Achieving Adaptivity for OLAP-XML Federations

• Torben Bach Pedersen
• Aalborg University
• Joint work with Dennis Pedersen, TARGIT

2
Overview

• Background OLAP-XML federations
• New challenges
• XML data changes
• Slow or unreliable XML sources
• Schema changes in data sources
• Other challenges
• Integration in TARGIT architecture
• Other applications of the techniques
• Conclusion and future work
• Related work

3
Data Warehousing OLAP

• Multidimensional analysis TARGIT Analysis

4
OLAP

• Good for complex ad hoc queries
• Simple natural, graphical queries
• Fast pre-aggregation
• A number of problems with physical integration
• Short-term and varying data needs
• Population, product info, ...
• Dynamical data
• Stock quotes, competitor pricing, ...
• Data with limited access
• Competitor product info, public databases, ...

5
OLAP-XML Federations

• Traditional OLAP architecture

6
OLAP-XML Federations

• Logical integration of XML data
• External dimensions
• External measures
• Data combined at query time

Client
Federation
XML
Cube
7
OLAP-XML Federations

• Logical integration of XML data
• External dimensions
• External measures
• Data combined at query time
• Transparent for users
• Flexible many XML sources
• Quick running in a few mins
• Data is always fresh
• Performance often comparable to physical
  integration

8
XPath Queries for Fetching XML

• ltBooksgt
• ltBookgt
• ltTitlegt1984lt/Titlegt
• ltAuthorgtOrwelllt/Authorgt
• lt/Bookgt
• ltBookgt
• ltTitlegtOf Mice and Menlt/Titlegt
• ltAuthorgtSteinbecklt/Authorgt
• lt/Bookgt
• lt/Booksgt
• /Books/BookAuthorSteinbeck/Title

XPath
Dimension value
9
Old And New TARGIT Architecture
10
New Challenges

• Our previous work focused on basic aspects
• Flexibility
• General performance
• Implementation
• New what can go wrong? need for adaptivity
• XML data changes
• XML sources slow or unreliable
• Schema changes (XML, OLAP, federation)
• We often have no control over the XML sources
• A solution has broad interest views over XML
  sources

11
XML Data Changes

• Basic federation
• XML data is integrated at query time gt XML data
  changes handled automatically
• However, XML data is cached for performance
• Cache timeout value ensures fresh data (set
  manually or automatically)
• 0 cache timeout gt always fetch from source
• Only few current XML databases inform about
  changes
• Xyleme allows users to subscribe to changes
• Only delta should be transferred

12
ICE Information and Content Exchange

• Protocol proposed by W3C for automatically
  informing about and requesting changes
• Supported by major vendors
• Push subscribe to changes and keep cache
  up-to-date
• Pull request changes from source at query time

13
Slow and Unreliable XML Sources

• Overload, maintenance, HW breakdown, attacks
• Often we no influence on this
• Incremental presentation for user
• What if source is too slow or no reply at all?
• Inform user that the system is not working?
• Specification of alternative sources
• Several queries per external dimension/measure
• Increased fault tolerance, also better performance

14
Slow and Unreliable XML Sources

• Start several queries and use the fastest
• Always uses the fastest, but heavy load on
  sources
• Use first response time as indicator for total
  time
• Start one query at a time
• Minimal load on sources, but slower

15
Slow and Unreliable XML Sources

• Alternative sources of lower quality better than
  no data?
• Alternatives
• Expired cache data
• Google, Xyleme, The WayBack Machine
• Backup-disk, tape
• Etc.

Source Speed Quality
Local cache Fastest Fresh
Original source Fast? Freshest
Expired cache Fastest Old
Backup source Fast/slow Very old
16
Slow and Unreliable XML Sources

• In practice?
• Sources with equal priority chosen at random

17
Result Algorithm for Fetching XML Data
18
Experiments

• 1st experiment fetching a 137 KB dimension
• Start 8 queries, when first 3 respond, (cancel)
  last 5, when fastest query finish, (cancel)
  remaining 2
• Fast reply good indication of overall speed
• 2nd experiment search local cache, then Google
  cache

19
Schema Changes In XML Sources

• How to synchronize XML views after schema change?
  (solution described in separate paper)

Bibliography
Bibliography
Book
Publisher
Publisher
Author
AName
Price
Book
PName
Author
Title
PName
Price
Title
AName
/Bibliography/AuthorANameOrwell/Book/Title
20
Additional Challenges

• Changes to federation schema
• Cache may be invalidated
• Discard affected cache results (unproblematic)
• OLAP data changes
• Cache may be invalidated
• Less frequent than XML data changes gt cache will
  often have expired anyway
• OLAP schema changes
• Federated schema may be invalidated
• Rare and easy to detect (and correct)

21
Integrating Techniques - Architecture
22
Integrating Techniques Query Processing

• Query Evaluator splits query into XMLOLAP parts
  and determines query plan based on cost
• Execution Engine coordinates and executes plan
• Cache Manager maintains cache, e.g., through ICE
• XML Component interface fetches XML data, chooses
  between available XML sources (Algorithm 1)
• View Synchronizer handles schema changes
• Metadata Manager manages info about external
  dimensions and measures XML component
  characteristics

23
Other Applications

• All XPath-based views on XML data
• Links to parts of XML documents
• Web pages
• Documents (DocBook)
• Software applications
• and many more
• Automatic recreation of broken links
• Increased fault tolerance and performance using
  alternative sources

?
24
Conclusion and Future Work

• Operational problems in OLAP-XML federations
• XML data changes
• Slow and unreliable XML sources
• Using several sources (Algorithm 1)
• Experiment with Algorithm1
• Techniques integrated into federation
  architecture
• Schema evolution and other challenges
• Future work
• TARGIT implementation and testing
• Using techniques in other applications

25
Related Work

• Data changes in XML/semistructured documents
• Xyleme Zhuge
• Schema changes in scientific documents
• Not XML
• Adaptive/dynamic query optimization
• Telegraph project
• We use once per source, rather than per tuple
• Does not consider one or more of OLAPXML
  concepts, schema changes, slow and unreliable
  sources
• Own previous OLAP-XML work is not adaptive
