Title: Thermodynamics I


1
(No Transcript)
2
(No Transcript)
3
Open Channel
  • Storm water
  • Irrigation
  • Waste water collection and treatment

4
(No Transcript)
5
  • Types of open channel flows
  • Steady flow when discharge (Q) does not change
    with time.
  • Uniform flow when depth of fluid does not
    change for a selected length or section of the
    channel
  • Uniform steady flow when discharge does not
    change with time and depth remains constant for a
    selected section.
  • cross section should remain unchanged referred
    to as a prismatic channel

6
Open Channel Flow
  • Hydraulic radius
  • R A/WP
  • Do not include free surface in wetted perimeter.

7
Open Channel Flow
  • Re V R/?
  • Laminar flow Re lt 500
  • Turbulent flow Re gt 2000

8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
Best Hydraulic Section
  • Design criteria

12
Manning Equation
  • USCS
  • Q (a/n) A R2/3 So1/2
  • a 1.49
  • SI a 1.0

13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
Weirs
  • Rectangular
  • V-notch
  • Cipolletti

17
(No Transcript)
18
Hydraulic Jump
  • Design concern
  • Tidal bore

19
(No Transcript)
20
(No Transcript)
