADH
NAD
NADH
NAD, FAD
NADH FADH2
Figure from Holes Human AP, 12th edition, 2010
5
Anaerobic Glycolysis Lactic Acid
During glycolysis, if O2 is not present in
sufficient quantity, lactic acid is generated to
keep glycolysis going so it continues to generate
ATP (even without mitochondria)
Figure from Holes Human AP, 12th edition, 2010
NOTE what happens with and without O2 being
available
6
Summary Table of Cell Respiration
GLYCOLYSIS TCA ETC

Where it takes place Cytoplasm Mitochondria Mitochondria
Products Produced ATPNADHPyruvate ATPNADH,FADH2CO2 ATPNAD,FADH2O
Purpose Breakdown of glucose (6 carbons) to 2 molecules of pyruvate (3 carbons) Generation of energy intermediates (NADH, FADH2, ATP) and CO2 Generation of ATP and reduction of O2 to H2O (Recall that reduction is the addition of electrons)
What goes on 1. Glucose is converted to pyruvate, which is converted to acetyl CoA when there is sufficient O2 present. 2. Acetyl CoA enters the TCA cycle. 3. If O2 is not present, pyruvate is converted to lactic acid to replenish the supply of NAD so glycolysis can continue to make ATP 1. The energy in acetyl CoA is trapped in activated carriers of electrons (NADH, FADH2) and activated carriers of phosphate groups (ATP). 2. The carriers of electrons that trap the energy from acetyl CoA bring their high energy electrons to the electron transport chain. 1. Chemiosmosis (that drives oxidative phosphorylation) uses the electrons donated by NADH and FADH2 to eject H from the matrix of the mitochondria to the intermembrane space. 2. These H then flow down their concentration gradient through a protein (ATP synthase) that makes ATP from ADP and phosphate. 3. During this process, the H that come through the channel in ATP synthase are combined with O2 to make H2O.
7
Some Definitions
Chromatin combination of DNA plus histone
proteins used to pack DNA in the cell nucleus
Gene segment of DNA that codes for a protein or
RNA - About 30,000 protein-encoding genes in
humans - DNAs instructions are ultimately
responsible for the ability of the cell to make
ALL its components
  • Genome complete set of genes of an organism
  • Human Genome Project was complete in 2001
  • Genomes of other organisms are important also

Genetic Code method used to translate a
sequence of nucleotides of DNA into a sequence of
amino acids
8
Structure of Nucleic Acids
Purines Adenine and Guanine (double
ring) Pyrimidines Cytosine, Thymine, and Uracil
(single ring)
Figure from Alberts et al., Essential Cell
Biology, Garland Press, 1998
9
Structure of DNA
5'
3'
A double-stranded DNA molecule is created by
BASE-PAIRING of the nitrogenous bases via
HYDROGEN bonds. Notice the orientation of the
sugars on each stand.
5'
3'
DNA is an antiparallel, double-stranded
polynucleotide helix
10
Structure of DNA
Complementary base pairing
Base pairing in DNA is VERY specific. -
Adenine only pairs with Thymine (A-T) - Guanine
only pairs with Cytosine (G-C)
Note that there are - THREE hydrogen bonds in
G-C pairs - TWO hydrogen bonds in A-T pairs - A
purine (two rings)base hydrogen bonds with a
pyrimidine base (one ring)
Figure from Martini, Human Anatomy
Physiology, Prentice Hall, 2001
11
DNA Replication
5
  • THINGS TO NOTE
  • DNA is replicated in the S phase of the cell
    cycle
  • New strands are synthesized in a 5 to 3
    direction
  • DNA polymerase has a proofreading function (1
    mistake in 109 nucleotides copied!)
  • Semi-conservative replication describes pairing
    of post-replication strands of DNA (1 new, 1 old)

3
5
3
5
3
3
5
3
Figure from Martini, Human Anatomy
Physiology, Prentice Hall, 2001
5
12
RNA
  • RNA is a polynucleotide with important
    differences from DNA
  • Uses Uracil (U) rather than Thymine (T)
  • Uses the pentose sugar, ribose
  • Usually single-stranded
  • There are three important types of RNA
  • mRNA (carries code for proteins)
  • tRNA (the adapter for translation)
  • rRNA (forms ribosomes, for protein synthesis)

13
Transciption/Translation
  • Transcription
  • generates mRNA from DNA
  • Occurs in nucleus of the cell
  • Uses ribonucleotides and RNA polymerase to
    synthesize mRNA
  • Translation
  • generates polypeptides (proteins) from mRNA
  • Occurs in the cytoplasm of the cell
  • Uses 3 components mRNA, tRNA w/aa, and ribosomes

14
The Genetic Code
  1. Codon group of three ribonucleotides found in
    mRNA that specifies an aa
  2. Anticodon group of three ribonucleotides found
    in tRNA that allows specific hydrogen bonding
    with mRNA
  3. AUG is a start codon and also codes for MET.
    UAA, UAG, and UGA are stop codons that terminate
    the translation of the mRNA strand.

15
Find the AMINO ACID SEQUENCE that corresponds to
the following gene region on the DNA Template
-gt C T A A G T A C T Coding -gt G A T T C A T
G A
16
tRNAs
Transfer RNAs (tRNA) function as adapters to
allow instructions in the form of nucleic acid to
be converted to amino acids.
Figures from Martini, Anatomy Physiology,
Prentice Hall, 2001
17
Eukaryotic Genes
The template strand of DNA is the one thats
transcribed. The coding strand of DNA is used as
the complementary strand for the template strand
in DNA and looks like the codons.
Figure from Alberts et al., Essential Cell
Biology, Garland Publishing, 1998
18
Eukaryotic mRNA Modification
Newly made eukaryotic mRNA molecules (primary
transcripts) undergo modification in the nucleus
prior to being exported to the cytoplasm. 1.
Introns removed2. 5' guanine cap added3.
Poly-A tail added
Figure from Alberts et al., Essential Cell
Biology, Garland Publishing, 1998
19
The Fate of Proteins in the Cell
  • Breakdown of proteins regulates the amount of a
    given protein that exists at any time.
  • Each protein has unique lifetime, but the
    lifetimes of different proteins varies
    tremendously.
  • Proteins with short life-spans, that are
    misfolded, or that become oxidized must be
    destroyed and recycled by the cell.

Enzymes that degrade proteins are called
proteases. They are hydrolytic enzymes.
Most large cytosolic proteins in eukaryotes are
degraded by enzyme complexes called proteasomes.
20
Cell Membranes
Figure from Martini, Anatomy Physiology,
Prentice Hall, 2001
21
Passage of Materials through the Cell Membrane
Carrier/channel proteins required for all but
fat-soluble molecules and small uncharged
molecules
oxygen, carbon dioxide and other lipid-soluble
substances diffuse freely through the membrane
22
Cellular Transport Review
TRANSPORT PROCESS IS ENERGY NEEDED? CONCEN- TRATION GRADIENT GENERAL DESCRIPTION EXAMPLE IN HUMANS SIGNIFICANCE
SIMPLE DIFFUSION NO HIGH TO LOW spreading out of molecules to equilibrium O2 into cells CO2 out of cells. Cellular Respiration
FACILITATED DIFFUSION NO HIGH TO LOW Using a special carrier protein to move something through the cell membrane (cm) Process by which glucose enters cells
OSMOSIS NO HIGH TO LOW water (solvent) moving through the cell membrane to dilute a solute maintenance of osmotic pressure. Same
FILTRATION NO HIGH TO LOW using pressure to push something through a cell mmembrane (sprinkler hose) manner in which the kidney filters things from blood Separates small from large molecules using hydrostatic pressure
ACTIVE TRANSPORT YES LOW TO HIGH opposite of diffusion at the expense of energy K-Na-ATPase pump maintenance of the resting membrane potential
23
Cellular Transport Review
TRANSPORT PROCESS IS ENERGY NEEDED? CONCEN- TRATION GRADIENT GENERAL DESCRIPTION EXAMPLE IN HUMANS SIGNIFICANCE
ENDOCYTOSIS YES LOW TO HIGH bringing a substance into the cell that is too large to enter by any of the above ways Phagocytosi cell eating Pinocytosis cell drinking. Phagocytosed (foreign) particles fuse with lysosomes to be destroyed help fight infection
EXOCYTOSIS YES LOW TO HIGH expelling a substance from the cell into ECF Exporting proteins dumping waste Same
24
Osmotic Pressure/Tonicity
Osmotic Pressure (Osmolarity) ability of solute
to generate enough pressure to move a volume of
water by osmosis
Osmotic pressure increases as the number of
nonpermeable solutes particles increases
  • isotonic same osmotic pressure as a second
    solution
  • hypertonic higher osmotic pressure
  • hypOtonic lower osmotic pressure

0.9 NaCl5.0 Glucose
Crenation
The O in hypotonic
25
Cell Nucleus
  • control center of cell
  • nuclear envelope (membrane)
  • porous double membrane
  • separates nucleoplasm from cytoplasm
    (eukaryotes only)
  • nucleolus
  • dense collection of RNA and proteins
  • site of ribosome production
  • chromatin
  • fibers of DNA and proteins
  • stores information for synthesis of proteins

Figure From Marieb Hoehn, Human Anatomy
Physiology, 9th ed., Pearson
26
Cellular Organelles
Table 1 of 2
CELL COMPONENT DESCRIPTION/ STRUCTURE FUNCTION(S)
CELL MEMBRANE Bilayer of phospholipids with proteins dispersed throughout cell boundary selectively permeable (i.e. controls what enters and leaves the cell membrane transport)
CYTOPLASM jelly-like fluid (70 water) suspends organelles in cell
NUCLEUS Central control center of cell bound by lipid bilayer membrane contains chromatin (loosely colied DNA and proteins) controls all cellular activity by directing protein synthesis (i.e. instructing the cell what proteins/enzymes to make.
NUCLEOLUS dense spherical body(ies) within nucleus RNA protein Ribosome synthesis
RIBOSOMES RNA protein dispersed throughout cytoplasm or studded on ER protein synthesis
ROUGH ER Membranous network studded with ribosomes protein synthesis
SMOOTH ER Membranous network lacking ribosomes lipid cholesterol synthesis
GOLGI Stack of Pancakes cisternae modification, transport, and packaging of proteins
27
Cellular Organelles
Table 2 of 2
CELL COMPONENT DESCRIPTION/ STRUCTURE FUNCTION(S)
LYSOSOMES Membranous sac of digestive enzymes destruction of worn cell parts (autolysis) and foreign particles
PEROXISOMES Membranous sacs filled with oxidase enzymes (catalase) detoxification of harmful substances (i.e. ethanol, drugs, etc.)
MITOCHONDRIA Kidney shaped organelles whose inner membrane is folded into cristae. Site of Cellular Respiration Powerhouse of Cell
FLAGELLA long, tail-like extension human sperm locomotion
CILIA short, eyelash extensions human trachea fallopian tube to allow for passage of substances through passageways
MICROVILLI microscopic ruffling of cell membrane increase surface area
CENTRIOLES paired cylinders of microtubules at right angles near nucleus aid in chromosome alignment and movement during metaphase, anaphase, and telophase of mitosis
28
The Cell Cycle
  • series of changes a cell undergoes from the time
    it forms until the time it divides
  • stages
  • interphase
  • mitosis
  • cytoplasmic division
  • differentiation

Figure From Marieb Hoehn, Human Anatomy
Physiology, 9th ed., Pearson
Differentiated cells may spend all their time in
G0 (neurons, skeletal muscle, red blood cells).
Stem cells may never enter G0
29
Why the Cell Cycle Must Have Controls
  • 1. DNA/Cell replication must not proceed unless a
    signal to proceed is received
  • 2. DNA must be completely and correctly replicate
    before mitosis takes place otherwise it should
    not occur.
  • 3. Chromosomes must be correctly positioned
    during mitosis so they are separated correctly

30
What are the Controls of the Cell Cycle?
  • cell division capacities vary greatly among cell
    types
  • skin and bone marrow cells divide often
  • liver cells divide a specific number of times
    then cease
  • chromosome tips (telomeres) that shorten with
    each mitosis provide a mitotic clock (cell
    senescence)
  • cells divide to provide a more favorable surface
    area to volume relationship
  • growth factors and hormones stimulate cell
    division
  • hormones stimulate mitosis of smooth muscle
    cells in uterus
  • epidermal growth factor stimulates growth of new
    skin
  • contact inhibition
  • Cyclins and Cyclin-dependent kinases provide
    central control
  • tumors are the consequence of a loss of cell
    cycle control

31
Mitosis and Meiosis
Figures from Martini, Anatomy Physiology,
Prentice Hall, 2001
Mitosis production of two identical diploid
daughter cells Meiosis production of four
genetically varied, haploid gametes
32
The Cell Cycle and Mitosis
  • I (INTERPHASE)
  • PASSED (PROPHASE)
  • MY (METAPHASE)
  • ANATOMY (ANAPHASE)
  • TEST (TELOPHASE/CYTOKINESIS)

33
Interphase and Mitosis (IPMAT)
Interphase
Early Prophase
Late Prophase
Metaphase
Anaphase
Telophase/Cytokinesis
34
Cell Death
  • Two mechanisms of cell death
  • Necrosis
  • Programmed cell death (PCD or apoptosis)
  • Necrosis
  • Tissue degeneration following cellular injury or
    destruction
  • Cellular contents released into the environment
    causing an inflammatory response
  • Programmed Cell Death (Apoptosis)
  • Orderly, contained cell disintegration
  • Cellular contents are contained and cell is
    immediately phagocytosed no inflammation

35
Stem and Progenitor Cells
  • Stem cell
  • can divide to form two new stem cells
  • can divide to form a stem cell and a progenitor
    cell
  • totipotent can give rise to any cell type
    (Embryonic stem cells)
  • pluripotent can give rise to a restricted
    number of cell types
  • Progenitor cell
  • committed cell further along differentiation
    pathway
  • can divide to become only a restricted number of
    cells
  • pluripotent
  • not self-renewing, like stem cells
Write a Comment
User Comments (0)
About PowerShow.com
